6 or 10-Year Limited Tank Warranties / 6-Year Limited Warranty on Component Parts.
For more information on warranty, please visit www.bradfordwhite.com
For products installed in USA, Canada and Puerto Rico. Some states do not allow limitations on warranties. See complete
copy of the warranty included with the heater.
MANUFACTURED UNDER ONE OR MORE OF THE FOLLOWING U.S. PATENTS: 5,954,492; 5,761,379; 5,943,984; 5,081,696; 5,988,117; 6,142,216; 5,199,385; 5,574,822; 5,372,185; 5,485,879; 5,277,171;
(B1)5,341,770; 5,660,165; 5,596,952; 5,682,666; 4,904,428; 5,023,031; 5,000,893; 4,669,448; 4,829,983; 4,808,356; 5,115,767; 5,092,519; 5,052,346; 4,416,222; 4,628,184; 4,861,968; 4,672,919; Re. 34,534;
7,270,087 B2. OTHER U.S. AND FOREIGN PATENT APPLICATIONS PENDING. CURRENT CANADIAN PATENTS: 1,272,914; 1,280,043; 1,289,832; 2,045,862; 2,112,515; 2,108,186; 2,107,012; 2,092,105; 2,409,271.
Defender Safety System®,Vitraglas®and Hydrojet®are registered trademarks of Bradford White®Corporation.
103-B-0508-A
Photo is of
DS1-50S6FBN
The Direct Vent FVIR Defender Safety System®Models Feature:
■Closed Combustion—All air for combustion is taken directly from the
outside. The co-axial vent pipe (pipe inside a pipe) draws combustion air in
through the outer pipe (5"), and exhausts the products of combustion through
the inner pipe (3"). The co-axial vent pipe at the top of the unit can be rotated
for venting flexibility.
■Reinforced Seals—Seals surround the closed combustion chamber and the
FVIR inner door, preventing the ignition of flammable vapors outside of the
water heater.
■Piezo Igniter—Easy and quick lighting of the pilot burner by push button.
■Pedestal Base—Rugged and durable base allows easy transport and
positioning, corrosion resistant contact with floor.
■Maintenance Free—The co-axial vent piping and the closed combustion
chamber with reinforced seals do not require regular cleaning under normal
operating conditions.
■Sight Window—Offers a view into the combustion chamber to observe the
operation of the pilot and burner.
■No Electrical Power Necessary.
■Factory installed Hydrojet®Total Performance System—Cold water inlet
sediment reducing device. Helps prevent sediment build up in tank. Increases
first hour delivery of hot water while minimizing temperature build up in tank.
■Vitraglas®Lining—Bradford White water heater tanks are protected from the
corrosive effects of hot water by an exclusive ceramic porcelain-like coating.
The BradfordWhite high silica Vitraglas®lining provides a tough interior surface
for our water heater tanks.
■Fully Automatic Controls—Built-in gas pressure regulation and energy cut-
off switch.
■Optional Vent Kits—Allow for up to 8 foot max vertical and 8 foot max
horizontal (2.4 meters). All DS models must be terminated horizontally.
■1" Non-CFC Foam Insulation—Surrounds the tank surface, saving energy
by retarding loss of heat.
■Water Connections—3/4" NPT factory installed true dielectric fittings extend
water heater life and eases installation.
■FactoryInstalled Heat Traps—Design incorporates a flexible disk that
reduces heat loss in piping and eliminates the potential for noise generation.
■Protective Magnesium Anode Rod—Provides added protection against
corrosion for long trouble-free service.
■Flue Baffle—Maximizes the amount of heat absorbed by the tank and
reduces heat loss during standby periods.
■Steel Tank—Heavy gauge steel automatically formed, rolled and welded.
■T&P Relief Valve—Included.
■Brass Drain Valve.
■Design Certified by CSA International (formerly AGA and CGA).
Residential Direct Vent
Energy Saver Gas Water Heater

Residential Direct Vent Water Heater
NATURAL GAS AND LIQUID PROPANE GAS
Direct Vent Energy Saver Models Meet or exceed ASHRAE 90.1b (current standard) C.E.C. Listed
80% Recovery Efficiency
Model
Number
Approx.
Shipping
Weight
lbs.
A
Floor
to Center
Line of
Vent
in.
B
Jacket
Dia.
in.
Capacity Recovery at
90°F Rise*
DS1-40S6FBN
DS1-50S6FBN
U.S.
Gal.
40
50
Imp.
Gal.
33
42
Nat.
BTU/Hr.
Input
38,000
42,000
LP
BTU/Hr.
Input
36,000
40,000
Nat.
U.S.
GPH
41
45
Nat.
Imp.
GPH
34
37
LP
U.S.
GPH
39
43
LP
Imp.
GPH
32
36
631/4min.
721/4min.
162
181
20
20
Model
Number
Approx.
Shipping
Weight
kg.
A
Floor
to Center
Line of
Vent
mm.
B
Jacket
Dia.
mm.
Capacity Recovery at
50°C Rise*
DS1-40S6FBN
DS1-50S6FBN
Liters
151
189
Nat.
kW
Input
11.1
12.3
LP
kW
Input
10.5
11.7
LP
Liters/
Hour
148
163
Nat.
Liters/
Hour
155
170
1607
1835
F
Floor
to Top
of Heater
in.
493/4
583/4
F
Floor
to Top
of Heater
mm.
1264
1492
E
Floor
to Gas
Conn.
in.
147/8
147/8
E
Floor
to Gas
Conn.
mm.
378
378
D
Floor
to T&P
Conn.
in.
431/2
521/4
D
Floor
to T&P
Conn.
mm.
1105
1327
H
Floor
to Water
Conn.
in.
503/4
593/4
H
Floor
to Water
Conn.
mm.
1289
1518
K
Depth
in.
299/16
299/16
K
Depth
mm.
737
737
C
Vent
Size
in.
3-5
3-5
C
Vent
Size
mm.
76-127
76-127
73
82
508
508
X
C
A
B
F
E
H
Y
73/4"
K
D
Meets NAECA Requirements
General
All gas water heaters are certified at 300 PSI test pressure (2068 kPa) and 150 PSI working pressure (1034 kPa). All potable water connections are 3⁄4" NPT
(19mm) on 8" (203mm) centers. All gas connections 1⁄2" (13mm).
All models design certified by CSA International (formerly AGA/CGA), ANSI Z-21.10.1 and peak performance rated.
Dimensions and specifications subject to change without notice in accordance with our policy of continuous product improvement.
Suitable for Water (Potable) Heating and Space Heating.
Toxic chemicals, such as those used for boiler treatment, shall NEVER be introduced into this system. This unit may NEVER be connected to any existing
heating system or component(s) previously used with a non-potable water heating appliance.
Optional vent kit :
Kit “A” Telescopes from 43⁄4"to 511⁄16" Part No. 243-41260-00
Kit “B” Telescopes from 61⁄2"to 93⁄16" PartNo. 243-41331-00
Kit “C” Telescopes from 133⁄4"to 2311⁄16" PartNo. 243-41029-00
Kit “D” Telescopes from 4913⁄16"to 9513⁄16"Part No. 243-41424-00
Horizontal Vent Termination Only.
Please specify part number when ordering optional vent kit.
For additional information, please reference the installation instructions.
Printed in U.S.A.
103-B-0508-A
©2008, Bradford White Corporation. All rights reserved.
Ambler,PA
For U.S. and Canada field service, contact your professional installer or local BradfordWhite sales representative.
Sales 800-523-2931 ●Fax [phone] / Technical Support800-334-3393 ●Fax [phone] ●Warranty 800-531-2111 ●Fax [phone]
International: Telephone [phone] ●Telefax 215-641-9750 / www.bradfordwhite.com
Sales / Technical Support866-690-0961 /905-238-0100 ●Fax [phone] /www.bradfordwhite.com
All Propane models feature a Titanium Stainless Steel propane burner. For Propane (LP) models change suffix "BN" to "SX".
For 10 year models, change suffix from “6” to “10”.
*Based on manufacturers rated recovery efficiency.
The water heater is shipped with a standard vent kit. Vent Kit components are: 3" Vent tube and elbow, 5" Air Intake tube and elbow, Vent terminal and
hardware, Inner and Outer wall terminal mounting flange, RTV silicone sealant.
Length “X”
Height “Y”
10"
143/4"to 1511/16"
161/2" to 193/16"
233/4" to 3311/16"
371/2" to 573/8"
5913/16" to 10513/16"
Order Kit A
Order (2) Kit A
Order Kit A
Order Kit A
Order Kit C & A
Order Kit D & A
Order Kit B
Order Kit A & B
Order (2) Kit B
Order Kit B
Order Kit C & B
Order Kit D & B
Order Kit C
Order Kit A & C
Order Kit B & C
Order (2) Kit C
Order (3) Kit C
Order Kit D & C
Order Kit D
Order Kit A & D
Order Kit B & D
Order Kit D
Order Kit C & D
Order (2) Kit D
No Add’l. Kit Req’d.
Order Kit A
Order Kit B
Order Kit C
Order (2) Kit C
Order Kit D
133/4" to 143/16" 15" to 1711/16"22
1/4" to 323/16"58 5/16" to 1045/16"36" to 557/8"
The Vent tube and Air Intake tube provided with the heater telescopes from 133⁄4"to 2311⁄16".
The kits found in the bold frame areneeded in addition to the vent and air intake tube
provided with the water heater (utilizes the vent tube provided).
The kits found outside the bold frame do not utilize the vent tube provided with the
standard vent kit.
For vent distances not found in the selection chart above, please contact the
Product Department for sizing recommendations.
