Bradley S19-220DCPT User manual

P.O. Box 309, Menomonee Falls, WI USA 53052-0309
PHONE 1-800-BRADLEY FAX [phone]
http://www.bradleycorp.com
Installation
215-1255 Rev. D; EN 06-532G
© 2007 Bradley Corporation
Page 1 of 4 4/30/07
S19-220DCPT
Wall-Mounted Eyewash with
Dust Cover
Table of Contents
Pre-Installation Information . . . . . . . . . . . . . . . .2
Installation Instructions . . . . . . . . . . . . . . . . . . . .3
Assembly of Components . . . . . . . . . . . . . . . . . .4
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

2
S19-220DCPT Installation
4/30/07 Bradley Corporation • 215-1255 Rev. D; EN 06-532G
WARNING
Read this installation manual completely to ensure proper installation, then file it
with the owner or maintenance department. Compliance and conformity to drain
requirements and other local codes and ordinances is the responsibility of the
installer.
Separate parts from packaging and make sure all parts are accounted for before
discarding any packaging material. If any parts are missing, do not begin
installation until you obtain the missing parts.
Flush the water supply lines before beginning installation and after installation is
complete. Test the unit for leaks and adequate water flow. Main water supply to
the eyewash should be “ON” at all times. Provisions shall be made to prevent
unauthorized shutoff.
The ANSI Z358.1 standard requires an uninterruptible supply of flushing fluid at a
minimum 30 PSI (0.21 MPa) flowing pressure. Flushing fluid should be tepid per
ANSI Z358.1.
The inspection and testing results of this equipment should be recorded weekly
to verify proper operation. This equipment should be inspected annually to
ensure compliance with ANSI Z358.1.
Workers who may come in contact with potentially hazardous materials should be
trained regarding the placement and proper operation of emergency equipment
per ANSI Z358.1.
For questions regarding the operation or installation of this product, visit
www.bradleycorp.com or call 1-800-BRADLEY.
Product warranties may also be found under ”Product Information” on our web
site at www.bradleycorp.com.
Installation
THIS
SIDE
UP
Packing List
!
!
!
!
P.O.Box309, MenomoneeFalls, WI 53051
R
TESTTHISUNITEACHWEEK
Test-operatevalve(s) each week and sign below.
Reportany malfunctions immediately.
Ventil(e)wöchentlich im Testbetrieb prüfen, bestätigt
durchUnterschrift. Jegliche Störung sofort melden.
Date
Datum
Date
Signed
Unterschrift
Signe
Date
Date
Date Signed
Signed
Signed
DIESESGERÄT1STWÖCHENTLICHZUPRÜFEN.
ESSAIHEBDOMADAIRE
Testle fonctionnement des valves chaque semaine et
signeen bas. S'il y à quelque chose qui ne va pas fait
unrapport immédiatement.
P.O.BOX309, MENOMONEE FALLS,WI 53052-0309 USA
TEL:1-800-BRADLEY FAX: [phone])
http://www.bradleycorp.com
114-051

3
Installation S19-220DCPT
Bradley Corporation • 215-1255 Rev. D; EN 06-532G 4/30/07
Installation Instructions
NOTE: Flush the water supply line
before beginning installation.
Supplies Required:
• (3) 3/8" wall fasteners and bolts
• Pipe sealant
• Piping to 1/2" IPS water supply inlet
on unit
• Sign-mounting hardware
Step 1: Install inlet drain fittings
NOTE: Top of eyewash heads should be
33"-45" (838mm-1142mm) from floor.
1. Position the inlet drain fitting over
the 1-1/4" drain outlet pipe from
wall.
2. Using the inlet drain fitting as a
template, mark the bolt hole
locations on wall OR install three
suitable fasteners (supplied by
installer) for 3/8" bolts in the wall
at the marked hole locations (see
Figure 1).
3. Bolt the inlet drain fitting to the
wall or wall fasteners using 3/8"
bolts (supplied by installer).
Step 2: Assemble eyewash
1. Assemble eyewash components as
shown in Figure 2 on page 4.
• Apply pipe sealant (supplied by
installer) to all male-threaded
pipe joints.
• Use a strap wrench around pipes
when tightening to prevent
marring.
Step 3: Connect water supply
1. Connect the water supply piping
(supplied by installer) to the 1/2"
IPS inlet on the eyewash.
2. Connect the P-trap and tailpiece to
the 1-1/4 IPS drain outlet on the
eyewash.
3. Mount the safety sign to a wall or
pipe using sign-mounting hardware (supplied by installer).
4. Open the water supply lines. Test for leaks and adequate water flow.
17-1/4"
(438mm)
8-3/4"
(222mm)
5-1/4"
133mm)
13-5/8"
(346mm)
8-1/4"
(210mm)
8-3/4"
(222mm)
14"
(357mm)
2-1/4"
(57mm)
5/16"
(8mm)
MTG.
HOLE
4"
(102mm)
36" (914mm)
Suggested
Height
To Floor
30-1/2" (775mm)
Suggested
Height
To Floor
4-5/8"
(119mm)
Ø10-3/4"
(273mm)
21-1/2"
(546mm)
Figure 1

Assembly of Components and Parts List
4
S19-220DCPT Installation
4/30/07 Bradley Corporation • 215-1255 Rev. D; EN 06-532G
1 S90-301 1 Dust Cover /Receptor Assembly
1.1 111-061 1 Inlet-Drain Fitting
1.2 124-028 1 Gasket
1.3 S90-009 1 Dust Cover Assembly
1.4 173-009 1 Cup Strainer
1.5 S21-071 1 Supply Stem
1.6 S05-091 1 Eyewash Yoke
1.7 269-447 1 Bumper
1.8 161-025 1 Hex Nut
1.9 113-1159 1 Spacer, Drain
2 113-006LQ 1 Pipe 1/2" IPS x 3-1/2" Long
3 169-025 1 Elbow 1/2" IPS Street
4 S30-072 1 1/2" Valve/Handle Prepack
4.1 S27-282 1 1/2" Ball Valve with Nut
4.11 110-215 1 Nut only
4.2 S08-056 1 Handle Assembly
4.3 142-002DA 1 Lockwasher
4.4 153-372R 1 Adapter
5 269-167 1 Tailpiece
6 269-142 1 Trap
7 114-051 1 Safety Sign
8 204-421 1 Emergency Tag
Item Part No. Qty Description Item Part No. Qty Description
P.O.Box 309, Menomonee Falls, WI 53051
R
TESTTHISUNIT EACHWEEK
Test-operate valve(s) each week and sign below.
Report any malfunctionsimmediately.
Ventil(e) wöchentlichim Testbetrieb prüfen, bestätigt
durch Unterschrift.Jegliche Störungsofort melden.
Date
Datum
Date
Signed
Unterschrift
Signe
Date
Date
Date Signed
Signed
Signed
DIESESGERÄT1ST WÖCHENTLICH ZU PRÜFEN.
ESSAI HEBDOMADAIRE
Test le fonctionnement desvalveschaque semaine et
signe en bas. S'il y à quelque chose qui ne va pasfait
un rapport immédiatement.
P.O.BOX 309, MENOMONEE FALLS,W I 53052-0309 USA
TEL:1-800-BRADLEY FAX:[phone])
http://www.bradleycorp.com
114-051
2
4.1
7
4.3
4.11
4.2
4.4
1/2" IPS
Supply Inlet
8
3
5
1-1/4" IPS
Drain Outlet
HANDLE NOTE:
Close the cover and
put the pin through
the clip to keep closed.
6
1
1.6
1.5
Flow Control
ThisEnd
1.4
1.3
1.2
1.1
1.8
1.7 1.9
NOTE: Items 1.1 -1.9 come presasembled as Item 1.
Figure 2
Prepack S30-087 includes items 4.11, 4.2, 4.3, 4.4
