Fire Alarm Systems | FPA‑1000 Analog Addressable Fire Panels
FPA‑1000 Analog Addressable Fire Panels
www.boschsecurity.com
uSupport for up to 508 points on two analog
addressable loops
uBuilt-in Ethernet connector for web-browser based
programming and Conettix Alarm-over-IP
communication
uTwo on-board NACs and dual-line PSTN DACT
uPeer-to-peer networking of up to eight -V2 panels in
a single group
uSuited to a wide range of applications and
compatible with the latest Bosch solutions -
including 440 Series Multi-criteria detectors
The FPA‑1000 Analog Addressable Fire Panels are a
scalable solution for fire detection. Protect your small
office with a single system or connect multiple panels
together as your needs grow. Networking capabilities
support the monitoring of up to 8 interconnected
panels (2,000 addressable points) in one system for
campuses or other large commercial environments.
The FPA‑1000 panels combine complete built-in Fire
Alarm Control Panel (FACP) equipment such as
Notification Appliance Circuits (NACs), Signaling Line
Circuits (SLCs), relays, power supply, Digital Alarm
Communicator Transmitter (DACT), and Ethernet
connection with expandability using the option bus or
plug‑in boards. The two integrated NACs can be
expanded with remote addressable NAC power
boosters and programmed with specific activation
patterns.
The control panel includes one SLC that supports 254
addressable points (254 analog detectors or modules,
or 127 analog sounder bases in combination with a
suitable detector). The control panel is easily
expandable with the FPE‑1000‑SLC Signaling Line
Circuit Plug-in Module, doubling the address points to
508.
The panel has a compact and solid metal housing with
a keyed lock and a removable dead front door to
access electronics. It features surface and semi-flush
mounting options. On the front of the panel, six light-
emitting diodes (LEDs) show Fire, Carbon Monoxide
(Gas) Alarm, Power, Supervisory, Silenced, and
Trouble conditions. The built‑in keypad can be used
for total system control and programming even when
wearing fireman gloves. In addition, a large 4‑line by
20‑character alphanumeric LCD display shows
programmed device point information. Four keys
enable Drill, Reset, Silence, and Acknowledge
functions.
The FPA‑1000 panels enable various programming
approaches:
• Front panel programming
• On-site programming, using a laptop with the
possibility of pre-programming at the office
• Off-site programming, with remote access via
Ethernet (browser-based)
Front panel programming provides an auto‑learn
function, allowing the installer to configure the system
quickly and easily in default mode. Using a local laptop
or remote access communication, the programming is
carried out by means of a browser‑based user

interface. Therefore, no software installation is
required. The panel can receive diagnostics from a
Web browser running on an internet‑connected PC.
System overview
Functions
Peer-to-peer Communications
The FPA‑1000-V2 panels allow peer-to-peer networking
of up to eight panels in a single group supporting a
system which can include up to 2000 points.
Networked panels act as a single panel enabling all
events to be displayed on all units. All connected
panels can easily be programmed and controlled via
any connected panel.
Ethernet, fiber optic, or 2-conductor wire inter‑panel
connections can be mixed providing flexibility in
system design.
System Management
A set of interactive Web pages gives you an instant
means to access and record important system
functions. This unique feature enables programming
and diagnostic capabilities while off-site, streamlining
installation and reducing the time required for
servicing the system. And, you can check status and
manage the system from virtually anywhere on the
network.
Communications
The FPA‑1000 panels have a dual phone line PSTN/
DACT circuit and an Ethernet connection featuring
Conettix IP reporting. The panels communicate in
Contact ID, SIA, and Modem IIIa2. The panels provide
miscellaneous reporting functions such as dialing
control and transmission supervision, priorities of
report groups, routing to destinations, manual and
auto test reports, and Anti-Replay feature.
For the primary and secondary account, the following
features are programmable:
• Two different phone or IP numbers
• Different dialing types for PSTN (pulse only,
automatic, or tone only)
• Individual PSTN line supervision (audible and visual
trouble signal in the case of a transmission path
failure)
• Selectable options for Report Steering Groups
• Programmable supervision time for each IP reporting
Conettix account
• Test report frequency individually programmable for
each account (4, 6, 24 hour, 7 and 28 day intervals,
standard frequency 24 hour)
Applications
The panels are recommended for a wide range of
commercial and public building applications, including:
• Retail - single building applications
• Education - schools and universities
• Residential - apartment buildings
• Commercial - manufacturing plants, warehouses and
office complexes
• Government and Public Service - military bases and
installations
• Medical - healthcare facilities
Multi-criteria Detectors
A range of pull stations, modules, accessories and
detectors are available to meet the needs of your
application. These include the new Automatic Fire
Detector 440 family that incorporates multi-criteria
technology for higher sensitivity, faster detection, and
fewer false alarms.
Gas detection
Integrated gas detection is an important element of
your facility’s fire and life safety strategy. Using
FCC-380 Carbon Monoxide detectors combined with
an addressable monitor module, you can set your
system to alarm for carbon monoxide to meet the
NFPA requirements for visual and audible annunciation
for this hazardous gas.
Notification Appliance Circuits (NACs)
Two Class A or Class B NACs provide up to 4 A of 24 V
power (non-synchronized: 2.5 A per NAC,
synchronized: 2.75 A NAC 1 + NAC 2 in total) to
operate horns, strobes, bells, and other notification
appliances. Each NAC can be programmed to provide
Temporal Code 4, Temporal Code 3, and steady,
pulsing, and synchronized protocol output for
Wheelock, Gentex, and System Sensor notification
appliances.
2 | FPA‑1000 Analog Addressable Fire Panels

On-board Relays
Three programmable on-board relays default to global
alarm (zone 226), global system trouble (zone 227),
and global system supervisory (zone 228). They can be
programmed to activate on a variety of conditions
including gas alarm.
Option Bus
On the Option Bus, the panels support up to:
• eight FMR-1000-RCMD Remote Command Centers
and FMR-1000-RA Remote Annunciators in any
combination
• eight D7030X Series LED Annunciators with eight LED
zones each
• eight D7030X Series/D7032 combinations
• two Octal Relay Modules or Octal Driver Modules
• four FPP‑RNAC‑8A‑4C Remote Notification Appliance
Circuit Power Supplies
The outputs of the Octal Relay Modules or Octal Driver
Modules are fully programmable, and can be activated
by system events. These outputs have the same
programming options as the local relays. Each output
operates independently of the other seven to provide
complete flexibility. Communication with the D7035/B
or D7048 is supervised.
Power
A transformer working with 120 VAC or 240 VAC is
supplied standard with the control panel. Two backup
batteries with 7 Ah to 18 Ah each fit inside the fire
panel cabinet. A separate battery box can provide
higher capacity. An automated battery calculator sheet
is available online to aid in battery selection and
submittal paperwork.
The panels provide two auxiliary power supplies (one
FWR and one DC) with 0.5 A at 24 V each, with
switchable AUX/RST. This auxiliary power can run
expansion boards or other low current auxiliary
devices.
For installations requiring battery capacity higher than
40 Ah, a regulated and UL1481 Listed external power
supply can be used. The external power supply
connects through the panel's battery terminals and is
supervised for AC and battery fault by an input module
on the SLC.
The FPP-RNAC-8A-4C Remote NAC Booster adds four
additional Notification Appliance Circuits (NFPA 72,
Class A or Class B) to the fire panel or serves as a
power supply for fire protective signaling systems.
This regulated power supply provides up to 8 A of
power that is used to recharge batteries and operate
continuous and intermittent alarm loads. This 8 A of
power can be distributed through the four NAC Power
Supply circuits that are part of the FPP-RNAC-8A-4C.
The FPP-RNAC-8A-4C is UL Listed for use in
commercial fire alarm applications.
Signaling Line Circuits (SLCs)
The panels communicate with each of the analog
addressable devices located on the SLCs. The SLCs
allow the use of standard non‑twisted, non‑shielded
wiring. Each panel supports two Class B circuits or
one Class X circuit or one Class A circuit per SLC.
Certifications and approvals
Region Regulatory compliance/quality marks
USA UL FSZI.S1871: Emergency Alarm System
Control Units (ANSI/UL 2017); UOJZ:
Control Units, System (ANSI/UL 864)
FM FPA-1000
CSFM see the Bosch website (www.boschse-
curity.com)
FDNY-
CoA
6101
Installation/configuration notes
Mounting Considerations
The cabinet can be either semi-flush (requires optional
FPM‑1000‑SFMK Semi-flush Mounting Kit) or surface
mounted.
Depending on the configuration and the battery
selection, the FPA‑1000 can be heavy. When attaching
the enclosure to a surface, use mounting hardware
(not supplied) capable of supporting this weight, and
reinforce the wall as necessary.
Wiring Considerations
The length of wire allowed between the control panel
and the last device on a wiring run depends on the
current drawn on that wiring run. Reducing the
number of devices on a wiring run allows the
individual runs to be longer.
If not otherwise specified, use wire gauge 12 AWG to
18 AWG (ISO 4 mm2 to 0.75 mm2).
Notice
Shared cable is not recommended for the Option
Bus, addressable‑points bus, telephone, or NAC
wiring. Do not run wiring for NAC, Option Bus,
and SLC in the same conduit. Avoid shielded or
twisted-pair wire except for network connections
and special applications where a reduced length
of wiring (roughly 50%) is acceptable for
tolerating a harsh electrical environment.
Point Capacity/Configuration
Each FPA-1000-V2 panel supports up to 508
addresses, 254 per loop. All compatible detectors and
modules are addressed using the D5070 Programmer.
You can use addresses 1 to 127 for any combination of
detectors and modules. SLC devices that support the
newest DCP protocol version 2.0 can use addresses 1
to 254. For a listing of devices that can use addresses
up to 254, see the SLC Address Assignment section of
the FPA-1000 Installation and Operation Guide.
3 | FPA‑1000 Analog Addressable Fire Panels

Detectors connected to a sounder base can use only
addresses 1 to 127. The sounder bases are addressed
automatically by the panel, depending on the
detector’s address (detector address +127).
Technical specifications
Electrical
Mains power supply (primary)
• Supervision Supervised for the presence of AC
power
• Voltage 120 VAC, 60 Hz, 1.1 A maximum,
or
240 VAC, 50 Hz, 0.6 A maximum
Power supply (secondary) with battery backup
• Voltage 24 VDC
• Supervision Supervised for the presence of AC
power
• Current consumption
(standby)
1.25 A maximum
• Current consumption
(alarm)
5 A maximum
1.0 A maximum shared between
panel and SLC(s)
• Panel ≤ 250 mA
• SLC 1 = 60 mA/card +
220 mA/loop maximum
• SLC 2 = 60 mA/card +
220 mA/loop maximum
4.0 A maximum shared between
NACs, Option Bus, and AUX power
• NACs (non-synchronized)
• NAC 1 =2.5 A maximum
• NAC 2 = 2.5 A maximum
• NACs (synchronized)
• NAC 1 + NAC 2 in total =
2.75 A maximum
• Option Bus = 0.5 A
maximum
• AUX/FWR = 0.5 A maximum
• AUX/RST = = 0.5 A
maximum
• Battery capacity 7.0 Ah minimum, 40 Ah maximum
• Charge current 2.0 A maximum
• Fuse 15 A blade-type
• Suitable battery type Two 12 VDC in series (7 Ah or 18 Ah
in enclosure, 24 Ah or 38 Ah in
additional battery box)
Recommended Manufacturers:
POWER SONIC: PS-1270,
PS-12170, PS‑12180
YUASA: NP7-12, NPG18-12
• Maintenance Replace batteries when they fail the
Battery Load test
Auxiliary power supply
AUX/FWR Full Wave Rectified 500 mA at 24 V FWR (17 to
31 VRMS), non‑switched, power-
limited, unfiltered,
non‑supervised
AUX/RST Resettable 500 mA at 24 V FWR (17 to
31 VDC), switched, power-
limited, filtered, non‑supervised
Line impedance for ground fault
detection (Option Bus, SLC, NAC,
secondary power circuit, City Tie/
Local Energy, AUX)
15 kΩ
Option Bus (OB)
Voltage Nominal 12 VDC, power-limited,
supervised
Current 500 mA maximum
Configuration 1 Class B
Circuit wiring distance 4000 ft. (1219 m) maximum,
depending on wire gage and
connected devices
Notification appliance circuits (NACs)
Mainboard NACs Two (NAC 1 and NAC 2)
NAC power from panel Nominal 24 V FWR (17 to
31 VRMS), regulated, power-
limited, supervised
2.5 A per NAC, maximum current
limited to overall 4.0 A shared
among AUX power, Option BUS,
and NACs
Line impedance 1.45 Ω maximum
Configuration Two Class B or two Class A
Signaling line circuits (SLCs)
Voltage Nominal 39 VDC (29 VDC to
40 VDC), power‑limited,
supervised
Current 204 mA (per FPE-1000-SLC)
Circuit resistance <50 Ω
Circuit capacitance <1 ΩF
Circuit inductance <1 mH
Configuration 1 or 2 Class B or 1 Class A or 1
Class X
City Tie
Circuit resistance 65 Ω maximum
Wire gauge 12 AWG to 18 AWG (ISO 4 mm2
to 0.75 mm2)
4 | FPA‑1000 Analog Addressable Fire Panels

City Tie
City Tie - Local Energy Mode
Type of connection In series
Alarm, trip coil 24 VDC
Alarm current 250 mA DC (momentary)
Supervisory/standby current <50 mA DC
Trip coil resistance 14.5 Ω
Nominal coil voltage 3.65 VDC, power-limited,
supervised
City Tie - Reverse Polarity Module
Nominal voltage Nominal 24 VDC (26.4 VDC
maximum), power‑limited,
supervised
Output current 33 mA maximum
Supervisory/standby current 5 mA
Networking cards
Current (per card) FPE-1000-NE: 100 mA
FPE-1000-NF: 170 mA
FPE-1000-NW: 330 mA
Circuit wiring distance (actual
length depends on connector
quality)
FPE-1000-NE: 328 ft. (100 m)
FPE-1000-NF: 6560 ft.
(2000 m) or 10 db loss
FPE-1000-NW: 3280 ft.
(1000 m) maximum
Trademarks
All hardware/software product names used in this
document are likely to be registered trademarks and
must be treated accordingly.
Ordering information
FPA-1000-V2 Fire panel, 2 SLC & networking
Advanced analog control panel listed by UL for central
station, local, auxiliary, and remote station systems
with networking capabilities allowing monitoring of up
to 2,000 addressable points in one system.
Order number FPA-1000-V2
FPA-1000-LC Fire panel, 2 SLC & networking, no encl.
FPA‑1000‑UL Mainboard for use as a replacement
board for system update or repair
Order number FPA-1000-LC
FPA-1000-LT Analog/networkable panel, no transformer
FPA‑1000‑V2 fire panel without transformer. For Latin
America only.
Order number FPA-1000-LT
Accessories
BATB-40 Battery box/enclosure, 22x20.75x7.25"
Holds two dry or wet cell batteries. Optional BATB-
SHELF battery shelf increases number of batteries.
Suitable for residential/commercial fire or burglary
applications.
Order number BATB-40
BATB-80 Battery box/enclosure, 14x20.75x7.25"
Battery box/enclosure with shelf holds up to four dry
or wet cell batteries. Suitable for residential/
commercial fire or burglary applications.
Order number BATB-80
D102 Replacement key for D101 lock set
The D102 is a replacement key for locks stamped with
1358.
Order number D102
D5070 Analog point programmer, hand-held
Used to program address settings on
EEPROM‑programmable analog devices
Order number D5070
D7030X Annunciator, 8 alarm LED
Eight zone LEDs indicate alarm conditions.
Order number D7030X
D7030X-S2 Annunciator, 8 LED (2 supervisory)
Two LEDs indicate supervisory conditions, six indicate
alarm conditions.
Order number D7030X-S2
D7030X-S8 Annunciator, 8 LED (8 supervisory)
All eight zone LEDs (yellow) indicate supervisory
conditions.
Order number D7030X-S8
D7032 Annunciator expander, 8 LED
Use with D7030X Family LED annunciators
Order number D7032
D7035 Multiplex octal relay module
Provide eight Form C relay outputs (w/o enclosure) for
the D7024, FPD-7024, or FPA‑1000 Fire Alarm Control
Panels (FACP)
Order number D7035
D7035B Multiplex octal relay module + enclosure
Provide eight Form C relay outputs (w/ enclosure) for
the D7024, FPD-7024, or FPA‑1000 Fire Alarm Control
Panels (FACP)
Order number D7035B
D7048 Octal driver module, 12V
Provides eight open-collector transistor outputs
(current sinks) to FPA‑1000, FPD-7024, or D7024
FACPs through the control panel's option bus.
Order number D7048
5 | FPA‑1000 Analog Addressable Fire Panels

FAA-325-B4 Analog sensor base, 4"
Is combined with analog addressable detectors that
use the advanced digital communication protocol to
provide early fire warning for life safety and property
protection
Order number FAA-325-B4
FAA-325-B6 Analog sensor base, 6"
6‑inch (152.4 mm) base for FAH‑325, FAI‑325, and
FAP‑325 sensors. US sales only
Order number FAA-325-B6
FAA-325-B6S Analog sensor base with sounder, 6"
Contains an addressable sounder which provides an
audible alarm in the immediate vicinity and only works
in combination with one of the FAH‑325, FAI-325, or
FAP‑325 analog sensors
Order number FAA-325-B6S
FAA-440-B4 Analog standard base, 4"
Standard 4-inch base. Used in combination with
FAP-440 and FAH-440 detectors to provide early fire
warning for life safety and property protection.
Order number FAA-440-B4
FAA-440-B4-ISO Analog isolator base, 4"
4-inch base with built-in isolator. Used in combination
with FAP-440 and FAH-440 detectors to provide early
fire warning for life safety and property protection.
Order number FAA-440-B4-ISO
FAA-440-B6 Analog standard base, 6"
Standard 6-inch base. Used in combination with
FAP-440 and FAH-440 detectors to provide early fire
warning for life safety and property protection.
Order number FAA-440-B6
FAA-440-B6-ISO Analog isolator base, 6"
6-inch base with built-in isolator. Used in combination
with FAP-440 and FAH-440 detectors to provide early
fire warning for life safety and property protection.
Order number FAA-440-B6-ISO
FAD-325-V2F Kit, analog duct housing w/ smoke head
Duct detector housing with an FAD-325-V2F-DH Analog
duct smoke head. It’s easy to install with a drill
template. The steel sampling tube means there are no
screens or filters to clean.
Order number FAD-325-V2F
FAD-325-V2F-DH Analog duct smoke head, 2-wire 24V
Replacement for the FAD-325-DH Analog duct smoke
head for use in FAD-325, FAD-325-R, FAD-325-V2F and
FAD-325-V2F-R Analog duct kits
Order number FAD-325-V2F-DH
FAD-325-V2F-R Kit, analog duct housing w/relays & head
Duct detector housing with an FAD-325-V2F-DH Analog
duct smoke head and two sets of Form C alarm relays.
It’s easy to install with a drill template. The steel
sampling tube means there are no screens or filters to
clean.
Order number FAD-325-V2F-R
FAH-440 Analog heat detector head, fixed/ROR
Use with FAA‑440 family bases and FAP-1000 Analog
Addressable Fire Panels to provide general property
protection
Order number FAH-440
FAP-325-V2F Analog Photo Detector Flat
Used to detect fast‑flaming fires and dense smoke
typically given off by plastic, foam, paper, wood, and
other materials that tend to smolder
Order number FAP-325-V2F
FAP-440 Analog photoelectric detector head, 24V
Analog photoelectric smoke detector used with
FAA‑440 bases and FAP-1000 fire panels
Order number FAP-440
FAP-440-T Analog photoelectric detector head, 24V
Analog photo/heat detector used with FAA‑440 bases
and FAP-1000 fire panels
Order number FAP-440-T
FAP-440-TC Analog detector head, photo/heat/CO
Analog photo/heat/CO detector used with FAA‑440
bases and FAP-1000 fire panels
Order number FAP-440-TC
FAP-440-D Analog dual-photoelectric detector head
Analog dual-photoelectric smoke detector used with
FAA‑440 bases and FAP-1000 fire panels
Order number FAP-440-D
FAP-440-DT Analog detector head, dual, photo/heat
Analog dual-photoelectric smoke/heat multi-sensor
detector used with FAA‑440 bases and FAP-1000 fire
panels
Order number FAP-440-DT
FAP-440-DTC Analog detector head, dual, heat/CO
Analog dual-photoelectric smoke/heat multi-criteria
detector used with FAA‑440 bases and FAP-1000 fire
panels
Order number FAP-440-DTC
FCC-380 CO detector (Macurco CM-E1)
Carbon monoxide detector
Order number FCC-380
FLM-325-2I4 Dual input module for FPA-1000
Provides two independent contact monitoring circuits
to monitor Normally Open (NO) or Normally Closed
(NC) dry contact types of fire alarm devices
Order number FLM-325-2I4
6 | FPA‑1000 Analog Addressable Fire Panels

FLM-325-2R4-2A Dual relay module, 2A
Provides 2 A current at two independently-controlled
Form C contacts for a variety of Normally Open and
Normally Closed applications, compatible with 254
addresses
Order number FLM-325-2R4-2A
FLM-325-2R4-2AI Dual relay module with isolator, 2A
Provides 2 A current with built-in short circuit isolator
circuitry at two independently-controlled Form C
contacts for a variety of Normally Open and Normally
Closed applications, compatible with 254 addresses
Order number FLM-325-2R4-2AI
FLM-325-2R4-8A Dual relay module, 8A
Provides 8 A current at two independently-controlled
Form C contacts for a variety of Normally Open and
Normally Closed applications, compatible with 254
addresses
Order number FLM-325-2R4-8A
FLM-325-2R4-8AI Dual relay module with isolator, 8A
Provides 8 A current with built-in short circuit isolator
circuitry at two independently-controlled Form C
contacts for a variety of Normally Open and Normally
Closed applications, compatible with 254 addresses
Order number FLM-325-2R4-8AI
FLM-325-CZM4 Conventional zone module for FPA-1000
Enables the FACP to interface and monitor up to 25
conventional devices depending on the device type
such as two‑wire smoke detectors or pull stations
Order number FLM-325-CZM4
FLM-325-I4-A Contact monitor, class A, 4"
Can be wired for Class A or Class B circuits, mounted
to a cover plate for a 4‑inch square or double gang
electrical back box, bi‑colored LED provides module
status, compatible with 254 addresses
Order number FLM-325-I4-A
FLM-325-I4-AI Contact monitor with isolator class A 4"
Can be wired for Class A or Class B circuits, has
built‑in short circuit isolator circuitry, mounted to a
cover plate for a 4‑inch square or double gang
electrical back box, bi‑colored LED provides module
status, compatible with 254 addresses
Order number FLM-325-I4-AI
FLM-325-IM Contact monitor for mounting in backbox
Allows compatible fire alarm control panels (FACP) to
supervise Form A or B dry contact devices in a polling
circuit
Order number FLM-325-IM
FLM-325-ISO Short circuit isolator for FPA-1000
Isolates a shorted section on a specific polling circuit
from the rest of the system to minimize the loss of
communication
Order number FLM-325-ISO
FLM-325-NA4 Supervised output module, Class A/B
Can be wired for Class A or Class B circuits,
compatible with 254 addresses
Order number FLM-325-NA4
FLM-325-NAI4 Supervised output module, isolator, A/B
Built-in short circuit isolator circuitry, can be wired for
Class A or Class B circuits, compatible with 254
addresses
Order number FLM-325-NAI4
FMM-325A Analog manual station, single, red
The single‑action manual station is UL listed for
commercial fire applications and meets Americans
with Disabilities Act (ADA) requirements. Set the
address on the polling circuit by programming an
EEPROM microchip with the D5070 Analog point
programmer.
Order number FMM-325A
FMM-325A-D Analog manual station, double, red
The double‑action manual station is UL listed for
commercial fire applications and meets Americans
with Disabilities Act (ADA) requirements. Set the
address on the polling circuit by programming an
EEPROM microchip with the D5070 Analog point
programmer.
Order number FMM-325A-D
FMR-1000-RA LCD annunciator FPA-1000 without con-
trol
LCD annunciator without system control capability for
use with the FPA‑1000 Analog Addressable Fire Panels
Order number FMR-1000-RA
FMR-1000-RCMD LCD annunciator FPA-1000 with con-
trol
LCD annunciator with system control capability for use
with FPA‑1000 Analog Addressable fire Panels
Order number FMR-1000-RCMD
FPE-1000-CITY Plug-in city tie module for FPA-1000
Provides the FPA‑1000 Analog Addressable Fire Panels
with two supervised City Tie Local Energy circuits or
Reverse Polarity circuits
Order number FPE-1000-CITY
FPE-1000-NE Network card, 3-Ethernet
Ethernet Networking Card for peer‑to‑peer
communication in an FPA‑1000‑V2 networked system
Order number FPE-1000-NE
FPE-1000-NF Network card, 1-Ethernet 2-fiber optic
Fiber Optic Networking Card for peer‑to‑peer
communication in an FPA‑1000 networked system
Order number FPE-1000-NF
FPE-1000-NW Network card, 1-Ethernet 2-wired
Wired Networking Card for peer‑to‑peer
communication in an FPA‑1000 networked system
Order number FPE-1000-NW
7 | FPA‑1000 Analog Addressable Fire Panels

FPE-1000-SLC Plug-in SLC module for FPA-1000
Provides a Signaling Line Circuit (SLC) for connection
of analog devices to the FPA‑1000 Analog Addressable
Fire Panels
Order number FPE-1000-SLC
FPM-1000-ENC Enclosure with dead-front door
Enclosure with dead front door
Order number FPM-1000-ENC
FPM-1000-SFMK Semi-flush mounting trim ring
The FPM-1000-SFMK Semi-flush Mounting Kit includes
a trim ring and 4 screw covers.
Order number FPM-1000-SFMK
FPP-RNAC-8A-4C Power supply, RNAC 8A 24V
When connected to a panel’s option bus, the FPP-
RNAC-8A-4C adds four additional NFPA 72, Class B or
Class A NACs. When connected directly to the NAC
output, it is also a NAC power supply for fire-
protective signaling systems.
Order number FPP-RNAC-8A-4C
8 | FPA‑1000 Analog Addressable Fire Panels
Represented by:
Europe, Middle East, Africa: Germany: North America: Asia-Pacific:
Bosch Security Systems B.V.
P.O. Box 80002
5600 JB Eindhoven, The Netherlands
Phone: + 31 40 2577 284
[email protected]
emea.boschsecurity.com
Bosch Sicherheitssysteme GmbH
Robert-Bosch-Ring 5
85630 Grasbrunn
Germany
www.boschsecurity.com
Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, New York, 14450, USA
Phone: [phone]
Fax: [phone]
[email protected]
www.boschsecurity.us
Robert Bosch (SEA) Pte Ltd, Security Systems
11 Bishan Street 21
Singapore 573943
Phone: [phone]
Fax: [phone]
[email protected]
www.boschsecurity.asia
© Bosch Security Systems 2017 | Data subject to change without notice
2690096139 | en, V14, 25. Oct 2017
