Bosch FPA-1000-UL Operating instructions

Analog fire panels
FPA-1000 Family
en Installation and Operation Guide

Analog fire panels Table of contents | en 3
Bosch Security Systems, Inc. Installation and Operation Guide 2017.11 | 2.0 | F.01U.173.607
Table of contents
1Notices 6
1.1 General information 6
1.1.1 Trademarks 6
1.2 Symbols and Notes Used 6
1.3 FCC Compliance Notice 7
1.4 NFPA Standard 72 8
2System information 9
2.1 Introduction 9
2.2 Features 11
2.3 System Overview Mainboard Components 13
2.4 Plug-in Modules 14
2.5 Power Supply 15
2.6 Components Connected to the Option Bus 16
2.7 Signaling Line Circuit Devices 17
2.8 Notification Appliance Circuit Devices 21
2.9 Communicator 21
2.10 Components and Accessories 21
2.11 Related Documents 22
3Planning Information 23
3.1 Power Supply Calculations 23
3.2 Network Wiring/Connection Considerations 23
3.2.1 Ground Fault Detection 23
3.3 Configuration and Programming Basics 24
3.3.1 Points 24
3.3.2 Advanced Point Features and Processing 26
3.3.3 Events 29
3.3.4 Zones 31
3.3.5 Special Alarm Features 34
3.3.6 Sequential Reset 36
3.3.7 Multi-combined/multi-separated Alarm Modes 36
3.3.8 External Signaling 36
3.4 Address Assignment 36
3.4.1 Option Bus Address Assignment 37
3.4.2 SLC Address Assignment 38
3.4.3 Mainboard Address Assignment 39
3.5 Reporting Requirements 40
3.6 UL 864 Standard-specific Requirements 43
3.7 NFPA Standard-specific Requirements 45
3.8 Fire Safety Considerations 46
4Installing 48
4.1 Installation Precautions 48
4.2 Installation Considerations for UL Listed Systems 48
4.3 FPA-1000 Fire Panel Components 49
4.4 General wiring requirements 49
4.5 Installing the Enclosure 52
4.6 Installing the Mainboard 55
4.7 Installing Optional Plug-in Modules 57
4.7.1 Mounting plug-in modules 58

4en | Table of contents Analog fire panels
2017.11 | 2.0 | F.01U.173.607 Installation and Operation Guide Bosch Security Systems, Inc.
4.7.2 CITY TIE module 59
4.7.3 SLC module 61
4.7.4 Network Connections 64
4.8 Control Panel Terminal Connections 66
4.9 Option Bus 67
4.10 NACS 67
4.10.1 NAC wiring 68
4.10.2 NAC specifications 68
4.10.3 Synchronicity 69
4.11 Mainboard Relays 69
4.12 Phone Line Connections (DACT) 70
4.13 Ethernet Connection 71
4.14 Power Supply Wiring 71
4.14.1 AC Power Connection 71
4.14.2 Battery Connection 73
4.14.3 Auxiliary Power Connection 76
4.14.4 External Power Supply 77
5Monitoring, Operating, and Programming 78
5.1 Authority Level and PIN Codes 78
5.2 Panel access 79
5.3 Keypads 80
5.4 Keypad Operations 84
5.5 System Normal Displays 86
5.6 Off-normal Displays 88
5.7 Menu Navigation and Structure 90
5.7.1 Menu Structure 92
5.8 Browser Navigation and Structure 98
5.8.1 Off-site and on-site access 98
5.8.2 Working with web pages 99
5.9 Overview of the web user Interface 100
6Diagnostics and Troubleshooting 103
6.1 Phone monitor troubleshooting 103
6.2 Diagnostics Data and System Information 103
6.3 FPE-1000-SLC LED Operation 104
6.4 Power and Battery Test 105
7Maintaining 106
7.1 Battery Maintenance 106
7.2 Fuse Replacement 106
7.3 Network Communication Reset 107
7.4 System Reset 107
8Specifications 108
8.1 Environmental 108
8.2 Electrical 108
8.3 Mechanical 111
8.4 Panel Address Data 113
9Appendices 114
9.1 Abbreviations on the Control Panel Display 114
9.2 Default Programming 116
9.3 Compatible SLC Devices for Retrofit Projects 126

Analog fire panels Table of contents | en 5
Bosch Security Systems, Inc. Installation and Operation Guide 2017.11 | 2.0 | F.01U.173.607
9.4 Reporting Codes 128
9.5 FPA-1000-UL Operating Instructions Sheet 135
9.6 FPA-1000-V2 Operating Instructions Sheet 137

6en | Notices Analog fire panels
2017.11 | 2.0 | F.01U.173.607 Installation and Operation Guide Bosch Security Systems, Inc.
1 Notices
1.1 General information
Notice!
Within this document, FPA-1000 refers to both the FPA-1000-UL and FPA-1000-V2. Reference
to a complete identifier (FPA-100-UL or FPA-1000-V2) indicates the text applies to only that
product/system.
Before using the device, read these instructions. If you do not read and understand these
explanations, you will not be able to operate the device properly. For proper installation, also
read and understand NFPA 72, The National Fire Alarm Code before installation.
The operating instructions do not eliminate the need for training by authorized personnel. The
operating instructions area required part of the system. The instructions must be available on
site and given to the new owner if the system is ever sold.
Install, test and maintain the device according to these instructions, NFPA codes, local codes,
and the authority having jurisdiction (AHJ). Failure to follow these instructions can result in
failure of the device to operate properly. Bosch Security Systems, Inc. is not responsible for
improperly installed, tested or maintained devices.
The Installation and Operation Guide does not contain special information about local
requirements and safety issues. Information on such issues is provided only to the extent that
it is needed for operation of the device. Ensure that you are familiar with all safety-related
processes and regulations in your area. This also includes:
– How to act in the event of an alarm
– Initial steps to take if a fire breaks out
Notice!
Bosch Security Systems, Inc. has tested and approved the FPA-1000 FACPs and their
associated Networking cards including the system software. The system must be operated
only with the software included in the product delivery or with authorized software upgrades
(downloadable from the official Bosch homepage – www.boschsecurity.com). Bosch cannot
be held responsible if devices are operated with any modified software or software from
other sources.
1.1.1 Trademarks
All hardware/software product names used in this document are likely to be registered
trademarks and must be treated accordingly.
1.2 Symbols and Notes Used
The various chapters contain only whatever safety information and notes are required for
installation and operation of the system.
The following symbols are used:
Notice!
Contains useful information to help you operate the FPA-1000 FACPs and to avoid damages or
possible dangerous situations.
!
Caution!
A hazard or unsafe practice could result in minor injury.

Analog fire panels Notices | en 7
Bosch Security Systems, Inc. Installation and Operation Guide 2017.11 | 2.0 | F.01U.173.607
!
Warning!
A hazard or unsafe practice could result in severe injury or death. Follow the instructions
without fail – for your own safety as well as that of the people around you.
Danger!
A hazard or unsafe practice will result in severe injury or death. Follow the instructions
without fail – for your own safety as well as that of the people around you.
For example:
Hazardous Voltage.
Danger of contact with live parts and wires.
Disconnect and lock out power before connecting equipment or servicing!
1.3 FCC Compliance Notice
This equipment was tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy, and if not installed and used in accordance with
the instructions, might cause harmful interference to radio communications. There is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, that can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
– Re-orient or relocate the receiving antenna.
– Increase the separation between the equipment and the receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio or TV technician for help.
FCC Phone Connection to Users
This control panel complies with Part 68 of the FCC rules.
On the inside of the enclosure is a label that contains, among other information, the ringer
equivalence number (REN) for this equipment. You must, upon request, provide this
information to your local telephone company.
The REN is useful to determine the quantity of devices that can be connected to your
telephone line and still have all of those devices ring when your telephone number is called. In
most, but not all areas, the sum of the RENs of all devices connected to one line should not
exceed five. To ascertain the number of devices that you can connect to your line, contact
your local telephone company to determine the maximum REN for your local calling area.
This equipment can not be used on coin service provided by the telephone company. Do not
connect this control panel to party lines. If this equipment causes harm to the telephone
network, the telephone company might discontinue your service temporarily. If possible, they
will notify you in advance. But if advance notice isn’t practical, you will be notified as soon as
possible.
You will be informed of your right to file a complaint with the FCC. The telephone company
might make changes in its facilities, equipment, operations, or procedures that could affect
the proper functioning of your equipment. If they do, you will be notified in advance to give
you an opportunity to maintain uninterrupted telephone service.
If you experience trouble with this equipment, contact the manufacturer for information on
obtaining service or repairs.

8en | Notices Analog fire panels
2017.11 | 2.0 | F.01U.173.607 Installation and Operation Guide Bosch Security Systems, Inc.
The telephone company might ask that you disconnect this equipment from the network until
the problem is corrected or until you are sure that the equipment is not malfunctioning. The
manufacturer, not the user, must make the repairs to this equipment.
To guard against accidental disconnection, there is ample room to mount the telco jack inside
of the control panel cabinet.
The operation of this control communicator might also be affected if events such as accidents
or acts of God cause an interruption in telephone service.
1.4 NFPA Standard 72
NFPA 72 (the National Fire Alarm and Signaling Code for the United States) is one of the
standards referenced in this manual. The current edition (2016) of this standard is available at
a nominal cost from: The National Fire Protection Association, Batterymarch Park, Quincy, MA
02269.
Older editions of the standard identified circuit types by Class and Style. The newer editions
use Class only. The following table identifies the relationship between the older and newer
designations.
New
Designations
Old Designations
IDC NAC SLC Supplementary
Class B Class B, Style B
Class B, Style C
Class B, Style Y Class B, Style 4
Class A Class A, Style D
Class A, Style E
Class A, Style Z Class A, Style 6
Class X Class A, Style 7
Class E Non-supervised
Tab.1.1: NFPA 72 circuit designations

Analog fire panels System information | en 9
Bosch Security Systems, Inc. Installation and Operation Guide 2017.11 | 2.0 | F.01U.173.607
2 System information
2.1 Introduction
The FPA‑1000 Analog Addressable Fire Panels are advanced analog addressable control panels
for small to medium facilities in residential, commercial or public building applications. They
are listed by UL for central station, local, auxiliary, and remote station systems.
The fire panels combine complete built-in Fire Alarm Control Panel (FACP) equipment such as
Notification Appliance Circuits (NACs), Signaling Line Circuits (SLCs), relays, power supply,
Digital Alarm Communicator Transmitter (DACT) and Ethernet connection with the
expandability through the Option Bus or plug-in boards. Each FPA‑1000 has two integrated
NACs that can be expanded with addressable Remote Notification Appliance Circuit Power
Supplies. These circuits can be programmed with specific activation patterns.
The standard control panel has one FPE-1000-SLC for up to 254addressable detectors and
modules, or up to 127analog sounder bases in combination with a suitable detector. The
control panel is easily expandable with a second FPE‑1000-SLC doubling the address points.
The panel has a compact and solid metal housing with a removable front door with keyed lock
and a removable dead front door to access electronics. It features surface and semi-flush
mounting options.
On the front of the panel, six light-emitting diodes (LEDs) show fire alarm, gas alarm, power,
supervisory, silence and trouble conditions. The built-in keypad can be used for total system
control and programming. In addition, a large 4-line by 20-character alphanumeric display
shows programmed device point information. Four keys enable acknowledge, reset, silence,
and drill functions.
The FPA‑1000 fire panels enable various programming approaches:
– Front panel programming
– On-site programming, using a laptop with the possibility of pre-programming at the office
– Off-site programming, with remote access via Ethernet (browser-based) or phone line
(PSTN)
For front panel programming, the system provides an Auto Learn function, allowing the
installer to configure the system quickly and easily in default mode.
Using a local laptop or remote access through a communicator, the programming is carried
out by means of browser-based user interface. Therefore, no software installation is required.
The panel can receive diagnostics from a Web browser running on a networked PC.
The FPA‑1000 Analog Addressable Fire Panels comply with the relevant standards.

10 en | System information Analog fire panels
2017.11 | 2.0 | F.01U.173.607 Installation and Operation Guide Bosch Security Systems, Inc.
Figure2.1: FPA-1000-V2 System architecture
Optional Networking Cards allow multiple panels to be interconnected into a networked
system.

Analog fire panels System information | en 11
Bosch Security Systems, Inc. Installation and Operation Guide 2017.11 | 2.0 | F.01U.173.607
Options
The FMR-1000-RCMD Four-wire LCD annunciator has system control capability. It shows the
equivalent LEDs and LCD display and includes a piezo, scrolling buttons, and operation keys
for acknowledge (ACK), drill, reset and silence. The scrolling functions and the acknowledge
key are accessible without restriction. The keys for reset, silence or drill can be enabled and
disabled by the device key lock.
The FMR-1000-RA is an LCD annunciator without control. It shows the equivalent LEDs and
LCD display. It includes a piezo sounder, scrolling buttons and acknowledge key. The scrolling
functions and the acknowledge key are accessible without restriction.
The City Tie Plug-in Module FPE-1000-CITY provides the system with two supervised City Tie
Local Energy circuits or Reverse Polarity circuits. The FPE-1000-CITY plugs into the FPA‑1000
mainboard.
2.2 Features
System Configuration
– Basic configuration includes one analog Signaling Line Circuit (SLC), configurable as two
ClassB , one ClassA, or one Class X circuit
– Second SLC easily expandable with FPE-1000-SLC Signaling Line Circuit
– Up to 254detectors and modules, or up to 127analog sounder bases in combination with
a suitable detector, for a total of 254addressable device capacity per SLC
– SLC circuits use standard wire; no shielded or twisted pair required. Twisted pair wire,
CAT5 cable, or fiber optic cable used on network connections
– Programmable sensitivity levels per device, and automatic day and night sensitivity modes
– Automatic calibration and drift compensation routine
– 120V/240V AC power, total 5.5A transformer output
– Two integrated NAC circuits rated at 2.5A each, allowing up to 4A total current (shared
between AUX power, Option Bus, and NAC)
– Up to four addressable FPP-RNAC-8A-4C Remote notification appliance circuit power
supplies, providing Aux power and up to 16synchronized remote NAC circuits
– Mainboard NAC patterns include Steady, Pulsing, Temporal Code3, and Temporal
Code4, Wheelock, System Sensor, and Gentex
– Built-in synchronization for appliances from Wheelock, System Sensor, and Gentex
– Three programmable FormC relays on the mainboard (fire, trouble, supervisory, gas
alarm or activation by zone)
– Option Bus for optional boards and expansions including LCD/LED annunciators, Octal
Driver Module, Octal Relay Module, and Remote Notification Appliance Circuit Power
Supply
– Optional City Tie Plug-in Module FPE‑1000‑CITY with two circuits, each programmable to
Local Energy or Reverse Polarity
– Optional plug-in Networking Cards (three models) for connecting fire panels into a
networked system
– Built-in Ethernet interface for Conettix IP reporting and/or programming and diagnostics
– Built-in dual phone line PSTN DACT communicator
– ContactID, SIA300 and Modem IIIA2 reporting formats
– UL Listed, FM/CSFM/MEA approved
Ease of Use and Functionality
– Large 4-line by 20-character LCD display
– Six LED status indicators on each panel keypad or remote LCD annunciators, including
gas alarm LED

12 en | System information Analog fire panels
2017.11 | 2.0 | F.01U.173.607 Installation and Operation Guide Bosch Security Systems, Inc.
– Menu-driven user interface on panel
– Easy programming from panel keypad
– Browser-based user interface for programming and diagnostics running on a Microsoft
Windows or Unix/Linux based network operating system, no software installation is
required
– Programmable authority levels, secured with a user-definable four-digit PIN
– 225 software zones for flexible input-output mapping on a non-networked panel
– 128 local zones per panel and 97 grouped zones for flexible input-output mapping on a
network
– Programming option for sandwich alarm allows time-triggered phased evacuation
(evacuation floor by floor)
– Auto Learn feature for easy start-up programming
– Local piezo sounder
– Fire drill test function
– Walk test function
– Alarm verification feature
– Bypass or unbypass point, output or zone individually
– 2999 events history buffer
– Event and history printing via network printer
– Three language versions (English, Spanish, and Portuguese), software configurable, LED
and keypad labeling easy exchangeable
– Programming option for IP reporting communication with the Advanced Encryption
Standard (AES)
Hardware Features
– Removable front door with keyed lock
– Removable dead front door to access electronics
– Mounting kit available for semi-flush installation with trim ring
– Metal oxide varistors (MOVs) and spark gaps for protection from lightning surges and
static discharges

Analog fire panels System information | en 13
Bosch Security Systems, Inc. Installation and Operation Guide 2017.11 | 2.0 | F.01U.173.607
2.3 System Overview Mainboard Components
Figure2.2: FPA-1000-V2 Mainboard
Designation Description
Keypad With LEDs, LCD display, and keys.
Transformer Works with 120VAC, 60Hz or 240VAC, 50Hz.
SLC 1 / SLC 2 Signaling Line Circuit (SLC), standard configuration with one SLC,
second SLC with FPE-1000-SLC Plug-in Module,
Nominal 39VDC (30 to 40VDC), 260mA maximum (per SLC),
power‑limited, supervised.
Option bus Provides serial data interface, with 500mA at12VDC, power-limited,
supervised.
AUX
FWR- / FWR+
RST- / RST+
Two auxiliary power supply terminals, with 500mA at24VDC each,
power‑limited, non-supervised,
FWR=Full Wave Rectified, non‑switched
RST=Resettable, switched and filtered.
NAC 1 / NAC 2 Terminal strips for two NACs, 2.5A each.
Wiring options ClassA or ClassB.
For Mainboard NAC wiring example, see NAC wiring, page 68 (NAC1
= ClassA, NAC2 = ClassB)
CITY TIE Slot for City Tie Plug-in Module FPE-1000-CITY

14 en | System information Analog fire panels
2017.11 | 2.0 | F.01U.173.607 Installation and Operation Guide Bosch Security Systems, Inc.
Designation Description
Networking Card Slot for one of three models of Networking Card
RELAY 1
RELAY 2
RELAY 3
Mainboard relays, default assignment is for alarm, trouble and
supervisory; individually programmable for alarm, trouble, supervisory,
gas alarm, activation by zone and system events, rated at 5A,
30VDC/10A, 120VAC.
LINE 1 / LINE 2 Phone line connections through central station receiver (2xRJ45).
ETHERNET Ethernet connection (RJ45).
BATT Terminal strip for battery connection, 2x 12V, 18Ah maximum within
enclosure or 40Ah maximum external.
Tab.2.2: Mainboard (MB) components
Notice!
Network cards can only be used with an FPA‑1000‑V2 board, never with an FPA‑1000‑UL
board.
The boards, expanders and devices, listed in the following sections, are available from Bosch
Security Systems, Inc. to be used with the FPA‑1000 fire panels. For a complete description of
and installation instructions for each product, refer to the appropriate section of this manual
and the documents supplied with the device.
2.4 Plug-in Modules
The following plug-in modules are available for the FPA-1000 fire panels:
Type Number Description
FPE-1000-NE Ethernet Networking Card
FPE-1000-NF Fiber Optic Networking Card
FPE-1000-NW Wired Networking Card
FPE-1000-SLC Signaling Line Circuit (second circuit or replacement)
FPE-1000-CITY City Tie Plug-in Module
Tab.2.3: Plug-in modules
When a networked system of fire panels is desired, the Networking Cards provide the means
to interconnect the panels.
A second SLC can easily be added by plugging in the FPE‑1000‑SLC to the mainboard.
The City Tie Plug-in Module FPE‑1000‑CITY provides two circuits which can be programmed as
Local Energy or Reverse Polarity mode.
Designation Description
M34-56 Local energy Trip, Surface Mount, Cottage Shell
M34-72 Local energy Trip, Sheet Metal Housing (less inner case test block, tap key &
bell), Plain Door

Analog fire panels System information | en 15
Bosch Security Systems, Inc. Installation and Operation Guide 2017.11 | 2.0 | F.01U.173.607
Designation Description
M34-75 Local energy Trip, Surface Mount, Cottage Shell (less inner case test block,
tap key & bell)
M34-92 Local energy Trip, Flush Mount, Gasketed cast frame for interior and exterior
use
M34-110 Same as M34-56 with plain door painted blue
M34-111 Same as M34-56 with plain door painted red
M34-112 Same as M34-56 with plain door painted yellow
M34-113 Same as M34-92 with plain door painted blue
M34-114 Same as M34-92 with plain door painted red
M34-115 Same as M34-75 with plain door painted blue
M34-116 Same as M34-75 with plain door painted red
Tab.2.4: Compatible Gamewell devices for the City Tie module in Local Energy mode
2.5 Power Supply
A transformer working with 120VAC or 240VAC is supplied standard with the control panel.
Two backup batteries with 7Ah or 18Ah each fit inside the fire panel cabinet. A separate
battery box can provide higher capacity.
Each FPA‑1000 provides two auxiliary power supplies: one 0.5A at24VFWR; one 0.5A
at24VDC RST (resettable). This auxiliary power can run expansion boards or other low
current auxiliary devices.
For a list of Bosch batteries and battery boxes, see the following table. For selecting the
necessary battery capacity, use the Microsoft Excel based FPA‑1000_Battery_Calculator.xls. The
spreadsheet can be downloaded at www.boschsecurity.com.
Type Number Description
D126 Battery 12V, 7Ah
D1218 Battery 12V, 18Ah
D1224 Battery 12V, 24Ah
D1238 Battery 12V, 38Ah
BATB-40 Battery Box - provides a single level (two-battery capacity) of battery
storage with an optional shelf that increases the battery capacity to four
batteries.
BATB-80 Battery Box - Includes a mounted shelf that holds up to four batteries.
Tab.2.5: Bosch batteries and battery boxes
For installations requiring battery capacity higher than 40Ah, a regulated and UL1481 Listed
external power supply can be used. The external power supplies connect through the panel's
battery terminals. Batteries and battery charger are not supervised. For supervision of AC and
battery fault use an input module (for example FLM‑325‑2I4) on the SLC.

16 en | System information Analog fire panels
2017.11 | 2.0 | F.01U.173.607 Installation and Operation Guide Bosch Security Systems, Inc.
2.6 Components Connected to the Option Bus
Remote Command Center and Annunciators
Each FPA-1000 panel supports up to:
– a total of eight FMR-1000-RCMD and/or FMR-1000-RA LCD annunciators
– eight D7030X Family annunciators with eight LED zones each
– eight D7030X Family/D7032 combinations
For wiring requirements, see Option Bus, page 67. For address restrictions, see Option Bus
Address Assignment, page 37.
Type Number Description
FMR-1000-RCMD LCD annunciator with control - remote operational terminal of the
FPA‑1000 panel, providing buttons for silence, reset, acknowledge, drill,
scrolling keys, key switch with 1358 key, built-in piezo sounder
FMR-1000-RA LCD annunciator without control - remote LCD annunciator, providing key
for acknowledge and scrolling keys, built-in piezo sounder
D7030X Annunciator, 8 alarm LED - identifies the location of a fire alarm for up to
eight zones allowed per system
D7030X-S2 Annunciator, 8 LED (2 supervisory) - with two zones reserved for
supervisory functions and with power and trouble LEDs plus eight-zone
LEDs that can be individually labeled
D7030X-S8 Annunciator, 8 LED (8 supervisory) - with eight zones reserved for
supervisory functions and with power and trouble LEDs plus eight-zone
LEDs that can be individually labeled
D7032 Annunciator expander, 8 LED - attaches to a D7030X, D7030X‑S2 or
D7030X‑S8 and identifies the location of a fire alarm for eight additional
zones, showing 16 LED zones in the D7030X/D7032 combination
Tab.2.6: Controla and Annunciators for the Option bus
Modules
Each FPA‑1000 supports up to two Octal Relay Modules or Octal Driver Modules.
The outputs are fully programmable and can be activated by system events. These outputs
have the same programming options as the local relays. Each output operates independently
of the other seven to provide complete flexibility. Communication with the D7035/B or D7048/
B is supervised.
Type Number Description
D7048/B Octal Driver Module
D7035/B Octal Relay Module
Tab.2.7: Option bus modules
NAC Power Supply
The FPP‑RNAC‑8A‑4C Power supply (RNAC 8A 24V) adds four additional NACs (NFPA72,
ClassA or ClassB) to the fire panel or serves as a power supply for fire protective signaling
systems. This regulated power supply provides up to 8A of power that is used to recharge

Analog fire panels System information | en 17
Bosch Security Systems, Inc. Installation and Operation Guide 2017.11 | 2.0 | F.01U.173.607
batteries and operate continuous and intermittent alarm loads. This 8A of power can be
distributed through the four NAC Power Supply circuits that are part of the FPP‑RNAC‑8A‑4C.
The FPP‑RNAC‑8A‑4C is UL Listed for use in commercial fire alarm applications.
Type Number Description
FPP-RNAC-8A-4C Power supply, RNAC 8A 24V
Tab.2.8: NAC power supply for the Option bus
2.7 Signaling Line Circuit Devices
The FPA‑1000 fire panels communicate with each of the addressable devices located on the
SLCs using fast and reliable protocol that allows the use of standard non-twisted, non-
shielded wiring for the SLCs.
Each FPA‑1000 supports two ClassB, one ClassA, or one Class X circuit per SLC.
For a list of all compatible devices for the FPA‑1000 SLCs, see the following table.
Type Number Description
FAP-440-T
FAP-440-TC
FAP-440-DT
FAP-440-DTC
[SMOKE-M]
Analog Multi-sensor Detector Photo/Heat
Analog Multi-criteria Detector Photo/Heat/CO
Incorporates a thermal element and a high performance photoelectric
smoke chamber. The -TC model includes a carbon monoxide (CO) sensor
as an indicator of fire.
Provides two user-selectable modes for making the fire decision:
multi‑combined and multi‑separated mode.
Allows programming LED behavior during polling of the internal device
LED and a remote connected indicator.
D models incorporate dual photoelectric emitters (infrared and blue) to
enhance catch performance.
Can use addresses 1 to 254.
FAP-325-V2F
[SMOKE-P]
Analog Photoelectric Smoke Detector Flat Head
Detects optically dense smoke typical of fires involving materials such as
soft furnishings, plastic, foam or other similar materials which tend to
smolder and produce large visible smoke particles.
Allows programming LED behavior during polling of the internal device
LED and a remote connected indicator.
Can use addresses 1 to 254.
FAP-325
FAP-440
FAP-440-D
[SMOKE-P]
Analog Photoelectric Smoke Detector
Analog Photoelectric Detector
Detects optically dense smoke typical of fires involving materials such as
soft furnishings, plastic, foam or other similar materials which tend to
smolder and produce large visible smoke particles.
The D model incorporates dual photoelectric emitters (infrared and blue)
to enhance catch performance.
FAH‑325
FAH-440
[HEAT]
Analog Heat Detector
Analog Heat Detector
Detects heat in environments where smoke detectors are unsuitable
because of the presence of steam or cooking fumes, such as in a kitchen.

18 en | System information Analog fire panels
2017.11 | 2.0 | F.01U.173.607 Installation and Operation Guide Bosch Security Systems, Inc.
Type Number Description
FAI-325
[SMOKE-I]
Analog Ionization Smoke Detector
For use in areas where early warning of trouble from superheated or
flaming combustibles is expected; also constructed to be used effectively
where outside Radio Frequency Interference (RFI) and other electrical
interference is expected.
FAA-325-B4
FAA-440-B4
FAA-440-B4-ISO
Analog Detector Base
Analog Standard Base (4-inch)
Analog Isolator Base (4-inch)
Compatible with all analog addressable detectors that use the advanced
analog communication protocol, except the FAD‑325‑DH or FAD-325-V2F-
DH.
4-in (10cm) diameter.
ISO base contains built-in circuit isolator.
FAA-325-B6
FAA-440-B6
FAA-440-B6-ISO
Analog Detector Base
Analog Standard Base (6-inch)
Analog Isolator Base (6-inch)
Compatible with all analog addressable detectors that use the advanced
analog communication protocol, except the FAD‑325‑DH or FAD-325-V2F-
DH.
6-in (15cm) diameter.
ISO base contains built-in circuit isolator.
FAD-325
FAD-325-DH
FAD-325-R
FAD-325-V2F
FAD-325-V2F-DH
FAD-325-V2F-R
[SMOKE-D]
Analog Duct Smoke Sensor Replacement
Analog Duct Smoke Detector
Provides early detection of smoke and products of combustion present in
air moving through HVAC ducts in Commercial, Industrial and Residential
applications.
The FAD-325-V2F-DH is a replacement for the sensor in any of the four
duct housing units. The FAD-325-DH is no longer available for purchase,
but can be used as a replacement for the sensor in either of the following
units:
FAD‑325 Analog Duct Smoke Detector (with Housing)
FAD‑325‑R Analog Duct Smoke Detector with Relay (with Housing)
FMM-325A
FMM-325A-D
[CONT-MOD]
Single-action Analog Manual Station
Double-action Analog Manual Station
Contact monitor module mounted in a corrosion-resistant rugged die-
cast housing for single-gang mounting.
Loop powered.
The FMM‑325A/FMM‑325A‑D devices are connected via an FLM‑325‑IM
Contact Module. For programming, refer to the Contact Monitor
information.

Analog fire panels System information | en 19
Bosch Security Systems, Inc. Installation and Operation Guide 2017.11 | 2.0 | F.01U.173.607
Type Number Description
FLM-325-I
[CONT-MOD]
Contact Monitors
Designed to use with pull stations, water-flow switches, and other
applications requiring the monitoring of dry-contact alarm-initiating
devices.
Can be programmed in NO EOL, NC EOL, NCnoEOL.
Independently from the type, the panel lists only an FLM-325-I.
Two types available for input switches to be connected as ClassB:
FLM‑325‑I4 Contact Monitor 4-inch
FLM‑325‑IM Contact Monitor, Mini
Two types available for input switches to be connected as ClassA:
FLM‑325‑I4‑AI Contact Monitor 4-inch Class A w/Isolator
FLM‑325‑I4‑A Contact Monitor 4-inch Class A
The types FLM-325-IM, FLM‑325‑I4‑AI, and FLM‑325‑I4‑A can use
addresses 1 to 254.
FLM-325-2I4
[CONT-MOD]
Dual Input Monitor
Provides two independent contact monitoring circuits while utilizing only
one address on the SLC.
Can be programmed to monitor normally open or normally closed contact
fire alarm and supervisory devices (NO EOL, NC EOL, NCnoEOL)
Supervises with StyleB (ClassB), loop powered.
FLM-325-CZM4
[CONVZ-MOD]
Conventional Zone Module
Monitors dry contacts (NO) devices such as two-wire conventional
detectors or pull stations.
Transmits the status of one zone of devices back to the panel
(25maximum per zone; number depends on type of connected devices).
ClassA or ClassB wiring is configured with a jumper on the module
Auxiliary (AUX) powered.
For compatible devices, refer to the manual supplied with the product.
The number of Conventional Zone Modules (FLM‑325‑CZM4) for each
SLC module is limited to 32.

20 en | System information Analog fire panels
2017.11 | 2.0 | F.01U.173.607 Installation and Operation Guide Bosch Security Systems, Inc.
Type Number Description
FLM-325-2R4
[RELAY-MOD]
Dual Relay Modules
Allows independent control of two FormC contacts for a variety of
normally open (NO) and normally closed (NC) contact applications such
as fan operation, elevator recall, door closure, and auxiliary notification.
Loop powered.
Five types available:
FLM‑325‑2R4 Dual Relay Module, rated for 1.0A at 30VDC or 0.5A at
125VAC
FLM‑325‑2R4‑2A Dual Relay Module 2A, rated for 2.0A at 30VDC or
1.0A at 125VAC
FLM‑325‑2R4‑2AI Dual Relay Module 2A w/Isolator rated for 2.0A at
30VDC or 1.0A at 125VAC
FLM‑325‑2R4‑8A Dual Relay Module 8A, rated for 8.0A at 30VDC or
8.0A at 250VAC)
FLM‑325‑2R4‑8AIDual Relay Module 8A w/Isolator, rated for 8.0A at
30VDC or 8.0A at 250VAC)
The types FLM‑325‑2R4‑2A, FLM‑325‑2R4‑2AI, FLM‑325‑2R4‑8A and
FLM‑325‑2R4‑8AI can use addresses 1 to 254.
D328A
[RELAY-MOD]
Analog Relay Module
Allows the control of one FormC contact (rated for 1.0A at 30VDC or
0.5A at 125VDC) for a variety of normally open (NO) and normally
closed (NC) contact applications such as elevator recall systems or HVAC
shutdown.
Loop powered.
FLM‑325‑N4
[NAC-MOD]
Supervised Output Module
Provides a supervised pole reversal output used for acoustic and optical
signaling devices or to trigger an RNAC power supply..
Requires a 24VDC auxiliary input voltage.
The output relay is rated to supply 2A at 30VDC.
Provides Steady, Pulsing and Temporal Code3 output pattern
ClassB type:
FLM‑325‑N4 Supervised Output Module
Two types available for ClassA:
FLM‑325‑NA4 Supervised Output Module ClassA
FLM‑325‑NAI4 Supervised Output Module ClassA w/Isolator
The types FLM‑325‑NA4 and FLM‑325‑NAI4 can use addresses 1 to 254.
FLM-325-ISO Short Circuit Isolator
Isolates a shorted section on a specific polling circuit from the rest of the
system to minimize the loss of devices.
Tab.2.9: Compatible SLC devices
When programming the SLC devices, first select the device group type and then specify the
type number. See the type designations in brackets in the table above.
