FormNo.MSC11083RevC
Owner'sManual
TGS300,600,and1100TailgateSpreaders
PartNo.TGS11300—SerialNo.402100000andUp
PartNo.TGS06000—SerialNo.400000000andUp
PartNo.TGS11000—SerialNo.400000000andUp
PartNo.TGS11087—SerialNo.400000000andUp
Registeratwww.bossplow.com.
OriginalInstructions(EN)*MSC11083*C

ThisproductcomplieswithallrelevantEuropean
directives;fordetails,pleaseseetheseparateproduct
specicDeclarationofConformity(DOC)sheet.
BOSSProductslimitedconsumerwarrantyandBOSS
Productscommercialwarrantypoliciesarelocatedat
www.bossplow.com.
Patentwww.ttcopats.com.
WARNING
CALIFORNIA
Proposition65Warning
Useofthisproductmaycauseexposure
tochemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
Introduction
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
YoumaycontactBOSSdirectlyatwww.bossplow.com
forproductandaccessoryinformation,helpndinga
dealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineBOSSparts,or
additionalinformation,contactanAuthorizedBOSS
DealerorBOSST echnicalService(1-800-286-4155)
andhavethemodelandserialnumbersofyour
productready.Figure1identiesthelocationofthe
modelandserialnumbersontheproduct.Writethe
numbersinthespaceprovided.
g031005
Figure1
1.Serialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafetyalertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
1.Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
Contents
Safety.......................................................................3
Preparation.........................................................3
Operation............................................................3
SafetyandInstructionalDecals..........................4
Setup........................................................................5
InstallingtheWireHarness.................................5
InstallingtheSlide-InAttachment........................5
MountingtheSpreaderwiththeSlide-In
Attachment......................................................6
InstallingtheRT3Attachment.............................7
MountingtheSpreaderwiththeRT3
Attachment......................................................7
InstallingtheSpreaderController........................9
ProductOverview...................................................10
Controls...........................................................10
Specications...................................................11
Operation.................................................................11
MountingtheSpreader......................................11
RemovingtheSpreader....................................12
MountingtheSpreader.....................................12
RemovingtheSpreader....................................13
LoadingtheSpreader.......................................14
OperatingtheSpreader....................................14
FreeingaClog..................................................15
UnloadingtheSpreader....................................15
AdjustingtheMaterialDeectors......................15
OperatingTips.................................................15
Troubleshooting......................................................16
©2020—BOSSProducts
P .O.Box787
IronMountain,MI498012
Contactusatwww.bossplow.com.
PrintedintheUSA
AllRightsReserved

Safety
Improperlyusingandmaintainingtheequipment
canresultininjury.Toreducethepotentialfor
injury,complywiththesesafetyinstructions
andalwayspayattentiontothesafety-alert
symbol,whichmeans:Caution,Warning,or
Danger—personalsafetyinstruction.Failureto
complywiththeinstructionmayresultinpersonal
injuryordeath.
Preparation
•Ensurethatonlytrainedpersonnelinstalland
performmaintenanceontheequipment.
•Alwayswearappropriatepersonalprotective
equipmentwhenloading,unloading,andservicing
thespreader.Wearsubstantial,slip-resistant
footwear,cold-weatherclothing,safetyglasses,
anddustprotection.
•Ensurethatyourrearviewmirrorisinagood
operatingposition.
•Manynewertrucksareequippedwithairbags.
Neverdisable,remove,orrelocateanysensorsor
othercomponentsrelatedtotheoperationofthe
airbags.
•TGS300spreadersmustonlybeusedwitha
minimumClassIIreceiverhitch.Donotexceed
thevehiclehitchrating.
•TheTGS300canholdamaximumweightof91
kg(200lb)ofsalt.Donotexceedthisweight.
•TGS600spreaderswithslide-inorRT3
attachmentsmustonlybeusedwithaminimum
ClassIIIreceiverhitch.Donotexceedthevehicle
hitchrating.
•TGS1100spreaderswiththeslide-inorRT3
attachmentsmustonlybeusedwithaminimum
ClassIVreceiverhitch.Donotexceedthevehicle
hitchrating.
•TheTGS600canholdamaximumweightof181
kg(400lb)ofsalt.Donotexceedthisweight.
•TheTGS1100canholdamaximumweightof363
kg(800lb)ofsalt.Donotexceedthisweight.
Operation
•ReadtheOwner’sManualbeforeoperatingor
servicingthespreader.
•Donotoperatethemachinewhileill,tired,or
undertheinuenceofalcoholordrugs.
•Forvehicle-mountedspreaders,alwaysfollow
themanufacturer’srecommendationsforproper
parkingprocedures.
•Alwayswearyourseatbeltwhileoperatingamotor
vehicle.
•Donotexceed22.5km/h(14mph)while
spreading.
•Thisspreaderhasanoperatingsoundlevelbelow
70dBA.
•Neverputanypartofyourbodybetweenthe
spreaderandthevehicle.
•Overloadingthespreadercouldresultin
anaccidentordamage.Neverexceedthe
gross-vehicle-weightrating(GVWR)orthefront
orreargross-axle-weightratings(FGAWRor
RGAWR)forthevehicle.
•Thisspreaderisrestrictedtotheuseofsaltonly.
Donotrunothermaterialsthroughthespreader.
•Donotattempttomountorremovethespreader
withmaterialinit.
•Turnthespreaderoffbeforelling,mounting,
removing,servicing,orcleaningit.
•Neveroperatethespreaderwithin7.6m(25ft)
ofbystanders.
•Donotclimbintoorrideonthespreader.
•Keepyourhands,feet,andclothingawayfrom
movingpartsandmountingpoints.
•Mountthespreadertoavehiclebeforeloading
material.
•Installratchetstrapsandkeepthemproperly
tightenedwiththeslide-inandRT3attachments.
•Whentransportingthespreader,ensurethatitis
properlysecured.Instructionsareavailableat
www.bossplow.com.
•Theslide-inattachmentmustbefullyengagedand
pinnedintothe5cm(2inch)receiverhitchofthe
vehicle.
•TheupperandlowerpinsoftheRT3attachment
mustbefullyengagedandpinnedintothe5cm(2
inch)receiverhitchofthevehicle.
•Materialsafetydatasheets(MSDS)areavailable
atwww.bossplow.com.
•Usea1/2tonminimumliftingdevicetomove
heavyspreadercomponents.
•Donotstorematerialinthehopper.
3

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decaltgs06269b
TGS06269
1.Warning—readtheOwner’s
Manual.
4.Warning—turnthemachine
offbeforelling.
7.Warning—donotstandor
rideonthemachine.
10.Warning—turnthemachine
offanddisconnectthe
powerbeforeservicingthe
machine.
2.Warning—alloperators
shouldbetrainedbefore
operatingthemachine.
5.Warning—emptythe
hopperanddisconnectthe
powerbeforeinstallingor
removingthemachine.
8.Warning—themachine
mustbeinstalledbefore
lling.
3.Lossofcontrolhazard—do
notoverllthemachine.
6.Thrownobject
hazard—keepbystanders
awayfromthemachine.
9.Warning—donotstore
materialsinthemachine.
decaltgs05895b
TGS05895
1.Cutting/dismemberment
hazard;auger—keep
ngersandhandsclearof
theauger.
3.Cutting/dismemberment
hazard;spinner—keep
ngersandhandsclearof
thespinner.
2.Crushinghazard—keep
ngersandhandsclearof
movingparts.
decaltgs06360
MSC06364
(non-replaceabledecal)
1.Power3.Blast
2.Vibrator4.Spinnerspeed
4

Setup
Note:Eithertheslide-inorRT3attachmentis
requiredtoinstallthismachine.Contactyour
AuthorizedBOSSDealerformoreinformation.
InstallingtheWireHarness
DANGER
Vehicleenginescontainmovingpartsandcan
becomeextremelyhot,capableofcausing
severeburnsandseriousbodilyharm.
Shutofftheengineandallowitsufcienttime
tocooldownbeforeinstallingthiskit.
DANGER
Vehiclebatteriescancausedangerous
electricalshocksthatcouldleadtosevere
burnsordeath.
Disconnectyourbatterybeforeinstallingthis
kit.
1.Securethespreaderendofthevehiclewire
harness(Figure3)tothecenteroftherear
vehiclebumperwithacabletie.
2.Routethewireharnessalongthedriver-side
frame-railandintotheenginecompartment,and
secureitwithcableties.
Note:Keepthewireharnessawayfromany
hotormovingparts.
3.Insertthecontrollerconnectors,spade
connector,andgroundcablethroughtherewall
andintothevehiclecab,andsecurethemwith
cableties.
Note:Routethecontrollerconnectorstothe
locationthatyouwanttoinstallyourcontroller.
4.Connecttheblackringconnectorintheengine
compartmenttothenegative(-)batteryterminal
(Figure3).
5.Connecttheredringconnectorintheengine
compartmenttothepositive(+)batteryterminal
(Figure3).
6.Connectthespadeconnectortoanignition
switchpowersourceonthevehicle(Figure3).
7.Connectthegroundcabletothenegative(–)
batterypostorchassisground(Figure3).
8.Wraptheexcesswireandsecureitintheengine
compartmentwithcableties.
g232908
Figure3
1.Controllerconnector4.Spadeconnector
2.Blackringconnector5.Groundcable
3.Redringconnector6.Spreaderconnector
InstallingtheSlide-In
Attachment
InstallingtheSlide-InAttachment
forTGS300
1.Mounttheslide-inattachmenttothespreader
using4bolts(1/2inch)andlocknuts(1/2inch)
andtorquetheboltsto76Nm(56ft-lb)asshown
inFigure4.
g232358
Figure4
1.Spinnerguard3.Bolt(1/2inch)
2.Locknut(1/2inch)4.Slide-inattachment
2.Mountthespinnerguardtothespreaderusing
the2existingbolts(3/8inch)andlocknuts(3/8
inch)andtorquetheboltsto27Nm(19.7ft-lb)
asshowninFigure4.
5

InstallingtheSlide-InAttachment
forTGS600orTGS1100
1.Mounttheslide-inattachmenttothespreader
using4bolts(1/2inch)andlocknuts(1/2inch)
andtorquetheboltsto76Nm(56ft-lb)asshown
inFigure5.
g031007
Figure5
1.Spinnerguard3.Bolt(1/2inch)
2.Locknut(1/2inch)4.Slide-inattachment
2.Mountthespinnerguardtothespreaderusing
the2existingbolts(3/8inch)andlocknuts(3/8
inch)andtorquetheboltsto27Nm(19.7ft-lb)
asshowninFigure5.
MountingtheSpreaderwith
theSlide-InAttachment
1.AttachtheD-ringendoftheratchetstrapsto
theupperholesontheoutsideofthespreader
frameusingabolt(1/2inch),washer(1/2inch),
andlocknut(1/2inch)andtorquetheboltsto76
Nm(56ft-lb)asshowninFigure6.
g234640
Figure6
1.Locknut(1/2inch)3.Washer(1/2inch)
2.Ratchetstrap4.Bolt(1/2inch)
2.Slidethehitchonthespreaderintothereceiver
hitchofyourvehicleandlineupthesecondhole
onthespreaderhitchwiththeholeinthehitch
ofyourvehicle(Figure7).
Note:Ifthespreadercontactsthebumperof
yourvehicle,slidethespreaderoutandalignthe
rstholeofthespreaderhitchinstead.
DANGER
Thespreaderisheavyandcouldcause
seriousinjuryifdropped.
Ensurethatyourfootingisstable,and
avoidliftingthespreaderonslipperyor
unevensurfaces.
g031009
Figure7
3.Securethespreaderhitchtothevehiclehitch
usingtheclevispinandcotterhairpin.
4.Attachthestabilizerarmstothespreaderframe
using8bolts(3/8inch)and8locknuts(3/8inch),
andtorquetheboltsto27Nm(19.7ft-lb)as
showninFigure8.
Note:Attachthearmssothatthestabilizer
padscontactyourtruckbumper.
g031012
Figure8
1.Locknut(3/8inch)3.Stabilizerarm
2.Bolt(3/8inch)4.Stabilizerpad
6

5.Rotatethepadsonthestabilizerarmsuntilthey
aretightagainstyourtruckbumperandtighten
thejamnuttosecurethem(Figure8).
6.Slidetheendsoftheratchetstrapsbetweenthe
bumperandtailgateonyourvehicleandattach
themtoasolidpointonthetruckframerail.
Note:Youmayhavetodrillaholeinthetruck
framerailtoattachthem.
7.Plugthespreaderharnessintothevehiclewire
harnessatthebumper.
InstallingtheRT3
Attachment
1.MounttheRT3attachmenttothespreaderusing
4bolts(1/2inch)andlocknuts(1/2inch)and
torquetheboltsto76Nm(56ft-lb)asshown
inFigure9.
g031010
Figure9
1.RT3attachment3.Locknut(1/2inch)
2.Bolt(1/2inch)4.Legassembly
2.Mountthelegassemblytothespreaderusing
the4existingbolts(3/8inch)andlocknuts(3/8
inch)andtorquetheboltsto27Nm(19.7ft-lb)
asshowninFigure9.
MountingtheSpreaderwith
theRT3Attachment
1.AttachtheD-ringendoftheratchetstrapsto
theupperholesontheoutsideofthespreader
frameusingabolt(1/2inch),washer(1/2inch),
andlocknut(1/2inch)andtorquetheboltsto76
Nm(56ft-lb)asshowninFigure10.
g234640
Figure10
1.Locknut(1/2inch)3.Washer(1/2inch)
2.Ratchetstrap4.Bolt(1/2inch)
2.SlidetheRT3hitchintothereceiverhitchof
yourvehicleandlineupthesecondholeonthe
spreaderhitchwiththeholeinthehitchofyour
vehicle(Figure11).
Note:Ifthespreadercontactsthebumperof
yourvehicle,slidethespreaderoutandalignthe
rstholeofthespreaderhitchinstead.
g031011
Figure11
3.Securethespreaderhitchtothevehiclehitch
usingtheclevispinandcotterhairpin.
4.RotatethelockingleverontheRT3attachment
totheLOCKposition(Figure12).
7

g031013
Figure12
1.Lockinglever
5.Gripthespreaderrmlyandstepontheleg
assemblytorotateitbackuntilthebottompinof
theRT3attachmentclearsthehookontheRT3
hitch(Figure13).
DANGER
Thespreaderisheavyandcouldcause
seriousinjuryifdropped.
Ensurethatyourfootingisstable,and
avoidliftingthespreaderonslipperyor
unevensurfaces.
g031014
Figure13
1.RT3hitchhook3.Stephere
2.Bottompin
6.Pushthespreaderforwardandlowerthebottom
pinoftheRT3attachmentontothehitchhook.
7.Tipthespreaderuprightuntilthetoppinofthe
RT3attachmentlocksintoplace.
DANGER
Thespreaderisheavyandcouldcause
seriousinjuryorpropertydamageifit
fallsoffyourvehicle.
EnsurethatthetoppinoftheRT3
attachmentisfullylockedintoplaceand
thatthesafetylatchisdown.
8.Attachthestabilizerarmstothespreaderframe
using8bolts(3/8inch)and8locknuts(3/8inch)
andtorquetheboltsto27Nm(19.7ft-lb)as
showninFigure8.
Note:Attachthearmssothatthestabilizer
padscontactyourtruckbumper.
9.Rotatethepadsonthestabilizerarmsuntilthey
aretightagainstyourtruckbumperandtighten
thejamnuttosecurethem(Figure8).
10.Slidetheendsoftheratchetstrapsbetweenthe
bumperandtailgateonyourvehicleandattach
themtoasolidpointonthetruckframerail.
Note:Youmayhavetodrillaholeinthetruck
framerailtoattachthem.
11.Stepontheleg-assemblywheelstopivotthem
andstowthemunderthelegassembly(Figure
14).
g031257
Figure14
1.Leg-assemblywheels
12.Plugthespreaderharnessintothevehiclewire
harnessatthebumper.
8

InstallingtheSpreader
Controller
Mountthecontrollerinthecabwhereitdoesnot
interferewithvehicleoperationorvisibility.
Important:Donotmountthecontrollerina
locationthatvehicleoccupantscouldcontactit
duringacrash.
1.Attachthemountingbrackettothevehicleusing
2sheet-metalscrews(Figure15).
g232911
Figure15
1.Thumbscrew3.Mountingbracket
2.Starwasher4.Sheet-metalscrew
2.Attachthecontrollertothemountingbracket
using4starwashersand2thumbscrews
(Figure15).
Note:Positionthecontrollerscreensothatitis
clearlyvisibletothedriver.
3.Connectthewireharnesscontrollerconnectors
tothecontroller(Figure16).
g233286
Figure16
9

ProductOverview
g315083
Figure17
1.Hoppercover4.Bagsplitter
2.Spinner5.Topscreen
3.Materialdeectorwithadjustmentpins
Controls
Becomefamiliarwithallthecontrolsbeforeyou
operatethespreader.
MaterialDeector
Thematerialdeectorcontrolsthespreadofmaterials;
youcanadjustthecontrolstoprovidedifferentspread
patterns;refertoAdjustingtheMaterialDeectors
(page15).
SpreaderController
Thespreadercontrollerletsyouoperateyourspreader
anddisplaysinformationaboutyourmachine.
g239569
Figure18
1.PowerLED5.Speeddial
2.VibratorLED6.Blastbutton
3.BlastLED7.Vibratorbutton
4.Speeddisplay8.Powerbutton
•Powerbutton—turnsthespreadercontrollerand
spinnermotoronoroff.Ifthecontrollerisnot
active,pressingthebuttonturnsiton.Ifthe
controllerisactive,pressingthebuttonstarts
thespinnermotorandvibrator(ifequippedand
enabled).Ifthespinnermotorison,pressingthe
buttonturnsitoff.Holdingthebuttonfor3seconds
turnsoffthespinnermotorandcontroller.
10

•Vibratorbutton—switchestheoptionalvibratoron
oroffwhenthespinnermotorison
•Blastbutton—momentarilysendsfullpowertothe
spinnermotoraslongasitispressed
•Speeddisplay—showsthespinnermotorspeed
•Speeddial—increasesthespinnermotorspeed
whenturnedclockwise,anddecreasesthespinner
motorspeedwhenturnedcounterclockwise
•PowerLED
–Solidred:lowvoltageindicator;checkthe
vehiclechargingsystemorbattery.
–Flashingred:thespreaderisjammedoris
disconnected.
–Green:thecontrollerisonorthespinnermotor
isturning.
–Amber:thespreaderisclearingajam.
•VibratorLED—indicatesthattheoptionalvibrator
isenabled.Itblinkswhiletheoptionalvibratoris
running.
•BlastLED—indicatesthattheBlastfunctionis
beingused
Specications
Note:Specicationsanddesignaresubjectto
changewithoutnotice.
TGS300TGS600TGS1100
Hopper
height
53cm(21-7/8
inches)
65cm(25.75
inches)
86cm(34
inches)
Hopperwidth74cm(29
inches)
97cm(38
inches)
112cm(44
inches)
Hopperdepth38cm(15
inches)
53cm(21
inches)
61cm(24
inches)
Weight
(empty)
31kg(70lb)46kg(101lb)69kg(152lb)
Capacity0.08m3(3ft3)0.2m3(6ft3)0.3m3(11ft3)
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
MountingtheSpreader
EquippedwiththeSlide-In
Attachment
1.Ensurethatthespreadercontrollerisoff.
2.Slidethehitchofthespreaderintothereceiver
hitchofyourvehicleandlineupthesecondhole
onthespreaderhitchwiththeholeinthehitch
ofyourvehicle(Figure19).
Note:Ifthespreadercontactsthebumperof
yourvehicle,slidethespreaderoutandalignthe
rstholeofthespreaderhitchinstead.
DANGER
Thespreaderisheavyandcouldcause
seriousinjuryifdropped.
Ensurethatyourfootingisstable,and
avoidliftingthespreaderonslipperyor
unevensurfaces.
g031019
Figure19
3.Securethespreaderhitchtothevehiclehitch
usingtheclevispinandcotterhairpin.
4.Rotatethepadsonthestabilizerarmsuntilthey
aretightagainstyourtruckbumperandtighten
thejamnuttosecurethem.
5.Slidetheendsoftheratchetstrapsbetweenthe
bumperandtailgateonyourvehicleandattach
themtoasolidpointonthetruckframerail.
6.Removetheweathercapsfromboththevehicle
andspreaderwireharnesses,andplugthe
spreaderharnessintothevehiclewireharness.
11

RemovingtheSpreader
EquippedwiththeSlide-In
Attachment
1.Ensurethatthespreadercontrollerisoff.
2.Unplugthespreaderwireharnessfromthe
vehiclewireharnessandattachtheweather
capstoeachend.
3.Loosentheratchetstrapsandstabilizerarms.
4.Removethecotterhairpinandclevispinfrom
thevehiclehitch.
5.Slidethespreaderoutofthereceiverhitchof
yourvehicle(Figure20).
DANGER
Thespreaderisheavyandcouldcause
seriousinjuryifdropped.
Ensurethatyourfootingisstable,and
avoidliftingthespreaderonslipperyor
unevensurfaces.
g031019
Figure20
6.Movethespreadertoyourstoragearea.
MountingtheSpreader
EquippedwiththeRT3Attachment
1.Ensurethatthespreadercontrollerisoff.
2.RotatethelockingleverontheRT3attachment
totheLOCKposition(Figure21).
g031013
Figure21
1.Lockinglever
3.Gripthespreaderrmlyandstepontheleg
assemblytorotateitbackuntilthebottompinof
theRT3attachmentclearsthehookontheRT3
hitch(Figure22).
DANGER
Thespreaderisheavyandcouldcause
seriousinjuryifdropped.
Ensurethatyourfootingisstable,and
avoidliftingthespreaderonslipperyor
unevensurfaces.
g031020
Figure22
1.RT3hitchhook3.Stephere
2.Bottompin
4.Pushthespreaderforwardandlowerthebottom
pinoftheRT3attachmentontothehitchhook.
5.Tipthespreaderuprightuntilthetoppinofthe
RT3attachmentlocksintoplace.
12

DANGER
Thespreaderisheavyandcouldcause
seriousinjuryorpropertydamageifit
fallsoffyourvehicle.
EnsurethatthetoppinoftheRT3
attachmentisfullylockedintoplaceand
thatthesafetylatchisdown.
6.Rotatethepadsonthestabilizerarmsuntilthey
aretightagainstyourtruckbumperandtighten
thejamnuttosecurethem.
7.Slidetheendsoftheratchetstrapsbetweenthe
bumperandtailgateonyourvehicleandattach
themtoasolidpointonthetruckframerail.
8.Stepontheleg-assemblywheelstopivotthem
andstowthemunderthelegassembly(Figure
23).
g031257
Figure23
1.Leg-assemblywheels
9.Removetheweathercapsfromboththevehicle
andspreaderwireharnesses,andplugthe
spreaderharnessintothevehiclewireharness.
RemovingtheSpreader
EquippedwiththeRT3Attachment
1.Ensurethatthespreadercontrollerisoff.
2.Unplugthespreaderwireharnessfromthe
vehiclewireharnessandattachtheweather
capstoeachend.
3.Pivottheleg-assemblywheelsfromunderthe
spreader(Figure24).
g031258
Figure24
1.Leg-assemblywheels
4.Loosentheratchetstrapsandstabilizerarms.
5.RotatethelockingleverontheRT3attachment
totheUNLOCKposition(Figure25).
g031021
Figure25
1.Lockinglever
6.Tiltthespreaderdowntoreleasethetoppinof
theRT3attachment(Figure26).
13

g031020
Figure26
1.RT3hitchhook3.Stephere
2.Bottompin
7.Gripthespreaderrmlyandstepontheleg
assemblytorotateitbackuntilthebottompinof
theRT3attachmentclearsthehookontheRT3
hitch(Figure26).
DANGER
Thespreaderisheavyandcouldcause
seriousinjuryifdropped.
Ensurethatyourfootingisstable,and
avoidliftingthespreaderonslipperyor
unevensurfaces.
8.Pullthespreaderbackandlowerittotheground.
9.Movethespreadertoyourstoragearea.
LoadingtheSpreader
Important:Onlyusesaltinthespreader.Other
materialscouldcausedamagetothemachine.
1.Ensurethatthespreaderissecurelymountedto
yourvehicleandisnotoverslipperyoruneven
terrain.
2.Removethehoppercoverandensurethatthe
topscreenisinstalledandclosed.
3.Determinetheamountofmaterialthatyou
cansafelytransportinyourspreader;referto
Specications(page11).
4.Fillthehopperusingthefollowingmethods:
•Ifusingbaggedmaterials,placethebagon
thetopscreenbagsplitterandworkitback
andforthtosplitthebag.Continuetomove
andshakethebaguntilitisempty.
Note:Have2peopleliftbagsweighing
morethan18kg(40lb).
Note:Keepyourhandsandngersclearof
thebagsplitterwhenloadingmaterials.
•Ifusingdrybulkmaterials,loadthematerials
intothehopperthroughthetopscreento
breakupanylarge,impassablechunksthat
mayclogthespreader.
OperatingtheSpreader
DANGER
Hands,feet,andclothingcangetcaughtin
themovingpartsofthespreaderandcause
seriousbodilyinjuryandlossoflimbs.
Keepyourhands,feet,andclothingawayfrom
themovingspinnerandattachmentpoints.
CAUTION
Thespreaderthrowsmaterialatahighspeed
thatcouldcauseminorinjuriestobystanders.
Bystandersshouldstayaminimumof7.6m
(25ft)awayfromoperatingspreaders.
1.Startthevehicle.
2.PressthePowerbuttontoturnonthespreader
controller.
3.PressthePowerbuttonasecondtimeto
activatethespreader.
Note:Alwayscheckforbystandersbefore
startingthespreader.
4.Usethespeeddialtosetyourdesiredspinner
speed.
Note:Thespinnerspeeddetermineshow
quicklythematerialisspreadaswellashowfar
itisthrown.
5.Whilespreading,youcanpresstheBlastbutton
tomomentarilyincreasethespeedofthespinner
motor.
6.PressthePowerbuttonwhenyouarenished
spreadingtostopthespreader.
7.PressandholdthePowerbuttonfor3seconds
orturnoffyourvehicletoturnoffthespreader
controller.
14

FreeingaClog
ThespreadercontrollerilluminatesAMBERLEDwhen
thespreaderisattemptingtoclearajam.
ThespreadercontrollerilluminatesFLASHINGREDLED
whenthespreaderisunabletoclearthejam.
Iftheclogisnotclearedautomatically,disconnectthe
spreaderwireharnessandmanuallyfreetheclog.
UnloadingtheSpreader
1.Positionthespreaderintheareawhereyou
wanttodepositthematerial.
2.Unloadthespreaderusingeitherofthemethods
below:
•Turnonthespreadercontrollerandrunthe
spreaderuntilthehopperisempty.
CAUTION
Thespreaderthrowsmaterialatahigh
speedthatcouldcauseminorinjuries
tobystanders.
Bystandersshouldstayaminimum
of7.6m(25ft)awayfromoperating
spreaders.
•Unplugthespreaderfromthevehiclewire
harness,andshoveloutthematerial.
AdjustingtheMaterial
Deectors
Youcanadjustthematerialdeectorsbyinserting
thedeectorpinsintothestaggeredholesnearthe
spinner(Figure27).
g031018
Figure27
1.Materialdeectorpins
Youcanadjustthespreadpatternbypositioningthe
deectorsasshowninFigure28.
g029499
Figure28
DeectionSettings
1.Driversideopen3.Bothsidesopen
2.Passengersideopen
OperatingTips
•Knowtheareainwhichyouareworking;hidden
obstructionssuchascurbs,sidewalks,manhole
covers,andpipescandamageyourspreaderor
vehicle.
•Donotlettheicebuildup;alwaysstartassoon
aspossible.
•Alwayswearyourseatbeltwhenspreading.
•Alwaysremembertospreadatasafespeed.
Spreadingfastercanbehardonyourvehicleas
itsloadisgreatlyincreased.
•Neverrideonorputbodypartsintothespreader
whileservicingoroperatingit.
15

Troubleshooting
ProblemPossibleCauseCorrectiveAction
1.Thespadeconnectorisnotconnected
totheignitionswitchpowersource.
1.Connectthespadeconnectortothe
ignitionswitchpowersource.
2.Thetheignitionswitch,battery,or
groundconnectionsarecorroded.
2.Cleantheignitionswitch,battery,and
groundconnections.
3.Thevehiclesidecircuitfuse,40A
in–linefuse,or5Ain-linefuseinthe
vehiclesideharnessisbad.
3.Replacethefuses.
Thecontrollerhasnopower.
4.Thecontrollerisnotpluggedintothe
wireharness.
4.Pluginthecontroller.
1.Thespreaderandvehiclewire
harnessesarenotconnected.
1.Connectthewireharnesses.
2.Thecontrollerisnotpluggedintothe
wireharness.
2.Pluginthecontroller.
Thespinnermotordoesnotworkorthe
PowerLEDisred.
3.Thespinnermotorisnotconnectedto
thespreadersideharness.
3.Connectthewireharnesses.
ThePowerLEDisashingred.1.Thespreaderisjammed.1.RefertotheFreeingaClogsection.
1.Theconnectionbetweentheaugerand
spinnerandthemotorshaftisbad.
1.ContactyourAuthorizedService
Dealer.
Thespinnermotorworksbutthespinner
andaugerarenotturning.
2.Theconnectionbetweenthemotor
shaftandthemotorhubisbad.
2.ContactyourAuthorizedService
Dealer.
16
