Bosch Professional GAC 250 User manual
Robert Bosch Power Tools GmbH
70538 Stuttgart
GERMANY
www.bosch-pt.com
1 609 92A 8GB (2023.04) O / 25
en Original instructions
hi
1 609 92A 8GB
GAC 250 Professional
| 3
MadeinXXX
20xx
0600xxxxxx
X
xxx V ~ xxHz
xAxxxxW
xxx mm
xxxxxxxx
Robert BoschGmbH
D-70745 Leinfelden Echterdingen
xxx
(1)
(2)
(3)
(4)
(1)
(3)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(14)
(15)
(13)
Bosch Power Tools 1 609 92A 8GB | (03.04.2023)
4 |
(16) (19)
(18)
(17)
(12)
(8) (9)
A
(21)
(21)
1 609 92A 8GB | (03.04.2023) Bosch Power Tools
| 5
(12)
(11)
B
C
Bosch Power Tools 1 609 92A 8GB | (03.04.2023)
6 |
3-4 mm
(11)
D
E
(4)
(13)
(4)
1 609 92A 8GB | (03.04.2023) Bosch Power Tools
| 7
F
G
(4)
(10)
Bosch Power Tools 1 609 92A 8GB | (03.04.2023)
8 |
I
(15)
(20)
(10)
H
1 609 92A 8GB | (03.04.2023) Bosch Power Tools
English | 9
English
Safety Notes
General Power Tool Safety Warnings
WARNING Read all safety warnings, instruc-
tions, illustrations and specifica-
tions provided with this power tool. Failure to follow all in-
structions listed below may result in electric shock, fire and/
or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cord-
less) power tool.
Work area safety
uKeep work area clean and well lit. Cluttered or dark
areas invite accidents.
uDo not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Power tools create sparks which may ignite the dust
or fumes.
uKeep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
Electrical safety
uPower tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
uAvoid body contact with earthed or grounded sur-
faces, such as pipes, radiators, ranges and refrigerat-
ors. There is an increased risk of electric shock if your
body is earthed or grounded.
uDo not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of elec-
tric shock.
uDo not abuse the cord. Never use the cord for carry-
ing, pulling or unplugging the power tool. Keep cord
away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric
shock.
uWhen operating a power tool outdoors, use an exten-
sion cord suitable for outdoor use. Use of a cord suit-
able for outdoor use reduces the risk of electric shock.
uIf operating a power tool in a damp location is un-
avoidable, use a residual current device (RCD) protec-
ted supply. Use of an RCD reduces the risk of electric
shock.
Personal safety
uStay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a
power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inatten-
tion while operating power tools may result in serious per-
sonal injury.
uUse personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask,
non-skid safety shoes, hard hat or hearing protection
used for appropriate conditions will reduce personal in-
juries.
uPrevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or en-
ergising power tools that have the switch on invites acci-
dents.
uRemove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal in-
jury.
uDo not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
uDress properly. Do not wear loose clothing or jew-
ellery. Keep your hair and clothing away from moving
parts. Loose clothes, jewellery or long hair can be caught
in moving parts.
uIf devices are provided for the connection of dust ex-
traction and collection facilities, ensure these are con-
nected and properly used. Use of dust collection can re-
duce dust-related hazards.
uDo not let familiarity gained from frequent use of tools
allow you to become complacent and ignore tool
safety principles. A careless action can cause severe in-
jury within a fraction of a second.
Power tool use and care
uDo not force the power tool. Use the correct power
tool for your application. The correct power tool will do
the job better and safer at the rate for which it was de-
signed.
uDo not use the power tool if the switch does not turn it
on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
uDisconnect the plug from the power source and/or re-
move the battery pack, if detachable, from the power
tool before making any adjustments, changing ac-
cessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool
accidentally.
uStore idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
uMaintain power tools and accessories. Check for mis-
alignment or binding of moving parts, breakage of
parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by
poorly maintained power tools.
Bosch Power Tools 1 609 92A 8GB | (03.04.2023)
10 | English
uKeep cutting tools sharp and clean. Properly main-
tained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
uUse the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into ac-
count the working conditions and the work to be per-
formed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
uKeep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpected situations.
Service
uHave your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
Special Safety Instructions for AAC Block Cutter
uKeep all parts of the body away from the saw chain
when the saw is running. Before starting up the saw,
ensure that the saw chain is not touching anything.
When working with a power tool, a moment of inattention
could lead to clothing or parts of the body being caught by
the saw chain.
uAlways hold the power tool with your right hand on
the rear grip and your left hand on the front grip. Hold-
ing the power tool with the reversed hand configuration
increases the risk of injuries and must not be used.
uOnly hold the power tool by the insulated gripping sur-
faces because the saw chain may come into contact
with hidden electrical cables or its own power cable. If
the saw chain comes into contact with a live wire, this
may make metal parts of the tool live as well, posing a risk
of electric shock.
uWear protective eyewear and a dust mask. Additional
protective equipment for ears, head, hands, legs and
feet is recommended. Appropriate protective clothing
reduces the risk of injury from flying chip material and
anything accidentally coming into contact with the saw
chain.
uDo not work with the power tool on a ladder, from a
roof or on an unstable support. Operating a power tool
in this way may lead to serious injuries.
uAlways ensure that you have a secure footing and only
use the power tool if you are standing on solid, secure
and level ground. Slippery or unstable surfaces can
cause you to lose your balance or lose control over the
power tool.
uWith the power tool switched off, carry it by the front
grip with the saw chain facing forwards. Always put on
the protective cover when transporting or storing the
power tool. Handling the power tool carefully reduces
the likelihood of the running saw chain accidentally com-
ing into contact with an object.
uFollow the instructions for the chain tension and for
changing the saw blade body and the chain. A chain
that is not tensioned correctly may break or may increase
the risk of kickback.
uOnly saw autoclaved aerated concrete. The power tool
must not be used for work that it is not intended for.
Example: Do not use the power tool to saw metal,
plastic, masonry, soil, ice or wood. Using the power tool
for work that is not intended for may lead to dangerous
situations.
uIf you are removing accumulated material, storing the
power tool or performing maintenance, follow all of
the instructions. Ensure that the on/off switch is
switched off and the mains plug is not plugged in. Un-
intentionally activating the power tool when removing ac-
cumulated material or during maintenance may lead to
serious injuries.
uCauses of kickbacks and prevention:
– Kickbacks may occur if the tip of the guide rail comes
into contact with an object.
– If an object comes into contact with the tip of the guide
rail, it may cause the power tool to react unexpectedly in
a backwards direction, during which the guide rail is
knocked upwards and in the direction of the operator.
– If the saw chain jams on the top edge of the guide rail,
the rail may quickly kick back in the direction of the oper-
ator.
– Any of these reactions may lead to you losing control of
the power tool or seriously injuring yourself. Do not solely
rely on the safety devices built into the power tool. As the
user of a power tool, you should take a number of meas-
ures so that you can work without accidents or injuries.
Kickback is the result of misuse or incorrect use of the
power tool. It can be avoided by taking proper precau-
tions as given below.
uHold the power tool firmly with both hands, with the
handles of the power tool grasped with your thumb
and finger. Move your body and arms into a position
from which you can withstand the kickback forces. If
suitable measures are taken, the operator can control the
kickback forces. Never let go of the power tool.
uAvoid adopting an abnormal posture and do not saw
above shoulder height. This prevents the tip of the guide
rail accidentally coming into contact with an object and
gives you better control of the power tool if unexpected
situations occur.
uAlways use replacement rails, saw chains and
sprocket wheels specified by the manufacturer. Using
incorrect replacement rails, saw chains and sprocket
wheels may cause the chain to break or lead to kickbacks.
uAlways follow the manufacturer's instructions for
maintaining the saw chain. Setting depth gauges too
low increases the likelihood of kickbacks.
Products sold in GB only:
Your product is fitted with an BS 1363/A approved electric
plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an au-
1 609 92A 8GB | (03.04.2023) Bosch Power Tools
English | 11
thorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
Explanation of symbols
Read instruction manual.
Do not expose to rain.
Before starting adjustment and maintenance
work or if the power cable is damaged or
severed, immediately unplug the mains plug.
WARNING: Keep bystanders away.
Always hold the power tool with both hands.
Pay attention to kickbacks from the power tool
and avoid contact with the tip of the chain bar.
Wear eye and head protection.
Wear hearing protection.
Wear a dust mask.
Wear slip-resistant footwear.
Wear hand protection.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended Use
The power tool is exclusively intended for sawing autoclaved
aerated concrete.
Product Features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1) Rear handle
(2) On/off switch
(3) Front handle
(4) Handguard/lever for activating the front brake
(5) Serial number
(6) Nose sprocket
(7) Chain guard
(8) TCT saw chain
(9) Chain bar
(10) Stop
(11) Rotary knob for cover
(12) Cover
(13) Tension wheel
(14) Lock-off function for On/Off switch
(15) Extraction outleta)
(16) Running direction and cutting direction symbol
(17) Sprocket wheel
(18) Fastening bolt
(19) Guide bar for chain bar
(20) Extraction hose
(21) Bolt
a) Not all of the accessories listed are included with the power
tool. Please refer to the product packaging to see which
items are included.
Technical Data
AAC Block cutter GAC 250
Article number 3 601 BB6 0..
Rated power input W 1200
Chain speed at no load m/s 12
Chain bar length cm 33.5
Saw chain type 3/8"–50
Drive link thickness mm 1.3 (0.050")
Number of drive links 44
Tool-free chain tensioning
(SDS)
●
Nose sprocket ●
Front brake ●
Run-out brake ●
Bosch Power Tools 1 609 92A 8GB | (03.04.2023)
12 | English
AAC Block cutter GAC 250
Stop ●
Weight according to EPTA-
Procedure01:2014
kg 4.7
Protection class / II
The specifications apply to a rated voltage [U] of 230 V. These spe-
cifications may vary at different voltages and in country-specific mod-
els.
Starting cycles generate brief voltage drops. Interference with other
equipment/machines may occur in case of unfavourable mains sys-
tem conditions. Malfunctions are not to be expected for system im-
pedances below 0.25ohm.
Values can vary depending upon the product and are subject to ap-
plication and environmental conditions. For further information
www.bosch-professional.com/wac.
Assembly
For Your Safety
uWarning! Switch off, remove plug from mains before
adjusting or cleaning. The same applies when the
mains cable is damaged, cut or entangled.
uCaution! Do not touch the rotating chain.
uNever operate the power tool in the vicinity of per-
sons, children or animals or after consuming alcohol,
drugs or taking numbing medication.
Mounting and Tensioning the Saw Chain
uOnly connect the power tool to the mains supply once
it has been fully assembled.
uAlways wear protective gloves when handling the
chain.
Assembling the Chain Bar and Saw Chain (see figuresA–
C)
– Carefully unpack all of the parts.
– Set down the power tool on a level surface.
– Insert the saw chain(8) into the circumferential groove of
the chain bar(9). Ensure that the running direction is cor-
rect. To do this, compare the saw chain against the run-
ning direction symbol(16).
– Make sure that the tension wheel(13) is in the – position.
– Put the chain links around the sprocket wheel(17) and
position the chain bar(9) on the fastening bolt(18).
Note: During initial assembly, the bolt(21) must engage
in the mounting hole on the chain bar(9) that is furthest
away from the sprocket wheel(17) (see figureA).
– Check whether all of the parts are positioned correctly
and hold the chain bar with the saw chain in this position.
Then turn the tension wheel(13) in the + direction until
the saw chain is partially tensioned and remains mounted
on the chain bar.
– Replace the cover(12).
– Tighten the cover(12) slightly with the knob(11).
– The saw chain is not yet fully tensioned. The saw chain is
tensioned as described in the "Tensioning the Saw Chain"
section.
Tensioning the Saw Chain (see figureD)
Check the chain tension regularly every ten minutes, includ-
ing before starting work, after the initial steps and during
sawing. Particularly when using new saw chains, increased
extension should be expected initially.
The service life of the saw chain relies heavily on it being ten-
sioned correctly.
Do not tension the saw chain if it is strongly heated because
it will tighten once it has cooled down and it will fit too tightly
on the chain bar.
– Set down the power tool on a level surface.
– Turn the knob(11) in the direction in order to release
the fixed chain bar.
– Check whether the chain links are correctly positioned in
the guide slot of the chain bar(9) and on the sprocket
wheel(17).
– Turn the tension wheel(13) in the+ direction until the
correct chain tension has been reached. The latching
mechanism stops the chain tension from being released.
If the tension wheel(13) is hard to turn, you must con-
tinue to loosen the knob(11) in the direction. The
knob(11) can also rotate if the tension wheel(13) is set.
Two hands may be required to hold the knob(11) in posi-
tion while setting the tension wheel(13).
– The saw chain(8) is tensioned correctly if it can be lifted
in the middle by approx. 3–4mm. This should be done
with one hand by pulling up the saw chain against the
power tool's own weight.
– If the saw chain(8) is tensioned excessively, turn the ten-
sion wheel(13) in the – direction.
– When the saw chain(8) is tensioned, secure the chain
bar(9) by turning the knob(11) in the direction. Do
not use a tool to do this.
Dust/chip extraction
Dust from materials can be harmful to health. Touching or
breathing in this dust can trigger allergic reactions and/or
cause respiratory illnesses in the user or in people in the
near vicinity.
Certain dusts are classified as carcinogenic.
– Use a dust extraction system that is suitable for the ma-
terial wherever possible.
– Provide good ventilation at the workplace.
– It is advisable to wear a P2 filter class breathing mask.
uAvoid dust accumulation at the workplace. Dust can
easily ignite.
External Dust Extraction (see figureI)
Insert the extraction hose(20) with adapter into the extrac-
tion outlet(15). Connect the dust extraction hose to a dust
extractor (accessory). You will find an overview of how to
connect to various dust extractors at the end of these oper-
ating instructions.
1 609 92A 8GB | (03.04.2023) Bosch Power Tools
English | 13
The power tool can be directly connected to the socket of a
Bosch all-purpose dust extractor with remote starter. This
dust extractor is started up automatically when the power
tool is switched on.
The dust extractor must be suitable for the material being
worked.
When extracting dry dust or dust that is especially detri-
mental to health or carcinogenic, use a special dust ex-
tractor.
Operation
Starting Operation
uPay attention to the mains voltage! The voltage of the
power source must match the voltage specified on the
rating plate of the power tool. Power tools marked
with 230V can also be operated with 220V.
uProducts that are only sold in AUS and NZ: Use a resid-
ual current device (RCD) with a nominal residual current
of 30 mA or less.
Switching On and Off
Pull the hand guard/lever for activating the front
brake(4) from position to position in the direction
of the front handle (3) (see figureE). If you have not op-
erated the hand guard/lever for activating the front
brake(4), the front brake has not been deactivated be-
fore use and the power tool will not start up.
Remove the chain guard(7).
Hold the power tool as described in the "Working with the
Power Tool" section.
To start the power tool, first press the lock-off button(14),
then press and hold the on/off switch(2).
If the power tool is running, you can release the lock-off func-
tion.
To switch off the power tool, release the on/off switch (2).
Note: For safety reasons, the on/off switch(2) cannot be
locked; it must remain pressed throughout operation.
Note: Do not slow down the power tool by activating the
front brake(4).
Run-Out Brake/Front Brake (see figureE)
The power tool is fitted with two protective devices:
The run-out brake slows down the saw chain after the on/off
switch(2) is released.
The front brake is a protective mechanism that is triggered
via the lever for activating the front brake(4) if the power
tool kicks back or the on/off switch fails. The saw chain stops
immediately.
Perform a function test from time to time. Push the lever for
activating the front brake(4) forwards (position ) and
briefly switch on the power tool. The saw chain must not
start up. To unlock the front brake again, pull the lever for ac-
tivating the front brake(4) back again (position ).
Do not carry the power tool by the lever for activating the
front brake.
Working with the Power Tool
Before Cutting
The following checks must be performed before starting op-
eration and regularly during sawing:
– Is the power tool in a safe state?
– Is the saw chain tensioned and sharpened correctly? Dur-
ing sawing, check the chain tension regularly every ten
minutes. Particularly when using new saw chains, in-
creased extension should be expected initially. The state
of the saw chain greatly influences the sawing perform-
ance. Only sharp saw chains protect against overload.
– Is the front brake released and its function ensured?
– Are you wearing the required protective equipment? Use
safety goggles, a dust mask and hearing protection. It is
recommended that you wear additional protective equip-
ment for your head, hands, legs and feet. Wearing suit-
able protective clothing reduces the risk of injury from fly-
ing cut material and the saw chain accidentally coming
into contact with an object.
Saw Kickback (see figureE)
A saw kickback is the sudden uncontrolled movement and
kickback of the running power tool, which can occur if the tip
of the chain bar comes into contact with the material to be
sawn or if the chain jams.
If a kickback occurs, the power tool may respond unpredict-
ably and cause severe injuries to the operator or bystanders
in the cutting area.
Particular care must be taken for lateral, bevel and rip cuts
because the stop(10) cannot be applied.
To prevent saw kickbacks:
– Position the power tool so that it is as flat as possible.
– Never work with a loose, extended or heavily worn saw
chain.
– Never saw above shoulder height.
– Never saw using the tip of the chain bar.
– Always hold the power tool firmly with both hands.
– Always use a Bosch saw chain for autoclaved aerated con-
crete (accessory).
– Use the stop(10) as a lever.
– Make sure that the chain tension is correct.
General Behaviour (see figuresE–H)
Always hold the power tool firmly with both hands, with your
left hand on the front handle and your right hand on the rear
handle. Always grasp the handles with your thumb and fin-
ger. Always guide the mains cable to the rear and keep it out-
side the area of the saw chain and material to be sawn.
Ensure you always have a secure footing when operating the
power tool.Hold the power tool slightly to the right of your
body.
Bosch Power Tools 1 609 92A 8GB | (03.04.2023)
14 | English
The saw chain must be running at full speed before coming
into contact with the autoclaved aerated concrete. To do
this, use the stop(10) to support the power tool on the auto-
claved aerated concrete. During sawing, use the stop as a
lever.
When sawing heavier autoclaved aerated concrete blocks,
reposition the stop at a lower point. To do this, pull the
power tool back to release the stop and reposition it at a
lower point. Do not remove the power tool from the cut.
Do not press on the saw chain with force, let it run by using
the stop(10) to create a slight leverage pressure.
Never operate the power tool with extended arms. Do not at-
tempt to operate the saw in hard-to-reach places or when
standing on a ladder. Never saw above shoulder height.
The best sawing results are achieved when the chain speed
is not reduced due to overload.
Be careful at the end of the saw cut. As soon as the power
tool has cut through, the weight force will change unexpec-
tedly. There is a risk of injury to legs and feet.
Only remove the power tool from the cut with the saw chain
running.
Sawing Autoclaved Aerated Concrete (see
figuresG–H)
When sawing autoclaved aerated concrete, refer to the fol-
lowing safety regulations:
Set down the autoclaved aerated concrete as shown in the
figure and support it such that the cut does not close and the
saw chain jams.
Before sawing, set up shorter autoclaved aerated concrete
structures and secure them in place.
Only saw objects made of autoclaved aerated concrete.
Avoid coming into contact with stones and nails because
they may be hurled upwards and damage the saw chain or
cause serious injuries to the user or bystanders.
Do not bring the running power tool into contact with wire
fencing or the ground.
Exercise particular caution when making rip cuts because
the stop(10) cannot be used. Guide the power tool at a shal-
low angle in order to avoid saw kickbacks.
Troubleshooting
The following table shows fault symptoms and how you can remedy the problem if your power tool does not work properly. If
this does not enable you to locate and rectify the problem, contact your service workshop.
uImportant: Before troubleshooting, switch off the
power tool and pull out the mains plug.
Problem Possible Cause Corrective measure
Power tool not running Front brake has been triggered Pull the lever for activating the front brake(4)
back to the position.
Plug not connected Connect the plug
Plug socket defective Use another plug socket
Fuse has been triggered Change the fuse
Extension cable damaged Do not attempt without an extension cable
Power tool works inter-
mittently
Mains cable defective Operate the front brake lever to stop the saw
chain; check the mains cable and replace it if ne-
cessary
External or internal loose connection Operate the front brake lever to stop the saw
chain; contact your Bosch after-sales service
On/off switch(2) defective Operate the front brake lever to stop the saw
chain; contact your Bosch after-sales service
Saw chain does not
slow down
Front brake/run-out brake defective Contact your Bosch after-sales service.
Saw chain/guide rail
hot
Chain tension too high Adjust the chain tension
Blunt saw chain Replace the saw chain
Power tool judders, vi-
brates or does not saw
correctly
Chain tension too low Adjust the chain tension
Blunt saw chain Replace the saw chain
Saw chain worn Replace the saw chain
Saw teeth pointing in the wrong direction Install the saw chain correctly
1 609 92A 8GB | (03.04.2023) Bosch Power Tools
English | 15
Maintenance and Service
Maintenance and Cleaning
uPull the plug out of the socket before carrying out any
work on the power tool.
uTo ensure safe and efficient operation, always keep
the power tool and the ventilation slots clean.
uIn extreme conditions, always use a dust extractor if
possible. Blow out ventilation slots frequently and in-
stall a residual current device (RCD) upstream.
In order to avoid safety hazards, if the power supply cord
needs to be replaced, this must be done by Bosch or by an
after-sales service centre that is authorised to repair Bosch
power tools.
Note: Perform the following maintenance work regularly to
ensure long and reliable use.
Check whether the covers and protective devices are un-
damaged and fitted correctly. Before use, carry out any re-
quired maintenance or repair work.
Regularly inspect the power tool for obvious defects, such as
a loose, dislodged or damaged saw chain, a loose fixing and
worn or damaged components.
Replacing the Saw Chain and Sprocket Wheel
Replace the saw chain and sprocket wheel with
originalBosch spare parts or have these parts replaced at
your authorised after-sales service centre for Bosch power
tools.
After Use/Storage
Place the chain guard(7) on the chain bar(9) in order to
prevent injuries.
The saw chain(8) may become blunt from unintentional im-
pacts or scratches.
Clean the moulded plastic housing of the power tool using a
soft brush and a clean cloth. Do not use water or any
solvents or polishes. Remove all of the dirt, particularly any
dirt in the motor's ventilation slots.
After an application time of 1–3 hours, remove the
cover(12), the chain bar(9) and the saw chain(8) and
clean them using a brush.
If the power tool is to be stored for a prolonged period of
time, clean the saw chain(8) and the chain bar(9).
Store the power tool in a safe, dry place out of the reach of
children.
Do not place any other objects on the power tool.
Do not make any alterations to the power tool. Unreliable
alterations may compromise the safety of your power tool
and lead to increased noise and vibrations.
After-Sales Service and Application Service
Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. You can find explosion drawings and information on
spare parts at: www.bosch-pt.com
The Bosch product use advice team will be happy to help you
with any questions about our products and their accessor-
ies.
In all correspondence and spare parts orders, please always
include the 10‑digit article number given on the nameplate
of the product.
India
Bosch Service Center
69, Habibullah Road, (Next to PSBB School), T. Nagar
Chennai– 600077
Phone: (044) 64561816
Bosch Service Center
18, Community Center
Phase 1, Mayapuri
New Delhi– 110064
Phone: (011) 43166190
Bosch Service Center
Shop no 7&8, Aspen garden
Walbhat road , Goregaon (E)
Near to Ram Mandir Railway Station
Mumbai– 400063
Mobile: 09819952950
You can find further service addresses at:
www.bosch-pt.com/serviceaddresses
Disposal
The power tool, accessories and packaging should be re-
cycled in an environmentally friendly manner.
Do not dispose of power tools along with
household waste.
Bosch Power Tools 1 609 92A 8GB | (03.04.2023)
16 |
, ,
, /
" "
( ) (
)
▶
▶ ,
,
,
▶
▶
, ( )
▶ , ,
,
,
▶
▶
,
, ,
▶ ,
▶
, (RCD)
▶ ,
, -
▶
,
, , ,
▶ /
,
▶
▶ -
▶ -
,
,
▶
,
-
▶ -
▶
,
▶ ,
,
1 609 92A 8GB | (03.04.2023) Bosch Power Tools
| 17
▶ ,
/
,
▶
▶
,
,
,
▶
▶
, , ,
▶ ,
▶
▶
,
▶
▶
,
▶
, , ,
▶ ,
▶
,
▶ - ,
▶
▶
,
: ,
, , ,
▶ - ,
-/
- -
-
▶
– ,
–
,
–
,
–
,
Bosch Power Tools 1 609 92A 8GB | (03.04.2023)
18 |
, :
▶ ,
▶
▶ ,
,
▶
,
:
-
,
(1)
(2) /
(3)
(4) /
(5)
(6)
(7)
(8) TCT-
(9)
(10)
(11)
(12)
(13)
(14) /
(15) A)
(16)
(17)
(18)
1 609 92A 8GB | (03.04.2023) Bosch Power Tools
| 19
(19)
(20)
(21)
a)
GAC 250
3 601 BB6 0..
W 1200
m/s 12
33.5
3/8"–50
1.3 (0.050")
44
(SDS)
●
●
●
●
●
EPTA-Procedure
01:2014
4.7
/ II
230 V [U] -
-
0.25
www.bosch-
professional.com/wac.
▶ !
-
, ,
▶ !
▶ ,
, ,
▶
▶
( A–C)
–
–
– (8) (9)
;
(16)
– (13)
–
– (17)
(9) (18)
: , (21)
(9) ,
(17) ( A)
–
(13) + ,
– (12)
– (12) (11)
–
, " "
( D)
,
10
, ,
, ,
–
– (11) , ,
– , (9)
(17)
– (13) + ,
(13)
, (11)
, (11)
(13)
Bosch Power Tools 1 609 92A 8GB | (03.04.2023)
20 |
(13) ,
(11)
– (8) ,
3–4 mm
, ,
– (8) ,
(13) –
– (8) , (9)
(11)
/
, ,
–
–
– P2
▶
( I)
(20) (15)
-
()
Bosch
-
,
,
/
▶ !
230 V 220 V
/
/ (4)
, (3) (
) E
/ (4) ,
(7)
" "
.
- (14)
-/- (2)
.
, -
.
- , -/
(2)
: - - (2)
,
: (4)
/ ( E)
:
-/ (2)
, -
-/-
(4)
(4) ( )
-
(4)
( )
:
– ?
– ?
10
,
,
–
?
1 609 92A 8GB | (03.04.2023) Bosch Power Tools
Other manuals for Professional GAC 250
2
Table of contents
Other Bosch Cutter manuals
Bosch
Bosch PTC 470 User manual
Bosch
Bosch GOP 10 User manual
Bosch
Bosch GOP 300 SCE User manual
Bosch
Bosch GCT 115 Professional User manual
Bosch
Bosch GOP 18 V-EC professional User manual
Bosch
Bosch Rotocut User manual
Bosch
Bosch GWS Professional 660 User manual
Bosch
Bosch GOP 18V-28 Professional User manual
Bosch
Bosch Professional GOP 12V-LI User manual
Bosch
Bosch GOP 250 CE User manual
Bosch
Bosch MAS42 SERIES User manual
Bosch
Bosch EasyCut 12 User manual
Bosch
Bosch GSC 160 Professional Operation instructions
Bosch
Bosch PTC 470 User manual
Bosch
Bosch PTC 1 User manual
Bosch
Bosch GCD 12 JL User manual
Bosch
Bosch GOP 30-28 Professional User manual
Bosch
Bosch AdvancedCut 18 User manual
Bosch
Bosch GUS 10 User manual
Bosch
Bosch GWS 18V-180 P Professional User manual
