Robern UPLIFT CABINET UC3027FPL Quick start guide

UPLIFTTM CABINET
Features
SUnique vertically opening, no-swing door allows for
zero clearance installations
SPosition hold door-opening mechanism lets you open
the door as low or as high as you need
S60% recycled aluminum construction
SRust-free anodized aluminum construction, no
formaldehyde resins
S1/4(6 mm) thick adjustable clear glass shelves
SAluminum handle for effortless two-finger lifting
SInterior mirror
SElectric column with six 1500 watt, 120VAC,
15A power outlets
SDiscreet wiring enclosure for clutter-free cable
management
SAuto-on high power, low wattage LED interior lighting
S2725 cubic inches (44,655 cc) storage capacity with
split compartment for maximum flexibility
SRecessed (frame and handle project 1-7/8[4.8 cm]),
semi-recessed 4(10.2 cm) in wall (cabinet, frame and
handle project 3-7/8[9.8 cm]), or surface mount
(cabinet, frame and handle project 7-5/8[19.4 cm])
SNight light in handle provides optimal lighting for
nighttime needs
SMirror defogger allows mirror use even in a humid
environment
Codes/Standards Applicable
Specified model meets or exceeds the following:
SETL listed
SMeets ADA requirements for door opening force for sliding doors
Specified Model
Model Description
UC3027FPL Uplift cabinet with electric, night light and defogger o
Required Accessories - For Surface Mount and Semi-Recessed Installations Only
USK27D6P Uplift mirrored side kit - surface mount o
USK27D6SR Uplift mirrored side kit - semi-recess mount o
Optional Accessories
UORGSHELF20 Uplift 20(50.8 cm) organizer shelf o
TVMOUNT20 TV mount (accommodates up to 19[48.3 cm] diagonal LCD television, width not to
exceed 19-1/2[49.5 cm])
o
POMM Pull-out 3X magnifying mirror o
UBK30D6A Aluminum top and bottom kit for surface mount installations (required when top or bottom is visible) o
UBK30D6ASR Aluminum top and bottom kit for semi-recessed installations (required when top or bottom is visible) o
UFLPAL Uplift pendant light with night light o
UFLWAL Uplift wall sconce with night light o
Page 1 of 2
1121007-4-A
USA: 1-800-877-2376
www.robern.com
UC3027FPL

UPLIFTTM CABINET
Technical Information
Roughing-in opening
(fully recessed)
28-3/4(73 cm) width x
26-1/4(66.7 cm) height x
6(15.2 cm) depth
Roughing-in opening
(semi-recessed)
28-3/4(73 cm) width x
26-1/4(66.7 cm) height x
4(10.2 cm) depth
Installation Notes
Install this product according to the installation guide.
Secure the screws (provided) to a stud to avoid possible
property and product damage. If this is not possible, anchors
(provided) must be inserted before installing the screws.
This cabinet can be surface mounted, semi-recessed or
fully recessed. To semi-recess, cabinets require 4(10.2 cm)
deep opening (2x4 wall). Fully recessed cabinets require 6
(15.2 cm) deep opening (2x6 wall).
Electrical rough-in cable should extend 24(61 cm) out of wall.
Other cables should extend 48(121.9 cm) from wall.
Page 2 of 2
1121007-4-A
UPLIFTTM CABINET
Product Diagram
27
(68.6 cm)
7-5/8
(19.4 cm)
5-5/8(14.3 cm)
20(50.8 cm)
30(76.2 cm)
TV Maximum Size
Width not to exceed
19-1/2(49.5 cm)
19(48.3 cm)
Surface Mount
Recess Mount
26-1/4
(66.7 cm)
7-3/4
(19.7 cm)
7-1/4
(18.4 cm)
26-1/4
(66.7 cm)
28-3/4(73 cm)
48-1/2(123.2 cm)
Minimum from
Finished Ceiling
49(124.5 cm)
Minimum from
Finished Ceiling
46(116.8 cm)
Suggested from
Finished Floor
46-1/2(118.1 cm)
Suggested from
Finished Floor
