Bradley Verge Crestt Series Quick start guide

Parts & Service
P.O. Box 309
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
[phone]
bradleycorp.com
Table of Contents
Soap Tank Dispenser Components .....................2
P20-230 Rev. B: ECO 22-15-015
© 2023 Bradley
Page 1 of 2 3/3/2023
Verge™Individual & Multi‑Feed
Soap Tank Dispensers
Verge™Soap Dispenser ‑ Crestt Series (6‑3100)
Verge™Soap Dispenser ‑ Metro Series (6‑3300)
Verge™Soap Dispenser ‑ Linea Series (6‑3500)
Verge™Soap Dispenser ‑ Zen Series (6‑3700)
For questions regarding the operation, installation or maintenance of this product, visit bradleycorp.com
or call 800.BRADLEY (800.272.3539).
Product warranties and parts information may also be found under “Resources” on our website at
bradleycorp.com.
Individual Soap Tank
(Shown with Crestt Soap Dispenser)
Multi-Feed Soap Tank
(Shown with Crestt Soap Dispenser)

23/3/2023 Bradley • P20-230 Rev. B: ECO 22-15-015
Soap Tank Dispenser Components
Ref. Part No. Description
1 P15-535 Control Box, Individual
2 P15-541 Control Box, Multi-Feed Soap Tank
3 P15-534 Soap Tank, Individual
4 P15-540 Soap Tank, Multi-Feed
5 P15-531 Soap Pump, Individual
5 P15-565 Soap Pump, Multi-Feed
6 P15-532 Soap Pump Foam, Individual
6 P15-566 Soap Pump Foam, Multi-Feed
7 P15-536 Dispensing Nozzle, Foam Only (5 pk)
8 P15-533 Fill Tube, Individual
9 P15-538 Slip Joint Washer, Individual (5 pk)
10 P15-539 Nut, Individual Soap Tank
11 P15-602 Set Screw, Spring
12 P15-529 Cap Screw, M4 x 10mm (5 pk)
13 P15-530 Allen Wrench, 3mm (5 pk)
Parts List
1
56
7
8
9
11
12
18
13
19
14
20
15
21
16
17
10
2
3 4
Ref. Part No. Description
14 P15-527 Locking Tab
15 P15-528 Wing Nut
16 A14-030 Battery Pack
17 A14-029 AC Adapter, Individual
18 P15-523 Silicone Washer, Crestt (5 pk)
19 P15-524 Silicone Washer, Metro (5 pk)
20 P15-525 Silicone Washer, Linea (5 pk)
21 P15-526 Silicone Washer, Zen (5 pk)
ns P15-576 Soap Sprout Spacers, Crestt
ns P15-596 Shank Assembly Kit, Crestt 6-3100
ns P15-597 Shank Assembly Kit, Metro 6-3300
ns P15-598 Shank Assembly Kit, Linea 6-3500
ns P15-599 Shank Assembly Kit, Zen 6-3700
ns = not shown
