BraunAbility STATIC SOLO ANCHOR User manual

STATIC SOLO
ANCHOR
User Manual
EN Instructions for tting and use

2S10
Thank you for choosing
Static Solo anchor
from BraunAbility!
The following manual is an important part of the product, providing
you with information on how to achieve maximum performance
and safe operation. Keep the manual in a safe place so that you can
refer to it when necessary.
If you have any questions about your equipment, please contact us.
Once again, thank you for placing your condence in our products!
Safe vehicle adaptation solutions
For your safety BraunAbility products are
designed and tested according to current
directives and standards.

Safety information
Fit and use
After care
General guidance
Installation planning
Fitting the static oor anchorage
Equipment storage and maintenance
Warranty
4
6
8
10
10
3
S10
EN
Index
“Declaration of conformity” at the end of the manual.

General Guidance
Safety information
• It is recommended that Solo oor anchors are installed only by an experienced technician/vehicle
converter.
• Do not make any alterations to the Solo oor anchors.
• Do not install the oor anchors to unsound metal, wood, or plastic structures without additional and
suitable reinforcement.
• These oor anchors meet the requirements of ISO 10542 & SAE J2249. Testing was conducted to the
same conguration to that recommended by this guide, any deviation from the recommendation is
the responsibility of the installer.
• The installer is responsible for ensuring that the tting meets all applicable regulations.
If in doubt about the method of installation or use please contact BraunAbility.
• Ensure that the wheelchair is correctly maintained and that the settings of any adjustable parts are
made according to ‘Instructions for Use in Transport’.
• Whenever possible remove any items of luggage etc that may be attached to the wheelchair
and secure or store separately during transport in order to reduce the potential for injury to other
passengers travelling in the vehicle.
• Extra care must be exercised when using vehicle boarding aids such as passenger lifts or ramps during
the loading process. Refer to ‘Instructions For Use’ for information on safe slopes.
4S10

Plastic Bolt Cap
M10 x 60 ISO Grade 12.9 Socket Head Cap Screw
Solo Anchor
50mm Diameter Under Floor Spreader Plate
M10 Nyloc Nut
5
S10
EN
Fit and use

Installation planning
Safety Information
• Position the wheelchair facing forward - centrally in the designated region of the
vehicle.
• To minimise the potential for head injuries in an impact, allow a clear space of at
least 400mm behind and 650mm, (FCZ, front clear zone), in front of the head of
the wheelchair user (Fig 1). The shoulder belt anchorage must be roof or side-wall
anchored at a height level such that the belt webbing passes over the midpoint
of the occupant shoulder and at a height that is at or just above the level of the
occupants shoulders so as not to impose downward loads on the spine.
• A height provision (HHT) ranging from 1000mm to 1550mm should be made,
depending on the size of the passenger. There should also be 200mm of clear
space either side of the wheelchair centre line. If these clear space dimensions
cannot be provided then any structure protruding into this space should be
adequately padded and comply with impact performance requirements of ECE
Regulation 21 ‘FMVSS 201’. All vehicle padding should comply with the ammability
requirements of ECE Regulation 118 ‘FMVSS 302’. Guidance positions are shown in
Fig 2.
• Once happy with the planned wheelchair position, lay the oor anchors in their
desired locations and check carefully immediately below the oor, that they and/or
the hole cutter will not foul brake lines, fuel tanks, chassis members etc. If in doubt
modify the wheelchair anchorage positions accordingly.
• Note: The xing screw supplied with each anchor is an M10 x 60mm long, ISO
grade 12.9, zinc plated socket head cap screw. Where a different length is required
care must be taken to source a cap screw of an equal grade.
Note: seated head
height (HHT)
ranges from as low
as 1000mm for a
6-year-old child to
1550mm for a tall
adult.
6S10

Figure 1 Figure 2
7
S10
EN
Safety information

Fitting the static oor anchorage
Fit and use
1. Mark out the chosen oor anchor positions.
2. Drill an 11mm diameter hole through the nished oor, ply and steel ooring.
3. From the top surface of the oor, counter bore the 11mm dia. hole to a diameter of
35mm and a depth of 13mm.
4. Clear the debris and install the oor anchors as shown in Fig 3, with the anchor slot
orientated as shown in Fig 4. Tighten to a torque of 25-30Nm from underneath,
using the nut and underoor spreader plate.
5. If you need to modify the spreader plate to clear an obstruction, always leave as
much material as possible around the bolt hole. Any modication must be made
such that the original load spreading properties are retained. Further reinforcement
may be required to meet minimum vehicle strength recommendations. Contact
the vehicle manufacturer for further advice.
6. Note: It may be necessary to provide llers between the vehicle oor convolutions
to prevent these from being crushed when tightening up on the nut/cap screw.
7. It is recommended that some type of body sealant or foam ll be used between the
under oor spreader plate and the vehicle under side to prevent ingress of water
and subsequent damage.
It is essential that the slot in each oor anchor is orientated as shown in Fig. 4
8S10

Vehicle
oor
Floor decking
or carpet
Figure 3
Figure 4
9
S10
EN
Fit and use

Equipment storage and maintenance
After care
Solo oor anchors are made from stainless steel and therefore only require a periodic brush to
remove debris from the slot and mating surfaces
Warranty
BraunAbility products are extensively tested using BraunAbility anchorage systems, and our full
warranty normally only applies to BraunAbility equipment when used with BraunAbility branded
anchorages or as instructed.
BraunAbility have also participated in test programs with other manufacturers anchorage
products and will support warranty on the BraunAbility products when used in conjunction with
such jointly tested systems.
For further details on specic applications please contact the Sales Ofce. In other situations,
using BraunAbility products, for which BraunAbility has not participated in a joint test program,
a limited BraunAbility warranty will apply.
10 S10

Declaration of conformity
Conforms to following directives
standards and regulations /
2007/46/EC
214/2014/EU Paragraphs 2.3.1 and 2.3.2.
R.14.07
BraunAbility, Martock, 14th June 2019
Rob Butcher
Director of Engineering
Manufacturer /
BraunAbility UK Ltd
Unwin House
The Horseshoe Coat Road
Martock, Somerset, TA12 6EY
UK
Phone: [phone]
E-mail: [e-mail]
www.braunability.eu
Declares that the products /
S10
Accredited by URS as testing laboratory in accordance with ISO/IEC 17025:2005
Quality system certied in accordance with ISO 9001:2008
Illustrations, descriptions and specications in the user manual are based on current product information.
BraunAbility UK Ltd reserves the right to make alterations without previous notice.
© 2019 BraunAbility UK Ltd
