BraunAbility Rampvan XT User guide

2013 Private Use"QQMJDBUJPO(VJEFt7PMVNFt*TTVFt
TOYOTA3".17"/
®
XT ttttttttttttttttttttt

Toyota3BNQWBO® XT: Engineered for Excellence
Built on the 2011-2013 Toyota Sienna chassis, the BraunAbility Rampvan® XT is the culmination of over forty
years experience in building personal mobility products. Style, performance, convenience and safety have been
aesthetically blended to achieve a new level of renement in a wheelchair-accessible minivan.
Striking and Stylish ExteriorThe bold new look of the Sienna is a refreshing take on the traditional minivan.
Strong, athletic lines give this vehicle an entirely new attitude.
*ODSFBTFE)FBE$MFBSBODF With 56” of door height, the Rampvan® XT provides over three additional inches
of head clearance over the 2010 model. Customers will love the 60”of interior head clearance for greater
comfort and visibility.
*ODSFBTFE3FBS$BSHP4QBDF The spare tire is now stored below the rear cargo area, providing much more
storage space over the 2010 model. Third row roll-and-tumble seats fold forward to oer additional cargo space
when needed.
4UFQBOE3PMM'SPOU4FBUTRemoving the front seats has never been easier -- just step on the foot lever and
roll the seat out of the van.
'PME%PXO'PPUSFTUA Braun-designed footrest adds comfort for backseat passengers and folds away when
not in use.
%FDSFBTFE3BNQ"OHMFThe newly designed kneeling system reduces the slope of the ramp to a
wheelchair-friendly 7.3 degrees. This makes the Rampvan® XT especially attractive for those in manual
wheelchairs.
0&.3FNPUF$POUSPM – Accessible features are controlled by the Toyota keyfob (patented by BraunAbility).
Additional control switches are conveniently located on the vehicle’s interior.
Ground Eects and OEM StylingThe lines of the vehicle are integrated into the custom ground eects,
complementing the sleek automotive styling.
Suspension and RideWe’ve made only minor modications to the rear suspension during the conversion
process, giving a smooth ride that’s as close to OEM as possible.
Safety has always been a top priority at BraunAbility. The Rampvan® XT has been crash tested and certied
to meet or exceed all applicable requirements of the Federal Motor Vehicle Safety Standards (FMVSS) and is
backed by our 3 year/36,000 mile limited and 5 year/unlimited mile rust-through metal protection on every
vehicle that leaves the factory. Add to this the
originalToyota warranty for unconverted parts
and a nationwide dealer network, and you can
rest assured BraunAbility will be there to sup-
port you no matter where your travels take you.
s
the
p
arts
can
s
up
-
y
ou.

Toyota3BNQWBO® XT 'FBUVSFT
tttttttttttttttttttt
Rampvan® XT
2011-2013 Toyota Sienna Chassis
SE Model Shown
See Chassis Information page for Chassis Requirements
Automatic Ramp (Power Conversion)
The lightweight power foldout ramp oers unparalleled ease of access for
wheelchair and scooter users. A manual conversion is also available.
“Step & Roll” Front Passenger Seats
Thedriverandpassengerseats canbe easilyremovedtoprovidewheelchair
securement positions in the front of the vehicle.
Automatic Door (Power Conversion)
The OEM Toyota power door operator opens the sliding door at the touch of a
button. A manual conversion is also available.
Automatic Kneeling Rear Suspension (Power Conversion)
The vehicle features a kneeling system to make boarding even easier.
An actuator lowers the rear suspension while the door opens, which
reduces the slope of the automatic ramp. The system can be de-acti-
vated when desired with the on/o switch.
Lowered Floor
14” lower than conventional minivans, the oor is lowered from the toe pan to
the rear axle and provides a choice of three wheelchair securement positions.
OEM-Style Switches (Power Conversion)
Operational switches are conveniently located throughout
theinteriorforwheelchairusers’convenience. Theswitches
resemble the OEM style and appearance.
Wheelchair/Occupant Securement System
One belt system is included for use with the oor-mounted tracks.
Custom Ground Eects
Adds stylish lines and enhances smooth OEM appearance.
Integrated Keyfob Remote (Power Conversion)
Control of the vehicle’s accessible features is built into the
Toyotakeyfobremote. Quick-touchoperationassuressimple,
convenientand reliableoperation. Two keyfobsareincluded
with the vehicle.
Fold-Down Footrest
Adds comfort for backseat passengers and folds away when not in use.
Rear Cargo Area
The spare tire is now stored below the rear cargo area. Third row roll-and-
tumble seats fold forward to oer additional cargo space when needed.
S
S
F
F
T
T

Toyota3BNQWBO®XT %JNFOTJPOT
BC
D
A
G
F
E
I
H
J
All dimensions are for reference only.
Door Opening Usable Width (Slide Door) A 33”
Door Opening Usable Height (Slide Door) B 56”
Interior Height at Center of Van* C 60”
Interior Height at Driver and Passenger Position** D 59”
Ramp Length E 52”
Ramp Width (Usable Clear Opening) F 29-1/4”
Ramp Angle (with Vehicle Kneeled on a Power Conversion) G 7.3°
Interior Floor Length (Behind Front Seats) H 45”
Overall Interior Floor Length (Flat Area) I 82-1/2”
Interior Width at B Pillars J 60”
Foldout Ramp
Due to manufacturing tolerances both with the OEM vehicle and the conversion components, all dimensions may vary slightly from those shown.
* Deduct 2” o of Interior Height for Applications with Overhead DVD/Rail System
** Deduct 1” o of Interior Height for Applications with Moon Roof

Toyota3BNQWBO®XT Options
Available factory installed at time of order,
or for ship-out (unless otherwise noted).
E90450 Protective Carpet Mat Folding Ramp - with Track Cutout
E90451 Protective Carpet Mat Folding Ramp - without Track Cutout
Clear plastic mat protects carpet from trac wear.
E38019TK-_ _ Altro Flooring - Smooth - Interior Color
Substitute Altro ooring in lieu of carpet.
/05"7"*-"#-&'034)*1065'"$503:*/45"--&%
 .645#&03%&3&%13*0350130%6$5*0/
E50430A EZ Lock Tie-Down Mounting Plate
Allows for mounting of EZ Lock Tie-Down in vehicle,
bolts to weld nuts already in oor assembly.
E90366FBI Extension for Lap Belt/Shoulder Harness ( 1st Row) - Bisque
E90366FLG Extension for Lap Belt/Shoulder Harness ( 1st Row) - Lt. Gray
E90366BI Extension for Lap Belt/Shoulder Harness ( 2nd Row) - Bisque
E90366LG Extension for Lap Belt/Shoulder Harness ( 2nd Row) - Lt. Gray
Connectsto oor-mountedtie-downtrack,standsrigid
for use with lap belt/shoulder harness. Bisque or Lt. Gray colors.
26558
Retractable Securement Belts Deluxe Kit, with Tensioning Knobs (4)
E90432KBI Extra Wheelchair and Occupant Securement System - Bisque
E90432KLG Extra Wheelchair and Occupant Securement System - Lt. Gray
Includes four wheelchair tie-downs, one lap belt/
shoulder harness connector and bag. One system
is included standard. Ivory or Gray colors.
33774
Multi Piece Chest and Waist Belt
Interfaces with standard and optional wheelchair securement
systems to facilitate proper occupant restraint with a wide
variety of wheelchair congurations.
E37556TK Rubber Flooring - Textured - Foam-Backed
Available in Black or Gray
Substitute rubber ooring in lieu of carpet.
/05"7"*-"#-&'034)*1065'"$503:*/45"--&%
 .645#&03%&3&%13*0350130%6$5*0/
E50709A_ _ Striker Covers (Pair) - Interior Color
Covers seat strikers when seat is not used.
Kit includes two covers for one seating position.

$IBTTJT*OGPSNBUJPO
All illustrations, descriptions and specications in this guide are based on the latest product information available at the time of publication. The Braun Corporation reserves the right to make changes at any time without notice.
© 2013 The Braun Corporation
631 West 11th Street, Winamac, IN 46996, USA Phone: [phone] Fax: [phone]
*40
www.braunability.com
Chassis for Power Conversion must be equipped with the OEM power door.
Chassis for Manual Conversion must be equipped with the OEM manual door.
Chassis must not have AWD (All Wheel Drive).
Converted chassis are not returned with the center seats and consoles. If customer requests center seats
and or consoles, a tracking fee will be applied
(see pricing ).
Before ordering or drop-shipping a chassis, we strongly recommend contacting BraunAbility for guid-
ance in deriving payload capacities and selecting equipment and seating options before you purchase
the chassis.
BraunAbility will only convert 2011-2013 chassis with 50,000 or less miles. Chassis must be in sound
condition and must never have been involved in an accident. All chassis are inspected and subject to
acceptance/rejection upon arrival at the BraunAbility plant.
BraunAbility is providing you with another opportunity to help in the sale of vehicles with new and enhanced
warranty options. The new warranty options will make it easier for your customers to take care of warranty
issues that might occur after the sale. The following benets are included in the service contract:
5PXJOH3PBETJEF4FSWJDFt3FOUBM7FIJDMFt5SJQ*OUFSSVQUJPOTt-PTU,FZ-PDL0VU
Purchases of lowered oor conversions with the Toyota Warranty still intact may be oered with the BAPP. A
service contract on a used van/conversion must be sold at time of sale. If you have any questions, you may
contact Burnie Blackmon at 1-800-946-7513 extension 3275 or via email at [e-mail].
#SBVOAbility Protection Plan
