Bosch GLL 30 Assembly instructions

Operating / Safety Instructions
Consignes d’utilisation / de sécurité
Instrucciones de funcionamiento y seguridad
GLL 30
Professional
GLL 30
IMPORTANT:
Read Before Using
IMPORTANT :
Lire avant usage
IMPORTANTE:
Leer antes de usar
English Version
See page 5 Version française
Voir page 18 Versión en español Ver la página 33
1-877-BOSCH99 (1-877-267-2499) www.boschtools.com

-2-
7
6
5
2
4
3
8
1

-3-
1213
9
11
4
3
10

-4-
A
B
Make sure that
this device
and the tool
are securely
mounted
before
operation.
Assurez-vous
que cet appareil
et l’outil sont
solidement
assujettis avant de
les utiliser.
Asegúrese de que
este dispositivo
y la herramienta
estén montados
de manera segura
antes de su
utilización.
!
WARNING
!
AVERTISSEMENT
!
ADVERTENCIA

-5-
Read all instructions. Failure to follow all
instructions listed below may result in
hazardous radiation exposure, electric shock, fire and/or serious
injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR
FUTURE REFERENCE
The term “tool” in the warnings listed below refers to your mains-
operated (corded) tool or battery-operated (cordless) tool.
The following labels are
on your laser tool for
your convenience and
safety. They indicate where
the laser light is emitted by the tool. ALWAYS BE AWARE of their
location when using the tool.
Do not direct the laser beam at persons or animals
and do not stare into the laser beam yourself. This tool
produces laser class 2 laser radiation and complies
with 21 CFR 1040.10 and 1040.11 except for deviations
pursuant to Laser Notice No. 50, dated June 24, 2007. This can
lead to persons being blinded.
Changes or modifications to this equipment not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
DO NOT remove or deface any warning or caution labels.
Removing labels increases the risk of exposure to laser radiation.
General Safety Rules
!
WARNING

-6-
ALWAYS make sure that any bystanders in the vicinity of use are
made aware of the dangers of looking directly into the laser tool.
DO NOT place the laser tool in a position that may cause anyone
to stare into the laser beam intentionally or unintentionally.
Serious eye injury could result.
ALWAYS position the laser tool securely. Damage to the laser tool
and/or serious injury to the user could result if the laser tool fails.
ALWAYS use only the accessories that are recommended by the
manufacturer of your laser tool. Use of accessories that have been
designed for use with other laser tools could result in serious injury.
DO NOT use this laser tool for any purpose other than those
outlined in this manual. This could result in serious injury.
DO NOT leave the laser tool “ON” unattended in any operating
mode.
DO NOT disassemble the laser tool. There are no user serviceable
parts inside.
DO NOT modify the product in any way. Modifying the laser tool
may result in hazardous laser radiation exposure.
DO NOT use the laser viewing glasses as safety goggles. The
laser viewing glasses are used for improved visualization of the laser
beam, but they do not protect against laser radiation.
DO NOT use the laser viewing glasses as sun glasses or in traffic.
The laser viewing glasses do not afford complete UV protection and
reduce color perception.
DO NOT use any optical tools such as, but not limited to,
telescopes or transits to view the laser beam. Serious eye injury
could result.
DO NOT stare directly at the laser beam or project the laser beam
directly into the eyes of others. Serious eye injury could result.

-7-
Work area safety
Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
DO NOT operate the laser tool around children or allow children
to operate the laser tool. Serious eye injury could result.
Electrical safety
Batteries can explode or leak, cause injury or fire. To reduce this
risk, always follow all instructions and warnings on the battery label and
package.
DO NOT short any battery terminals.
DO NOT charge alkaline batteries.
DO NOT mix old and new batteries.
Replace all of them at the same time with new batteries of the
same brand and type.
DO NOT mix battery chemistries. Dispose of or recycle batteries
per local code.
DO NOT dispose of batteries in fire.
Keep batteries out of reach of children.
Remove batteries if the device will not be used for several
months.
Personal safety
Stay alert, watch what you are doing and use common sense
when operating a tool. Do not use a tool while you are tired or
under the influence of drugs, alcohol or medication. A moment of
inattention while operating a tool may result in serious personal injury
or incorrect measurement results.

-8-
Use safety equipment. Always wear eye protection. Safety
equipment such as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions will reduce personal
injuries.
Use and care
Use the correct tool for your application. The correct tool will do the
job better and safer.
Do not use the tool if the switch does not turn it on and off. Any
tool that cannot be controlled with the switch is dangerous and must be
repaired.
Store idle tool out of the reach of children and do not allow
persons unfamiliar with the tool or these instructions to operate
the tool. Tools are dangerous in the hands of untrained users.
Maintain tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may
affect the operation. If damaged, tool repaired before use. Many
accidents are caused by poorly maintained tools.
Use the tool, accessories, etc., in accordance with these
instructions and in the manner intended for the particular type
of tool, taking into account the working conditions and the work
to be performed. Use of the tool for operations different from those
intended could result in a hazardous situation.
Service
Have your tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the
tool is maintained.
Develop a periodic maintenance schedule for tool. When cleaning
a tool be careful not to disassemble any portion of the tool since

-9-
internal wires may be misplaced or pinched or may be improperly
mounted. Certain cleaning agents such as gasoline, carbon
tetrachloride, ammonia, etc. may damage plastic parts.
SAVE THESE INSTRUCTIONS.
Preparation
Inserting/Replacing the Battery
Use only alkaline batteries.
To open the battery lid 4, press the latch of the battery lid 3and fold the
battery lid up. Insert the supplied batteries.
When inserting, pay attention to the correct polarity according to the
representation on the inside of the battery compartment.
When the batteries are low, the laser beams flash 0.10 s off, 0.20 s on,
0.10 s off, 1.0 s on in a cycle.
Always replace all batteries at the same time. Only use batteries from
one brand and with the identical capacity.
Remove the batteries from the tool when not
using it for extended periods. When storing for
extended periods, the batteries can corrode and discharge themselves.
The tool is intended for determining and checking horizontal and
vertical lines. The measuring tool is suitable exclusively for operation in
enclosed working sites.
Intended Use
!
WARNING

-10-
The numbering of the product features shown refers to the illustration
of the tool on the graphic page.
1Laser beam outlet
2On/Off switch
3Latch of battery lid
4Battery lid
51/4”-20 screw of flexible mounting device
6Locking screw of flexible mounting device
7Fastening screw of flexible mounting device
8Flexible mounting device
9Tripod mount 1/4”-20
10 Laser warning label
11 Serial number
12 Tripod*
13 Laser viewing glasses*
*not included.
Features
