English | 3
English
Safety Notes
Explanation of symbols
General hazard safety alert.
Never direct the water jet at
people, animals, the machine
or electric components.
Warning: High pressure jets can be
dangerous if subject to misuse.
According to the applicable
regulations, the appliance
must never be used on the
drinking water network without a
system separator. Use a separator
as per IEC61770 Type BA.
Water flowing though a system sep-
arator is considered not drinkable.
≥100 A
The AdvancedAquatak 150/
AdvancedAquatak 160 is in-
tended for use only in
premises having a service current ca-
pacity ≥100A per phase, supplied
from a distribution network having a
nominal voltage of 230V. If in doubt
please contact your Supply Authority.
Safety Notes for pressure washer
Read all safety warnings
and all instructions. Failure
to follow the safety warnings
and instructions may result in electric
shock, fire and/or serious injury.
The warning and information signs
attached to the unit provide import-
ant information for safe operation.
Apart from the information in the
operating instructions comply with
the general safety regulations and
regulations for the prevention of ac-
cidents.
Connecting to the mains
uThe voltage of the power source
must correspond with the data on
the type plate of the product.
uWe recommend that this product is
only connected into a socket which
is protected by a circuit-breaker that
would be actuated by a 30mA resid-
ual current.
uThe circuit breaker supplying mains
power to the high-pressure washer
should have no less than a C16 rat-
ing. If in doubt consult a qualified
electrician for further advice. Do not
attempt to modify your electrical
system yourself.
uRemove the plug from socket
whenever the machine is left unat-
tended for any period.
uThe electric supply installation
should comply with IEC60364-1.
uIf the supply cord is damaged, it
must be replaced by the manufac-
turer, its service agent or similarly
qualified persons in order to avoid a
hazard.
uIf the plug is damaged, pay attention
to the following:
Bosch Power Tools F 016 L81 292 | (04.03.2019)

4 | English
uPlugs and sockets situated near the
work site or outdoors should be to
class IP 55 of BS 5490 to provide
adequate protection against ingress
of water, etc. and cable entries re-
quire effective sealing. Rubber
shrouds should be provided over
cable glands. Drip-proof (class IP X2
of BS 5490) plugs and sockets to BS
4343 are suitable for use indoors
where the plug is away from the wa-
ter spray area where the appliance is
in use.
uNever touch the mains plug with wet
hands.
uDo not pull plug while operating the
device.
uDo not run over, crush or pull the
power supply cord or extension
cord, otherwise it may be damaged.
Protect the cable from heat, oil and
sharp edges.
uDo not use the unit, if the power sup-
ply cord or important parts, e.g.
high-pressure hose, power gun or
safety devices are damaged.
uWarning: Inadequate extension
cables can be dangerous.
uIf an extension cord is used, the plug
and socket must be of watertight
construction. The extension cord
must have a cross section in accord-
ance with the operating instructions
and be protected against splashed
water. The connection must not be in
water.
uWhen replacing plugs on the power
supply cable or extension lead the
spray water guard and mechanical
stability must remain intact.
Water connection
uComply with the regulations of your
water supply company.
uAll connecting hoses must have
properly sealed joints.
uMake sure that the supply hose is at
least 12.7mm (1/2") in diameter
and is reinforced.
uThe appliance should never be used
on the drinking water supply without
a back flow valve. Water which has
passed the back flow valve is re-
garded as undrinkable.
uThe high-pressure hose must not be
damaged (danger of bursting). A
damaged high-pressure hose must
be replaced immediately. Only use
hoses and connections recommen-
ded by the manufacturer.
uHigh-pressure hoses, fittings and
couplings are important for the
safety of the appliance. Use only
hoses, fittings and couplings recom-
mended by the manufacturer.
uOnly clean or filtered water should
be used for intake.
Application
uBefore use, check that the machine
and operating equipment are in per-
fect condition and are safe to oper-
ate. Do not use if it is not in perfect
condition.
F 016 L81 292 | (04.03.2019) Bosch Power Tools

English | 5
uDo not direct the jet against yourself
or others in order to clean clothes or
footwear.
uDo not use solvent-containing li-
quids, undiluted acids, acetone or
solvents, including petrol, paint thin-
ners, heating oil. The sprayed va-
pours are highly flammable, explos-
ive and toxic.
uThe appropriate safety regulations
must be observed when using the
unit in dangerous areas (e.g. petrol
stations). It is forbidden to operate
the unit in potentially explosive loca-
tions.
uThe unit must be placed on a solid
base.
uTake care if using the machine in a
confined space ensuring that there is
adequate ventilation. Ensure that all
vehicles are switched off at all times
whilst cleaning.
uOperation of this machine requires
both hands to be used at all times.
Do not operate from a ladder. Take
care when using the machine on bal-
conies or other raised areas ensuring
that you can see any edges at all
times.
uOnly use detergents recommended
by the manufacturer. Comply with
the application, disposal and warn-
ing instructions of the detergent
manufacturers.
uThe use of other cleaning agents or
chemicals may adversely affect the
safety of the machine.
uAll current-conducting components
in the work area must be protected
against splashed water.
uThe gun trigger must not be jammed
in position “ON” during operation.
uDuring use of high pressure clean-
ers, aerosols may be formed. Inhal-
ation of aerosols can be hazardous to
health.
uShielded nozzles can reduce the aer-
osol effect. If necessary wear per-
sonal protective equipment (PPE)
e.g. safety goggles, breathing pro-
tection etc to protect against water,
particles and/or aerosols sprayed
back from parts.
uHigh pressure may cause objects to
rebound. If necessary wear suitable
personnel protective equipment
such as safety goggles.
uVehicle tyres/tyre valves may only be
cleaned from a minimum distance of
30cm in order to avoid damages by
the high-pressure jet. The first indic-
ation of damage is the discolouration
of the tyre. Damaged vehicle tyres/
tyre valves are dangerous to life.
uMaterials containing asbestos and
other materials which contain sub-
stances which are hazardous to your
health must not be sprayed.
uDetergents must not be used undi-
luted. The products are safe to use
as they contain no acids, alkalis or
substances which are detrimental to
the environment. We recommend
that the detergents are kept out of
Bosch Power Tools F 016 L81 292 | (04.03.2019)

6 | English
the reach of children. If detergent
comes into contact with the eyes,
wash immediately with plenty of wa-
ter and if swallowed contact a doctor
immediately.
uNever use the pressure washer
without the filter or with a dirty or
damaged filter. Using the pressure
washer without a filter or with a dirty
or damaged filter may invalidate the
warranty.
uMetal parts may become hot after
prolonged usage. If necessary wear
protective gloves.
uAvoid high pressure washing in bad
weather conditions especially when
there is a risk of lightning.
uWear suitable protective clothing to
protect against splash water. Do not
use the appliance within the range of
persons, unless they wear protective
clothing.
Operation
uThe operator must use the product in
accordance with the regulations. The
local conditions must be taken into
account. When working, pay atten-
tion to other people, especially to
children.
uThe unit may only be used by author-
ised persons who have received
training or have demonstrated their
ability to operate the unit. The unit
must not be operated by children or
juveniles (danger of accidents due to
incorrect use of the unit).
uNever allow children, persons with
physical, sensory or mental limita-
tions or a lack of experience and/or
knowledge and/or people unfamiliar
with these instructions to use the
product. Local regulations may re-
strict the age of the operator.
uChildren should be supervised to en-
sure that they do not play with the
product.
uThe unit must never be left unsuper-
vised while the unit is switched on.
uThe water jet from the high-pressure
nozzle produces a recoil on the gun.
You should therefore hold the gun
and spray lance firmly with both
hands.
uNever use a roto nozzle or pencil jet
to clean motor vehicles.
Transport
uSwitch off the motor and secure the
unit before transporting.
Maintenance
uSwitch off the unit prior to all clean-
ing and maintenance work and be-
fore replacing components. Pull out
the mains plug if the unit is mains-
operated.
uRepairs may only be carried out by
authorised Bosch Service Centres.
Accessories and spare parts
uAccessories and spare parts which
have been approved by Bosch must
be used. Original accessories and
spare parts guarantee that the ma-
F 016 L81 292 | (04.03.2019) Bosch Power Tools

English | 7
chine can be operated safely and
without any breakdowns.
Symbols
The following symbols are important for reading and under-
standing the original instructions. Please take note of the
symbols and their meaning. The correct interpretation of the
symbols will help you to use the product in a better and safer
manner.
Symbol Meaning
Movement direction
Reaction direction
Weight
Symbol Meaning
On
Off
Lo Low pressure
Hi High pressure
Accessories
Intended Use
The product is intended for cleaning areas and objects out-
side the house, tools, vehicles and boats, if the appropriate
accessories and cleaning agents approved by Bosch are
used.
The intended use is related to operation within 0°C and
40°C ambient temperature.
This product should not be used for professional use.
Technical Data
Pressure washer AdvancedAquatak 150 AdvancedAquatak 160
Article number 3 600 HA7 7.. 3 600 HA7 8..
Rated power kW 2.2 2.6
Supply temperature max. °C 40 40
Supply rate min. l/min 8 9.5
Allowable pressure MPa 15 16
Rated pressure MPa 11 12
Rated Flow l/min 7.5 8.5
Maximum inlet pressure MPa 1 1
Autostop Function ● ●
Weight according to EPTA‑Procedure 01:2014 kg 21.1 23.4
Protection class / I / I
Serial number See serial number (rating plate) on pressure washer.
The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-
specific models.
Starting cycles generate brief voltage drops. Interference with other equipment/machines may occur in case of unfavourable
mains system conditions. Malfunctions are not to be expected for system impedances below 0.276ohm. If in doubt please
contact your Supply Authority.
Mounting and Operation
Action Figure Page
Delivery scope A 63
Adjusting the Handle B 64
Connecting high pressure wa-
ter supply hose/nozzle
C 64
Connecting to the water supply D 65
Switching On and Off E – F 65
Action Figure Page
Clean the water filter G 66
Clean nozzle H 66
Connecting high pressure gun
to lance
I 66
Tube Assembly J 67
Connect detergent bottle K 67
Variable Fan lance
Connecting high pressure gun
L 68
Bosch Power Tools F 016 L81 292 | (04.03.2019)

8 | English
Action Figure Page
to lance
Adjust water jet
Roto lance
Connecting high pressure gun
to lance
Adjust water jet
M 69
Gun storage N 70
Storage O 70
Transport P 71
Selecting Accessories Q 72
Switching on
For Your Safety
Warning: Switch off, remove plug from
mains before adjusting, cleaning or if cable
is cut, damaged or entangled.
The operating voltage is 230VAC, 50Hz (for non-EU coun-
tries 220V, 240V as applicable). Contact your Bosch Ser-
vice Centre for details. If in doubt contact a qualified electri-
cian or the nearest Bosch Service Centre.
If you want to use an extension cable when operating your
high pressure washer, only the following cable dimensions
should be used:
– 2.5mm2 – max length 25m
Note: If an extension cable is used it must be earthed and
connected through the plug to the earth cable of your supply
network in accordance with prescribed safety regulations.
If in doubt contact a qualified electrician or the nearest
Bosch Service Centre.
WARNING! Inadequate extension cables can
be dangerous. Extension cable, plug and
socket must be of watertight construction
and intended for outdoor use.
The connections (plugs and sockets) should be kept dry and
off the ground.
For increased electrical safety use a Residual Current Device
(RCD) with a tripping current of not more than 30mA. Al-
ways check your RCD every time you use it.
If the supply cord is damaged, it must be replaced by a
Bosch Service Centre.
For products not sold in GB:
Warning: For your safety, it is required that the plug at-
tached to the product is connected with the extension cord.
The coupling of the extension cord must be protected
against splash water, be made of rubber or coated with rub-
ber. The extension cord must be used with a cable strain re-
lief.
Products sold in GB only:
Your product is fitted with an BS 1363/A approved electric
plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an au-
thorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
uProducts that are only sold in AUS and NZ: Use a resid-
ual current device (RCD) with a nominal residual current
of 30 mA or less.
Operation
uTo prevent damage to the appliance, do not allow it to
operate dry.
Starting
Attach water supply hose (not supplied) to the mains water
supply and machine.
Connect the product to the mains supply ensuring that the
mains switch is in the off position.
Open water tap.
Press the safety lock (back button on the gun handle) to re-
lease the trigger. Fully press the trigger until there is a con-
stant flow of water to clear the air from the machine and wa-
ter supply hose. Release trigger. Press the safety lock (front
button on the gun handle).
Turn button on main switch. Point the power gun down-
wards. Press the trigger safety lock to release the trigger.
Fully press the trigger.
Autostop Function
The machine is designed to switch off the motor when the
trigger is released on the gun.
Working Advice
General
uNever use a roto nozzle or pencil jet to clean motor
vehicles.
Ensure that the pressure washer is on level ground.
Do not overreach with the high pressure hose or move the
pressure washer by pulling the hose, this could cause the
ma-chine to become unstable and fall over.
Do not kink or drive a motor vehicle over the high pressure
hose. Do not expose the high pressure hose to sharp edges
or corners.
Working advice for cleaning with detergents
uOnly use cleaning agents suitable specifically for high
pressure washers.
We recommend that you use detergent sparingly for the sake
of the environment. Observe the recommended dilution on
the detergent label.
Recommended cleaning method
Step 1: Attach the fan nozzle and remove the heavy dirt.
F 016 L81 292 | (04.03.2019) Bosch Power Tools

English | 9
Step 2: Attach the foam bottle and spray on the detergent
sparingly.
Step 3: Rinse off the loosened dirt and detergent with the
fan nozzle.
Note: When cleaning a vertical surface spray off dirt/deter-
gent from the bottom and work in an upwards direction.
Rinse from the top and work downwards.
Use with alternative water sources
This high-pressure washer will self prime and can draw water
from water tanks and natural water sources. It is IMPORT-
ANT that the water is clean and the BOSCH inlet filter is clear
and fitted to the machine.
Open tanks/containers and natural water
sources
Use the Self Priming accessory kit comprising:
– Inlet strainer with non return valve
– 3m reinforced supply hose
– Universal coupling to the pressure washer
This enables the pressure washer to draw water up to 0.5m
above the water level in the source. This may take up to 15
seconds.
Submerge the 3m hose in water to displace the air. Connect
the 3m supply hose to the pressure washer ensuring that
the inlet strainer remains submerged in the water source.
Run the pressure washer with the lance disconnected until a
steady flow of water appears from the high pressure hose.
Stop if this has not been achieved within 25 seconds and
check all the connections. Switch off and connect the lance
and nozzle to operate.
It is important to ensure that all hose and coupling connec-
tions are of good quality, air tight and that all washers are in
good condition and correctly seated in place. Failure to do
so may affect the self priming performance.
Water Tanks with outlet connections
When connecting the pressure washer to a water tank with a
suitable tap outlet, first connect the supply hose (not
provided) to the tank outlet, open the tap to allow the water
to displace all the air in the hose and then connect to the
pressure washer.
Troubleshooting
Problem Possible Cause Corrective Action
Motor refuses to start Plug not connected Connect plug
Mains socket faulty Use another socket
Fuse faulty / blown Replace fuse
Extension cable damaged Try without extension cable
Motor protector has activated Allow to cool for 15 minutes
Frozen Wait for pump/water supply hose/accessory to
thaw
Motor stops Fuse faulty / blown Replace fuse
Wrong mains voltage Check that mains voltage corresponds to specific-
ations on the model tag
Motor protector has activated Allow to cool for 15 minutes
Fuses blow Fuses incorrectly rated Change to a mains supply higher than the pres-
sure washer amp consumption
Motor starts but no
pressure
Nozzle partly blocked Clean nozzle
Motor “sounds” but
fails to start
Insufficient power supply Check that the voltage of the mains power supply
line is the same as that on the plate.
Voltage loss due to use of extension cable Check characteristics of extension cable
Appliance not used for a long period of time Contact your Bosch Service Centre
Problems with TSS (Total Stop System) device Contact your Bosch Service Centre
Pressure pulsating Air in the inlet water supply hose/pump Allow pressure washer to run with open spray
handle and nozzle at low pressure until regular
working pressure is obtained
Inadequate water supply Check that the water supply corresponds to spe-
cifications. The minimum specification for the wa-
ter supply hose is 1/2" or 13mm diameter
Bosch Power Tools F 016 L81 292 | (04.03.2019)

10 | English
Problem Possible Cause Corrective Action
Water filter blocked Clean water filter
Water supply hoses squeezed Straighten out kinked water supply hoses
High pressure hose too long Remove high pressure extension hose. Retry (ex-
tension hose max. 7m)
Pressure too low, but
steady
Note: Several types of
accessory will normally
deliver a lower pres-
sure
Nozzle worn Change the nozzle
Start/stop valve worn Activate trigger five times in quick succession
Motor starts up but
with restricted or no
working pressure
No water supply Connect water supply
Water filter clogged up Clean the water filter
Nozzle clogged up Clean nozzle
The pressure washer
starts irregularly by it-
self
Pump/ power gun leaky Contact your Bosch Service Centre
Water leaks from ma-
chine
Leaking pump A slight water leak is permissible; in case of ex-
cessive leak, contact Bosch Service Centre.
Maintenance and Service
Maintenance
uStop, remove plug from the power supply and discon-
nect from water supply.
Note: To ensure long and reliable service, carry out the fol-
lowing maintenance regularly.
Regularly check for obvious defects such as loose fixings,
and worn or damaged components.
Check that covers and guards are undamaged and correctly
fitted. Carry out necessary maintenance or repairs before
using.
In order to avoid safety hazards, if the power supply cord
needs to be replaced, this must be done by Bosch or by an
after-sales service centre that is authorised to repair Bosch
power tools.
After use/Storage
Turn the main switch off and operate the trigger to drain the
water from the high pressure hose.
Clean the exterior of the machine thoroughly using a soft
brush or cloth. Do not use water, solvents or polishes. Re-
move all debris, especially from the ventilation slots.
End of season storage: Drain water out of pump running mo-
tor for a few seconds. Pull trigger to release all water.
Do not place other objects on top of the machine.
Store in a frost-free area.
Ensure cables are not trapped when storing. Do not kink high
pressure hose.
After-sales Service and Application
service
www.bosch-do-it.com
In all correspondence and spare parts orders, please always
include the 10‑digit article number given on the nameplate
of the product.
Cambodia
Robert Bosch (Cambodia) Co., Ltd
Unit 8BC, GT Tower, 08th Floor, Street 169,
Czechoslovakia Blvd, Sangkat Veal Vong
Khan 7 Makara, Phnom Penh
VAT TIN: 100 169 511
Tel.: [phone]
Tel.: [phone]
www.bosch.com.kh
People’s Republic of China
China Mainland
Bosch Power Tool (China) Co. Ltd.
Bosch Service Center
567, Bin Kang Road
Bin Kang District
Hangzhou, Zhejiang Province
China 310052
Tel.: [phone] / 5588
Fax: [phone] x 5566# / 5588#
E-mail: [email protected]
www.bosch-pt.com.cn
HK and Macau Special Administrative Regions
Robert Bosch Co. Ltd.
21st Floor, 625 King’s Road
North Point, Hong Kong
Customer Service Hotline: [phone]
Fax: [phone]
F 016 L81 292 | (04.03.2019) Bosch Power Tools

English | 11
E-mail: [email protected]
www.bosch-pt.com.hk
India
Bosch Service Center
69, Habibullah Road, (next to PSBB School), T. Nagar
Chennai–600077
Phone: [phone]
Bosch Service Center Rishyamook
85A, Panchkuin Road
New Delhi–110001
Phone: [phone]
Bosch Service Center 79,
Crystal Bldg., Dr. Annie Besant Road, Worli
Mumbai–400018
Phone: [phone] /
[phone] / [phone]
Indonesia
PT Robert Bosch
Palma Tower 10th Floor
Jalan RA Kartini II-S Kaveling 6
Pondok Pinang, Kebayoran Lama
Jakarta Selatan 12310
Tel.: [phone]
www.bosch-pt.co.id
Malaysia
Robert Bosch Sdn. Bhd.(220975-V) PT/SMY
No. 8A, Jalan 13/6
46200 Petaling Jaya
Selangor
Tel.: [phone]
Toll-Free: 1800 880188
Fax: [phone]
E-mail: [email protected]
www.bosch-pt.com.my
Pakistan
Robert Bosch Middle East FZE – Pakistan Liaison Office
2nd Floor Plaza # 10, CCA Block, DHA Phase 5
Lahore, 54810
Phone: [phone]
E-mail: [email protected]
Philippines
Robert Bosch, Inc.
28th Floor Fort Legend Towers,
3rd Avenue corner 31st Street,
Fort Bonifacio, Global City,
1634 Taguig City
Tel.: [phone]
Fax: [phone]
www.bosch-pt.com.ph
Singapore
Powerwell Service Centre Ptd Ltd
Bosch Authorised Service Centre (Power Tools)
4012 Ang Mo Kio Ave 10, #01-02 TECHplace
Singapore 569628
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
www.powerwellsc.com
www.bosch-pt.com.sg
Thailand
Robert Bosch Ltd.
Liberty Square Building
No. 287, 11 Floor
Silom Road, Bangrak
Bangkok 10500
Tel.: [phone]
Fax: [phone]
Robert Bosch Ltd., P. O. Box 2054
Bangkok 10501
www.bosch.co.th
Bosch Service – Training Centre
La Salle Tower Ground Floor Unit No.2
10/11 La Salle Moo 16
Srinakharin Road
Bangkaew, Bang Plee
Samutprakarn 10540
Tel.: [phone]
Fax: [phone]
Vietnam
Branch of Bosch Vietnam Co., Ltd in HCMC
14th floor, Deutsches Haus, 33 Le Duan
Ben Nghe Ward, District 1, Ho Chi Minh City
Tel.: [phone]
Fax: [phone]
Hotline: [phone]
E-mail: [email protected]
www.bosch-pt.com.vn
Armenia, Azerbaijan, Georgia, Kyrgyzstan, Mongolia,
Tajikistan, Turkmenistan, Uzbekistan
TOO "Robert Bosch" Power Tools, After Sales Service
Rayimbek Ave., 169/1
050050, Almaty, Kazakhstan
Service e-mail: [email protected]
Official website: www.bosch.com, www.bosch-pt.com
Bahrain
Hatem Al Juffali Technical Equipment Establishment.
Kingdom of Bahrain, Setra Highway, Al Aker Area
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Egypt
RBEG-LLC
22 Kamal Eldin Hussein
Sheraton Heliopolis
11799 Cairo
E-mail: [email protected]
Iran
Robert Bosch Iran
3rd Floor, No 3, Maadiran Building
Aftab St., Khodami St., Vanak Sq.
Tehran 1994834571
Phone: [phone]
Iraq
Bosch Power Tools F 016 L81 292 | (04.03.2019)

12 | English
Sahba Technology Group
Al Muthana airport road
Baghdad
Phone: [phone]
Phone Dubai: [phone]
E-mail: [email protected]
Jordan
Roots Arabia – Jordan
Nasser Bin Jameel street, Building 37 Al Rabiah
11194 Amman
Phone: [phone]
E-mail: [email protected]
Kuwait
Al Qurain Automotive Trading Company
Shuwaikh Industrial Area, Block 1, Plot 16, Street 3rd
P.O. Box 164 – Safat 13002
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Lebanon
Tehini Hana & Co. S.A.R.L.
P.O. Box 90-449
Jdeideh
Dora-Beirut
Phone: [phone]
E-mail: [email protected]
Libya
El Naser for Workshop Tools
Swanee Road, Alfalah Area
Tripoli
Phone: [phone]
Oman
Malatan Trading & Contracting LLC
P.O. Box 131
Ruwi, 112 Sultanate of Oman
Phone: [phone]
E-mail: [email protected]
Qatar
International Construction Solutions W L L
P. O. Box 51,
Doha Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Saudi Arabia
Juffali Technical Equipment Co. (JTECO)
Kilo 14, Madinah Road, Al Bawadi District
Jeddah 21431
Phone: [phone] Ext. 1528
Fax: [phone]
E-mail: [email protected]
Syria
Dallal Establishment for Power Tools
P.O. Box 1030
Aleppo
Phone: [phone]
E-mail: [email protected]
United Arab Emirates
Central Motors & Equipment LLC, P.O. Box 1984
Al-Wahda Street – Old Sana Building
Sharjah
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Yemen
Abualrejal Trading Corporation
Sana’a Zubiery St. Front to new Parliament Building
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Ethiopia
Forever plc
Kebele 2,754, BP 4806,
Addis Ababa
Phone: [phone]
E-mail: [email protected]
Ghana
Peew-Williams Services Company Ltd
Mile 7, Plot 331, Before Achimota Mall.
Accra
Tel. +233552352511
E-mail: [email protected]
Kenya
Robert Bosch East Africa Ltd
Mpaka Road P.O. Box 856
00606 Nairobi
Nigeria
Robert Bosch Nigeria Ltd.
52–54 Isaac John Street P.O. Box
GRA Ikeja – Lagos
Republic of South Africa
Customer service
Hotline: [phone]
Gauteng – BSC Service Centre
35 Roper Street, New Centre
Johannesburg
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
KZN – BSC Service Centre
Unit E, Almar Centre
143 Crompton Street
Pinetown
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
Western Cape – BSC Service Centre
Democracy Way, Prosperity Park
Milnerton
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
Bosch Headquarters
Midrand, Gauteng
F 016 L81 292 | (04.03.2019) Bosch Power Tools

中文 | 13
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
Tanzania
Diesel & Autoelectric Service Ltd.
117 Nyerere Rd., P.O. Box 70839
Vingunguti 12109, Dar Es Salaam
Phone: [phone]
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: [phone]
Fax: [phone]
Inside New Zealand:
Phone: [phone]
Fax: [phone]
Outside AU and NZ:
Phone: [phone]
www.bosch-pt.com.au
www.bosch-pt.co.nz
Environmental Protection
Chemicals dangerous to the environment must not be al-
lowed to enter the ground, ground water or ponds, streams,
etc.
For the use of cleaning agents, observe the instructions on
the package and the prescribed concentration exactly.
For the cleaning of motor vehicles the local regulations
should be observed: Do not allow oil sprayed off to enter into
the ground water. Recycle raw materials instead of waste
disposal.
Disposal
The product, accessories and packaging should be sorted
for environmental-friendly recycling.
Do not dispose of products into household
waste!
中文
安全规章
图标说明
一般性警告。
不可以把喷射出的水流朝
向人、动物、机器或电动
零件。
注意：如果使用不当，高压水柱
可能造成危险。
根据适用的法规，如果机
器不具备系统分离功能，
便不可以连接到饮用水的
供应系统上。根据IEC61770 ，
得使用 BA 型的系统分离器。
流过系统分离器的水，已经不再
是饮用水。
≥100 A
AdvancedAquatak
150/AdvancedAquatak
160适合电源为：每相线
电流 ≥100A，电压 230V。如有
供电方面的疑问，请联系您当地
的电力公司。
高压清洁机的安全规章
阅读所有警告和所有说
明!不遵照以下警告和说
明会导致电击、着火和／
或严重伤害。
机器上的警告和提示牌提供了重
要的讯息，能够确保操作安全。
除了遵循使用说明书上的指示之
外，还必须兼顾一般性的安全规
章和意外防范规定。
Bosch Power Tools F 016 L81 292 | (04.03.2019)

14 | 中文
用电须知
u电源电压必须和产品铭牌上指
定的电压一致。
u建议只将产品插在配有 30mA
剩余电流保护开关的插座上。
u供电电源的保护开关设计, 至少
要具备C特性并能够负担16 A的
电流。如有疑问，请询问合格
的电工。不要试图擅自改变电
气装置。
u即使您只是暂时离开机器，也
要从插座上拔出插头。
u电源的电压必须符合 IEC
60364-1 的要求。
u如果需要更换电线，得由机器
的制造商、经过制造商授权的
客服中心或合格的专业人员执
行此工作，以避免危害安全。
u不可以使用潮湿的手拿电线。
u操作机器时不要拉扯插头。
u不可以辗过、压过电线或延长
线，也不可以拉扯它们。电线
必须远离高温、油垢和锋利的
边缘。
u如果电线或重要的零件，例如
高压软管、喷射枪或安全装备
等损坏了，便不可以使用机
器。
u注意：不符合规定的延长线可
能造成危险。
u使用延长线时，它的插头和连
接装备都必须是防水的。延长
线横截面的尺寸必须符合使用
说明书上的规定，延长线也要
具备防水花的功能。插头不可
以浸泡在水中。
u更换电线或延长线的插头时，
不可以破坏电线或延长线的防
水安全性能和稳定性。
用水须知
u请注意贵国供水单位的规定。
u所有水管的接头都不可以漏
水。
u只能使用直径 12.7 毫米
（1/2"）的增强软管。
u把机器连接在饮用水源上时，
务必在机器上安装逆流阀。通
过逆流阀的水则不适合饮用。
u高压软管不能受损（有爆裂的
危险）。高压软管如果损坏了
必须马上更换。只能使用制造
商推荐的水管和连接件。
u高压软管，节流装备和连接装
备都攸关机器的安全性能。只
能使用机器制造厂商推荐的软
管，放流开关和联结装备。
u水源接头只能连接干净或经过
过滤的水。
使用须知
u正式操作之前，先检查机器和
附件是否一切正常，是否会危
害操作安全。如果发现任何故
障则不可以使用机器。
u不可以使用水流清洗自己的或
别人的衣服、鞋子。
u不可以吸汲含有溶解剂的液
体、未稀释的酸性液体、丙酮
或溶解剂， 例如汽油、颜料稀
释剂或柴油等。因为它们的喷
雾极度易燃，容易爆炸并且有
毒。
F 016 L81 292 | (04.03.2019) Bosch Power Tools

中文 | 15
u在危险的场所（例如加油站）
使用本机器，务必遵守有关的
安全规定。不可以在有爆炸危
险的场所使用本机器。
u本机器需要稳固的放置面。
u在密闭的空间使用本机器时要
确保通风良好。确定清洁过程
中车辆处于熄火状态（已经关
闭马达）。
u必须用双手操控高压清洁机。
不可以在梯子上使用本机器。
当在阳台或其他凸起的表面工
作时，要确保随时能看到所有
的场地边缘。
u只能使用机器制造商推荐的清
洁剂。确实遵循机器制造商提
出的使用说明、废弃处理建议
和警告提示。
u使用其它清洁剂或化学剂可能
会影响机器的安全性。
u工作区域内的所有带电部件, 必
须能够防范飞溅的水花。
u操作机器时，不可以让喷射枪
上的启动开关，卡牢在 “ON”
的位置。
u使用高压清洁机时可能产生气
溶胶。吸入气溶胶会危害健
康。
u屏蔽了的喷嘴可以减少气溶胶
效应。必要时得穿上合适的防
护装备(PSA)来防护喷溅的水
花，例如佩戴护目镜、防尘面
具等来防护从物体上反弹的
水、颗粒和/或气溶胶。
u高压可能造成物体回弹。必要
时，得穿上合适的个人防护装
备，例如护目镜。
u为了避免高压水流造成伤害，
清洁汽车轮胎/阀门时 至少要保
持 30 公分的距离。这一点的第
一个迹象就是轮胎变色。受损
的轮胎/阀门都可能造成生命危
险。
u不可以喷洗含石棉和其它含有
毒素的物体。
u经推荐的清洁剂必须先稀释了
再使用。目前为止这些产品都
是安全的，因为它们不含酸、
碱或 其它有害环境的物质。我
们建议您，将清洁剂放在儿童
接触不到的地方。万一眼睛接
触到清洁剂，立即用清水彻底
冲洗眼睛，如果误食了清洁剂
请即刻就医。
u使用高压清洁机时务必安装滤
网，勿使用肮脏或已经损坏的
滤网。如果使用高压清洁机时
未安装滤网，或是用了肮脏、
已经损坏的滤网，将导致保修
失效。
u长时间使用后，金属零件可能
变烫。如果必要的话得戴上防
护手套。
u不要在恶劣的天气条件下特别
是在雷雨来临时，操作高压清
洁机。
u穿着能够防水花的合适防护
衣。在水流的喷射范围内如果
有旁人则不可以使用机器，除
非他穿著了防护衣。
操作须知
u操作者务必按照规定使用机
器。要注意操作现场的实际状
Bosch Power Tools F 016 L81 292 | (04.03.2019)

16 | 中文
况。使用本产品时务必顾及到
旁人，尤其是儿童。
u本机器只能由经过使用和操作
指导的人员，或可以证明能够
操作本机器的人使用。儿童或
青少年不可以使用本机器。
u不允许儿童、生理丶感官或心
理受限的人员、经验不足和/或
对本产品了解不足和/或不熟悉
本使用说明书的人员操作本产
品。您本国的法规可能也会对
使用者的年龄有所限制。
u请看管好小孩，以确保他们不
会玩耍本产品。
u开动机器后，绝对不可以弃机
器于不顾。
u从高压喷嘴射出来的水柱会产
生反冲。因此要用双手握牢喷
射枪和枪体。
u不可以使用旋转喷头和线状水
柱清洗车辆。
搬运须知
u搬运之前必须先关闭机器并固
定好机器。
维修
u清洁，维修机器和更换附件之
前，都要先关闭机器。如果机
器连接在插座上则要拔出插
头。
u维修的工作只能交给博世授权
的维修工厂执行。
附件和备件
u只能使用制造厂商规定的附件
和备件。使用原厂的附件和原
厂的备件才能够确保机器的正
常功能。
代表符号
以下符号可以帮助您阅读和了解本使用说明书。请
牢记各符号和它们的代表意思。正确瞭解各符号的
含义，可帮助您更有把握更安全地操作本产品。
符号 含义
移动方向
反应方向
重量
开启
关闭
Lo 较低的压力
Hi 较高的压力
附件
正确地使用机器
本机器可以清洗户外的表面和物体，安装了合适的
附件及经过博世认可的清洁剂后，也能够使用本工
具清洗机器，车辆和船。
合适的操作环境温度位在摄氏 0度和 40度之间。
本产品不适合从事工业用途。
技术数据
高压清洁机 AdvancedAquatak 150 AdvancedAquatak 160
产品号 3 600 HA7 7.. 3 600 HA7 8..
额定输入功率 千瓦 2.2 2.6
进口温度最大 °C 40 40
进口水流最小 公升/每
分8 9.5
F 016 L81 292 | (04.03.2019) Bosch Power Tools

中文 | 17
高压清洁机 AdvancedAquatak 150 AdvancedAquatak 160
许可压力 兆帕 15 16
额定压力 兆帕 11 12
流量 公升/每
分7.5 8.5
最大进口压力 兆帕 1 1
自动关机功能 ● ●
重量符合 EPTA-Procedure 01:2014 kg 21.1 23.4
保护等级 / I / I
序列号 请参见高压清洁机上的序列号（铭牌）
所有参数适用于230伏的额定电压[U]，对于其他不同的电压和国际规格，数据有可能不同。
开机过程电压会短暂下降。如果电源线路状况不佳，可能会干扰其它机器。在电源电阻小于0,276Ohm
时，就不会产生干扰。如有供电方面的疑问，请联系您当地的电力公司。
安装和操作
执行目的 图片 页数
供货范围 A 63
调节手柄 B 64
连接高压软管/喷射枪 C 64
用水须知 D 65
开动/ 关闭 E – F 65
清洁滤器 G 66
清洁喷嘴 H 66
将枪管连接在喷射枪上 I 66
安装喷嘴 J 67
连接洗涤剂罐 K 67
配备了可调式扇形水柱的
枪管
把枪管连接在喷射枪上
调整喷嘴水柱
L 68
配备了旋转水柱的枪管
把枪管连接在喷射枪上
调整喷嘴水柱
M 69
储放喷射枪 N 70
储存 O 70
搬运须知 P 71
选择附件 Q 72
操作
针对您的安全
注意！维修或清洁机器之前，先关闭机
器并从插座上拔出插头。如果电线受
损、被割坏或缠绕在一起也要执行以上
的防范措施。
电压是 230V AC，50Hz（针对非欧盟国家，因为
机型不同电压可能是 220V 或 240V）。只能使用
经过核准的延长线。有关的信息，请联系经过授权
的顾客服务中心。
操作本高压清洁机时，如果必须使用延长线，该延
长线的截面积必须 符合以下的规定：
– 2,5 毫米2到最长 25 米
指示：该安全引线可以透过插头和 您的电动设备的
安全引线联结。
如有任何疑问可以向合格的电工或就近的博世售后
服务代表询问。
小心：不符合规定的延长线可能造成危
险。只能使用能够防水，适合户外使用
的延长线、插头和联结装置。
电线的连接件（插头和插座）应保持干燥，而且不
可以放在地上。
为了确保工作安全，必须使用最多 30 mA 额定剩馀
电流的漏电断路器 (RCD) 。每次使用前，都必须先
检查 FI - 开关
如果电源电线受损了，只能把电线送给博世授权的
维修厂修理。
针对 非在英国贩卖的产品的指示：
注意：为了您的安全，必须将园艺工具上的插头连
接到延长线上。延长线上的联结装置必须能够防喷
溅水花,必须是由橡胶制成的或配备了橡胶套。延长
线上必须有防拉扯装备。
操作
u请注意，本机器不可以在无水的情况下运转。
开动
把水管（不包含在供货范围中）连接在水源接头和
机器上。
确定电源开关是设定在"0" 的位置并且把机器连接到
插座上。
打开水龙头。
启动锁定开关（喷射枪手柄上的后端开关）以释放
扳机。完全按下扳机，直到水流均匀并且机器和高
压软管中没有空气为止。松开扳机。启动锁定开关
（喷射枪手柄上的前端开关）。
Bosch Power Tools F 016 L81 292 | (04.03.2019)

18 | 中文
打开电源开关。把噴射槍朝下。启动锁定开关以便
释放扳机。完全按下扳机。
自动关机功能
只要喷射枪手柄上的扳机被放开了，机器就会关闭
马达。
工作指示
一般通则
u不可以使用旋转喷头和线状水柱清洗车辆。
确定高压清洁机是放置在平坦的地面上。
不可以提着高压软管走得太前面，换句话说不可以
使用软管来拉动高压清洁机。这样可能导致高压清
洁机摇晃并且翻倒。
不可以弯折高压软管，也不可以让车辆压辗高压软
管。保护高压软管免被锋利的边缘或尖锐的凸角割
损。
有关使用清洁剂时的操作指示
u只能使用经过推荐并且适合高压清洁机的清洁
剂。
基于环保的理念，必须节约使用清洁剂。请注意清
洁剂容器上所标示的有关稀释清洁剂的建议说明。
建议的清洁方法
第1步:安裝扁状噴嘴并粗步去除污垢。
第2步:裝入洗滌劑瓶并涂抹少量的清潔劑。
第3步:使用扁状噴嘴冲洗被溶解的污垢和清洁剂。
指示：清洁竖立的平面时，先以清洁剂由下往上清
洗。接着再从上端朝下冲洗。
使用替代水源
本自吸式高压清洁机，能够从水箱或天然的水源吸
水。重要的是， 在入水口安装已经清洁过的博世过
滤器，而且只能吸汲干净的水。
开放式水箱/容器和天然水域
使用自吸配件，它是由以下部件组成：
– 吸汲滤网有逆止阀
– 3 米增强软管
– 高压清洁机的通用联结器
有了这些配件，高压清洁机可以将水吸到离水面 0.5
米处。这个过程可能需要约15秒。
将3米软管完全浸入水中，以便排出空气。把3米长
的吸汲软管连接到高压清洁机上，并确保吸汲滤网
位在水面下。
取出喷射枪并让高压清洁机运行，直到从高压清洁
机中流出的水流顺畅为止。如果经过 25 秒仍然没有
水流出, 则要关闭机器并检查所有的接头。如果水顺
利流出，先关闭高压清洁机，并在正式操作之前装
上喷射枪和枪杆。
软管和联结器的品质非常重要，另外软管和联结器
务必要紧密结合，密封件不可以有毁损，而且要将
软管垂直的插入联结器中。如果连接不紧密会影响
吸力。
配备出水龙头的水箱
将高压清洁机连接到带有合适出水龙头的水箱之
前，必须先把水管（未提供）连接到龙头上。打开
水龙头，排空软管中所有的空气，然后将它连接到
高压清洁机上。
寻找故障的原因
症状 可能的原因 补救方法
马达无法起动 未插上插头 插好插头
插座故障 使用另一个插座
保险丝熔断 更换保险丝
延长线受损 拿掉延长线再试一次
马达防护功能被启动了 让马达冷却15分钟
结冰了 让泵、水管或配件解冻
马达停止转动 保险丝熔断 更换保险丝
电压不符 检查电压，电压必须和机器铭牌上的规定
一致
马达防护功能被启动了 让马达冷却15分钟
保险丝熔断 保险丝太弱 把机器连接在别的电源系统，该系统的保
险丝必须能够承担高压清洁机的功率
马达运转，但是没
有压力 喷嘴有一部分被堵塞了 清洁喷嘴
马达发出声音但是
不运作 电压不足 检查电源的电压是否和机器铭牌上的规定 一致。
因为使用延长线导致电压太低 检查所使用的延长线是否是合适的
F 016 L81 292 | (04.03.2019) Bosch Power Tools

中文 | 19
症状 可能的原因 补救方法
长期未使用机器 请向授权的博世顾客服务处求助
自动停止功能出现问题 请向授权的博世顾客服务处求助
压力不均匀 水管或泵中有空气 打开喷射枪和水龙头，将喷嘴调整到低压
位置并让高压清洁机不断运转至恢复到均
匀的工作压力为止
水源供应不正常 檢查供水是否符合技術數據上的規定。允
许使用的最小水管是 1/2 英寸或直径 13
毫米的水管
滤网堵塞了 清洁滤网
水管被压住或弯折了 摆好水管
高压软管太长 拆下高压软管-延长件，最大的水管长度是
7 米
压力虽然均匀但太
低
指示：特定的配件
会造成低压
喷嘴磨损了 更换喷嘴
起/停阀磨损了 连续 5 次快速地按下板机
马达在运转，但是
压力受限，或是无
操作压力
未连接水源 连接好水源
滤网阻塞了 清洁滤器
喷嘴阻塞了 清洁喷嘴
高压清洁机自动起
动泵或喷射枪不紧密 请向授权的博世顾客服务处求助
机器漏水 泵不紧密 微量漏水是可容许的，如果漏水量加大得
接洽顾客服务中心。
维修和服务
维修
u在机器上进行任何维护、修理的工作之前必须先
拔出插头和连接水管。
指示：定期执行以下的维修工作，以延长机器的使
用寿命和确保操作安全。
定期检查机器是否有明显的故障，例如松脱的固定
零件和磨损的机件等。
检查遮罩和安全防护装备是否完好、是否安装正
确。必要时，得在使用机器前进行必需的维修或修
理工作。
如果必须更换连接线，务必把这项工作交给Bosch
或者经授权的Bosch电动工具顾客服务执行，以避
免危害机器的安全性能。
使用完毕后/收藏
关闭起停开关并扣动扳机来排空高压软管。
使用软刷和布清洁高压清洁机的外壳。切勿使用
水、稀释剂和抛光剂清洁机器。去除所有的污垢，
尤其得清洁马达的通气缝隙。
工季结束后存储：放出泵中所有的水，此时要让马
达运行数秒并扣动扳机。
不可以把其它的物品放置在机器上。
把机器存放在无霜的环境中。
要确定储存时电线不会被夹住。勿折弯高压软管。
客户服务和应用咨询
www.bosch-do-it.com
如有反馈问题和订购备件，请务必给出产品铭牌上
的10位数产品号。
香港和澳门特别行政区
罗伯特博世有限公司
香港北角英皇道625号，
21楼
客户服务热线：[phone]
传真：[phone]
电子邮件：[email protected]
www.bosch-pt.com.hk
中国大陆
博世电动工具（中国）
有限公司，中国浙江省杭州市
滨江区滨康路567号
102/1F服务中心
邮政编码：310052
电话：[phone] / 5588
传真：[phone] x 5566# / 5588#
电邮：[email protected]
中华人民共和国
中国大陆
博世电动工具（中国）有限公司
博世服务中心
中国浙江省杭州市
滨江区
滨康路567号，
Bosch Power Tools F 016 L81 292 | (04.03.2019)

20 | 繁體中文
310052
电话：[phone] / 5588
传真：[phone] x 5566# / 5588#
电子邮件：[email protected]
www.bosch-pt.com.cn
环保须知
不可以让有害生态环境的化学物品残留在地面、地
下水、池塘和河流中。
使用清洁剂时，务必详阅包装上的使用说明，以及
注意规定的使用浓度。
清洁机动车辆时，请遵守当地法规：必须防止被冲
刷掉的油流入地下水中。
处理废弃物
以符合环保要求的方式回收设备、配件和包装材
料。 请勿将产品扔进家庭垃圾中！
繁體中文
安全規章
圖標說明
一般性警告。
不可以把噴射出的水流朝
向人、動物、機器或電動
零件。
注意:如果使用不當，高壓水柱是
危險的。
根據適用的法規，如未分
離系統，不得將機器連接
到飲用水網絡。根據IEC
61770類型BA選用系統隔離器。
流過系統分離器的水，已經不再
是飲用水。
≥100 A
AdvancedAquatak 150/
AdvancedAquatak 160 適
用於每相額定電流
≥100A，額定電壓230V的電源。
如有疑問，請聯系您當地的電力
公司。
高壓清潔機的安全規章
閱讀所有安全指示和說
明。不遵照以下安全指示
和說明會導致電擊、火災
和／或嚴重傷害。
機器上的警告和提示牌提供了重
要的訊息，能夠確保操作安全。
除了遵循使用說明書上的指示之
外，還必須兼顧一般性的安全規
章和意外防範規定。
用電須知
u電源的電壓必須和產品銘牌上
提供的電壓一致。
u最好將產品插在配備了 30 mA
剩餘電流保護開關的插座上。
u供電電源的保護開關設計, 至少
要具備C特性並能夠負擔16 A的
電流。如有任何疑問可以向合
格的電工詢問。不要試圖擅自
改變電氣裝置。
u即使您只是暫時離開機器，也
要從插座上拔出插頭。
u電源的電壓必須符合 IEC
60364-1 的要求。
u如果需要更換電線，得由機器
的製造商、經過製造商授權的
客服中心或合格的專業人員執
行此工作，以避免危害安全。
u不可以使用潮濕的手拿插頭。
u操作機器時不要拉扯插頭。
u不可以輾過，壓過電線或延長
線，也不可以拉扯它們，這樣
F 016 L81 292 | (04.03.2019) Bosch Power Tools
