Brecknell 6710 Series User manual

Scale Setup
Parts Included
Tools Required
• Scale body
• Display pad with cable
• Display bracket
• 4 Mounting screws
• USB cable
• Power adapter (12V)
• Phillips screwdriver
• 8mm wrench (included)
NC DCG 09 002 (4/21)
1. Feed display pad cable through
front square cutout in display
bracket.
2. Flip display pad upside down to locate both hinge pins. Insert hinge pins
into hinge holes of display bracket and snap in place.
DateCodeGenie®Scale Quick Start Guide
model Brecknell 6710 Series

6. Feed display pad cable through round opening in
scale body.
4. Turn scale body upside down. Remove and discard,
five short mounting screws with Phillips screwdriver
and shipping screw with 8mm wrench provided.
3. Remove cover from scale body and set aside.
5. Align four holes of the display unit with the four
mounting holes on the scale body. Insert longer
mounting screws and tighten with Phillips
screwdriver to attach.
7. Turn the scale body upright and connect display
pad cable to matching port inside scale body.

12. Press the display pad to power on scale and
press again (less than 3 seconds) to zero the
scale. Press (less than 3 seconds) to change
unit of measure. Press and hold (more than 3
seconds) to turn scale off.
Scale must be certified by your local weights and
measures inspector
11. Remove blue film from scale cover. Then place
cover onto scale body. Adjust display to best
viewing angle.
9. Turn the scale body upright. Connect Power
adapter and USB cable to matching ports on scale
body and to outlet and USB port on DateCodeGenie
device.
8. Wrap excess cable around display bracket hooks.
10. Place the scale in final location for use and view
the level bubble. Adjust the feet until the bubble is
centered.

NC DCG 09 002 (4/21)
Training Resources Contact & Support
Go to DateCodeGenie.com to view available videos
For access to all training tools available 24/7, log into
your portal at DateCodeGenie.com and click HELP from
the gray box on your dashboard or go to the Support
Tab. See all Updates, Videos, and more!
North America
Customer Service
800.328.6508
[e-mail]
International
Customer Service
00 44 (0)1283 527977 option 4
supportdc[email protected]om
NCCO is committed to the quality and reliability of its
DateCodeGenie®products. For more info and full details
of the device limited 1-year warranty, log into your portal
at DateCodeGenie.com, locate the Support Tab then
Documentation to download the full DateCodeGenie
Limited Warranty.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Technical Support
800.774.0478
dcgsuppor[email protected]
Technical Support
00 44 (0)1283 527977 option 4
supportdc[email protected]om
LCD Display Pad
policies. Direct questions to the NTEP Administrator or refer to the NTEP Logo Use
Guideline at www.ncwm.com
2.5. A one-time license fee is charged to non-holders of NTEP Certificates of Conformance
for use of the NTEP Logo. No license fee is charged to current holders of active NTEP
Certificates of Conformance.
3. The States
States participating in NTEP (that is, permitting the sale of devices in their states based on NTEP
Certificates of Conformance) and/or states operating NTEP Participating Laboratories are
encouraged to communicate their activities to potential clients and the public. NTEP
authorization means that a Participating Laboratory is competent to perform standard tests of
specific weighing or measuring devices.
A statement about a state’s participation and/or authorization and the NTEP logo may be used in
correspondence, brochures, test reports, and data sheets (provided the tests or services are
performed in accordance with the terms of its authorization.)
3.1. Statement
•A state whose laboratory has been authorized may use the following statement:
•“Authorized by NCWM under NTEP for testing (identify device types covered by the
Authorization Certificate).”
•A state accepting Certificates of Conformance may use the following statement:
•“(Name of state) permits the sale of weighing or measuring devices for use based on
the issuance of NTEP Certificates of Conformance.”
3.2. Logo
The NTEP Logo (see Section 23.2.5 below) may be used in conjunction with the above
statements or alone in material dealing with NTEP.
4. Questions About Use of Statements or Logo
Any questions regarding the use of the statement or logo not specifically covered above, or any
questions concerning the propriety or acceptability of their use in a particular situation, should be
brought to the attention of the NTEP Committee through the NTEP Administrator.
5. The NTEP Logo
For further information, please contact:
National Conference on Weights and Measures
1135 M Street, Suite 110
Lincoln NE 68508
Tel: [phone]
Fax: [phone]
Email: [e-mail]
LCD Annunciator Description
0
Better known as the "Center of Zero"
annunciator. It is lit when the scale is at the
zero point and the gross weight is 0.
NET
Indicates net mode and the tare weight is not
0.
lb
Indicates the current unit of measure is lb.
oz
Indicates the current unit of measure is oz.
kg
Indicates the current unit of measure is kg.
g
Indicates the current unit of measure is g.
Pcs
Indicates counting mode. Unit of measure is
pieces.
HOLD
Flashes when HOLD key is presses. Remains
permanently on when the Hold function has
become activated.
AC/CHG
When battery is being used or charged, is fully
charged or not installed.
OK
Indicates when data compare is enabled and
current data (weight, pieces or percent) is
between the specified upper and lower limits
Key Mode Condition Function
Weight or count Press for less than 3 seconds Enter or exit HOLD/PRINT mode
Weight or count Press [HOLD] + [ON/OFF] for
more than 3 seconds Enter setup mode
Input data mode Press for more than 3
seconds Input decimal point
Input data mode Press for less than 3 seconds Rotate the flashed position from
right to left
Menu selection mode Select next item of current menu
Weight or count Press [HOLD] + [UNIT] for
more than 3 seconds
Select working mode (weight or
count)
Weight mode Press for less than 3 seconds
Change weighing units: kg->lb->oz
lb:oz (not available in some
conditions)
g (not available in some conditions)
kg (not available in some conditions)
Count mode Press for less than 3 seconds To enter piece weight mode (by way
of sample or input directly)
Weight or count Press for more than 3
seconds
To input compare data (for weight or
pieces) of high and low limitation
Display voltage mode Press for more than 3
seconds To calibrate input voltage value
Display ADC code
mode
Select displaying code from: no-fil-
ter, filter1, filter2
Input data mode Press to enter data one will be added to the flashing
digit
Menu selection mode Select next item of current menu
Weight or count Press for less than 3 seconds Tare function
Weight or count Press for more than 3
seconds
Input pre-set tare weight at selected
weight unit
Input data mode or
Menu selection mode Press to enter data
To confirm input data or current
item selection. Select next item of
current menu or next operation
Display ADC code mode Set or clear tare code
Power off mode Power on
Count or weight Press for less than 3 seconds Zero function
Count or weight Press for more than 3 seconds Power off
Input data Ignore current operation
Menu selection mode Return to last sub-menu
