Bosch FPA-5000 User guide

Modular fire panel
FPA‑5000 | FPA‑1200
en System Information

Modular fire panel Table of contents | en 3
Bosch Sicherheitssysteme GmbH System Information 07.2020 | 12.0 | F.01U.028.089
Table of contents
1Notes 6
2Product Description 6
2.1 FPA-1200 Fire Panel and FPA-5000 Fire Panel with Functional Modules 6
2.2 Panel controller 11
2.2.1 MPC Panel Controller 11
2.2.2 FPE-8000-SPC | FPE-8000-PPC | FPE-2000-SPC | FPE-2000-PPC panel controller 13
2.3 Remote keypad 16
2.3.1 FMR-5000-C Remote keypad 16
2.3.2 FPE-8000-FMR Remote keypad 16
2.4 Housings for Frame Installation 18
2.5 Housings for Wall Mounting 21
2.6 System Overview 22
2.7 Networking 27
2.8 Connection to BIS 27
2.9 Connecting a Voice Alarm System 27
3Planning 28
3.1 General Information 28
3.2 Detection Points 29
3.3 Address Setting 30
3.4 Topologies in Local Security Network 31
3.5 Failure handling in Local Security Network 33
3.6 Redundancy 34
3.7 Achievable Cable Length with LSN 0300 A 36
3.8 Achievable Cable Length with LSN 1500 A 38
3.9 Examples of Housing Equipment 42
3.10 Configuration of BCM Battery Controller Module 43
3.11 Protective earth and equipotential bonding 47
4Installation 47
4.1 General Information 47
4.2 Quick Installation Guide 48
4.3 Installation of Housing Components 49
4.3.1 Installation Instructions for Housing 50
4.3.2 Installation Dimensions for Wall Mounting Housing 52
4.3.3 Installation Dimensions for Frame Installation Housing 58
4.3.4 Installation Dimensions for Mounting Frames 61
4.3.5 Installation Kits for 48 cm (19”) Racks 64
4.4 Accessories for Housing 66
4.4.1 RLE 0000 A Junction Board 66
4.4.2 HMP 0003 A Mounting Plate for Mounting Frame 68
4.4.3 FPO-5000-EB Earth Bar 70
4.5 Power Supply Brackets 70
4.5.1 FPO‑5000‑PSB‑CH Power Supply Bracket 72
4.5.2 FPO-5000-PSB1 Power Supply Bracket 76
4.6 UPS 2416 A Universal Power Supply 24 V/6 A 77
4.7 Panel Rails 83
4.7.1 PRS-0002-C Panel Rail Short for 2 Modules 83
4.7.2 PRD 0004 A Panel Rail Long for 4 Modules 85
4.7.3 Panel Rail Installation 86

4en | Table of contents Modular fire panel
07.2020 | 12.0 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
4.8 MPC Panel Controller 89
4.9 Functional Modules 100
4.9.1 Installation and Removal 100
4.9.2 ANI 0016 A Annunciator Module 101
4.9.3 BCM‑0000‑B Battery Controller Module 101
4.9.4 CZM 0004 A 4 Zone Conventional Module 106
4.9.5 ENO 0000 B Fire Service Interface Module 107
4.9.6 FPE‑5000‑UGM Interface Module 108
4.9.7 IOP 0008 A Input/Output Module 109
4.9.8 IOS 0020 A 20 mA Communication Module 110
4.9.9 IOS 0232 A RS232 Communication Module 111
4.9.10 LSN 0300 A LSN improved Module 300 mA 112
4.9.11 LSN 1500 A LSN improved Module 1500 mA 113
4.9.12 NZM 0002 A Notification Appliance Zone Module 115
4.9.13 RMH 0002 A Relay Module for Mains Voltage 116
4.9.14 RML 0008 A Relay Module for Low Voltage 117
4.9.15 Accessories for Functional Modules 118
4.10 Cable Sets 119
4.11 Extended line monitoring (VdS 2540, VdS 2543) 120
4.12 FPP‑5000 External Power Supply Unit Kit 24 V/6 A 120
4.13 THP 2020 A Thermal Printer 122
4.14 Remote Keypad 126
5Commissioning 141
5.1 Notes 141
5.2 Documentation 141
5.3 Quick Guide for Commissioning 141
5.4 Functional Test 141
5.4.1 Preparation 141
5.4.2 Testing the Power Supply 142
5.4.3 Testing the Conventional and LSN Functions 142
5.4.4 Testing the Addressing/Activation 143
6Maintenance and Service 143
6.1 Warranty 143
6.2 Repair 143
6.3 Disposal 143
6.4 Additional Documentation 143
7Technical Data 144
7.1 System Limits 144
7.2 Power loss of components 145
7.3 Housing and Accessories 146
7.3.1 Housings for Frame Installation 146
7.3.2 Housings for Wall Mounting 146
7.3.3 PRS-0002-C Panel Rail Short for 2 Modules 147
7.3.4 PRD 0004 A Panel Rail Long for 4 Modules 147
7.3.5 FPO‑5000‑PSB1/FPO‑5000‑PSB‑CH Power Supply Brackets 147
7.3.6 UPS 2416 A Universal Power Supply 24 V/6 A 148
7.4 Panel Controller and Remote Keypad 148
7.4.1 MPC 148
7.4.2 Remote Keypad 149

Modular fire panel Table of contents | en 5
Bosch Sicherheitssysteme GmbH System Information 07.2020 | 12.0 | F.01U.028.089
7.4.3 FSP-5000-RPS Programming Software 149
7.5 Functional Modules 149
7.5.1 ANI 0016 A Annunciator Module 150
7.5.2 BCM‑0000‑B Battery Controller Module 150
7.5.3 CZM 0004 A 4 Zone Conventional Module 151
7.5.4 ENO 0000 B Fire Service Interface Module 151
7.5.5 FPE‑5000‑UGM Interface Module 152
7.5.6 IOP 0008 A Input/Output Module 152
7.5.7 IOS 0020 A 20 mA Communication Module 152
7.5.8 IOS 0232 A RS232 Communication Module 152
7.5.9 LSN 0300 A LSN improved Module 300 mA 153
7.5.10 LSN 1500 A LSN improved Module 1500 mA 153
7.5.11 NZM 0002 A Notification Appliance Zone Module 154
7.5.12 RMH 0002 A Relay Module for mains voltage 154
7.5.13 RML 0008 A Relay Module for Low Voltage 155
7.6 FPP‑5000 External Power Supply Unit Kit 24 V/6 A 155
7.6.1 FPP‑5000 Kit 155
7.6.2 FPP‑5000‑TI Trouble Interface 156
7.6.3 FPP‑5000‑TI13 Communication Interface 156
8Appendix 156
8.1 Options with requirements under EN 54‑2:1997/A1:2006 156
8.2 Component Overview 157
8.2.1 Frame Installation Housings, Mounting Frames and Installation Kits 157
8.2.2 Wall Mounting Housings and Installation Kits 157
8.2.3 Accessories for Housing 158
8.2.4 Panel Rails 158
8.2.5 Power Supply Units, Power Supply Brackets, Batteries 158
8.2.6 Panel Controller/Remote Keypad 159
8.2.7 Functional Modules 161
8.2.8 Cable Sets 161
8.2.9 Thermal Printer 161
8.2.10 ETH/FOC Adapters 162
8.3 Additional documentation 162
8.3.1 Frame installation housings, mounting frames and installation kits 162
8.3.2 Wall mounting housings and installation kits 163
8.3.3 Accessories for housing 163
8.3.4 Panel rails 164
8.3.5 Power supply units 164
8.3.6 Panel controller | Remote keypad 164
8.3.7 Functional modules 165
8.3.8 Cable sets 166
8.4 Special Applications 167
8.4.1 Controlling Extinguishing Systems 167
Index 168

6en | Notes Modular fire panel
07.2020 | 12.0 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
1 Notes
Danger!
The fire panel and devices contain live components.
Touching live components can result in electric shock.
Disconnect the power supply before all maintenance or installation work.
Notice!
Installation must only be carried out by authorized specialist personnel.
Notice!
Have maintenance and inspection work carried out regularly by trained, qualified personnel.
Bosch recommends a functional and visual inspection at least once a year.
Notice!
The fire panel is designed for indoor installation.
After installing batteries, the poles must be masked. Appropriate masking strips are included
with the housing in which the batteries are installed.
Use fuses complying with national regulations to protect the power lines.
Notice!
Batteries must not be disposed of in household waste. Please take used batteries to the local
collection points. See www.boschsecurity.com/xc/en/weee/ for further information.
Notice!
Consider national and local regulations when installling and operating the fire system.
2 Product Description
The fire panel is easily adapted to local requirements and regulations. Due to the different
functional modules, country-specific characteristics are accommodated in the connection just
as quickly as the respective alarm protocol.
2.1 FPA-1200 Fire Panel and FPA-5000 Fire Panel with Functional
Modules
Compare FPA-1200 fire panel to FPA-5000 fire panel:
FPA-1200 FPA-5000 (MPC-xxxx-C)
Ethernet interface to
Building management
system (BIS, FSM-5000-
FSI)
• •

Modular fire panel Product Description | en 7
Bosch Sicherheitssysteme GmbH System Information 07.2020 | 12.0 | F.01U.028.089
FPA-1200 FPA-5000 (MPC-xxxx-C)
UGM-2040 Hierarchy
panel
• •
Voice alarm system
(Smart Safety Link)
• •
Modularity (maximum number)
LSN 0300 A modules 4 32
LSN 1500 A modules 11
Functional modules
(including LSN modules)
6 46
Panel redundancy
Redundant panel
controller
•
Network
Panel network remote keypads panels, remote keypads, servers
Max. number of nodes 4 (1 panel, 3 keypads) 32
The fire panel is available with two different types of housings:
– Wall mount housing
– Frame mount housing
The slim wall mount housings are for mounting directly to the wall. Frame mount housings
require an additional frame between the housing and the wall. The frame lets space for e.g.
cabling, media converters, and larger batteries. Special installation kits also allow installation
in 19" racks.
The panel controller is the central component of the fire panel. A color display shows all
messages. The touch screen is for operation of the entire system. The user-friendly interface
adapts to various situations. This causes correct operation that is simple and clear as well as
targeted and intuitive.
The fire panel is configured on a laptop using the FSP-5000-RPS programming software. The
programming software enables further adaptation, e.g. to country-specific requirements and
regulations.
The panels can be networked with one another and with the remote keypad using the Ethernet
and the CAN bus interfaces.
The fire panel can be connected to the Bosch Hierarchy panel (UGM) and thus integrated into
large-scale systems.
Connection to the Bosch Building Integration System BIS is possible via an Ethernet interface
using an OPC server. The FSM-5000-FSI Software Interface Package allows custom integration
to external management systems.
The panel can be connected to a voice alarm system. The Praesideo or PAVIRO system can be
connected using an Ethernet interface. Plena voice alarm system can be connected via an
RS232 module.
The remote keypad allows decentralized operation of the panel or the panel network.
System Overview
The figure below shows an example configuration:

8en | Product Description Modular fire panel
07.2020 | 12.0 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
N
I
TUO
N
I
TUO
#
0
*
8 9
5 6
2 3
7
4
1
?
PQRS TUV WXYZ
GHI JKI MNO
ABC DEF
F i r e
Test
City Tie
City Tie Fa ult
Ground F ault
Battery F ault
Power
Trouble
Signal S ilence
Bypass ed
Superv isory
N AC 1 N AC 3N A C 7NA C
9
N A C 5
N A C 2N A C 4N A C 8NA C
10
N A C 6
PS 2PS 3 PS 5PS
6
PS 4
BC B A T
BC B A T
BA T 2
10 A
25 A
25 A
Bridge 2-3 Bridge 3-4 Bridge 4-5 Bridge 5-6
- - - --+ + + ++
- + - +
-
+
BA T 1 AB AT 1 B
-
+-
+
NETZEIN
NETZSTROM
Störung
BATTERIE1
Störung
BATTERIE2
Störung
FAULT
MAIN
+ - BAT1 + - BAT2 + - BAT1 + - +-
FAULT AC FAULT
AUX3
+ - AUX4 + -
AUX2
+ -
AUX1
+ - AUX5 + - AUX6 + -
BCM0000A
L S N 0 3 0 0 A
AU X 1
+ - L S N 1 a -b + AU X 2 + - L S N 2 a -b +
ZONE4
Störung
ZONE3
Störung
ZONE2
Störung
ZONE1
Störung
CZM0004A
AUX1
+ - OUT1 +- IN1 +- AUX2 + - OUT2 +- IN2 +-
AUX3
+ - OUT3 +- IN3 +- AUX4 + - OUT4 +- IN4 +-
ANI0016A
F2F1
NC1 NO1
C1
NC2 NO2
C2
FB1
+-FB2 + -
RELAIS2
Störung
RELAIS1
Störung
RMH0002A
OUT3 OUT2 OUT4 OUT6 OUT5 OUT7 GND OUT8 GND GND GND
IN1 IN3 IN2 IN4 IN6 IN5 IN7
GND
IN8
GND GND GND
OUT1
IOP0008A
3
4
2
5
1
6
7
9
110
11
8
Figure2.1: Example configuration
Position Description Position Description
1 Functional modules 7 Power supply unit
2 Panel controller 8 Housing (in this case: HCP0006A)

Modular fire panel Product Description | en 9
Bosch Sicherheitssysteme GmbH System Information 07.2020 | 12.0 | F.01U.028.089
Position Description Position Description
3 Distributor, optional (RLE) 9 Panel rail, long
4 Fire brigade peripheral module 10 Batteries
5 Panel rail, short 11 Remote keypad
6 Power supply bracket
Functions
The panel provides complete flexibility and thus customized solutions for any application.
The configuration of the components is supported by Safety Systems Designer for fire alarm
systems. The software provides information about the size and number of housings, the
modules and the energy balance calculation.
Depending on specific requirements, the planning involves choosing from the following
options:
–Housing type (frame and wall mounting)
– Selection of a basic housing
– Extension housing, optional
– Power supply housing, optional
– Installation kits (optional) for installation in 482.6mm (19") racks
–Panel controller
– Selection from a range of language versions
–Panel rail
– Selection according to housing type and/or number of functional modules required
–Power supply
– Batteries
– Power supply units for additional power supply
– Power supply brackets
The power supply brackets on frame installation housings are preinstalled ex works;
for wall-mounted housings, power supply brackets can be selected as required.
–Thermal printer
– THP2020A Thermal Printer
The thermal printer is used to document operating procedures on the panel, as well
as alarm and fault messages. Plain text can also be printed. Programming is carried
out via the programming software FSP-5000-RPS.
–Additional accessories
– Front doors
– Cable sets for special applications.
–Functional modules
Functional modules are independent, encapsulated units that can be inserted into any
slot on the panel. The power supply and the data traffic with the panel are therefore
provided automatically. The module is identified by the panel with no further settings and
operates in the default operating mode (plug and play).
Wiring to external components is performed using compact connector/screw terminals.
After a replacement, only the connectors need to be reinserted; there is no need for
extensive rewiring.
Module Description Function
ANI 0016 A Annunciator module Indicating system statuses, with 16 red and 16
yellow freely programmable LEDs

10 en | Product Description Modular fire panel
07.2020 | 12.0 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
Module Description Function
BCM-0000-B Battery controller
module
Controlling the power supply to the panel and the
battery charge level
CZM 0004 A Conventional zone
module
Connecting conventional peripheral devices using
four monitored conventional lines
ENO 0000 B External notification
module
Connecting fire service equipment complying with
DIN 14675
FPE-5000-UGM Module interface to
UGM
Connection to UGM systems
IOP 0008 A Input-output module Individual displays or flexible connection of various
electrical devices, with 8 independent digital inputs
and 8 open collector outputs
IOS 0020 A Communication
module, 20mA
With S20 and RS232 interfaces
IOS 0232 A Communication
module, RS232
Connection of two devices using two independent
serial interfaces, e.g. Plena or a printer.
LSN 0300 A LSN bus module
300mA
Connection of an LSN loop with up to 254LSN
improved elements or 127LSN classic elements at a
maximum line current of 300mA
LSN 1500 A LSN bus module
1500mA
Connection of an LSN loop with up to 254LSN
improved elements at a maximum line current of
1500mA or 127LSN classic elements at a maximum
line current of 300mA
NZM 0002 A Notification
appliance zone
module
Allows connection of two conventional, monitored
notification appliance circuit lines
RMH 0002 A Relay module high-
voltage
Monitored connection of external elements with
feedback, with two changeover contact relays
suitable for switching mains voltage
RML 0008 A Relay module low-
voltage
For low voltage switching, with eight changeover
contact relays
– Fire brigade peripheral module
A fire brigade peripheral module is connected via FPE-5000-UGM or via IOS 0020 A
functional module. The fire brigade peripheral module FMF-ADP-TTY connects fire service
devices e.g. a Fire service operating panel or a Fire brigade information center to the fire
panel.
Notice!
Safety Systems Designer can be used to plan fire alarm systems that conform to the relevant
limits (e.g. in terms of cable length and power supply).

Modular fire panel Product Description | en 11
Bosch Sicherheitssysteme GmbH System Information 07.2020 | 12.0 | F.01U.028.089
Notice!
Safety Systems Designer for fire alarm systems enables the system dimensions, the energy
requirements and the quantity and prices of the elements required to be estimated at each
different phase in the planning process.
The software is designed for planners and engineering offices that want to produce a
quotation for a fire alarm system.
Notice!
Trouble handling
A trouble indication disappears as soon as the triggering fault is rectified, and you have reset
the trouble message. If you cannot reset a trouble message, then contact the service
personnel.
Refer to
– Networking, page 27
– Connection to BIS, page 27
– Connecting a Voice Alarm System, page 27
2.2 Panel controller
2.2.1 MPC Panel Controller
The panel controller is the central component of the fire panel. All messages are shown on the
color display. The entire system is operated via a touch screen. The user-friendly user interface
adapts to various situations. This allows correct operation that is both simple and clear as well
as targeted and intuitive.
The FSP-5000-RPS programming software enables adaption to project- and country-specific
requirements.
For operating the panel controller and the keypad refer to the user manual (F.01U.258.929)
available for download at www.boschsecurity.com.

12 en | Product Description Modular fire panel
07.2020 | 12.0 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
1234
5
Figure2.2: Overview of MPC system
Position Description
1 LEDs for displaying the operating status, with labeling strips
2 Key switch
3 Touch screen
4 Membrane keys
5 CAN bus, internal
Networking
Up to 32panel controllers, remote keypads and OPC servers can be combined to form a
network.
Alarm Indication
The display element is an TFT touch screen with automatically activated backlighting. 12LEDs
provide continuous information about the operating status of the panel or system. Additional
LED indicator modules each with 16detection points can be used to provide visual indication
of alarms or faults.
Operation and Processing of Messages
The panel is operated and all messages are processed on the functionally designed operating
panel with the integrated TFT touch screen. There are permanent keys on the right, at the
bottom, and along the top of the display as well as variable virtual keys located in the touch
screen area.
The language for the menu navigation can be selected as required.
Below the status LEDs is a key switch with two programmable positions, e.g.:
– for switching between day/night mode, or

Modular fire panel Product Description | en 13
Bosch Sicherheitssysteme GmbH System Information 07.2020 | 12.0 | F.01U.028.089
– for switching local alarm on/off (internal/external alarm)
Interfaces
A USB interface is provided to quickly transfer the required configuration to the panel
controller. There is also an Ethernet interface for adding the BIS software to the local network,
for example.
Saving and Printing Messages
Incoming messages and events are saved internally and can be viewed on the display. A log
printer for printing incoming messages can be connected.
2.2.2 FPE-8000-SPC | FPE-8000-PPC | FPE-2000-SPC | FPE-2000-PPC panel
controller
The panel controller is the central component of the fire panel. All messages are shown on the
color display. The entire system is operated via a touch screen. The user-friendly user interface
adapts to various situations. This allows correct operation that is both simple and clear as well
as targeted and intuitive.
The FSP-5000-RPS programming software enables adaption to project- and country-specific
requirements.
For operating the panel controller and the keypad refer to the user manual (F.01U.378.877)
available for download at www.boschsecurity.com.
Licenses
The panel controller is delivered with a hard coded software license. This software license is
implemented during production and cannot be modified, revoked or transported. The license
defines the maximum panel network size and availability of certain features and interfaces. In
total 4 different licenses are available.
Notice!
Building Management System
A premium license is required for each panel that needs to be available in a building
management system (e.g. BIS, FSM-5000-FSI). It is not sufficient to equip only one panel of
the network with a premium license, if you need all panels of the network in the building
management system.
Notice!
UGM-2040 hierarchy panel
A premium license is required for each panel that needs to be available in the UGM-2040
hierarchy panel. It is not sufficient to equip only one panel of the network with a premium
license, if you need all panels of the network in the hierarchy panel.
Notice!
Voice alarm system
Each fire panel which is physically connected to a voice alarm system (Praesideo, PAVIRO or
Plena) via Smart Safety Link needs a premium license.
!
Caution!
Do not use any pointed or sharp objects (e.g. screw drivers, pens, etc.) when operating the
touch-sensitive display. The touchscreen may not be exposed to direct sunlight. Both can
seriously damage the touchscreen.

14 en | Product Description Modular fire panel
07.2020 | 12.0 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
!
Warning!
The power button must be used to switch off the device before removing the power supply. It
may not be disconnected from power supply while system is running. The device may be
damaged if this procedure is violated. Not following this procedure may result in loss of
warranty. Refer to user guide for further information.
Figure2.3: Overview of panel controller
Pos. Designation Function
A Interfaces Panel networking and inputs for internal device monitoring
B Touchscreen Operating the networked system through virtual buttons and variable display
windows
C 6 fixed buttons Standard entries
D Power button Shutdown and restart of the device
E Memory card slot Memory card reader for maintenance services
F Ethernet ports Panel networking and interface to various systems
G 18 LEDs Indicating the operating status
Networking
A panel controller with premium license can be networked with up to 32panel controllers,
remote keypads and OPC servers.
Panels and keypads display all messages, or you can form a group of panels and keypads.
Within one group, only messages of this group are displayed.
Alarm indication
All messages are shown on the display with a bright color. The displayed messages contain the
following information:
– Message type
– Type of the triggering element
– Description of the exact location of the triggering element
– Logical zone and sub-address of the triggering element
At any time, the operator can request a status overview for each evacuation zone and each
output connected to the fire protection equipment.

Modular fire panel Product Description | en 15
Bosch Sicherheitssysteme GmbH System Information 07.2020 | 12.0 | F.01U.028.089
18Icon LEDs give continuous information about the operating status of the panel or the
system. A red icon LED shows an alarm. A blinking yellow icon LED shows a fault. A steady
yellow icon LED shows a disabled function. A green icon LED shows proper operation.
Two status LEDs, one red and one yellow, are programmable. The red one shows a self-
defined alarm. The yellow one shows a self-defined fault or deactivation.
Additional annunciator modules, each with 16red and 16yellow LEDs are available to indicate
a larger number of self-defined alarms, faults or deactivations.
Operator management
The system can have up to 200 different registered operators. Login is permitted with a user
ID and an 8-digit pin code.
There are four different authorization levels. Depending on the authorization level it is possible
for the operator to do certain functions according to EN54-2.
Languages
The operator can change the language of the user interface. A printed quick user guide for
each language is supplied with the package. Following languages are included: English,
German, Bulgarian, Croatian, Czech, Danish, Dutch, Estonian, French, Greek, Hungarian,
Italian, Latvian, Lithuanian, Polish, Portuguese, Romanian, Russian, Serbian, Slovak, Slovenian,
Spanish, Swedish and Turkish.
Operation and processing of messages
For operating the panel, an 8 inch touch pad as input medium is put upon the display. There
are 6 buttons with fixed functionality as well as 3 programmable function keys.
Examples for the assignment of the function keys:
– Set the panel controller to day mode, set the panel controller to night mode
– Enable detection points or outputs, disable detection points or outputs
– Set standard sensor sensitivity, set alternative sensor sensitivity
Each function key has a virtual status indicator.
At any time, an operator with sufficient user rights can activate each evacuation zone and each
output connected to fire protection equipment via the user interface.
The panel controller features
– 2 CAN interfaces (CAN1/CAN2) for networking
– 1 Rail connector
– 4 Ethernet interfaces (1 / 2 / 3 / 4) for networking, prescribed usage:
– 1 and 2 (blue): Panel network
– 3 (green): Building management system, hierarchy panel, voice alarm system
– 4 (red): Remote Services
– 2 signal inputs (IN1/IN2)
– 1 USB function interface for configuration via FSP-5000-RPS
– 1 Memory card interface
Saving and printing messages
The history log keeps incoming alarms and events internally. The history log has a capacity to
store 10000 messages. The messages can be shown on the display, and you can export the
messages. Additionally, you can connect a log printer via a serial interface module for real-time
printing incoming messages.
Installation
Refer to the Installation guide for FPE-8000-SPC | FPE-8000-PPC | FPE-2000-SPC | FPE-2000-
PPC panel controller (F.01U.347.557) available for download at www.boschsecurity.com.

16 en | Product Description Modular fire panel
07.2020 | 12.0 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
Refer to
– MPCPanel Controller, page 89
– MPC, page 148
2.3 Remote keypad
2.3.1 FMR-5000-C Remote keypad
The remote keypad can be used to perform the same operating procedures as the panel itself,
enabling a networked system to be operated decentrally.
Power can be supplied by the panel or an external power supply unit such as the FPP-5000.
The easy-to-install housing was designed for tilted installation and for surface or flush wall
mounting.
2
3
41
Figure2.4: FMR-5000-C Remote Keypad
Position Description
1 Touch screen
2 Membrane keys
3 LEDs for displaying the operating status
4 Key switch
For operating the panel controller and the keypad refer to the user manual (F.01U.258.929)
available for download at www.boschsecurity.com.
2.3.2 FPE-8000-FMR Remote keypad
The remote keypad can be used to perform the same operating procedures as the control
panel, enabling variable operation of a networked system. It has the following functional
elements.

Modular fire panel Product Description | en 17
Bosch Sicherheitssysteme GmbH System Information 07.2020 | 12.0 | F.01U.028.089
A B C
D
E
G F
Pos. Designation Function
A Interfaces Power supply input, panel networking and inputs for internal device monitoring
B Touchscreen Operating the networked system through virtual buttons and variable display
windows
C 6 fixed buttons Standard entries
D Memory card slot Memory card reader for maintenance services
E Power button Shutdown and restart of the device
F Ethernet ports Panel networking and interface to various systems
G 18 LEDs Indicating the operating status
It comes with easy-to-install housing for tilted installation and for surface or flush wall
mounting. Power can be supplied by the panel or an external power supply unit such as the
FPP-5000.
Installation
Refer to the installation guide for the FPE-8000-FMR Remote keypad (F.01U.347.558) available
for download at www.boschsecurity.com.
For operating the panel controller and the keypad refer to the user manual (F.01U.378.877)
available for download at www.boschsecurity.com.
Refer to
– MPCPanel Controller, page 89
– MPC, page 148

18 en | Product Description Modular fire panel
07.2020 | 12.0 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
2.4 Housings for Frame Installation
Figure2.5: Housings for frame installation
Frame installation housings are always used in conjunction with the associated mounting
frame.
The housings are hooked into the mounting frame and can be swiveled to the front for
installation and servicing. The mounting frames are screwed to the wall surface and hold the
pre-cabling.
Alternatively to surface mounting, installation in 482.6mm (19") racks is also possible using
special installation kits.
12V/45Ah batteries can be used in the frame installation housing.
The modular system makes it easy to extend the system.
Housing Designs and Combinations
Two frame installation housings are available as a base unit:
– CPH0006A (for 6 modules) or
– MPH0010A (for 10 modules)
These housings can accommodate a panel controller with an operating and display unit.
The CPH0006A and MPH0010A basic housings can be extended to meet individual
requirements using:
– EPH0012A extension housing for an additional 12 modules, frame installation
– PSF0002A or PMF0004power supply housing for two or four 12V/45Ah batteries
respectively and an additional power supply unit.
– USF0000A Universal Housing Small, Frame Installation.
A power supply bracket for a UPS power supply is fitted ex-works in housing units
CPH0006A, PSF0002A and PMF0004A.
Mounting Frames
All mounting frames have integrated terminal blocks for the mains supply, integrated junction
boards, as well as permanently installed cable ducts to facilitate clear and tidy cable routing.
The mounting frames are available in three sizes:
– FBH0000A Mounting Frame Large
– FMH0000A Mounting Frame Medium
– FSH0000A Mounting Frame Small
The housings for frame installation require the following mounting frames for surface-mounted
version:

Modular fire panel Product Description | en 19
Bosch Sicherheitssysteme GmbH System Information 07.2020 | 12.0 | F.01U.028.089
Housing type Mounting frames
CPH 0006 A FBH0000A
MPH 0010 A FBH0000A
EPH 0012 A FBH0000A
PSF 0002 A FSH 0000 A
PMF 0004 A FMH 0000 A
USF 0000 A FSH 0000 A
Notes:
– All mounting frames have an opening for routing cables that is sealed with an insert. Pre-
punched cable entries can be created from this insert.
– The FBH0000A and FHS0000A mounting frames are equipped with an earth bar ex
works.
– For the FMH0000A, the FPO‑5000‑EB Earth Bar can be ordered as an extension if
required.
– For continuous installation in combination, all mounting frames have T-shaped guide rails
on the base and T-shaped grooves on the top.
Mounting Plate
An HMP0003A Mounting plate can be mounted in large mounting frames FBH0000A and
FHS 0000 A; this mounting plate can be individually equipped. It contains fixing holes for a
distributor rail.
USF 0000 A is fitted with a mounting plate ex works, which can be equipped as required. It
contains fixing holes for two distributor rails.
Equipment Limits
The table below shows the maximum number of:
– Modules
– Panel rails (short PRS-0002-C, long PRD 0004 A)
Housing type Modules Short rails Long rails
CPH 0006 A 6 1 1
MPH 0010 A 10 1 2
EPH 0012 A 12 - 3
PSF 0002 A - - -
PMF 0004 A - - -
USF 0000 A - - -
The table below shows the maximum number of:
– Panel controllers
– UPS power supply units
– Batteries
Housing type Panel controller UPS power
supply units
Batteries
CPH 0006 A 1 1 2x45Ah
MPH 0010 A 1 - -

20 en | Product Description Modular fire panel
07.2020 | 12.0 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
Housing type Panel controller UPS power
supply units
Batteries
EPH 0012 A - - -
PSF 0002 A - 1 2x45Ah
PMF 0004 A - 1 4x45Ah
USF 0000 A - - -
Installation Kits for 48cm (19") racks
Special installation kits are available for installing the frame installation housing in 482.6mm
(19") racks:
Housing type Installation kit, 482.6mm
CPH 0006 A FRB 0019 A
MPH 0010 A FRB 0019 A
EPH 0012 A FRB 0019 A
PSF 0002 A FRB 0019 A
PMF 0004 A FRM 0019 A
USF 0000 A FRS 0019 A
No mounting frame is required when using the 482.6mm installation kits.
Front Doors
The CPH0006A, MPH0010A and EPH0012A housings can be equipped with optional
transparent front doors made of impact-resistant plastic, with a lock on the left or right:
– FDT 0000A Front Door Transparent, lock right side
– FDT 0003A Front Door Transparent, lock left side
Scope of Delivery
Housing type Scope of delivery (each x 1)
CPH 0006 A - Housing, painted sheet steel
- Power supply bracket
- Sheet steel front panel with plastic cover
- Accessories pack with installation material
MPH 0010 A - Housing, painted sheet steel
EPH 0012 A - Housing, painted sheet steel
PSF 0002 A - Housing, painted sheet steel
- Power supply bracket
- Cable set for battery connection
PMF 0004 A - Housing, painted sheet steel
- Power supply bracket
- Cable set for battery connection
USF 0000 A - Housing, painted sheet steel
- Mounting plate
