Brecknell DS 1000-LCD User manual

Model DS 1000-LCD
Operator Manual
AWT35-100107 Rev AB

AWT35-100107 Rev AB 2/30
Avery Weigh-Tronix is a trademark of the Illinois Tool Works group of companies whose ultimate parent company is
Illinois Tool Works Inc (“Illinois Tool Works”). Copyright © 2021 Illinois Tool Works. All rights reserved.
No part of this publication may be reproduced, stored in an electronic retrieval system, or transmitted in any form or by any
means, electronic, mechanical, photocopying, recording or otherwise without the prior written consent of the copyright owner, or
as permitted by law or under license. Full acknowledgment of the source must be given.
Avery Weigh-Tronix is a registered trade mark of the Avery Weigh-Tronix group of companies. This publication was correct at the
time of going to print however, Avery Weigh-Tronix reserves the right to alter without notice the specification, design, price or
conditions of supply of any product or service at any time.
All third party brands and product names used within this document are trademarks or registered trademarks of their respective
holders.
© Groupe de sociétés Avery Weigh-Tronix, 2021. Tous droits réservés.
Aucune partie de cette publication ne peut être reproduite, enregistrée dans un système de récupération électronique ou
transmise sous quelque forme ou par quelque moyen que ce soit, électronique ou mécanique, par photocopie, enregistrement
ou autre, sans l’accord écrit préalable du propriétaire du droit d’auteur ou tel qu’autorisé par la loi ou dans le cadre d’une licence.
La source doit être reconnue dans son intégralité. Avery Weigh-Tronix est une marque déposée du groupe de sociétés Avery
Weigh-Tronix. Le contenu de cette publication était correct au moment de sa mise sous presse. Toutefois, Avery Weigh-Tronix
se réserve le droit de modifier à tout moment et sans préavis les spécifications, la conception, les tarifs ou les conditions
d’approvisionnement de tout produit ou service.
Toutes les marques et tous les noms de produits tiers utilisés dans ce document sont des marques de commerce ou des
marques déposées de leurs propriétaires respectifs.

AWT35-100107 Rev AB 3/30
TABLE OF CONTENTS
1. Warnings.......................................................................................................................................... 5
2. Introduction.....................................................................................................................................6
2.1. Unpacking .................................................................................................................. 6
2.2. General Installation Guidelines ................................................................................... 6
2.2.1 Positioning the Scale.......................................................................................... 6
2.2.2 Levelling the Scale.............................................................................................. 6
2.3. Powering ON/OFF the Scale ...................................................................................... 6
2.4. Error Codes ................................................................................................................ 7
2.5. Front Panel and Keys ................................................................................................. 7
2.5.1. Display Annunciators ........................................................................................ 7
2.5.2. Operation Keys................................................................................................... 7
3. Scale Operation.............................................................................................................................. 9
3.1. Simple Weighing......................................................................................................... 9
3.2. Tare Weighing ............................................................................................................ 9
3.3. Changing Units ........................................................................................................... 9
3.4. Changing Weighing Mode .......................................................................................... 9
3.5. Print Function (Com Ports) ......................................................................................... 9
4. Weighing Modes .......................................................................................................................... 11
4.1. Hold Function ........................................................................................................... 11
4.1.1 Automatic Hold Mode (Default) ........................................................................... 11
4.1.2. Average Hold Mode ........................................................................................... 11
4.1.3. Manual (Toggle) Hold Mode............................................................................... 12
4.2. Accumulation Function............................................................................................. 12
4.2.1. View Totals........................................................................................................ 12
4.2.2. Clear Totals....................................................................................................... 12
4.3. Comparison Function................................................................................................ 13
4.3.1 Setting HI / OK /LO Limits................................................................................... 13
4.4. Counting Mode [Pcs]................................................................................................ 13
4.3.1. Sampling – Piece Weight .................................................................................. 13
4.4. Percent Weighing Mode........................................................................................... 14
4.4.1. Calculating % Item Weight................................................................................. 14
5. Menus ..............................................................................................................................................15
5.1. User Menu................................................................................................................ 15
5.1.1 User Options ....................................................................................................... 15

AWT35-100107 Rev AB 4/30
5.2. Diagnostics............................................................................................................... 19
5.2.1 Test Menu ........................................................................................................... 19
5.2.2 Misc Menu........................................................................................................... 19
5.3. Calibration Menu ...................................................................................................... 20
5.3.1 Calibration Options.............................................................................................. 20
5.3.2. Calibration Procedure......................................................................................... 21
5.4. Service Configuration Menus.................................................................................... 21
5.4.1 Configuration Options ......................................................................................... 21
6. Specifications .................................................................................................................................25
Appendix - Print Out Formats (FMT)...............................................................................................25
Manual revision history
Current Issue
Date Created
Details of Changes
Rev AA
Nov 2021
New
Rev AB
March 2022
Hold modes

AWT35-100107 Rev AB 5/30
1 Warnings
United States
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Canada
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus
set out in the Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’ émet pas de bruits radioélectriques dépassant les limites applicables aux
appareils numériques de la Classe A prescrites dans le Règlement sur le brouillage radioélectrique edicté
par le ministère des Communications du Canada
1.1 Safe installation
THE EQUIPMENT CONTAINS NO USER SERVICEABLE COMPONENTS.
Installation and maintenance of the equipment must only be carried out by trained and
authorized personnel.
Electrical installation
The mains lead must be connected to a supply outlet with a protective earth contact. The
electrical supply at the socket outlet must provide over current protection of an appropriate
rating.
For your protection all mains (110V or 230V) equipment used out of doors or in wet or damp
conditions should be supplied from a correctly fused source and protected by an approved
ground fault protection device (RCD, GFCI etc.)
IF IN DOUBT SEEK ADVICE FROM A QUALIFIED ELECTRICIAN.
Routine maintenance
To avoid the possibility of electric shock or damage to the machine, always switch off the
machine and isolate from the power supply before carrying out any routine maintenance.
To avoid the risk of the machine falling, where applicable, ensure that it is placed securely on a
flat and level surface.
1.1 Safe use
Caution – Cleaning the indicator/weigh head
Harsh abrasives, solvents, scouring cleaners and alkaline cleaning solutions, such as washing soda,
should not be used especially on the display windows. Under no circumstances should you attempt to
wipe the inside of the machine.
The outside of standard products may be wiped down with a clean cloth, moistened with water containing
a small amount of washing up liquid.
Training
Do not attempt to carry out any procedure on a machine unless you have received the appropriate
training or read the Instruction Manual.
EMC compliance
The following may be applicable to your machine.
WARNING: This is a class A product. In a domestic environment this product may cause radio interference
in which case the user may be required to take adequate measures.

AWT35-100107 Rev AB 6/30
2 Introduction
The DS 1000-LCD is a portable, electronic drum weigher scale. The platform has adjustable locking
feet and a deck with built-in, front and rear ramp angles to easily roll the drums on and off the scale.
The scale provides accurate weight with an easy-to-read LCD display, which can be mounted on
desk/pole stand/guide rail and powered using the included AC/DC power adaptor.
2.1 Unpacking
Carefully take the scale out of its package, make it sure it’s not damaged and all accessories are
included:
•SBI 210-LCD Indicator with 10 in (25 cm) interface cable, pole and bench brackets
•9 Vdc 600 mA Power supply with plug adaptor
•DS1000 Platform with 10 ft (3 m) interface cable
•Installation Manual and Safety Sheet
2.2 General Installation Guidelines
To get the best performance from the scale, link the platform and indicator connectors and, place the
DS 1000-LCD scale in a location that will not degrade its accuracy.
•Try to avoid placing the scale in direct sunlight or near air vents
•Place the scale on a level flat surface. It is not advised to place the scale near vibrating machinery
•Avoid unstable power sources. Do not use near large users of electricity.
2.2.1 Positioning the Scale
Two wheels built into the side channels allow the base to be easily tilted and moved.
2.2.2 Levelling the Scale
Level the scale using the four adjustable feet on the bottom of the platform.
Always check the level prior to using scale.
2.3 Powering ON/OFF the Scale
With the charger plugged into the indicator, press the ZERO/ON/OFF key to turn the scale on.
Press and hold the ZERO/ON/OFF key for 5s to turn the scale off.
Optional: remove the battery compartment lid on the rear to insert 6x AA batteries (not included).

AWT35-100107 Rev AB 7/30
2.4 Error Codes
0---------- Initial zero weight over max load (default, 100% F.S.)
----------- Overload, >1004.5 lb or >501.8 kg (default, 100% F.S. + 9 divisions)
EEP.E# Settings error #
2.5 Front Panel and Keys
Never press a key with anything but your finger. Damage to the overlay may
result if sharp or rough objects are used.
2.5.1 Display Annunciators
Display reading is stable
Scale at Zero. Gross weight is 0, Tare is 0
NET Indicates a Net weight. Tare is not 0.
Indicates an ACCUMULATION transaction
lb kg Current unit of measure (%and Pcs in PERCENTAGE and COUNTING modes)
HI OK|LO Scale is working in COMPARISON mode
Battery status (or AC/DC operated)
HOLD Scale is working in HOLD mode
2.5.2 Operation Keys
The key functions are listed below. In menu mode, the keys have secondary functions.
-Enters/exits the HOLD function.
-In Menu mode goes to previous menu screen; exit menu.
-Sends information to a device; selects WEIGH / COUNTING / PERCENT modes.
-In Menu mode goes to previous menu screen; increase / change a data value.

AWT35-100107 Rev AB 8/30
-Enables the ACCUMULATION mode; displays instances and totals.
-In Menu mode goes to next menu option; decrease / change a data value.
-Selects the unit of measure; opens the COMPARISON limit settings.
-In Menu mode selects / goes to next data value position.
-Tares the scale.
-In Menu mode opens menu option; confirms a value / function / operation.
-Zeroes the scale; turns the scale on / off.
-In Menu mode: cancel an operation and exit from the current working mode.

AWT35-100107 Rev AB 9/30
3 Scale Operation
This section covers the scale operations of simple weighing and basic DS 1000-LCD scale functions.
A warm-up time of 15 minutes is required to stabilize the measured values.
3.1 Simple Weighing
1. Power up the scale and zero the display, if necessary, by pressing the ZERO/ON/OFF key. Be
sure the scale is displaying weight in your preferred unit of measure. Press the UNIT key, if
necessary
2. Place the item to be weighed on the scale platform
The weight is displayed in the weight window.
3.2 Tare Weighing
To carry out a Net weighing, follow the steps below:
1. Power up the scale and zero the display, if necessary, by pressing the ZERO/ON/OFF key. Be
sure the scale is displaying weight in your preferred unit of measure. Press the UNIT key, if
necessary.
2. Place the item to be tared (e.g., hand truck) on the scale platform
Weight of the item is displayed in the weight window.
3. Press the TARE key
The weight is tared, 0 weight is displayed and the Net annunciator lights.
4. Place the item to be weighed on the scale platform
The Net weight is displayed in the weight window.
To remove a tare, remove the item(s) from the scale platform and Press the TARE key…0 weight is
displayed, and the Net annunciator light turns off. The unit is now in gross weighing mode.
3.3 Changing Units
This scale can be used in either kg or lb units of measure. To change the unit of measure, press the
UNIT key.
3.4 Changing Weighing Mode
This scale can be used in weigh / count / percent mode. Press and hold the FUNC key to open the
modes screen and the keys to change weighing mode.
3.5 Print Function (Com Ports)
The DS 1000-LCD comes as standard with one full duplex RS-232 serial port and A type USB port,
designed for connection to either a PC or a serial printer using the appropriate adaptor and cable.

AWT35-100107 Rev AB 10/30
Open the Submenu 1 RS232 / USB in the User Menu to select and configure
the Com Port, print mode, and format. Default print out format MULTIPLE.
1. Power up the scale and zero the display, if necessary, by pressing the ZERO/ON/OFF key. Be
sure the scale is displaying weight in your preferred unit of measure. Press the UNIT key, if
necessary.
2. Place the item to be weighed on the scale platform.
3. Press the PRINT key to send the data out to an external device.

AWT35-100107 Rev AB 11/30
4 Weighing Modes
This section covers the scale operations and functions of the DS 1000-LCD scale.
4.1 Hold Function
This function can be used to freeze a displayed weight/pcs value. In Hold mode, the scale can capture
and hold stable weight/pcs values, or average an unstable value. Then, the indicator temporarily freezes
(Hold) the value on screen for the user to view or record.
The DS 1000-LCD is featured with three hold modes: Manual, Average and Automatic (default).
The indicator provides special mode settings to accommodate weight movements in the
User Menu. Open the Submenu 1 HOLD to enable this mode and change the parameter
values: NLD.RNG (10div), HLD.RNG (5div), AVG.TIM (5sec), STB.TIM (15 sec) accordingly.
4.1.1 Automatic Hold Mode (Default)
When this mode is activated, the scale automatically grabs and holds the weight on the display until the
weight returns to zero and a new Hold weighing session starts.
1. Power up the scale and zero the display, if necessary, by pressing the ZERO/ON/OFF key. Be
sure the scale is displaying weight in your preferred unit of measure. Press the UNIT key, if
necessary.
2. Press the HOLD key to enable this function
The Hold annunciator flashes.
5. Place the item to be weighed/counted on the scale platform
If the weight sensed is above the NLD.RNG zero range (10 div = 5 lb, 2 kg) and doesn’t exceed
the HLD.RNG oscillations range (5 div = 2.5 lb, 1 kg) within the AVG.TIM average time (5 sec),
the indicator calculates and displays the Hold mode weight.
The Hold annunciator stops flashing.
3. Remove the item(s) from the scale platform and repeat the steps above for other Hold weighments.
4. Press the HOLD key to exit the current mode.
If the weight oscillations exceed the HLD.RNG division range value (5 div) within the
STB.TIM time value (15 sec), the indicator will display STB.ER. See Hold Menu.
4.1.2 Average Hold Mode
When this mode is activated, the scale calculates accurate weight of unstable loads e.g., live animal
and holds that weight on the display until the weight returns to zero and tare or hold button is pressed.
1. Power up the scale and zero the display, if necessary, by pressing the ZERO/ON/OFF key. Be
sure the scale is displaying weight in your preferred unit of measure. Press the UNIT key, if
necessary.
2. Press the HOLD key to enable this function
The Hold annunciator flashes.
6. Place the item to be weighed on the scale platform
If the weight sensed is above the NLD.RNG zero range (10 div = 5 lb, 2 kg) and doesn’t exceed
the HLD.RNG oscillations range (5 div = 2.5 lb, 1 kg) within the AVG.TIM average time (5 sec),
the indicator calculates and displays the Hold mode weight.
The Holdannunciator stops flashing.
3. Press the TARE key to repeat the Hold weighment or the HOLD key to exit the current mode.
The scale will automatically exit the Hold mode after the HLD.TIM time value (default, disabled).

AWT35-100107 Rev AB 12/30
If the weight oscillations exceed the HLD.RNG division range value (5 div) within the
STB.TIM time value (15 sec), the indicator will display STB.ER. See Hold Menu.
4.1.3 Manual (Toggle) Hold Mode
When this mode is activated, the scale grabs the first stable weight reading and holds that weight on
the display until the weight returns to zero and the tare or hold button is pressed.
1. Power up the scale and zero the display, if necessary, by pressing the ZERO/ON/OFF key. Be
sure the scale is displaying weight in your preferred unit of measure. Press the UNIT key, if
necessary.
2. Press the HOLD key to enable this function
The Hold annunciator flashes.
7. Place the item to be weighed on the scale platform
If the weight sensed is stable for STB.TIM (15 s) and above the NLD.RNG zero range (10 div
= 5 lb, 2 kg), the indicator displays the Hold mode weight. The Hold annunciator stops flashing.
3. Press the TARE key to repeat the Hold weighment or the HOLD key to exit the current mode.
If the weight is not stable within the STB.TIM time value (15 sec), the indicator displays
STB.ER. See Hold Menu.
4.2 Accumulation Function
This function can be used to record totals of individual weighments and transactions number.
The DS1000-LCD is featured with two accumulation modes: Manual and Automatic (default).
The ACC mode can be disabled and the mode changed in the Config Menu.
The Automatic Acc mode is activated when the load is stable and above the NLD.RNG (10
div = 5 lb, 2kg) zero range. These settings can be changed in the Submenu 1 HOLD.
1. Power up the scale and zero the display, if necessary, by pressing the ZERO/ON/OFF key. Be
sure the scale is displaying weight in your preferred unit of measure. Press the UNIT key, if
necessary.
2. Place the item(s) to be weighed / counted on the scale platform.
3. Press the ACC key to add up the weight/pcs to total weight/pcs and number of transactions.
4. Remove the item(s) from the scale platform and repeat the steps above for other Acc weighments.
In accumulation mode, the function of Hold, Print, Acc, Data, Tare and, Zero keys are available.
4.2.1 View Totals
1. Press and hold the TOTAL key to view the current total weight/pcs and number of transactions.
2. Press the TOTAL key to exit the accumulation screen.
4.2.2 Clear Totals
1. Press and hold the TOTAL key to view the current total weight/pcs and number of transactions.
2. Press the ZERO/ON/OFF key to clear the accumulation memory and return to main screen.
3. Press the TOTAL key to exit the accumulation screen.

AWT35-100107 Rev AB 13/30
4.3 Comparison Function
The DS1000 Comparison mode can be used to quickly check the acceptability or unacceptability of an
item’s weight / count i.e., check-weighing / check-counting. This function is available in weighing,
percent and counting modes. Open the User Submenu 1 BEEP to enable the audible alarm. The
COMPAR function can be disabled in the Config Menu.
1. Power up the scale and zero the display, if necessary, by pressing the ZERO/ON/OFF key. Be
sure the scale is displaying weight in your preferred unit of measure. Press the UNIT key, if
necessary.
2. Press and hold the FUNC key for three seconds. Toggle the weighing modes by pressing the ↑
↓keys and select either the WEIGH, PERCNT or COUNT mode.
3. Place the item(s) to be weighed/counted on the scale platform
If the weight/pieces is beyond the upper limit, the HI annunciator lights
If the weight/pieces is within the limits, the OK annunciator lights
If the weight/pieces is below the lower limit, the LO annunciator lights
4. Remove the item(s) from the platform and repeat the steps above for other Compar weighments.
In comparison mode, the function of Hold, Print, Acc, Data, Tare and, Zero keys are available.
4.3.1 Setting HI / OK /LO Limits
1. In weighing or counting mode, press and hold the DATA key. Release the key when the “COMP”
message pops up. Press the TARE key to confirm.
2. The HI annunciator lights. Adjust the upper limit pressing the ↑↓→keys. Press the TARE key.
3. The LO annunciator lights. Adjust the lower limit pressing the ↑↓→keys. Press the TARE key
to confirm.
4. The indicator stores the limits and returns to weighing / counting mode screen.
4.4 Counting Mode [Pcs]
The DS1000 Counting mode has been designed to allow the operator to easily carry out basic sampling
and counting routines on this scale. The COUNT mode can be disabled in the Config Menu.
1. Power up the scale and zero the display, if necessary, by pressing the ZERO/ON/OFF key. Be
sure the scale is displaying weight in your preferred unit of measure. Press the UNIT key, if
necessary.
2. Press and hold the FUNC key for three seconds. Press the ↑↓keys to navigate the options.
3. Select the COUNT option and press the TARE key to confirm.
The Pcs annunciator flashes and the last stored piece weight is recalled.
4. Place the item(s) to be counted on the scale platform.
5. The number of parts is displayed in the Pcs window.
6. Remove the item(s) from the platform and repeat the steps above for other Count weighments.
In counting mode, the function of Hold, Print, Acc, Data, Tare and, Zero keys are available.
4.4.1 Sampling – Piece Weight
1. In counting mode, press the DATA key. Release the key when the “SPL.---” message pops up.
2. Place a known quantity of items to be counted on the scale platform. Press the TARE key to confirm.
The “INP.PCS” message pops up.

AWT35-100107 Rev AB 14/30
3. Use the ↑↓keys to adjust the number of items to be sampled.
4. Press the TARE key to confirm.
5. The indicator calculates the piece weight and returns to counting mode screen.
If the piece weight obtained is less than 0.5 div, the indicator displays PWT.ER.
4.5Percent Weighing Mode
As the counting mode, the DS1000 Percent weighing mode has been designed to allow the operator to
easily carry out weighments on % basis. The PERCNT mode can be disabled and the % format changed
in the Config Menu.
5. Power up the scale and zero the display, if necessary, by pressing the ZERO/ON/OFF key. Be
sure the scale is displaying weight in your preferred unit of measure. Press the UNIT key, if
necessary.
6. Press and hold the FUNC key for three seconds. Press the ↑↓keys to navigate menu options.
7. Select the PERCNT option and press the TARE key to confirm.
The %annunciator flashes and the last stored % item weight is recalled.
8. Place the item(s) to be weighed on the scale platform.
9. The weight as percentage value of the % item weight is displayed.
10. Remove the item(s) from the platform and repeat the steps above for other %weighments.
In % weighing mode, the function of Hold, Print, Acc, Data, Tare and, Zero keys are available.
4.5.1 Calculating % Item Weight
3. In percent mode, press the DATA key. Release the key when the “SPL.---” message pops up.
4. Place a known weight item(s) to be weighed as % weight on the scale platform. Press the TARE
key to confirm.
The “INP.PCS” message pops up.
5. Use the ↑↓keys to adjust the % value.
6. Press the TARE key to confirm.
7. The indicator calculates the 100% item weight and returns to percent mode screen.
If the piece weight obtained is less than 0.5 div, the indicator displays PWT.ER.

AWT35-100107 Rev AB 15/30
5 Menus
There are four menus that allow you to configure, enable, or execute specific functions or options.
•User and Diagnostics Menu,
page 16
•Calibration Menu, page 17
•Service Configuration Menu, page 18.
5.1 User Menu
In the User Menu there are various submenus available to configure specific sections of the scale
operating modes, including the print and communication settings.
In general weighing mode, press the HOLD and ZERO/ON/OFF keys. Release the keys when the
“USER” message pops up to open the User Menu.
Navigate the menu using the keys, press the TARE key to confirm or the ZERO/ON/OFF
key to cancel the operation / exit the menu.
5.1.1 User Options
USER
SubMenu1
SubMenu2
Option
Default
Description
RESET
NO
NO NO
Returns the USER parameter to the factory
setting
YES
RS232
Port
(com1)
BAUD.RT
600
9600 Sets the baud rate of com1
1200
2400
4800
9600
19200
BYT.FMT
8N1
8N1 Sets the data bits format of com1
7O1
7E1
7O2
7E2
OUT.MOD
NONE
PRTCMD
Sets the output mode of com1:
NONE = no communication;
CONT = continuous output;
PRINT = press PRINT key for output;
CMD = via print format command only;
PRT.CMD = output with PRINT key and
print format command (See FMT);
STABLE = output when the weight stable
condition is met (See Motion settings)
Note: when set to PRINT or CMD mode,
the weighing must be in stable condition.
CONT
PRINT
CMD
PRTCMD
STABLE

AWT35-100107 Rev AB 16/30
FMT
Print Out
Format
MULTPL
MULTPL
Com1 output content and format:
MULTPL = default format. See Appendix;
SINGLE= only displayed content and
current status will be output, it’s
compatible with NCI-SCP01;
EH-SCP = command / response mode;
SCP-12 = only displayed content and
status will be output, it’s compatible with
NCI-SCP12(NCI3835);
Eh-sp2 = See Appendix;
Lfuulf / ------ = special characters. Do not
use.
SINGLE
EH-SCP
SCP-12
Eh-sp2
Lfuulf
Lfuu--
Lf--lf
Lf----
--uulf
--uu--
----lf
------
USB
Port
(com2)
BAUD.RT
600
9600 Sets the baud rate of com2
1200
2400
4800
9600
19200
BYT.FMT
8N1
8N1 Sets the bits format of com2
7O1
7E1
7O2
7E2
OUT.MOD
NONE
PRT.CMD
Sets the output mode of com2:
NONE = no communication;
CONT = continuous output;
PRINT = press PRINT key for output;
CMD = via print format command only;
PRT.CMD = output with PRINT key and
print format command (See FMT);
STABLE = output when the weight stable
condition is met (See Motion settings)
Note: when set to PRINT or CMD mode,
the weighing must be in stable condition.
CONT
PRINT
CMD
PRT.CMD
STABLE

AWT35-100107 Rev AB 17/30
FMT
See
Appendix
MULTPL
MULTPL
Com2 output content and format:
MULTPL = default format. See Appendix;
SINGLE= only displayed content and
current status will be output, it’s
compatible with NCI-SCP01;
EH-SCP = command / response mode;
SCP-12 = only displayed content and
status will be output, it’s compatible with
NCI-SCP12(NCI3835);
Eh-sp2 = See Appendix;
Lfuulf / ------ = special characters. Do not
use.
SINGLE
EH-SCP
SCP-12
Eh-sp2
Lfuulf
Lfuu--
Lf--lf
Lf----
--uulf
--uu--
----lf
------
BEEP
KEY YES / NO YES
Yes = enables the beep when a key is
pressed
COMPAR
mode
NONE
NONE
COMPARE function modes:
NONE =disabled.
L.LOW
IN.LMT
O.HIGH
OUT.LMT
HOLD
Function
HLD.MOD
NONE
AUTO
Enables the HOLD function mode:
NONE = disabled.
TOGGLE (Manual) = if selected, press the
HOLD key to enter HOLD mode. If the
weight is over (NLD.RNG) and stable
(STB.TIM), the data is hold on the display.
Press the HOLD key to exit the Hold mode.
AVERAG = if selected, the
weight over
(NLD.RNG), which variatio
n is less than
(HLD.RNG), it’s averaged
in (AVG.TIM)
and hold on the display. To exit this mode:
press the HOLD key or wait (HLD.TIM)
elapses.
TOGGLE
AVERAG

AWT35-100107 Rev AB 18/30
AUTO
AUTO = if selected, acts as the AVERAG
mode and after each NLD.RNG zero, any
loads over (NLD.RNG),
is hold on the
display.
AVG.TIM
Average
1~60 5 Averages weights in Hold mode for: 1~60
seconds.
STB.TIM
Stable
3*AVG.TI
M ~255 15 Allows 3*(AVG.TIM) ~ 255 seconds for
stable conditions to be met in Hold mode.
HLD.TIM
Hold
0~
65535
0
Displays Hold mode weight for:
0 = until HOLD key pressed;
1~65535 = the scale exits the Hold mode
after 1 ~ 65535 seconds.
HLD.RNG
Oscillations
0~255 5
Sets the weight oscillation range that can
be averaged in Hold mode:
0 = any weight range can be averaged;
1~255 = only the weight which oscillates
within the 1 ~ 255 div range
can be
averaged.
NLD.RNG
No Load
Detected
Range
1~255 10
Sets the weight range that the indicator
considers as
the Zero range for the
relevant function e.g. Auto Hold Mode.
1~255 = the range of weight is 1 ~ 255
div.
Note: It must be above the Config-Motion.
A.OFF.T 0~255 3
Sets the auto off time:
0 = disabled;
1~255 = if in standby mode for 1~ 255
minutes, turn the scale off.
LCD.BLT
AUTO
AUTO
Sets the LCD backlight:
Auto: if in standby mode for 10 seconds,
turn the display backlight off.
OFF：always off;
ON：always on.
OFF
ON
LCD.CST
CST1-5
CST5
Adjusts the LCD contrast

AWT35-100107 Rev AB 19/30
5.2 Diagnostics
In the menus below there are various submenus available to check the scale LCD display and Comm
Ports statuses and SBI 210-LCD indicator information.
5.2.1 Test Menu
In general weighing mode, press the PRINT and ZERO/ON/OFF keys. Release the keys when the
“TEST” message pops up to open the Calibration Menu. The number of calibrations is shown.
Navigate the menu using the keys, press the TARE key to confirm or the ZERO/ON/OFF
key to cancel the operation / exit the menu.
TEST
SubMenu1 Description
DSP.TST LCD testing: the indicator lights all the annunciators, including the 8 digits.
232.RD
RS232 receive data testing: the indicator displays 2.RD.--
It receives and displays any HEX codesless than 7F. E.g. ,If the code received is
0x31, the indicator displays 2.RD.31
232.TD
RS232 send data testing: the indicator displays 2.TD.55 and the serial port
continuously transmits 0x55. Use the and keys to change the character.
USB.RD USB receive data testing: same as RS232 receiving data testing.
USB.TD USB send data testing: same as RS232 send data testing.
KEY.TST
Operation keys testing: the indicator displays KEY.--
The following code will be displayed when any of the below key is pressed
HOLD
01
PRINT
02
ACC
04
UNIT
08
TARE
10
ZERO
20
5.2.2 Misc Menu
In general weighing mode, press the ACC/TOTAL and ZERO/ON/OFF keys. Release the keys when
the “MISC” message pops up to open the Misc Menu.
Navigate the menu using the keys, press the TARE key to confirm or the ZERO/ON/OFF
key to cancel the operation / exit the menu.
MISC
SubMenu1 Description
CODE
Do not use.
VOL
Checking the voltage: the indicator board voltage is shown U X.X（V）

AWT35-100107 Rev AB 20/30
VER
Checking the version: the indicator software version is shown
5.3 Calibration Menu
The scale is configured from the factory to match the specified settings for each unit, as defined by the
product specifications and sales brochure. Modification of the settings can be accomplished by altering
the calibration settings below.
Calibration and/or configuration of calibration settings of your scale should be
accomplished by a trained service technician using certified weights to ensure proper
operation and accuracy. Calibration is not covered under warranty.
5.3.1 Calibration Options
In general weighing mode, press the TARE and ZERO/ON/OFF keys. Release the keys when the
“CAL” message pops up to open the Calibration Menu. The number of calibrations is shown.
Navigate the menu using the keys, press the TARE key to confirm or the ZERO/ON/OFF
key to cancel the operation / exit the menu.
CAL
SubMenu1 SubMenu2 Option Description
ZERO
Adjusts the CAL.P0 point only.
LINE
CAL.P0
Stores the Zero calibration point (mandatory).
CAL.P1
Adds the cal. point 1 (mandatory). Use a
standard weight over 10% F.S.
END.Y YES / NO
Saves and exits the calibration points:
Yes = go to CAL.END;
No = add another calibration point
CAL.P2
Adds the cal. point 2 (optional). Use a standard
weight over 10% F.S. and load used in CAL.P1.
END.Y YES / NO
Saves and exits the calibration points:
Yes = go to CAL.END;
No = add another calibration point
CAL.P3
Linear calibration point3: do third weight point
calibration, standard weight must be over
10%FS and be larger than it in CAL.P2, this
point can be omitted.
GEO 16
Do not use.
See SBI 210-LCD Operation Manual. See
Confi-Geo.Cal
INPUT
Do not use.
