BRAYER BR4975 User manual

Instruction manual
Инструкция по эксплуатации
Fan BR4975
Вентилятор BR4975
brayer.ru

СОДЕРЖАНИЕ
EN......................................................................................................................................3
DE....................................................................................................................................11
RU ...................................................................................................................................20
KZ....................................................................................................................................29

3EN
FAN BR4975
The fan is intended for articial ventilation of the
room.
DESCRIPTION
1. Base
2. Outgoing Airow Grill
3. Indication Panel
4. Control Panel
Control Panel (4)
5. Fan «ON/OFF» power button « »
6. Remote control holder (17)
7. Oscillation mode on/o󰀨 button «OSC» « »
8. Timer on/o󰀨 button «TIMER» « »
9. Airow type selection button «BLOW» « »
10. Airow speed selection button «SPEED» « »
Indication panel (3)
11. Fan housing rotation indicator « »
12. Airow types indicators « - - »
13. Airow indicators « »
14. Room temperature indicator «ºС»
15. Room temperature/timer operation numeric
symbols
16. Power-on indicator of the timer «H»
EN
Remote control (17)
17. Remote control
18. Mode power button «SILENT BLOW»
19. Timer on/o󰀨 button «TIMER»
20. Fan «ON/OFF» power button
21. Аirow rate selection button «SPEED»
22. Airow type selection button «BLOW»
23. Oscillation mode on/o󰀨 button «OSC»
24. Battery Holder

4EN
ВКЛ./ВЫКЛ
СКОРОСТЬ
ОБДУВ ТАЙМЕР
ПОВОРОТ
ВКЛ./ВЫКЛ СКОРОСТЬ
ТАЙМЕР ОБДУВ
НОЧНОЙ
РЕЖИМ
ПОВОРОТ
4
3
2
1
620
24
21
5
9 8
10
12
11
g. 1 g. 2 g. 3 g. 4 g. 5
19 22
23
18
17
7
14
15
16

5EN
SAFETY MEASURES AND OPERATION
RECOMMENDATIONS
Read the operation manual carefully before using the
fan; after reading, keep it for future reference.
• Use the unit for its intended purpose only, as it is
stated in this manual.
• Mishandling the unit can lead to its breakage and
cause harm to the user or damage to the user’s
property, which is not covered by warranty.
• Do not use the power cord as a carrying handle for
the fan.
• Do not wind the power cord around the fan body.
• Provide that the power cord does not contact with hot
surfaces and sharp furniture edges.
• Protect the unit from impacts, falling, vibrations and
other mechanical stress.
• Avoid blocking the air inlet grid of the fan with foreign
objects, do not cover the unit during the operation.
• Do not use the unit in places where inammable
liquids are used or aerosols are sprayed, do not use
the unit in the places where such liquids are stored.
• Do not use the unit near heating appliances, heat
sources or open ame.
• Do not use the unit outdoors, in bathrooms or in
places with high humidity.
• Do not use the unit in proximity to the kitchen sink,
near swimming pools or other containers lled with
water.
• If the unit is dropped into water, unplug it immediately,
and only then you can take the unit out of water. Apply
to the authorized service center for testing or repairing
the unit.
• Do not touch the unit body, the power cord and the
power plug with wet hands.
• It is not recommended to use the unit during lightning
storms.
• Do not block the fan grids and do not insert foreign
objects onto them.
ATTENTION! A lithium battery is used in the remote
control. To avoid danger, do not allow children to play
with the battery. If your child swallowed a battery,
immediately see your doctor.
• Make sure that the operating voltage of the unit
indicated on the label corresponds to your home
mains voltage.
• Place the fan vertically on a at dry moisture- and
heat-resistant surface, do not place it horizontally and
do not turn it over.
• Do not place the fan on soft surfaces, such as carpets
with high pile, sofas or beds.
• Do not place the fan near curtains and do not direct it
to house plants.
• Do not use the fan in a limited space, for example, in
built-in cabinets or wall niches.
• It is not recommended to stay in the zone of the air
ow from the fan for a long period of time, especially
for children and the elderly.

6EN
• Never leave the unit connected to the mains
unattended.
• Unplug the unit after usage or before cleaning.
• Switch the fan o󰀨 and unplug the power cord plug from
the mains socket.
• When unplugging the unit, hold the power plug and
carefully remove it from the mains socket, do not pull
the power cord, as this can lead to its damage or
cause a short circuit.
• Do not immerse the unit into water or any other liquids.
• If water droplets fall on the fan body, switch it o󰀨 and
disconnect the power plug from the mains before
touching the unit, then wipe the fan body with a dry
cloth.
• For child safety reasons do not leave polyethylene
bags used as packaging unattended.
ATTENTION!
Do not allow children to play with polyethylene bags or
packaging lm. Danger of su󰀨ocation!
• During the unit operation and breaks between
operation cycles, place the unit out of reach of
children.
• The device is not intended to be used by people
(including children) with physical, sensory,
psychological, or mental disabilities, or lacking
experience or knowledge, if they are not under the
supervision of or have not been instructed on the
usage of the device by the person responsible for
their safety.
• From time to time check the power cord integrity.
• If the power cord is damaged, it should be replaced
by the manufacturer, a maintenance service or similar
qualied personnel to avoid danger.
• Do not repair the unit by yourself. Do not disassemble
the unit by yourself, if any malfunction is detected, and
after the unit was dropped, unplug it and apply to the
service center.
• To avoid damages, transport the unit in the original
package.
• Keep the unit in a dry cool place out of reach of
children and disabled persons.
• The unit is not intended for usage by children.
• Do not leave children unattended to prevent them
using the device as a toy.
• Do not allow children to touch the operating surface,
the unit body, the power cord or the power plug during
operation of the unit.
• Be especially careful if children or disabled persons
are near the operating unit.

7EN
THE UNIT IS INTENDED FOR HOUSEHOLD USE
ONLY, DO NOT USE THE UNIT FOR COMMERCIAL
OR LABORATORY PURPOSES.
BEFORE THE FIRST USE
After the unit’s transportation or storage at negative
temperature, unpack it and wait for at least 3 hours
before using it.
• Unpack the unit and remove all the packaging
materials.
• Keep the original package.
• Read the safety measures and operating
recommendations.
• Check the delivery set.
• Examine the unit for damages, in case of damage do
not plug it into the mains.
• Make sure that specied specications of power supply
voltage of the unit correspond to the specications
of your mains. No additional settings required when
using the device in the mains with 60 Hz frequency.
• Wipe the fan body with a slightly damp cloth and then
wipe it dry.
FAN ASSEMBLY
• Fan is supplied with its Base (1) disassembled. Do not
turn on the fan without the Base (1).
• Loosen the shaped fastening screws on the bottom
of the fan housing by rotating them counterclockwise
(Fig. 1).
• Thread the power cable through the opening between
the two halves of the Base (1).
• Align the two halves of the Base (1) and join them so
that the locks would trigger.
• Route the power cord into the corresponding grooves
(Fig. 3).
• Align the protrusions on the lower part of the fan
housing with the holes on the base (1), x the base
(1) by tightening the shaped screws clockwise along
the thread (Fig. 4).
• Making sure that the Base (1) is properly secured (g. 3).
REMOTE CONTROL (17)
ATTENTION! A lithium battery is used in the remote
control. To avoid danger, do not allow children to
play with the battery. If your child has swallowed a
battery, immediately see a doctor.
Battery installation/replacing
• Press on the clamp and remove the battery holder
(24) from the remote control (17) body, insert a
CR2025 battery (are not included) into the holder,
strictly following the polarity.
• Install the battery holder (24) into the remote control
(17).
Notes:
- if there is an isolation insert in the battery holder
(24), remove the insert;

8EN
- replace the battery in time;
- do not recharge the lithium battery;
- remove the battery if you are not planning to use
the unit for a long time;
- remove the used battery from the remote control
(17) and dispose of it.
• When you use the remote control, direct it to the front
part of the fan body.
• The distance between the remote control and the fan
should not exceed 5 m, the coverage angle should be
up to 30 degrees.
• Avoid exposing the receiver to direct sunlight,
otherwise false activation of control commands is
possible.
• If you are not using the remote control (17), insert it
into the remote control holder (6).
FAN USAGE
• Place the fan Base (1) on a at, dry and steady
surface.
• Do not place the fan on soft surfaces, such as carpets
with high pile, sofas, or beds.
• Insert the plug of the power cord into an electric
socket, while room air temperature will be displayed
with numeric symbols (15) on the indication panel (3),
and symbol (14) «ºС» will light up.
Note: numeric temperature readings may slightly di󰀨er
from readings of other thermometers.
Switching the fan on/o󰀨 and selecting the airow
speed
• To turn on the fan, press the « » «ON/OFF» Power
Button (5) on the Control Panel (4) or the «ON/OFF»
button (20) on the Remote Control (17) – the fan will
turn on.
• To turn o󰀨 the fan, press the « » «ON/OFF» Power
Button (5) on the Control Panel (4) or the «ON/OFF»
button (20) on the Remote Control (17) a second time
- the fan will turn o󰀨.
• Press the « » «SPEED» (10) on the Control Panel
(4) or the «SPEED» buttons (17) on the Remote
Control (21), you can select the mode of airow to be
displayed on the Indication Panel (3) through the
«» indicators (13):
- « » low airow speed;
- « » medium airow speed;
- « » high airow speed.
Selecting the airow type
• Press the « » «BLOW» button (9) on the Control
Panel (4) or the «BLOW» button (22) on the Remote
Control (17), select the airow type.
• The airow type is displayed through the « - - »
indicators (12) on the Indication Panel (3):
- « » - normal mode - normal air ventilation;

9EN
- « » - breeze - a mode that simulates natural wind.
Intensity of the air ow randomly changes from a
light breath to a strong gust;
- « » - «night», airow speed will gradually increase
and decrease.
Note: to turn on the «night mode» by the remote control
(17), press the button (18) «NIGHT MODE», and the
indicator (12) « » will light up on the indication panel
(3). To turn o󰀨 the «night mode», press the button (18)
«NIGHT MODE» on the remote control (17) again, and
the indicator (12) « » will go out.
• When you turn on the «night mode», the indication
panel (3) will go out after 8 seconds. Press any button
to turn on the indication panel (3).
Fan operation time timer
• To set the fan operation time, press the « » «TIMER»
button (8) on the Control Panel (4) or the «TIMER»
button (19) on the Remote Control (17); the «H»
indicator (16) on the Indication Panel (3) will turn on.
• Setting the timer operation time from 1 hour to 15
hours with 1 hour increment. The set time will be
displayed on the indication panel (3) with numeric
symbols (15).
• To turn o󰀨 the timer, repeatedly press the button (8
or 19) until the indication panel (3) displays the room
temperature with numeric symbols (15) and the
indicator (14) «ºС» lights up.
Note: in the timer mode, the indication panel (3) will
go out after 8 seconds. Press any button to turn on the
indication panel (3).
Switching the fan body oscillation on/o󰀨
• To turn the oscillation mode on, press the « » «OSC»
button (7) on the Control Panel (4) or the «OSC»
button (23) on the Remote Control button (17) to turn
o󰀨 the oscillation mode, press the « » «OSC»
button (7) on the Control Panel (4) or the «OSC»
button (23) on the remote control (17).
• Once you are nished, turn o󰀨 the fan by pressing
the «ON/OFF» Power Button « » (5) on the Control
Panel (4) or the «ON/OFF» button (20) on the Remote
Control (17), unplug the power cord from the mains
socket.
• For easy storage of the remote control (17), insert it
into the remote control holder (6).
CLEANING AND MAINTENANCE
• Before cleaning the fan, switch it o󰀨 and unplug it.
• Wipe the fan body with a slightly damp cloth and then
wipe it dry.
• Do not use liquid detergents, abrasive cleaners and
any solvents to clean the fan.
• To avoid the risk of electric shock provide that no
water or other liquid gets into the fan body.
• You can use a vacuum cleaner with an appropriate
attachment to clean the Air-Inlet Grill and the Outgoing
Airow Grill (2).

10 EN
STORAGE
• After cleaning put the fan away for storage in a dry
cool place away from children and disabled persons.
• Remove the battery from the remote control (17) if it
will not be used for a long time.
• Before using the fan next time, it is recommended to
check the unit operability and integrity of the power
cord isolation and the power cord plug.
DELIVERY SET
1. Fan — 1 pc.
2. Base – 1pc.
3. Remote control - 1
4. Instruction manual — 1 pc.
TECHNICAL SPECIFICATIONS
• Power supply: 220-240 V, ~ 50/60 Hz
• Rated input power: 50 W
• Remote control
RECYCLING
To prevent possible damage to the
environment or harm to the health of
people by uncontrolled waste disposal,
after service life expiration of the unit or
the batteries (if included), do not discard
them with usual household waste, deliver the unit and
the batteries to specialized centers for further recycling.
The manufacturer reserves the right to change the
appearance, design and specications not a󰀨ecting
general operation principles of the unit, without prior
notice.
The unit operating life is 3 years
The manufacturing date is specied in the serial
number.
In case of any malfunctions promptly apply to the
authorized service center.
The waste generated during the disposal of the unit is
subject to mandatory collection and consequent disposal
in the prescribed manner.
For further information about recycling of this product
apply to a local municipal administration, a disposal
service or to the shop where you purchased this product.
