English | 3
English
Safety Notes
uWARNING! Read all safety warn-
ings and all instructions. Failure to
follow the safety warnings and in-
structions may result in electric
shock, fire and/or serious injury.
Explanation of symbols on the
machine
General hazard safety alert.
Read instruction manual.
Never direct the
water jet against
the face of people
and animals, the
machine itself or
electric components.
Operation
uThe operator must use the product in
accordance with the regulations. The
local conditions must be taken into
account. When working, pay atten-
tion to other people, especially to
children.
uNever allow children, persons with
physical, sensory or mental limita-
tions or a lack of experience and/or
knowledge and/or people unfamiliar
with these instructions to use the
product. Local regulations may re-
strict the age of the operator.
uChildren should be supervised to en-
sure that they do not play with the
product.
uThe operator is responsible for third
parties in the work area. Make sure
that the water jet does not point in a
direction where it can cause dam-
age.
Application
uAll current-conducting components
in the work area must be protected
against splashed water.
uMaterials containing asbestos and
other materials which contain sub-
stances which are hazardous to your
health must not be sprayed.
uOperate the machine only when the
battery compartment is shut. This
protects the battery against
splashed water.
uBefore use, check that the machine
and operating equipment are in per-
fect condition and are safe to oper-
ate. Do not use if it is not in perfect
condition.
uThe machine must be placed on a
stable surface.
uDo not use solvent-containing li-
quids, undiluted acids, acetone or
solvents, including petrol, paint thin-
ners, heating oil. The sprayed va-
pours are highly flammable, explos-
ive and toxic.
uNever fill the water tank with the fil-
ter removed or if the filter is dam-
aged.
Bosch Power Tools F 016 L94 145 | (09.12.2020)
4 | English
uDo not modify the machine. Unau-
thorized modifications can impair
the safety of your machine, lead to
increased noise and vibrations, and
poor performance.
uDo not direct the spray jet against
the faces of persons or animals.
uNever immerse the machine into wa-
ter to fill the tank.
uHigh pressure may cause objects to
rebound. If necessary wear suitable
personnel protective equipment
such as safety goggles.
uUse only fresh (not saline) water to
fill the water tank.
Recommendations for Optimal
Handling of the Battery Pack
uDo not open the battery. There is a risk of short-circuit-
ing.
Protect the battery against heat (e.g.,
against continuous intense sunlight), fire,
water, and moisture. There is a risk of explo-
sion.
uIn case of damage and improper use of the battery
pack, vapours may be emitted. Ventilate the area and
seek medical help in case of complaints. The vapours can
irritate the respiratory system.
uOnly use the battery with products from the manufac-
turer. This is the only way in which you can protect the
battery against dangerous overload.
uThe battery can be damaged by pointed objects such
as nails or screwdrivers or by force applied externally.
An internal short circuit may occur, causing the battery to
burn, smoke, explode or overheat.
uDo not short-circuit the battery. There is a risk of explo-
sion.
uOccasionally clean the venting slots of the battery using a
soft, clean and dry brush.
uCharge the machine only with the supplied battery
charger.
Safety Warnings for Battery
Chargers
Read all safety warnings and all instruc-
tions. Failure to follow the safety warnings and
instructions may result in electric shock, fire
and/or serious injury.
Save all safety warnings and instructions for future ref-
erence.
Use the battery charger only when you fully understand and
can perform all functions without limitation, or have received
appropriate instructions.
uNever allow children, persons with
physical, sensory or mental limita-
tions or a lack of experience and/or
knowledge and/or people unfamiliar
with these instructions to use the
battery charger. Local regulations
may restrict the age of the operator.
uSupervise children at all times.
This will ensure that children do not
play with the battery charger.
uCharge only Bosch lithium-ion bat-
teries with a capacity above 1.5 Ah
(3 battery cells or more). The battery
voltage must match the battery char-
ging voltage of the charger. Do not
charge non-rechargeable batteries.
Otherwise there is a danger of fire
and explosion.
Keep the battery charger away from rain or
moisture. Penetration of water in the battery
charger increases the risk of an electric shock.
uKeep the charger clean. Dirt poses a risk of electric
shock.
uAlways check the charger, cable and plug before use.
Stop using the charger if you discover any damage. Do
not open the charger yourself, and have it repaired
only by a qualified specialist using only original re-
placement parts. Damaged chargers, cables and plugs
increase the risk of electric shock.
uDo not operate the charger on an easily ignited sur-
face (e.g. paper, textiles, etc.) or in a flammable envir-
onment. There is a risk of fire due to the charger heating
up during operation.
F 016 L94 145 | (09.12.2020) Bosch Power Tools
English | 5
uDo not cover the ventilation slots of the battery char-
ger. Otherwise, the battery charger can overheat and no
longer operate properly.
uFor increased electrical safety, we recommend using a re-
sidual current device with a max. tripping current of 30
mA. Before using, always check your residual current
device.
Transport and Storage
uSwitch the machine off and ensure
that the extendable handle is locked
before transporting.
Care should be taken when
lifting and moving the ma-
chine, particularly when the
water tank is full. Check if the extend-
able handle is securely locked. Use the
extendable handle and the lower front
handle to lift the machine. Ensure a
healthy back posture when lifting the
machine. Keep your back straight and
bend the knees.
uUse caution when moving the ma-
chine over slopes or steps. The ma-
chine is heavy when filled with wa-
ter.
uBefore storing, drain the water from
the tank and the pump system.
Maintenance
uSwitch off the unit prior to all clean-
ing and maintenance work and be-
fore replacing components. Pull out
the mains plug if the unit is mains-
operated.
uRepairs may only be carried out by
authorised Bosch Service Centres.
Accessories and spare parts
uAccessories and spare parts which
have been approved by Bosch must
be used. Original accessories and
spare parts guarantee that the ma-
chine can be operated safely and
without any breakdowns.
Symbols
The following symbols are important for reading and under-
standing the original instructions. Please take note of the
symbols and their meaning. The correct interpretation of the
symbols will help you to use the product in a better and safer
manner.
Symbol Meaning
Movement direction
Reaction direction
Switching on
Switching off
Accessories/Spare Parts
Intended Use
The machineis intended for domestic use, either fed from
the internal tank or the mains water connection, to clean
vehicles, tools, windows, boots, bicycles, dogs (in low-pres-
sure mode), outdoor toys, greenhouses, garden furniture,
etc.
The pressure mode and spray pattern should be correctly
adjusted for the respective cleaning task.
Product features (see figures A and
D)
The numbering of the product features refers to the illustra-
tion of the product on the graphics pages.
(1) Nozzle head
(2) Trigger
(3) Hose connector for spray gun
(4) Hose
(5) Brush
(6) Battery charge-control indicator
(7) Storage compartment
Bosch Power Tools F 016 L94 145 | (09.12.2020)
6 | English
(8) Front handle
(9) Water outlet
(10) Connector for mains water feed and filter element
(under cap)
(11) Filler cap
(12) Pressure selector
(13) On/Off switch
(14) Battery compartment cover
(15) Battery compartment release button
(16) Extendable handle lock
(17) Extendable handle
(18) Spray gun
(19) Batterya)
(20) Battery unlocking button
(21) Chargera)
(22) Detergent nozzlea)
a) Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
Technical Data
Cordless pressure cleaner Fontus 18V
Article number 3 600 HB6 1..
Rated voltage V 18
Rated power W 170
Protection class III, IP X4
Max. pressure (system) MPa 4.0 (+/- 0.4)
Rated pressure (user output) MPa 2.0 (+/- 0.2)
Max. water temperature °C 50
Weight according to EPTA‑Procedure 01:2014A) kg 7.5
Serial number See serial number (nameplate) on machine
Permitted ambient temperature
– during charging °C 0 … +45
– during operation B) °C +5 … +50
– during storage °C -20 … +50
Battery type PBA 18V...W-.
1.5 Ah, 2.0 Ah, 2.5 Ah, 3.0 Ah, 4.0 Ah, 5.0
Ah, 6.0 Ah
A) Depends on battery in use
B) Limited performance at temperatures <0°C
Charger AL 1810 CV AL 1820 CV AL 1830 CV
Charging current A 1,0 2,0 3,0
Charging period (battery dis-
charged) (80 %)/100 % (80 %)/100 % (80 %)/100 %
– Battery with 1.5Ah min (72)/94 (36)/49 (24)/33
– Battery with 2.0Ah min (96)/124 (48)/64 (32)/45
– Battery with 2.5Ah min (120)/154 (60)/79 (40)/60
– Battery with 3.0Ah min (144)/184 (72)/94 (48)/72
– Battery with 4.0Ah min (192)/244 (96)/124 (64)/95
– Battery with 5.0Ah min (240)/304 (120)/154 (95)/105
– Battery with 6.0Ah min (288)/364 (144)/184 (96)/130
Weight according to EPTA‑Pro-
cedure 01:2014 kg 0,17 0,21 0,40
Protection class / II / II / II
The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-specific models.
F 016 L94 145 | (09.12.2020) Bosch Power Tools
English | 7
Noise/Vibration Information
Noise emission values determined according to EN
60335-2-79.
Typically the A-weighted noise levels of the product are:
Sound pressure level 67dB(A); sound power level
78dB(A). Uncertainty K=4,0dB.
Overall vibrational values ah (vector sum of three directions)
and uncertainty K determined according to
EN 60335-2-79: ah = 0,4 m/s2, K = 0,5 m/s2.
Mounting and Operation
Representation/Action Ob-
jective Figure Page
Product Features A27
Delivery scope B28
Filling the water tank C1 28
Fill water tank with mains water
connection C2 29
Fill water tank with mains water
connection (continuous)/auto-
matic filling
C3 29
Battery charging and inserting D30
Carrying and transporting E30
Connecting the hose F31
Switching on G31
Adjusting the pressure setting H32
Spray-pattern variants I32
Using the brush J33
Switching off
Disconnecting the hose K34
Removing the battery L34
Maintenance M35
Storage N35
Accessories O36
Switching on
Charging the Battery
uPay attention to the mains voltage. The voltage of the
power source must match the voltage specified on the
rating plate of the charger.
The battery is equipped with temperature monitoring that al-
lows charging only in the temperature range between 0 °C
and 35 °C. In this manner, a high battery service life is
achieved.
Note: The battery is supplied partially charged. To ensure
full battery capacity, completely charge the battery in the
battery charger before using for the first time.
The lithium-ion battery can be charged at any time without
reducing its service life. Interrupting the charging procedure
does not cause damage to the battery.
The “Electronic Cell Protection (ECP)” protects the lithium-
ion battery against deep discharging. When the battery is
empty, the product is switched off by means of a protective
circuit: The product no longer operates.
Do not continue to press the On/Off switch after an auto-
matic shut-off of the product. The battery could become
damaged.
Observe the notes for disposal of the battery.
Inserting/Removing the Battery (see figures D
and L)
Note: Using unsuitable batteries can lead to malfunctions or
damage the machine.
Press the battery compartment release button (15) to open
the battery compartment cover (14). Insert the charged bat-
tery (19). Ensure the battery is inserted correctly.
Close the battery compartment cover and ensure that the
lock of the battery compartment release button (15) has en-
gaged. The battery compartment cover (14) protects the
battery against splashed water during operation.
Press the battery compartment release button (15) to open
the battery compartment cover (14). To remove the battery
(19) from the machine, press the battery unlocking button
(20) and pull the battery out.
Meaning of the Indication Elements
(AL1810CV)
Flashing battery charge indicator
The charging process is indicated by the flash-
ing of the battery charge indicator .
Solid light on battery charge indicator
A solid light on the battery charge indicator
signals that the battery is fully charged or that
the temperature of the battery is not within the
permitted charging temperature range, and
can therefore not be charged. The battery is charged as soon
as the allowable charging temperature range is reached.
When the battery is not inserted, a solid light on the battery
charge indicator signals that the mains plug is inserted in the
plug socket and that the charger is ready for operation.
Meaning of the Indication Elements
(AL1830CV)
(Fast) Flashing of the Green Battery Charge Indicator
The rapid-charging procedure is indicated by
fast flashing of the green battery charge in-
dicator .
Note: The rapid-charging procedure is only possible when
the battery temperature is within the allowable charging
temperature range, see section “Technical Data”.
Bosch Power Tools F 016 L94 145 | (09.12.2020)
8 | English
(Slow) Flashing of the Green Battery Charge Indicator
When the charging condition of the battery is
80%, the green battery charge indicator
flashes slowly.
The battery can be removed for immediate use.
Continuous Lighting of the Green Battery Charge
Indicator
Full
Continuous lighting of the green battery
charge indicator indicates that the battery is
fully charged.
When the battery is not inserted, continuous lighting of the
battery charge indicator indicates that the mains plug is in-
serted in the socket outlet and that the battery charger is
ready for operation.
Continuous Lighting of the Red Battery Charge Indicator
Continuous lighting of the red battery charge
indicator indicates that the temperature of the
battery is not within the allowable charging temperature
range, see section “Technical Data”. As soon as the allowable
charging temperature range is reached, the battery charger
automatically switches to rapid charging.
Flashing Red Battery Charge Indicator
A flashing red battery charge indicator indic-
ates a different malfunction of the charging
procedure, see section “Troubleshooting – Causes and Cor-
rective Measures”.
Operation
Starting
Always use fresh water to fill the internal tank either directly
or via the water connection. Check if the fillter (10) is inser-
ted and undamaged (see figures C1 and C2).
Connect the hose (4) to the water outlet (9) and the spray
gun (18) (see figure F).
Select the desired spray pattern by rotating the nozzle head
(1) (see figure I).
Select the desired jet strength with the pressure selector
(12) (see figure H).
Press the On/Off switch (13) and pull and hold the trigger
(2) until water comes out (see figure G).
Note: It can take up to 10 seconds for water to come out
when the product is first used after the water tank has been
emptied.
Autostop Function
The machine is designed to switch off the motor as soon as
the spray-gun trigger (2) is released.
Auto-off Function
The motor switches off when the product runs continuously
for 30 minutes.
Autosleep Function
The machine automatically switches off after 5 minutes
without operation.
Mounting/dismounting the brush (see figure J)
The brush (5) mounts onto the spray gun and makes clean-
ing more effective.
Slide the brush straight onto the spray gun (18). Guide the
upper and bottom clip of the brush into the corresponding
openings on the spray gun.
Remove the brush by pressing the bottom clip upward and
pulling the brush off the spray gun.
Troubleshooting
Cordless pressure cleaner
Problem Possible Cause Corrective Measure
Machine does not
power up Battery discharged Recharge battery
Battery too hot/cold Allow to cool/warm
Machine frozen Wait until machine has defrosted
Pressure pulsating Blocked nozzle Clean nozzle
Air in pump Operate machine in turbo-pressure mode with
nozzle set to shower jet until system is air-free
Motor running but no
or limited working
pressure
Water tank empty Refill water tank
Pump not vented Press and hold trigger to vent air
Power indication lights
up but pump no longer
running
The auto-off function has been activated Switch machine off and then on again
Machine switches off The autosleep function has been activated Press On/Off switch for activation
Battery discharged Recharge battery
F 016 L94 145 | (09.12.2020) Bosch Power Tools
English | 9
Problem Possible Cause Corrective Measure
Water leaks from ma-
chine Leaking pump Slight water leaks are possible; in case of excess-
ive leaks, contact Bosch Service Centre
Leaking connections Check if connections are properly mounted
Filler cap untight Check if filler cap is properly closed
Motor starts in standby
mode Pump, spray gun or hose leaking In case of continuous malfunctions in standby
mode, contact Bosch Service Centre
Hose cannot be re-
moved When machine is still switched on, pressure in
system increases the required force to remove
connectors
Switch machine off, then pull trigger to release
the pressure
Tank is not being filled,
although the tap water
is connected
Water hose and/or hose connection is clogged or
blocked Switch machine off, check and clean water hose
or hose connection
Battery and charger
Problem Possible Cause Corrective Measure
Flashing red battery
charge indicator
No charging procedure
possible
Battery not (properly) inserted Properly insert battery in charger
Battery contacts contaminated Clean the battery contacts (e. g. by inserting and
removing the battery several times) or replace
the battery
Battery defective Replace battery
Battery charge indicat-
ors do not light up Mains plug of battery charger not plugged in
(properly) Insert mains plug (fully) into the socket outlet
Socket outlet, mains cable or battery charger de-
fective Check the mains voltage; have the battery char-
ger checked by an authorised after-sales service
agent for Bosch power tools
Maintenance and Service
Maintenance, Storage and Transportation (see
figures K – N)
Switch the machine off and press the trigger to drain the wa-
ter from the hose.
Disconnect hose from spray gun and water outlet. The spray
gun, brush and hose can be stored with the machine.
Drain water from the system and remove the battery.
Clean the filter regularly.
Battery Maintenance
Use the following procedures to enable optimum usage of
the battery:
– Protect the battery against moisture and water.
– Store the machine and battery only within a temperature
range between –20°C and 50°C . As an example, do not
leave the battery in the car in summer.
– It is recommended that the battery is not stored within
the product but stored separately.
– Do not leave the battery in the product in direct sunlight.
– The ideal storage condition for the battery is 5°C.
– Occasionally clean the venting slots of the battery using a
soft, clean and dry brush.
A significantly reduced working period after charging indic-
ates that the battery is used and must be replaced.
After-Sales Service and Application Service
Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. You can find explosion drawings and information on
spare parts at: www.bosch-pt.com
The Bosch product use advice team will be happy to help you
with any questions about our products and their accessor-
ies.
In all correspondence and spare parts orders, please always
include the 10‑digit article number given on the nameplate
of the product.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham Uxbridge
UB 9 5HJ
At www.bosch-pt.co.uk you can order spare parts or arrange
the collection of a product in need of servicing or repair.
Tel. Service: (0344) 7360109
E-Mail: [email protected]
Bosch Power Tools F 016 L94 145 | (09.12.2020)
10 | English
You can find further service addresses at:
www.bosch-pt.com/serviceaddresses
Transport
The contained lithium-ion batteries are subject to the Dan-
gerous Goods Legislation requirements. The batteries are
suitable for road-transport by the user without further re-
strictions.
When shipping by third parties (e.g.: by air transport or for-
warding agency), special requirements on packaging and la-
belling must be observed. For preparation of the item being
shipped, consulting an expert for hazardous material is re-
quired.
Dispatch battery packs only when the housing is undam-
aged. Tape or mask off open contacts and pack up the bat-
tery in such a manner that it cannot move around in the
packaging. Please also observe the possibility of more de-
tailed national regulations.
Disposal
The product, batteries, accessories and pack-
aging should be sorted for environmental-
friendly recycling.
Do not dispose of the product and batteries/re-
chargeable batteries into household waste!
Only for EU countries:
According to the European Guideline 2012/19/EU, products
that are no longer usable, and according to the European
Guideline 2006/66/EC, defective or used battery packs/
batteries, must be collected separately and disposed of in an
environmentally correct manner.
Battery packs/batteries:
Li-ion:
Please observe the notes in the section on transport (see
"Transport", page10).
UK Importer:
Robert Bosch Ltd.
Broadwater Park
North Orbital Road
Uxbridge UB9 5HJ
F 016 L94 145 | (09.12.2020) Bosch Power Tools
| 11
t
t
t
t
t
t
t
t
t
t
t
t
Bosch Power Tools F 016 L94 145 | (09.12.2020)
12 |
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
F 016 L94 145 | (09.12.2020) Bosch Power Tools
| 13
t
t
t
t
t
t
t
t
t
Bosch Power Tools F 016 L94 145 | (09.12.2020)
14 |
Fontus 18V
3 600 HB6 1..
18
170
III, IP X4
4,0 -/+) 0,4(
2,0 -/+) 0,2(
50
7,5
) (
0+ … 45
+5+ … 50
-20+ … 50
PBA 18V...W-. 1,5: ,2,0/,2,5/ ,3,0/,4,0/ ,5,0/,6,0/
AL 1810 CVAL 1820 CVAL 1830 CV
1,02,03,0
)80 / (% 100% )80 / (% 100% )80 / (% 100%
)72 / (94)36 / (49)24 / (33
)96 / (124)48 / (64)32 / (45
)120 / (154)60 / (79)40 / (60
)144 / (184)72 / (94)48 / (72
)192 / (244)96 / (124)64 / (95
F 016 L94 145 | (09.12.2020) Bosch Power Tools
| 15
AL 1810 CVAL 1820 CVAL 1830 CV
)240 / (304)120 / (154)95 / (105
)288 / (364)144 / (184)96 / (130
0,170,210,40
/ II / II / II
] U [ 230 . .
A
27
B
28
C1
28
C2
29
C3
29
D
30
E
30
F
31
G
31
H
32
I
32
J
33
K
34
L
34
M
35
N
35
O
36
t
Bosch Power Tools F 016 L94 145 | (09.12.2020)
16 |
Full
F 016 L94 145 | (09.12.2020) Bosch Power Tools
| 17
Bosch Power Tools F 016 L94 145 | (09.12.2020)
18 |
F 016 L94 145 | (09.12.2020) Bosch Power Tools
| 19
t
t
t
t
t
t
t
t
t
t
t
t
Bosch Power Tools F 016 L94 145 | (09.12.2020)
20 |
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
F 016 L94 145 | (09.12.2020) Bosch Power Tools
Other manuals for Fontus 18V
2
This manual suits for next models
1
Table of contents
Languages:
Other Bosch Pressure Washer manuals
Bosch
Bosch AQT 35-12+ User manual
Bosch
Bosch 0600910300 User manual
Bosch
Bosch GHP 5-55 User manual
Bosch
Bosch AQT 35-12+ User manual
Bosch
Bosch Advanced Aquatak 150 User manual
Bosch
Bosch AQT 42-13 User manual
Bosch
Bosch AQT 33-11 User manual
Bosch
Bosch GHP 5-14 User manual
Bosch
Bosch AQT 35-12+ User manual
Bosch
Bosch GHP 8-15 XD User manual
Bosch
Bosch GHP 5-55 User manual
Bosch
Bosch AQUATAK 110 User manual
Bosch
Bosch AdvancedAquatak Series User manual
Bosch
Bosch Universal Aquatak 125 User manual
Bosch
Bosch GHP 5-13 C User manual
Bosch
Bosch AQT 42-13 User manual
Bosch
Bosch AQT 35-12+ User manual
Bosch
Bosch EasyAquatak 120 User manual
Bosch
Bosch AQUATAK 10 User manual
Bosch
Bosch UniversalAquatak 1900 Assembly instructions
