Bounce LED SIGNATURE Series User manual

Blaster
SIGNATURE SERIES

Blaster
SIGNATURE SERIES
4.5W
360lm
5 Years
15 Modules per chain
68
MODULE DIMENSIONS
POWER OUTPUT
LUMENS
WARRANTY
SERIES CONNECTIVITY
IP67 (Suitable for outdoor use)
IP RATING
33 21
The Blaster is the ultimate sidelit solution for large size
cabinets. Packing an impressive 4.5W per module the
Blaster projects a sheet of light up to 1.5M
150
-
300
SUITABLE FOR SIGN DEPTH
DOUBLE-SIDED SINGLE SIDED
70%
200
-
420
(mm) (mm)
50%
3500K
6500K
COLOUR TEMPERATURES AVAILABLE
SALES & SUPPORT
PH 02 9517 3222 | E [email protected]
www.bounceled.com.au
Micro
Apex
Aspect
Luminaire
SIGNATURE SERIES / BACK LIGHT
0.48W
0.96W
1.44W
3.0W
50lm
100lm
150lm
310lm
5YR
5YR
5YR
5YR
34x19x7mm
52x19x7mm
75x19x7mm
60x60x7mm
50/series
40/series
30/series
25/series
45-100mm
60-150mm
80-200mm
120-300mm
Blade
Blade Plus
Bolt
SIGNATURE SERIES / SIDE LIGHT
Blaster
2.88W
6.0W
3.0W
4.5W
240lm
540lm
250lm
360lm
5YR
5YR
5YR
5YR
100x26x11mm
150x30x14mm
63x33x15mm
68x33x21mm
20/series
10/series
20/series
15/series
60-120mm
50-125mm
100-280mm
150-300mm
3000 / 6500K
3000 / 6500K
6500K
6500K
3000 / 6500K
3000 / 6500K
6500K
3000 / 6500K

Not sure where to start?
Use the complimentary Bounce Wizard online tool to generate
LED layouts and calculate exactly how many Bounce LED modules
you’ll need to illuminate your channel letters and sign cabinets. bounceled.com.au/wizard
215 mm
MAX. PITCH
(MODULE SPACING)
55°15°
ASYMMETRIC VIEWING ANGLE
0° 10° 20° 30° 40°
50°
60°
70°
80°
90°
100°
50°
60°
70°
80°
90°
100°
10°20°30°40°
0° 0.2
30
60
90
120
150
0.4 0.6 0.8 1.00.20.40.60.81.0
BEAM DISTRIBUTION DETAIL
SALES & SUPPORT
PH 02 9517 3222 | E [email protected]
www.bounceled.com.au
Micro
Apex
Aspect
Luminaire
SIGNATURE SERIES / BACK LIGHT
0.48W
0.96W
1.44W
3.0W
50lm
100lm
150lm
310lm
5YR
5YR
5YR
5YR
34x19x7mm
52x19x7mm
75x19x7mm
60x60x7mm
50/series
40/series
30/series
25/series
45-100mm
60-150mm
80-200mm
120-300mm
Blade
Blade Plus
Bolt
SIGNATURE SERIES / SIDE LIGHT
Blaster
2.88W
6.0W
3.0W
4.5W
240lm
540lm
250lm
360lm
5YR
5YR
5YR
5YR
100x26x11mm
150x30x14mm
63x33x15mm
68x33x21mm
20/series
10/series
20/series
15/series
60-120mm
50-125mm
100-280mm
150-300mm
3000 / 6500K
3000 / 6500K
6500K
6500K
3000 / 6500K
3000 / 6500K
6500K
3000 / 6500K

Secure LEDs by gluing modules in place.
4
WARNING Please read these instructions completely and carefully.
Risk of electrical shock. Disconnect power before servicing or installing product
Installation Guide
Ensure the inside of your channel letter or sign box is clean and
free of debris. For best illumination ensure the inside of the box
is white (matte finish preferred).
Using supplied LED layout, remove tape from module and press in
place. For best illumination, install modules two-thirds of the way
towards the back of the box for single sided signs and centralised
for double-sided signs
1 2
Drill a suitably sized hole out the back of the sign for connection
to DC power supply.
5
Note that LEDs are only cuttable every 3x modules. This is
indicated by a printed red marking on the wire.
Cut only where marked
3
Connect modules from the sign to power supply, making sure to
not exceed 15 modules per series. Exceeding 15 modules per
series will lead to voltage drop and uneven illumination.
6
SALES & SUPPORT
PH 02 9517 3222 | E [email protected]
www.bounceled.com.au

PLEASE CONTACT US FOR FURTHER WARRANTY INFORMATION
PH 02 9517 3222 | E [email protected]
www.bounceled.com.au
LED Product Warranty
LIMITED WARRANTY | Subject to change without notice
Bounce LED is committed to providing defect-free products that will give the purchaser years of trouble-free operation. All
production facilities maintain strict quality assurance standards and our products are have been designed and thoroughly
tested ensure the highest quality.
Bounce LED products are warranted to meet the performance criteria outlined in the written data sheets and specifications
and are to be free from defects in materials and workmanship for the warranty period stated. Should any LED products fail to
perform as specified during the warranty period, Bounce LED will replace all defective product in accordance with the terms
and conditions.
Modules must be installed with qualified constant voltage SMPS with international certificate to guarantee warranty.
TERMS AND CONDITIONS
This warranty is based on reasonable indoor or outdoor usage in architectural and/or signage applications for image
identification, when installed and used in accordance with instructions from Bounce LED. Normal operating conditions are
defined as 8-12 hours per day, 7 days per week, continuous use in typical outdoor heat and humidity, and environmental
conditions as stated in our product specification.
All LED systems, to varying degrees, have some amount of light degradation over the life of the product. Bounce LED designs
all of its LED systems to minimise this light degradation but considers this a normal part of LED technology.
This warranty is valid when the LED products of Bounce LED are properly installed and wired in accordance with all
instructions, building codes, the latest domestic and international safety agencies that are recognised as having applicable
safety requirements.
Any improper use in conditions that are not stated in Bounce LED’s written data sheets and instruction, or stated herein,
including the use of third party dimming, flashing or other effect devices, extreme environmental conditions or any other
unintended usage will void this warranty.
LIMITATION OF LIABILITY
Bounce LED is committed to making high quality lighting products. Returning of defective products will help us monitor and
further improve product quality. Repair or replacement of the product is the sole remedy available.
Under no circumstance shall Bounce LED be liable for any incidental or consequential loss or damage whatsoever arising out
of, or in any way related to any defect in or non-performance of the products. No warranty of merchantability or fitness for a
particular purpose is made or implied.
Furthermore, Bounce LED shall not be responsible for any other costs, including installation or field support labour or loss of
profits, income or revenue. Additionally, any drawing, layout, quotation or other communication regarding suggested product
type, amount of usage is for reference only and should be treated as an estimate.
Bounce LED shall not be responsible for minimum illumination levels or other performance criteria that is not stated in Bounce
LED’s written data sheets and instructions, or stated herein.
Bounce LED reserves the right to test and examine all products returned under this warranty to evaluate proper usage,
determine the cause of failure, and make a determination, in its sole judgement whether the products are defective and
covered by this warranty.
