Bradley Terreon Multi-Fount Series User manual

Bradley Multi-Fount™ Series
MF2949/IR
Terreon® Quadra-Fount™
Wall-Hung Washfountain
with Adaptive Infrared
Control
(Standard* & Juvenile Height)
*ADA compliant when mounted at recommended
heights
Installation
Instructions
Table of Contents
Pre-Installation Information . . . . . . . . . . . . . . . . . . . .2
Washfountain Component Parts . . . . . . . . . . . . . . . . .3
Installation Instructions . . . . . . . . . . . . . . . . . . . . .4-10
Cleaning Instructions . . . . . . . . . . . . . . . . . . . . . .11-12
Solenoid Valve Troubleshooting . . . . . . . . . . . . . . .13
215-1249 Rev. H; EN 03-045
© 2003 Bradley Corporation
Page 1 of 13 9-15-2003
P.O. Box 309, Menomonee Falls, WI 53052-0309
TEL. 1-800-BRADLEY FAX [phone]
http://www.bradleycorp.com
IMPORTANT
Read through this installation manual to
ensure proper installation.
Make sure that water supply is completely
off before installation is begun.
When drilling into tile, masonry, or other
hard materials to install wall and floor
anchors, be sure to wear safety goggles
to prevent eye injuries.
Wall anchors used must have a minimum
pull-out rating of 1,000 lbs.
The Quadra-Fount™ requires a water
flowing pressure of at least 20 psi but no
greater than 100 psi.
File these instructions with the owner or
maintenance department.

Terreon® Quadra-Fount™ Wall-Hung Washfountain with Adaptive Infrared Control
MF2949/IR Installation Instructions
Bradley Corporation • 215-1249 Rev. H; EN 03-045
29-15-2003
Terreon® Quadra-Fount™ Washfountain Warranty
Bradley Corporation warrants to commercial and institutional purchasers only each unit free from defects in material and
workmanship under normal use and service upon the following terms and conditions.
1. This warranty is limited to replacing or repairing, at our option, transportation charges prepaid by the purchaser, any
Bradley unit or part thereof which our inspection shall show to have been defective within the limitations of this
warranty.
2. The period during which Terreon® Quadra-Fount™ components are warranted is as follows:
• Terreon® side panels, bowl, and top cover warranted for 2 years.
• All other Quadra-Fount™ components warranted for 1 year.
3. This warranty does not cover installation or any other labor charges and does not apply to any units which have been
damaged by accident, abuse, improper installation or improper maintenance.
4. The replacement or repair of defective units as stated in this warranty shall constitute the sole remedy of the purchaser
and the sole liability of Bradley Corporation under this warranty. Bradley Corporation shall not otherwise be liable
under any indirect damages caused by defects in the repair or replacement thereof.
5. This warranty extends only to commercial and institutional purchaser and does not extend to any others, including
consumer customers of commercial institutional purchasers.
6. This warranty is in lieu of all other warranties, expressed or implied, including any implied warranty of merchants
ability or fitness for a particular purpose or otherwise.
Pre-Installation Information
Terreon® material
The Quadra-Fount™ features Terreon®, a durable solid surface material used on the bowl and pedestal.
Terreon® resists stains, burns and impact, and is repairable with everyday cleaners or fine-grit
abrasives.
Adaptive sensor and solenoid valve
Each nozzle is controlled by a separate solenoid valve, allowing each user to activate a flow of
tempered water from one spray nozzle. Each valve uses less than half the maximum amount of hat
water allowed by the ANSI/ASHRAE/IES 90A-1980 Standard.
Adaptive Infrared sensor: The Adaptive sensor modules are housed in the sprayhead. The sensor eyes
are secured behind the sprayhead to protect it from water, soap, and dirt. The sensor is accessible by
removing the top cover. All other electrical components are housed within the pedestal.
Solenoid valve: An electronically controlled solenoid valve serves as the metering mechanism. Few
moving parts provide reliable metering performance and the solenoid is unaffected by chemicals and
minerals often present in municipal water supplies.
Barrier-free and ADA compliant
The Terreon® Quadra-Fount™ with Adaptive Infrared is designed to comply with all ADA guidelines
on reaches, clearances and operation when mounted at recommended height dimensions by the
installer (see page 4 for rough-in and mounting dimensions).

Terreon® Quadra-Fount™ Wall-Hung Washfountain with Adaptive Infrared Control
Installation Instructions MF2949/IR
3
Bradley Corporation • 215-1249 Rev. H; EN 03-045 9-15-2003
Supplies required:
• (6) 3/8" diameter bolts with washers and (6) wall anchors appropriate for your installation.
• 1/2" NPT Hot and cold water supply lines
• Drain trap and waste connection
• Pipe sealant and plumber’s putty
• 110 VAC power source for 110/24 VAC plug-in transformer supplied
• OPTIONAL: Bradley recommends installing an electrical cut-off switch to the unit. This feature
prevents accidental water delivery during regular maintenance and service.
Parts Included with the Wall-Hung Quadra-Fount™
Separate all parts from packaging materials and ensure you have all the parts required for assembly.
If any parts are missing, do not attempt to assemble the Quadra-Fount™ until you obtain all parts.

Figure 1 * Subtract 4" from this dimension for juvenile height model.
Terreon® Quadra-Fount™ Wall-Hung Washfountain with Adaptive Infrared Control
MF2949/IR Installation Instructions
Bradley Corporation • 215-1249 Rev. H; EN 03-045
49-15-2003
Installation Instructions
Step 1: Install the 24 VAC transformer
WARNING: The Tri-Fount™ must be connected with a 24 VAC Class II plug-in
transformer. Connection with 110 VAC could result in personal injury
and will result in damage to the electronics.
IMPORTANT: Consult local electrical codes for the mounting location of the 110/24
VAC Class II plug-in transformer. Compliance and conformity to local
codes and ordinances is the responsibility of the installer.
Step 2: Rough-in piping and install pedestal frame assembly
NOTE: See Figure 1a or 1b for piping rough-in dimensions and wall anchor locations for the
pedestal frame assembly.
IMPORTANT: Make sure that the water is completely shut off before beginning
installation.
1. Rough-in hot and cold supply lines through the wall.
2. Rough-in a drain waste connection through the wall.
IMPORTANT: Make sure the frame is level when using as a template for drilling
anchor holes.
IMPORTANT: Wall anchors need to withstand 1000 lb. pull force.
3. Drill four 1/2" diameter holes in the wall using the pedestal frame as a template.
4. Secure the pedestal frame to the wall anchors using four 3/8" dia. bolts and washers (supplied by
installer).
1-1/2" (38) Drain
Stub Out 2" (51)
23-1/4"
(591)
8-1/2"
(216)
4-1/4"
(108)
2-1/4"
(57)
4-1/4"
(108)
12"
(305)
25-1/2"
(648)
26-1/2"
(673)
1/2 NPT Cold Supply
Stub Out 1" (25)
1/2 NPT Hot Supply
Stub Out 1" (25)
Finished Floor
110 V GFI ELECTRICAL OUTLET
RECOMMENED LOCATION.
REFER TO LOCAL CODES
BEFORE ROUGH-IN.
**
*
22"
(559)
12"
(305)
3/8" (10) Wall Anchors (6 total)
10"
(254) 9-1/4"
(235) Outline of
Plumbing Opening
Outline of
Wall Frame
18-3/4"
(476)
Finished Floor
110 V GFI ELECTRICAL OUTLET
RECOMMENED LOCATION.
REFER TO LOCAL CODES
BEFORE ROUGH-IN.

Terreon® Quadra-Fount™ Wall-Hung Washfountain with Adaptive Infrared Control
Installation Instructions MF2949/IR
5
Bradley Corporation • 215-1249 Rev. H; EN 03-045 9-15-2003
Pipe Clamp
Stop/Check Valve
Mounting Stud
and 1/4" Nut
Vernatherm
Assembl
Braided Hose
y
Flexible Hose
Filter Washer
Figure 2
Installation Instructions continued . . .
Step 3: Install Vernatherm™ valve
1. Connect the supply hoses to the Vernatherm™ valve as shown.
2. Mount the Vernatherm™ valve assembly to the studs on the pedestal frame using the pipe
straps, 1/4" nuts and washers provided.
3. Connect the 1/2" NPT female end of the stop/check valves to the rough-ins.
5. Insert the filter washers provided into the swivel nut at the end of the supply hoses.
6. Connect the supply hoses to the stop/check valves.
IMPORTANT: The hose attached to the hot water inlet of the Vernatherm™ valve
(marked with red paint) must be connect to the hot water rough-in.
6. Connect the last flexible hose to the Vernatherm™ outlet.
NOTE: The thermostatic mixing valve requires at least 115° F water from the hot water side for
proper operation. As with all lavatories, there will be a delay in obtaining warm water. If the hot
water is too far away from the washfountain, a circulating pump may be required.

Terreon® Quadra-Fount™ Wall-Hung Washfountain with Adaptive Infrared Control
MF2949/IR Installation Instructions
Bradley Corporation • 215-1249 Rev. H; EN 03-045
69-15-2003
Installation Instructions continued . . .
Step 4: Install solenoid assembly
1. Inside the pedestal frame, install the two 1/4-20 x 5/8" screws (supplied with solenoid assembly) in
the mounting holes on the right side of the frame. DO NOT thread the screws completely into the
frame, but allow 5/16" of the screw to be exposed (see Figure 3).
2. Hang the solenoid assembly on the exposed portion of the screws.
Connect Flexible
Hose at this end
Solenoid
Assembly
Pedestal
Frame
1/4"-20 x 5/8"
Screws
Figure 3
Step 5: Install pedestal panels
1. Install three 1/4-20 x 1/2" screws
(provided) on each pedestal panel so
that about 3/16" of each screw is
exposed. DO NOT tighten screws
(see Figure 4).
2. Slide each of the pedestals onto the
frame assembly so that the exposed
portions of the screws fit into the
slots on the frame assembly. Slide the
pedestal panel toward the wall until
the screws fit in the narrow end of the
notches in the frame assembly.
3. Tighten the screws to secure the
pedestal panels to the frame assembly.
Screw Narrow
End of
Notch
Right
Pedestal
Left
Pedestal
Figure 4

Terreon® Quadra-Fount™ Wall-Hung Washfountain with Adaptive Infrared Control
Installation Instructions MF2949/IR
7
Bradley Corporation • 215-1249 Rev. H; EN 03-045 9-15-2003
Installation Instructions continued . . .
Step 6: Assemble and install bowl
1. Install two 3/8" wall anchors (supplied by installer). These will be used to mount the bowl to the
wall.
WARNING: Do not attempt to install the bowl by yourself. To prevent injury, install
the bowl with the assistance of another person and always use
appropriate lifting procedures.
2. With the help of an an assistant, carefully lift the bowl on the pedestal frame using appropriate
lifting procedures. Ensure bowl remains 3 - 4 inches from the wall.
WARNING: Do not leave the bowl on the pedestal unsupported, as it may fall and
cause personal injury or damage to property.
3. Install the 2 wall anchor brackets to the back of the bowl using the 3/8-16 x 2" hex head bolts,
13/32" I.D. plain washers, anchor plates, lockwashers and hex nuts provided (see Figure 5).
4. Uncoil the infrared sensor leads and plastic tubing from the rear of the backsplash.
5. Slide the bowl back to the wall and secure the bowl’s wall brackets to the wall anchors with two
3/8" diameter bolts and washers (supplied by installer).
6. Fasten the front underside of the bowl to the upper bracket on the pedestal frame with the two
1/4-20 x 1/2" round head screws and 5/16" I.D. washers supplied.
7. Install the drain spud in the bowl using plumber’s putty (see Figure 6).
NOTE: Discard rubber gasket included with drain spud. It cannot be used in this application.
8. From beneath bowl, thread the washer and locknut onto the drain spud and tighten the locknut
against the bowl.
9. Install strainer in the bowl drain using the two #10-24 x 1/2" oval Phillips head screws supplied.
Back View of Washfountain Bowl Figure 6
Spud
Washer
#10-24 x 1/2"
Screw for
Strainer
Drain
Spud
Dome
Strainer
Discard this
washer; it is not
used on
washfountains.
Washfountain
Bowl
Spud
Locknut
Drain Assembly
Figure 5

Terreon® Quadra-Fount™ Wall-Hung Washfountain with Adaptive Infrared Control
MF2949/IR Installation Instructions
Bradley Corporation • 215-1249 Rev. H; EN 03-045
89-15-2003
Installation Instructions continued . . .
Step 7: Electrical and supply connections
WARNING: Adaptive Infrared control must be connected with a 24 VAC Class II
transformer. Connections to 110 VAC can cause personal injury and
will result in damage to the electronics.
IMPORTANT: Connection of leads other than shown may cause permanent damage
to the sensor.
IMPORTANT: Compliance and conformity to local codes and ordinance is the
responsibility of the installer.
NOTE: The solenoid valves have been pre-wired.
1. Snap the sensor circuit plug from the bowl into the solenoid circuit plug located on the valve bracket.
2. Snap the transformer circuit plug into the female transformer circuit plug located on the valve bracket.
3. Insert four sprayhead supply tubes into four solenoid tube connectors by loosening the tube
connector cap and firmly pushing tubing into tube connector until the tubes are fully seated, then
re-tighten connector cap (see Figure 7.
IMPORTANT: Looking at the back of the Quadra-Fount™ , refer to the sprayheads as
follows: left (L #1), middle (M #2 and #3) and right (R #4). Refer to the solenoid tube
connectors as follows: left (L #1), middle (M #2 and #3) and right (R #4). When
connecting the 1/4" dia. supply tubes from the sprayheads to the solenoid tube
connectors,
• supply tube from sprayhead #1 must be connected to solenoid tube connector #1
• supply tube from sprayhead #2 must be connected to solenoid tube connector #2
• supply tube from sprayhead #3 must be connected to solenoid tube connector #3
• supply tube from sprayhead #4 must be connected to solenoid tube connector #4
4. Connect the flexible hose from the thermostatic mixing valve to the supply inlet on the left side of
solenoid valve assembly.
IMPORTANT: Verify that power to your Quadra-Fount™ is 24 VAC!
Figure 7
Supply Inlet
4-Solenoid Wire Harness Plug
Transformer
Plug
4-Solenoid
Wire
Harness
Solenoid Tube
Connector

Terreon® Quadra-Fount™ Wall-Hung Washfountain with Adaptive Infrared Control
Installation Instructions MF2949/IR
9
Bradley Corporation • 215-1249 Rev. H; EN 03-045 9-15-2003
Installation Instructions continued . . .
Step 8: Check Adaptive operation
1. Check to make sure both stop valves are fully open (refer to Figure 2 on page 5).
2. Turn on the main water supply to the Quadra-Fount™ and check for leaking.
3. Pass your hand in front of each sensor until air is purged from the lines.
Step 9: Install top cover
1. Install the threaded rods into the holes on the bottom of the top cover (see Figure 8).
2. Carefully place the top cover with threaded rods on top of washfountain sprayhead.
3. Inside the pedestal assembly of the washfountain (use front access), slide the anchor plate onto
the threaded rods and secure anchor plate against bowl using the wing nuts provided.
Figure 8

Terreon® Quadra-Fount™ Wall-Hung Washfountain with Adaptive Infrared Control
MF2949/IR Installation Instructions
Bradley Corporation • 215-1249 Rev. H; EN 03-045
10 9-15-2003
Installation Instructions continued . . .
Step 10: Install access panel
1. Install a #10-32 x 3/8" screw (supplied) through the welded nut on the bottom flange of the
access panel (see Figure 9). DO NOT tighten.
2. Position the access panel by sliding the screw into the bracket slot on the pedestal frame.
3. Secure the access panel to the top of the pedestal frame using the self-retaining screw.
4. Tighten the screw to secure the bottom of the access panel in place.
Self
Retaining
Screw
Acess
Panel
Pedestal
Frame
#10-32 x 3/8"
Screw
Bracket Slot
Figure 9

Terreon® Quadra-Fount™ Wall-Hung Washfountain with Adaptive Infrared Control
Installation Instructions MF2949/IR
11
Bradley Corporation • 215-1249 Rev. H; EN 03-045 9-15-2003
Cleaning and Maintenance Instructions for Terreon®
Material Description: Terreon® is a NAHB Certified densified solid surface material composed of polyester
resin and is resistant to chemicals, stains, burns and impact. Surface damage can be easily repaired with
everyday cleansers or fine grit abrasives.
Routine Cleaning: Clean daily or as often as conditions require using a standard commercial or household
cleaner such as Formula 409®or Windex®.
Stubborn Stains: Remove tough stains with Ajax®, Comet®, or Soft-Scrub®and a green Scotch-Brite®pad or
lightly sand in a circular motion with 240 grit wet/dry sandpaper. The finish can be renewed with a maroon
Scotch-Brite pad.
Special Situations for Material
Scratches: Remove scratches with a green Scotch-Brite®pad. The finish can then be renewed with a maroon
Scotch-Brite®pad.
Hard Water Deposits: Remove hard water deposits with a mild solution of vinegar and water. Always rinse
the unit thoroughly after cleaning.
Restoring the surface: Use Hope's®Solid Surface cleaner and polish to refresh and protect the Terreon
Solid Surface material.Bradley recommends additional care and maintenance for the darker colored Terreon,
for complete instructions on this additional maintenance see Bradley document #1505.
IMPORTANT: DO NOT USE STRONG ACID OR ALKALINE CHEMICALS AND
CLEANSERS TO CLEAN TERREON. IF THESE CHEMICALS COME IN
CONTACT WITH THE TERREON SURFACE, WIPE THEM OFF
IMMEDIATELY AND RINSE WITH SOAPY WATER.
AVOID CONTACT WITH HARSH CHEMICALS SUCH AS PAINT REMOVER,
BLEACH, ACETONE, ETC. AVOID CONTACT WITH HOT PANS AND
OBJECTS.
Repair Kits: Terreon®repair kits are available. Contact your Bradley representative or distributor for part
numbers and pricing.
NOTE: Repair kits are made to order and have a shelf life of 30 days.
Brand Names: Use of brand names is intended only to indicate a type of cleaner. This does not constitute an
endorsement, or does the omission of any brand name cleaner imply it’s inadequacy. Many products named are
regional in distribution, and can be found in local supermarkets, department and hardware stores, or through
your cleaning service. It is emphasized that all products should be used in strict accordance with package
instructions.
NOTE: When cleaning units equipped with infrared (electronic eye) activation, it is helpful to turn
off the power to the unit or cover the windows to prevent accidental activation. After the window is
covered, the water will run for approximately 30 seconds and then shut off.

Terreon® Quadra-Fount™ Wall-Hung Washfountain with Adaptive Infrared Control
MF2949/IR Installation Instructions
Bradley Corporation • 215-1249 Rev. H; EN 03-045
12 9-15-2003
Cleaning and Maintenance Instructions for Stainless Steel
Material Description: Stainless steel is extremely durable, and maintenance is simple and inexpensive.
Proper care, particularly under corrosive conditions, is essential. Always start with the simplest solution and
work your way toward the more complicated.
Routine cleaning: Daily or as often as needed use a solution of warm water and soap, detergent, or
ammonia. Apply the cleaning solution per the manufactures instructions and always use a soft cloth or
sponge to avoid damaging the finish.
Stubborn Stains: To remove stains from stainless steel use a stainless steel cleaner and polish such as Ball®
stainless steel cleaner or a soft abrasive. Always follow the manufactures instructions and apply in the same
direction as the polish lines.
IMPORTANT: NEVER USE ORDINARY STEEL WOOL OR STEEL BRUSHES ON
STAINLESS STEEL. ALWAYS USE STAINLESS STEEL WOOL OR
STAINLESS STEEL BRUSHES.
Special Situations for Material
Fingerprints and Smears: To remove fingerprints or smears use a high quality stainless steel cleaner and
polish in accordance with the manufactures instructions. Many of these products leave a protective coating
the helps prevent future smears and fingerprints.
Grease and Oil : To remove grease and oil use a quality commercial detergent or caustic cleaner. Apply in
accordance to the manufactures instructions and in the direction of the polish lines.
Precautions: Avoid prolonged contact with chlorides (bleaches, salts), bromides (sanitizing agents),
thiocyanates (pesticides, photography chemicals, and some foods), and iodides on stainless steel equipment,
especially if acid conditions exist.
IMPORTANT: DO NOT PERMIT SALTY SOLUTIONS TO EVAPORATE AND DRY ON
STAINLESS STEEL.
The appearance of rust streaks on stainless steel leads to the belief that the stainless steel is rusting. Look for the
actual source of the rust in some iron or steel particles which may be touching, but not actually a part of the
stainless steel structure.
NOTE: Strongly acidic or caustic cleaners may attack the steel causing a reddish film to appear. The use of
these cleaners should be avoided.
Brand Names: Use of brand names is intended only to indicate a type of cleaner. This does not constitute an
endorsement, nor does the omission of any brand name cleaner imply its inadequacy. Many products named
are regional in distribution, and can be found in local supermarkets, department and hardware stores, or
through your cleaning service. It is emphasized that all products should be used in strict accordance with
package instructions.

Terreon® Quadra-Fount™ Wall-Hung Washfountain with Adaptive Infrared Control
Installation Instructions MF2949/IR
13
Bradley Corporation • 215-1249 Rev. H; EN 03-045 9-15-2003
Solenoid Valve Troubleshooting
CAUTION: Turn off electrical and water supplies to unit before troubleshooting.
Problem: An individual operating station fails to shut off and drips.
Cause: There is debris trapped between the diaphragm and the valve seat.
Solution: Remove debris between diaphragm and the valve seat.
1. Disconnect the wires to the appropriate solenoid valve by firmly pulling the fully insulated disconnects
(not the wires) from the coil located on top of the valve.
2. Loosen the screw on top of the coil and remove.
3. Using a small wrench, loosen the bonnet nut, unscrewing counterclockwise, and gently tip forward
to remove from the valve body. Be careful not to lose the armature or spring.
4. Remove the diaphragm. Remove any particles that have been trapped between the diaphragm
and the valve seat. Rinse off the diaphragm and inspect for damage. Make sure both orifices are
open.
5. Reassemble in reverse order. Do not overtighten the bonnet nut or you may crack the plastic
valve body. Hand tight plus 1/8 turn is sufficient.
6. Reconnect the wiring per Figure 9 on page 9.
Problem: An individual operating station fails to turn on.
Cause: A failed coil for the valve, or loose electrical connection to the terminal.
Solution: Test the station to determine cause.
1. Disconnect the wires from the coil of an adjacent valve. Disconnect the wires from the problem
valve and reconnect to the adjacent valve.
2. Turn on electrical and water supplies to the unit. Pass your hand in front of the sensor of the
problem station, and the adjacent station should operate.
If the adjacent station operates and cycles normally, replace the coil on the problem valve.
If the adjacent valve fails to turn on, inspect the wires from the sensor cable and preform the
following:
•make sure there are no breaks and that the fully insulated disconnect terminals are firmly
crimped in place;
• turn off electrical and water supplies;
• reconnect to the adjacent valve and turn on electrical and water supplies to the unit;
• pass your hand in front of the sensor. If the station still fails to turn on, replace the sensor.
