BRAHMA E8 Series User manual

4080_r05 1/4
E8/... SERIES
SOLENOID GAS VALVES WITH 1/8” and
1/4” CONNECTIONS AND OPERATING
PRESSURE UP TO 1,5 bar.
GENERAL DESCRIPTION
This series of solenoid valves are of normally closed type,
suitable for civil and industrial applications, supplied with
alternate or direct current.
E8/S version, which can be fitted with a flow adjustment
device and outlet pressure plug, are supplied with alternate
current, but provided with an inside rectification circuit, which
permitted to make actions as silent as possible.
Gas valves of this series, conforming to EN161, have a CE
type Certificate (CE Reg. N° 63AQ0626) in accordance to
European directives 90/396 and 93/68.
−EC- type certification in accordance with the new
European Gas Appliances Regulation (EU) 2016/426
(GAR);
−conformity to EC Low-voltage directive 2014/35/EU
TECHNICAL FEATURES
Class: A
Group: 2
Supply voltage (1): 230Vac / 50-60Hz
110Vac / 50-60Hz
Operating temperature: -10°C / +60°C
Closing time: 1s
Opening time: 1s
Mounting: vertical and horizontal
Body: die-cast brass
(1) Versions with different supply voltages are available.
DIRECTIONS FOR INSTALLATION AND MAINTENANCE
•This valve is a safety appliance and should not be modified.
The manufacturer's responsibility and guarantee are
invalidated in case the device is tampered with by the user.
•The applicable national regulation and European standards
(Ex. EN 60335-1 and EN 60335-2-102) related to the
electrical safety must be respected;
•Assemble the valve to the installation so that the arrow on
the valve body has the same direction as the fuel flow.
•During the assembly of the valve to the installation piping,
avoid twisting on the sheath and always use an hexagonal
wrench to be fitted to the valve body.
•Make sure that no foreign matters have entered the valve
body.
•Make sure that the max. fuel input pressure never exceeds
the value appearing on the label.
•All operations (installation, maintenance, etc.) must be
carried out by a qualified technician.
•Before any connection operation, completely isolate the
system from power supply (multi-pole disconnection). Place
the system safely to avoid accidental switch-on and make
sure there is no voltage. If the system is not switched off,
there is a risk of electric shock.
•During and after any operation (installation, maintenance,
etc.), make sure that the type and code are the ones
provided, check the correct functioning and the internal and
external thickness of the valve.
•In the event of a fall or impact, the valves must not be
started, as safety functions may be compromised even if no
damage is visible to the outside.
•Faulty valves or damaged must be unplugged from power
supply and cannot be used.
•The valve has a designed lifetime* based on the endurance
tests in the standard EN 161. A summary of the conditions
has been published by the European Control Manufacturers
Association (Afecor) (www.afecor.org). The designed lifetime
is based on use of the valve according to the manufacturer’s
technical notes. After reaching the designed lifetime in terms
of the number of burner startup cycles, or the respective
time of usage, the valve has to be replaced by authorized
personnel.
* The designed lifetime is not the warranty time specified in
the Terms of Delivery

2/4 4080_r05
FLOW ADJUSTMENT FOR E8/SR...
After removing the top protection, rotate clockwise the screw
marked with 1 in Fig.1 to reduce the flow, rotate it counter
clockwise to increase the same.
Fig.1
Nut: G1/4"
Es. ch. 16
Ogive

6

6 orifice
E8/B FIXING
OVERALL DIMENSIONS
PRESSURE
mbar
FLOW RATE
m/h
3
A: standard flow rate m /h of NATURAL GAS dr 0.554
B: standard flow rate m /h of LPG dr 1.54
C: standard flow rate m /h of TOWN GAS dr 0.411
D: standard flow rate m /h of AIR dr 1
3
3
3
3
DIAGRAM
Type
Operating
pressure
(mbar)
Orifice
diameter
(mm)
Connections
Weight
(g)
Coil
Consumption
(VA)
230Vac
Consumpti
on
(VA)
110Vac
Flow
(m³/h
gas with
P
2.5mbar)
Possibility
to fit
pressure
test point
E8/B
E8/B
E8/B
E8/B
E8/B
E8/B
0 ÷ 2000
0 ÷ 2000
0 ÷ 2000
0 ÷ 2000
0 ÷ 2000
0 ÷ 2000
4
4
4
4
4
4
1/4" M
1/4" M
1/4" M
1/4" M
1/4" M
1/4" M
243
222
222
243
222
222
BE7*D3C
BE7*DFP
BE7*DFD+MPM182
BE7*C3C
BE7*CFP
BE7*CFD+MPM182
10
10
10
7
7
7
10
10
10
7
7
7
0.5
0.5
0.5
0.5
0.5
0.5
No
No
No
No
No
No
E8/L
E8/L
E8/L
E8/L
E8/L
E8/L
0 ÷ 2000
0 ÷ 2000
0 ÷ 2000
0 ÷ 2000
0 ÷ 2000
0 ÷ 2000
4
4
4
4
4
4
1/8" F
1/8" F
1/8" F
1/8" F
1/8" F
1/8" F
230
220
220
230
220
220
BE7*D3C
BE7*DFP
BE7*DFD+MPM182
BE7*C3C
BE7*CFP
BE7*CFD+MPM182
10
10
10
7
7
7
10
10
10
7
7
7
0.5
0.5
0.5
0.5
0.5
0.5
No
No
No
No
No
No
E8/S
E8/S
E8/S
E8/S
0 ÷ 100
0 ÷ 100
0 ÷ 100
0 ÷ 100
6
6
6
6
1/4" F
1/4" F
1/4" F
1/4" F
280
260
250
250
BE7*GMO
BE7*C3C
BE7*CFP
BE7*CFD+MPM182
7
7
7
7
7
7
7
7
0.8
0.8
0.8
0.8
Yes
Yes
Yes
Yes
1

4080_r05 3/4
DIAGRAM
PRESSURE
mbar
FLOW RATE
m3/
h
A: standard flow rate m3/h of NATURAL GAS dr 0.554
B: standard flow rate m3/h of LPG dr 1.54
C: standard flow rate m3/h of TOWN GAS dr 0.411
D: standard flow rate m3/h of AIR dr 1
SUMMARY TABLE
Type
DN
Operating
pressure
(mbar)
Orifice
diameter
(mm)
Connection
s
Weight
(g)
Coil
Consumption
(VA)
230Vac
Consumption
(VA)
110Vac
Flow
(m³/h gas
with P
2.5mbar)
Possibility to
fit pressure
test point
E8/B
E8/B
E8/B
E8/B
E8/B
E8/B
8
8
8
8
8
8
0 ÷ 1500
0 ÷ 1500
0 ÷ 1500
0 ÷ 1500
0 ÷ 1500
0 ÷ 1500
4
4
4
4
4
4
1/4" M
1/4" M
1/4" M
1/4" M
1/4" M
1/4" M
243
222
222
243
222
222
BE7*D3C
BE7*DFP
BE7*DFD+MPM182
BE7*C3C
BE7*CFP
BE7*CFD+MPM182
10
10
10
7
7
7
10
10
10
7
7
7
0.5
0.5
0.5
0.5
0.5
0.5
No
No
No
No
No
No
E8/L
E8/L
E8/L
E8/L
E8/L
E8/L
6
6
6
6
6
6
0 ÷ 1500
0 ÷ 1500
0 ÷ 1500
0 ÷ 1500
0 ÷ 1500
0 ÷ 1500
4
4
4
4
4
4
1/8" F
1/8" F
1/8" F
1/8" F
1/8" F
1/8" F
230
220
220
230
220
220
BE7*D3C
BE7*DFP
BE7*DFD+MPM182
BE7*C3C
BE7*CFP
BE7*CFD+MPM182
10
10
10
7
7
7
10
10
10
7
7
7
0.5
0.5
0.5
0.5
0.5
0.5
No
No
No
No
No
No
E8/S
E8/S
E8/S
E8/S
E8/S
E8/SR
E8/SRP
8
8
8
8
8
8
8
0 ÷ 100
0 ÷ 100
0 ÷ 100
0 ÷ 100
0 ÷ 100
0 ÷ 100
0 ÷ 100
6
6
6
6
6
6
6
1/4" F
1/4" F
1/4" F
1/4" F
1/4" F
1/4" F
1/4” F
280
260
250
250
250
290
290
BE7*GMO
BE7*C3C
BE7*CFP
BE7*CFD+MPM182
BE7*CFD+MPM532
BE7*GMOE
BE7*GMOE
7
7
7
7
7
13
13
7
7
7
7
7
7
7
0.8
0.8
0.8
0.8
0.8
0.8
0.8
Yes
Yes
Yes
Yes
Yes
Yes
Yes

NOTES FOR THE DISPOSAL OPERATION
The controller contains electronic components and it must not be disposed of as a domestic waste. For the disposal operation
refer to the local rules concerning special waste.
BRAHMA S.p.A.
Via del Pontiere, 31
37045 Legnago (VR) - ITALY
Tel. [phone] - Fax [phone]/2020 Subject to amendments without notice
http://www.brahma.it
E-mail : [email protected]t
4/4 4080_r05
ATTENTION --> Company Brahma S.p.A. declines any responsibility for any damage resulting from Customer tampering with the device.
TYPE REFERENCES
Type
Body type
Type
Description
110/50-60
110Vac/50-60Hz
230/50-60
230Vac/50-60Hz
Body
Connections
Orifice
B
G1/4” M
4 mm
L
G1/8” F
4 mm
S
G1/4” F
6 mm
Type
Description
2C
Connection with two core cable-
IP65.
3C
Connection with three core
cable-IP65.
FP
Connection with flat fast-on.
FD
Connection with fast-on for plug
DIN43650-IP65.
MO
Connection with terminal board-
IP40.
MOE
Connection with terminal board
for valve inclusive of flow
adjustment-IP40.
Type
Description
A
Supply in alternate current.
B
Supply in alternate current with
use of two external diodes: the
first in series to the coil, the
other in parallel to it.
C
Supply in direct current.
D
Supply in alternate current, but
valve operates in direct current
thanks to two embodied diodes.
G
Supply in alternate current, but
valve operates in direct current
thanks to an embodied
rectification bridge.
E8 / S R P * G MO 230/50-60
Supply voltage
Winding type
Flow adjustment
Valve fitted with equipment for
flow adjustment.
Pressure plug
Valve inclusive of pressure plug.
Connection type
