Bradley OmniDeck 3000 Series User manual

Installation
P.O. Box 309
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
[phone]
bradleycorp.com
215-1219 Rev. Q: ECO 19-08-037B
© 2020 Bradley
Page 1 of 37 2/27/2020
LD-3010
OmniDeck™ 3000 Series
OmniDeck™ série 3000
OmniDeck™ serie 3000
LD-3010-2 is shown with optional
Bradley SL-TO1 oval undermount,
faucet and access panel
Modèle LD-3010-2 est montrée
avec cuvette ovale SL-TO1 à
monture par le dessous, le robinet
et le panneau d’accès en option
Modelo LD-3010-2 se muestra
con palangana de montaje inferior
ovalada SL-TO1, el grifo y el panel
de acceso opcional
Table of Contents
Supplies Required .....................................2
Components .........................................3
Side View Dims .....................................4–6
Rough-ins for LD-3010 SL-TO1...........................7
Rough-ins for LD-3010 SL-TR1...........................8
Rough-ins for LD-3010 HS-Series.........................9
OmniDeck Mounting ..................................10
Optional Drain and P-Trap..............................11
Multi-Feed System Option..............................12
Cleaning and Maintenance Instructions ...................13
Table des matières
Equipements nécessaires ..............................14
Composants ........................................15
Dimensions — Vue de côté ..........................16–18
Mises en place des canalisations pour LD-3010 SL-TO1 ......19
Mises en place des canalisations pour LD-3010 SL-TR1 ......20
Mises en place des canalisations pour série LD-3010 HS .....21
Montage d’unité de de lavabo ...........................22
Drain et siphon en P en option ..........................23
Multi-Feed System Option..............................24
Instructions de nettoyage et d’entretien. . . . . . . . . . . . . . . . . . . . 25
Contenido
Materiales necesarios .................................26
Componentes .......................................27
Dimensiones - Vistas laterales .......................28–30
Colocación de tuberías empotradas del LD-3010 SL-TO1 .....31
Colocación de tuberías empotradas del LD-3010 SL-TR1 .....32
Colocación de tuberías empotradas del serie LD-3010 HS ....33
Montaje de la cubierta del lavabo ........................34
Desagüe opcional y sifón en P ..........................35
Multi-Feed System Option..............................36
Instrucciones de limpieza y mantenimiento.................37
LD-3010-1 is shown with optional Bradley
SL-TR1 rectangular undermount, faucet and
access panel
Modèle LD-3010-1 est montrée avec cuvette
rectangulaire SL-TR1 à monture par le
dessous, le robinet et le panneau d’accès
en option
Modelo LD-3010-1 se muestra con palangana
de montaje inferior rectangular SL-TR1, el
grifo y el panel de acceso opcional

LD-3010 Series Installation
22/27/2020 Bradley • 215-1219 Rev. Q: ECO 19-08-037B
Supplies Required:
• ½" nominal copper tubing for hot and cold supply piping and 1½" NPT drain piping
• Silicone caulk/sealant for sealing between deck and walls
• For optional mounting brackets: 3⁄8" wall anchors and fasteners with washers suitable for wall construction
• For optional carrier sleeves: in-wall carrier sleeves by others (Josam model #17100-203 or equivalent
recommended; refer to the table below for carrier sleeve requirements).
• For optional stainless steel access panel: four #10 wall anchors and mounting fasteners (for each cover)
suitable for wall construction
Model # Carrier Sets
Recommended Carrier Sleeves Required
LD-3010 30" 1 2
LD-3010 60" 2 3
LD-3010 90" 2 4
LD-3010 120" 3 6
Basin Model # Carrier Arm
Spacing (min.)
SL-TO1 22" (559 mm)
SL-TR1 23" (584 mm)
HS-TO1 27½" (699 mm)
HS-TS1 19" (483 mm)
HS-TR1 27½" (699 mm)
WARNING
Make sure that all water supply lines have been flushed and then completely turned off before beginning
installation. Debris in supply lines can cause valves to malfunction.
Turn OFF electrical power to the electrical outlets, then unplug all electrical units prior to installation. Electrical
power MUST remain off until installation is complete. After installation is complete, turn on the water supply
first, then turn on the electrical power.
Installer's hardware must be appropriate for wall construction. Wall anchors must have a minimum pull-out
rating of 1,000 pounds.
IMPORTANT
Read this entire installation manual to ensure proper installation. When finished with the installation, file this
manual with the owner or maintenance department. Compliance and conformity to local codes and ordinances
is the responsibility of the installer. Product warranties may be found under “Products” on our website at
www.bradleycorp.com.
Separate parts from packaging and make sure all parts are accounted for before discarding any packaging
material. If any parts are missing, do not begin installation until you obtain the missing parts.
For standard height mounting, do not exceed the recommended 34" distance from the top of the lav deck to
the finished floor. To meet ADA requirements, the lav deck cannot exceed the 34" maximum height dimension.

Installation LD-3010 Series
Bradley • 215-1219 Rev. Q: ECO 19-08-037B 2/27/2020 3
Components
Terreon OmniDeck
(shown with SL-TO1
oval integral bowl) LD-3010-1
LD-3010-2
LD-3010-3
LD-3010-4
Components for Mounting Options
Contact your Bradley representative for Terreon lav deck and sink options.
Optional P-Trap
(S29-094)
Drain
Assembly
(269-1839)
for SL-
TO1 oval
undermount
only
Strainer
Rubber Washer
Fiber Washer
Nut
Right-Hand Mounting Bracket with
Mounting Strip (S45-2452RH)
Left-hand Mounting Bracket with
Mounting Strip (S45-2452LH)
PrePack, Access Panel
SL-TO1 (S45-2733) PrePack, Access Panel, SL-TR1
(S45-2708)
Optional Waste Chute
(P10-696)
Carrier Sleeve, 18"
(266-049J)
Strainer and ADA
Offset Tailpiece
(269-1751)
for SL-TR1
rectangular
undermount only
Drain
Assembly
(269-1863)
for HS-Series
Only
Strainer
Rubber Washer
Mounting Ring
Lock Nut
Tailpiece Washer
Slip Nut
PrePack, Access Panel HS-Series
(S45-2820)

LD-3010 Series Installation
42/27/2020 Bradley • 215-1219 Rev. Q: ECO 19-08-037B
Standard Height
(SL-TR1
Undermount
Bowl)
15¾"
(400)
9"
(229)
22"
(559)
17"
(432)
Standard Height
(SL-TO1
Undermount
Bowl)
Juvenile Height
(SL-TR1
Undermount
Bowl)
Juvenile Height
(SL-TO1
Undermount
Bowl)
27"
(686)
34"
(864)
14⁷⁄₁₆"
(367)
9"
(229)
22"
(559)
27"
(686)
34"
(864)
17"
(432)
12¾"
(324)
9"
(229)
22"
(559)
17"
(432)
24"
(610)
31"
(787)
9"
(229)
22"
(559)
17"
(432)
24"
(610)
31"
(787)
11⁷⁄₁₆"
(291)
Dimensions - Side View (mm)
Surface mount brackets shown. Also available with carrier
sleeves for concealed in wall carriers.

Installation LD-3010 Series
Bradley • 215-1219 Rev. Q: ECO 19-08-037B 2/27/2020 5
Standard Height
(HS-TO1
Undermount
Bowl)
16½"
(418)
9"
(229)
22"
(559)
17"
(432)
Standard Height
(HS-TS1
Undermount
Bowl)
27"
(686)
34"
(864)
16½"
(418 )
9"
(229)
22"
(559)
27"
(686)
34"
(864)
17"
(432)
Dimensions - Side View (mm)
Juvenile Height
(HS-TO1
Undermount
Bowl)
9"
(229)
22"
(559)
17"
(432)
24"
(610)
31"
(864)
Juvenile Height
(HS-TS1
Undermount
Bowl)
13½"
(418)
9"
(229)
22"
(559)
24"
(610mm)
31"
(787)
17"
(432)
Surface mount brackets shown. Also available with carrier
sleeves for concealed in wall carriers.
13½"
(418)

LD-3010 Series Installation
62/27/2020 Bradley • 215-1219 Rev. Q: ECO 19-08-037B
Standard Height
(HS-TR1
Undermount
Bowl)
16½"
(418)
9"
(229)
22"
(559)
17"
(432)
Juvenile Height
(HS-TR1
Undermount
Bowl)
27"
(686)
34"
(864)
16½"
(418)
9"
(229)
22"
(559)
24"
(610)
31"
(864)
17"
(432)
Dimensions - Side View (mm)
Surface mount brackets shown. Also available with carrier
sleeves for concealed in wall carriers.

Installation LD-3010 Series
Bradley • 215-1219 Rev. Q: ECO 19-08-037B 2/27/2020 7
1a Rough-Ins for OmniDeck with SL-TO1 Oval Undermount Bowl
Typical OmniDeck rough-ins for single SL-TO1 oval bowl are shown. Other multiple-bowl rough-ins
are similar.
For juvenile height mounting, the mounting height dimension from the deck surface to the finished
floor is 31" (787) maximum. Adjust all other mounting locations accordingly.
Code Description Qty.
A1 3⁄8" Anchors with a Minimum Pull-Out Force of 1,000 lb (reinforce wall at anchor points) 2 per bracket
A2 Square Washers (provided) 2 per bracket
B #10 Wall Anchors and Screws 6
H, C ½" Nominal Copper Tubing for Hot/Cold Supplies, Stub-Out 2" (51) From Finished Wall 2
D AC Option Only: 110V GFI Protected Electrical Outlet 1
E 1½" NPT Drain, Stub-Out 2" (51) From Wall 1
F TMA Option Only: #10 Wall Anchors and Screws 2
G 8" (203) 2
Variable
Finished Floor
Variable
1½" (38)
2" (51)
2" (51)
27¾"
(705)
22"
(559)
24"
(610)
9"
(229)
22"
(559)
19"
(483)
20¼"
(514)
10¹⁄₈"
(257)
Access
Panel
34" (864)
deck surface
maximum
ADA
3¼"
(83)
H C
D
E
A1
A2
A1
A2
A1
A2
A1
A2
B
B
B
F
G
G
F
B
B
B
(mm)

LD-3010 Series Installation
82/27/2020 Bradley • 215-1219 Rev. Q: ECO 19-08-037B
1b Rough-Ins for OmniDeck with SL-TR1 Rectangular Undermount Bowl
Typical OmniDeck rough-ins for single SL-TR1 rectangular bowl are shown. Other multiple-bowl rough-ins are similar.
For juvenile height mounting, the mounting height dimension from the deck surface to the finished floor is 31" (787)
maximum. Adjust all other mounting locations accordingly.
Code Description Qty.
A1 3⁄8" Anchors with a Minimum Pull-Out Force of 1,000 lb (reinforce wall at anchor points) 2 per bracket
A2 Square Washers (provided) 2 per bracket
B #10 Wall Anchors and Screws 4
H, C ½" Nominal Copper Tubing for Hot/Cold Supplies, Stub-Out 2" (51) From Finished Wall 2
D AC Option Only: 110V GFI Protected Electrical Outlet 1
E 1½" NPT Drain, Stub-Out 2" (51) From Wall 1
F TMA Option Only: #10 Wall Anchors and Screws 2
Variable
Finished Floor
Variable
1½" (38)
2" (51)
2" (51)
27¾"
(705)
22"
(559)
24"
(610)
9"
(229)
22"
(559)
19"
(483)
8¼"
(210) ref.
5⁵⁄₈"
(143)
Access
Panel
34" (864)
deck surface
maximum
ADA
3¼"
(83)
H C
D
E
A1
A2
A1
A2
F
F
B
11¼"
(286)
A1
A2
A1
A2
B
B B
(mm)

Installation LD-3010 Series
Bradley • 215-1219 Rev. Q: ECO 19-08-037B 2/27/2020 9
1c Rough-Ins for OmniDeck with HS-Series Bowl
Typical OmniDeck rough-ins for single HS-Series bowl are shown. Other multiple-bowl rough-ins are similar.
For juvenile height mounting, the mounting height dimension from the deck surface to the finished floor is 31" (787)
maximum. Adjust all other mounting locations accordingly.
Code Description Qty.
A1 3⁄8" Anchors with a Minimum Pull-Out Force of 1,000 lb (reinforce wall at anchor points) 2 per bracket
A2 Square Washers (provided) 2 per bracket
B #10 Wall Anchors and Screws 4
H, C ½" Nominal Copper Tubing for Hot/Cold Supplies, Stub-Out 2" (51) From Finished Wall 2
D AC Option Only: 110V GFI Protected Electrical Outlet 1
E 1½" NPT Drain, Stub-Out 2" (51) From Wall 1
F TMA Option Only: #10 Wall Anchors and Screws 2
Finished Floor
Variable
1¹⁄₈" (27)
2" (51)2" (51)
24"
(610)
22"
(559)
4⁵⁄₈"
(117)
9"
(229)
22"
(559)
24"
(610)
17½"
(444)
Access
Panel
34" (864)
deck surface
maximum
ADA
7½"
(191)
HC
D
E
A1
A2
A1
A2
A1
A2
A1
A2
F F
B
9"
(229)
B
B B
Variable
1¹⁄₈" (27)
9¼"
(233)
(mm)

LD-3010 Series Installation
10 2/27/2020 Bradley • 215-1219 Rev. Q: ECO 19-08-037B
2OmniDeck™ Mounting
Secure the carrier
sleeves to the bottom
of the lav deck at the
desired locations with
silicone caulk/sealant.
B
With help, slide the lav deck
onto the carrier, aligning the
access holes in the carrier
sleeves with the carrier arm
leveling screws and locking
device. Adjust the carrier
sleeves as needed.
C
Leveling
Screws
Locking
Device
Carrier
Sleeve
FinishedFloor
Carrier
Sleeve
6" (152) 9"
(229)
6" (152)
Install the concealed
arm lav carrier
(supplied by installer)
per manufacturer's
instructions.
A
Bottom View of Lav Deck
with Carrier Sleeves
Apply PC-Concrete®injectable
repair and anchoring epoxy (or
equal) to the top of the mounting
strips (left-hand bracket shown).
A
Carrier Sleeve Mounting
Bracket Mounting
Leveling Screw
Access Hole
Locking Device
Access Hole
Leveling Screw
Access Hole
Position the access panels
snug to the underside of the
basin. Secure the access
panels to the wall with four
#10 fasteners (supplied by
installer).
B
Terreon SL-TO1 oval bowl is shown.
All other bowls are similar.
SL-TR1 rectangular bowl is shown, all other
bowls are similar.
Backing substrate required for structural
integrity if brackets aren't secured to a stud.
Table A
Basin Model # Carrier Arm Spacing
(min.)
SL-TO1 22" (559)
SL-TR1 23" (584)
HS-TO1 27½" (699)
HS-TS1 19" (483)
HS-TR1 27½" (699)
See Table A
