Boss Audio Systems BV9366B User manual

Unit Installation
25
26
Wires Connection Description

UNIT INSTALLATION
Bracket
1.Put the 2 brackets to the left and right side of the unit;
2.Use screws to fix the brackets to the unit.
Bracket
Screw

WIRES CONNECTION DESCRIPTION
The Description of the Input/Output Interface
Description of the Wiring Diagram for Socket A and B
YELLOW..................(B+)12V
RED...................ACC(+12V)
BLUE..................ANT.CONT
BLACK..................GROUND
Connector A Connector B
WHITE............LEFT FRONT(+)
WHITE/BLACK......LEFT FRONT(-)
GREEN.............LEFT REAR(+)
GREEN/BLACK.......LEFT REAR(-)
GREY............RIGHT FRONT(+)
GREY/BLACK......RIGHT FRONT(-)
VIOLET............RIGHT REAR(+)
VIOLET/BLACK......RIGHT REAR(-)
WHITE KEY A (SWC)
BROWN KEY B (SWC)
BLACK KEY GROUND(SWC)
LT.GREEN PARKING BRAKE
VIOLET/WHT(+) REV.SIGNAL
BLUE/WHT(+) 500mA-REMOTE
ANTENNA
VIDEO
OUT REAR
CAMERA
INPUT
FRONT PRE-AMP
OUTPUT
REAR PRE-AMP
OUTPUT A/V INPUT
SUBWOOFER
OUTPUT
