Indiana Furniture One 10 Split Top Parsons Table User manual

1
One 10: Split Top Parsons Table
Parts List:
Qty (2) Tops
Qty (2) Ends
Qty (1) Trough Assembly
Hardware Included
#8 x1-1/4 ” Flat Head Screws (For Attaching the Tops to the Trough)
#8 x 2” Pan Head Screws (For attaching the Tops to the black metal Suport Brackets)
Tools Required
(2) People
Drill with phillips screw bit
Level
2298-110PST Split Top Parsons Table Assembly Instructions.

2
Step 1: Remove the metal cord covers off of the bases by unscrewing the two pan head screws on the top and set them aside
Step 2: Using the Post and Cam placement guides, place one end of the Trough into the post located on the top of the End and tighten the Cam with a Phillps Screw Driver
Remove Cord Covers
2298-110PST Split Top Parsons Table Assembly Instructions.

3
Step 3: Repeat Step 2 on the remaining End, while keeping the Trough Assembly and the Ends Square with respect to each other.
Step 4: Place (1) Top on the assembly and fasten to the black metal Support Brackets using the #8 x 2” Pan Head Screws Note: the Top is placed on the inside of the trough and is
flush with the ends. Be sure to push the top all the way down prior to fastening) Next, fasten the top to the trough using the pre-marked holes in the Trough and the #8 x 1-1/4” Flat
head screws.
Top is inside the Trough and
Flush with the outside
2298-110PST Split Top Parsons Table Assembly Instructions.

4
Step 5: Repeat Step 4 for the remaining Top. Next (if power modules were ordered with the table), insert power modules and fasten per the provided instructions in
the Power Module box. Now, route cords thru the acces cut out in the Ends and re-install the Metal Cord Covers from Step 1
2298-110PST Split Top Parsons Table Assembly Instructions.
