Bradley Verge LVGD1 User manual

Installation
P.O. Box 309
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
[phone]
bradleycorp.com
215-1709 Rev. M: ECN 19-08-037G
© 2020 Bradley
Page 1 of 12 2/24/2020
LVGD1
Verge®Lavatory System – LVGD-Series
with Evero®Natural Quartz Material
Table of Contents
Components..................................2
Supplies Required .............................3
Dimensions ................................3–4
Rough-Ins ...................................5
Frame Mounting...............................6
Mounting Valve to Frame ........................7
Drain Assembly ...............................8
Faucets and Optional Soap Valve .................8
Bowl Mounting ................................9
Strainer and P-Trap ...........................10
Adjust the Temperature ........................10
Trap Cover ..................................11
Cleaning and Maintenance .....................12
U.S. Pat. Nos. D625,792 & D633,992
WARNING
Turn OFF electrical power to the electrical outlets, then unplug all electrical units prior to installation.
Electrical power MUST remain off until installation is complete.
Installer’s hardware must be appropriate for wall construction. Wall anchors must have a minimum pull-out
rating of 1,000 lb.
NOTICE
Make sure that all water supply lines have been flushed and then completely turned off before beginning
installation. Debris in supply lines can cause valves to malfunction.
IMPORTANT
Read this entire installation manual to ensure proper installation. When finished with the installation, file
this manual with the owner or maintenance department. Compliance and conformity to local codes and
ordinances is the responsibility of the installer. Product warranties may be found under “Products” on our
Web site at bradleycorp.com.
Separate parts from packaging and make sure all parts are accounted for before discarding any packaging
material. If any parts are missing, do not begin installation until you obtain the missing parts.
For standard height mounting, do not exceed the recommended 34" distance from the top of the lav deck
to the finished floor. To meet ADA requirements, the lav deck cannot exceed the 34" maximum height
dimension.

LVGD1 Installation
22/24/2020 Bradley • 215-1709 Rev. M: ECN 19-08-037G
Components
Frame
(S17-364)
Access Panel
(186-1858)
Complete Hardware Prepack (S45-2473)
Frame Mounting Qty.
Washer, Square 9 (4 extra)
Washer, Flat 1" O.D. 2
Bowl-To-Frame (S45-2481) Qty.
Screw, ¼-20 x ½" 3 (1 extra)
Washer, Flat ⁵⁄₈" O.D. 3 (1 extra)
Trap Cover (S45-2482) Qty.
Screw, 10-24 x ½" 6 (2 extra)
#10 Finishing Washer 6 (2 extra)
Trap Hook Bracket 1
Screw, 10-24 x 3⁄8" 1
Washer, Flat 35⁄64" O.D. 1
Bowl
Contact your Bradley Representative for color options
Complete Drain Prepack
(S45-2471)
Strainer and
Screw
(S45-2479)
O-Ring
(125-111)
Drain
Adapter
Packing
Washer
#10-24
Screw
Drain Adapter
Prepack
(S45-2480)
Chrome P-Trap (S29-094)
Plastic P-Trap (269-1697)
Water supply to Battery Box Solenoid MUST be supplied
using a plastic hose (provided by Bradley).
TMV Valve
(½" NPTM
Outlet)
(S45-2701)
Hose Prepack
(S45-2730)
Supply
Fittings
(S45-2712)
Hose Prepack
(S45-2702)
TMV Supply Connections
Plastic Hose
Plastic
Hose
Use for faucets not
supplied by Bradley
that require a TMV.
TMV & Tempered Supply Connections
Two (2) connections
are required for TMV.

Installation LVGD1
Bradley • 215-1709 Rev. M: ECN 19-08-037G 2/24/2020 3
Dimensions (mm)
Supplies Required:
• (7)
3⁄8" lag screws, wall anchors, bolts (minimum pull-out rating of 1,000 lb)
• ½" hot/cold or tempered supply piping
• 1½" NPT drain piping
• OPTIONAL: 110V GFCI protected electrical outlet for 100–120V AC plug-in transformer (for Bradley Faucets)
• Screen filter(s) as needed, if not included with faucet(s)
15⁄8" (41)
¼"
(6)
5⁄64"
(2)
13⁄16"
(30)
3⁄32" (2)
Drain inside dia.
15⁄16" (8)
LVGD Drain and Strainer —Close-up View
Top View
Front View
30" (762)
Top of Deck at Front
20"
(508)
30⁷⁄₈"(784)
Bottom of Deck at Front
15"
(381)
7¾"
(197)
22½"
(572)
30½" (775)
Bottom of Deck at Back Wall
29⁷⁄₈"(759)
Top of Deck at Back Wall

LVGD1 Installation
42/24/2020 Bradley • 215-1709 Rev. M: ECN 19-08-037G
Dimensions – Side View (mm)
33½"
(851)
8½"
(216)
22½"
(572)
22½"
(572)
Standard
Height
Juvenile
Height
TAS, Grades 6
through 8 or 9
TAS, Pre-K
through Grades
5 or 6
301⁄8"
(765)
27"
(765)
24"
(610)
217⁄8"
(556)
363⁄8"
(924)
14"
(356)
14"
(356)
30½"
(775)
8½"
(216)
187⁄8"
(479)
333⁄8"
(848)
29½"
(749) 8½"
(216)
22½"
(572)
261⁄8"
(664)
177⁄8"
(454)
323⁄8"
(822)
14"
(356)
271⁄8"
(689)
31½"
(800)
8½"
(216)
22½"
(572)
281⁄8"
(714) 197⁄8"
(505) 343⁄8"
(873)
14"
(356)

Installation LVGD1
Bradley • 215-1709 Rev. M: ECN 19-08-037G 2/24/2020 5
Rough-Ins (mm)
C
E
36³⁄₈"
(924)
D
F
F
34³⁄₈"
(873)
5½"
(141) 5⁷⁄₈"
(149)
H
22¾"
(578)
33¾"
(858)
32¹⁄₈"
(815)
A A
B
B
B
B
B
7³⁄₈"
(189)
Finished Floor
3"
(76)
Reinforce wall at points A and B.
Standard rough-in shown.
RIM HEIGHT VERTICAL HEIGHT ADJUSTMENTS FOR CODES A–E and H FIXTURE STYLE
33½" None Standard Height
31½" Subtract 2" TAS, Grades 6 through 8 or 9
29½" Subtract 4" TAS, Pre-K through Grades 5 or 6
30½" Subtract 3" Juvenile Height
CODE DESCRIPTION QTY.
A
3⁄8
" Lav Deck Bowl Anchors with a Minimum Pull-Out Force of 1,000 lb (reinforce walls at anchor points) 2
B
3⁄8
" Lav Deck Frame Anchors with a Minimum Pull-Out Force of 1,000 lb (reinforce walls at anchor points) 5
H, C ½" Hot/Cold Supplies, Stub-Out 2" From Wall 1
D110V GFI Protected Electrical Outlet (AC faucet and soap only) 1
E1½" NPT Drain, Stub-Out 2" from Wall 1
F#10 Anchors for Faucet Control Box Installation 2
12½"
(318)
12½"
(318)
1½"
(39)
4½"
(114)
4½"
(114)
30⁵⁄₈"
(778)
27¾"
(706)
¾"
(19)
2¼"
(57)
15³⁄₈"
(394)
15"
(381)

LVGD1 Installation
62/24/2020 Bradley • 215-1709 Rev. M: ECN 19-08-037G
1Frame Mounting
16"
(406mm)
centers
13"
(330mm)
A
Finished Floor
Drywall Drain, supplies and electrical box are
shown in their approximate locations.
Cut clearance holes in the backing as
required.
NOTE: Backing should equal the
thickness of the drywall (½" minimum).
B
The frame and
the bowl must
be adequately
supported.
A
Use 3⁄8" lag screws and square washers provided to secure the
frame to the backing (5) places. Shim frame as necessary.
NOTE: Other fasteners may be used based on wall material.
D
Support Backing Mounting Height "A" Dimension
Standard Height 19" (483mm)
TAS, Grades 6 through 8 or 9 17" (432mm)
TAS, Pre-K through Grades 5 or 6 15" (381mm)
Juvenile Height 16" (406mm)
If needed, shim the frame
at anchor points to ensure
the offset bracket is straight.
Leave the top screw loose.
C
11"
(279mm)
Typical installation is shown. It may be necessary to repair the wall
after mounting. The fixture may not cover all of the wall modifications.

Installation LVGD1
Bradley • 215-1709 Rev. M: ECN 19-08-037G 2/24/2020 7
2Mounting Valve to Frame
A portion of the frame has been removed
from the view for clarity of valve installation.
Water supply to Battery Box Solenoid MUST be supplied
using a plastic hose (provided by Bradley).
Cold
Hot
Optional TMA Valve
(½" NPTM Outlet)
Connect the faucet hoses. Attach the valve to
the back side of the frame member with the
(2) #10-24 self tapping screws provided.
TMA Option
NONE Option
Plastic Hose
Plastic
Hose
For TMV and TL Bradley faucets, two (2)
connections are required for TMV.
For non-Bradley faucets only.

LVGD1 Installation
82/24/2020 Bradley • 215-1709 Rev. M: ECN 19-08-037G
4Faucets and Optional Soap Valve
3Drain Assembly
O-Ring
Drain Adapter
Packing Washer
#10-24
Screw
For ease of drain installation, lay the bowl on its back.
For ease of installation, leave the bowl laying on its back. Install the faucets and optional soap
valves according to manufacturer's instructions.

Installation LVGD1
Bradley • 215-1709 Rev. M: ECN 19-08-037G 2/24/2020 9
5a Bowl Mounting (to Frame)
Washer
¼"-20
Screw
5b Bowl Mounting (to Wall)
Reinforce behind the wall
at the two bowl mounting
locations, then secure the
bowl to the wall.
A
Press firmly on the back
of the bowl to seat the
bowl into the frame.
Tighten the top screw on
the frame.
A
Bowl is heavy!

LVGD1 Installation
10 2/24/2020 Bradley • 215-1709 Rev. M: ECN 19-08-037G
Strainer
6Strainer and P-Trap
Thread the strainer screw
through the boss on the
drain adapter and secure
the strainer to the bowl.
B
Attach the strainer
screw to the strainer.
Do not overtighten.
A
7Adjust Temperature with Water Running
H
C
ALoosen Cap Screw about 1/4" (4-6 turns)
and lift up cover (do not remove).
BUsing cover, turn cartridge gently until
desired water temperature is reached. Do
not turn past stops as this may damage
unit. Push cover down and tighten screw.
This valve is NOT factory preset.
Upon installation, the temperature
of this valve must be checked and
adjusted to ensure delivery of a
safe water temperature. Water
in excess of 110°F (43°C) may
cause scalding.
