Bresser Nightlux 200 Pro User manual
Art. No. 1877492
Digital Night Vision Device
3x Nightlux 200 Pro
EN Instruction manual
2Digital Night Vision Device 3x Nightlux 200 Pro · www.bresser.de www.bresser.de · Digital Night Vision Device 3x Nightlux 200 Pro
About this instruction manual
Read the safety instructions and the instruction
manual carefully before using this device.
Keep this instruction manual in a safe place
for future reference. When the device is sold or given to
someone else, the instruction manual must be provided
to the new owner/user of the product.
General warnings
DANGER!
Children must only use the device under adult super-
vision. Keep packaging materials (plastic bags, rubber
bands, etc.) away from children! There is a DANGER OF
CHOKING!
Do not expose the device to high temperatures. Use only
the recommended batteries. Do not short-circuit the
device or batteries or throw them into a re. Excessive
heat and improper handling can cause short circuits, res
and even explosions!
FIRE HAZARD!
Do not expose this device - especially the lenses - to direct
sunlight! The concentration of light rays could cause a
re.
DANGER OF AN ELECTRIC SHOCK!
This device contains electronic parts that are powered by
a power source (batteries). Never leave children unat-
tended when handling the device! Only use the device as
described in the manual. Otherwise, you run the DANGER
of an ELECTRIC SHOCK.
DANGER OF BURNS!
Leaking battery acid can lead to chemical burns. Avoid
contact of battery acid with skin, eyes and mucous
membranes. In the event of contact with acid, rinse the
aected areas immediately with plenty of clean water
and seek medical attention.
NOTE!
Do not disassemble the device! In the event of a defect,
please contact your dealer. They will contact the Service
Centre and can arrange the return of this device for repair
if necessary.
Use only the recommended batteries. Always replace
weak or empty batteries with a new, complete set of
batteries at full capacity. Do not use batteries from dier-
ent brands or types or with dierent capacities. Remove
batteries from the device if it is not in use for a long time!
Privacy PROTECTION!
The binoculars are intended only for private use.
Respect the privacy of your fellow human beings -
do not look into ats with this device, for example!
Scope of delivery
› night vision device
› shoulder strap
› transport bag
› instruction manual
8×AA/LR 6 batteries required (not included).
3
www.bresser.de · Digital Night Vision Device 3x Nightlux 200 Pro
Device overview
Focus wheel - focus objective lens
+ Battery compartment (4 × AA batteries required)
Tripod connection
Micro SD card slot
Viewing area
Shoulder strap hook
Power button (on/off)
Video record button - Press to record a video.
Screen Brightness - Press to adjust screen brightness.
IR button - Press for 7 brightness levels while using the night vision device
at night.
Photo button - Press to take a photo.
Zoom button - Press to gradually zoom.
The maximum zoom is 2 ×. When you have reached 2x, press
the button again to return to 1x.
4Digital Night Vision Device 3x Nightlux 200 Pro · www.bresser.de www.bresser.de · Digital Night Vision Device 3x Nightlux 200 Pro
Inserting the batteries
Open the battery compartments (
+) and insert 4 x
AA batteries in each compartment. Pay attention to the
polarity markings in the battery compartment.
Close the battery compartment cover.
Inserting/Removing the micro SD
Card
Insert the micro SD card into the micro SD card slot
and press until it clicks into place.
To remove the installed micro SD card, please push the
micro SD card inward to release it. When the card is
partially ejected, pull it out.
Storage Capacity: 4 GB or more is recommended.
Note: The device will display "Please insert SD card" if
the micro SD card is not installed.
Operating instructions
Turning the device on: Press and hold the power button
to turn the device on. Once the device is turned on,
look at the LCD screen inside for a preview. Adjust the
focus by turning the focus wheel at the bottom of
the front side. For night mode, turn on the infrared by
pressing the IR button . Increase the brightness by
pressing the button repeatedly. There are 7 levels of
brightness.
Adjusting screen brightness: Press the Screen Bright-
ness button for an adjustment in several steps up to 9.
When you have reached 9, press again to go back to 0.
Using digital zoom: Press the zoom button to zoom
in up to 2x in multiple steps. When you have reached 2x,
press again to return to 1x.
Taking a photo: Turn the device on by pressing the pow-
er button. Adjust the focus by turning the focus wheel
. When taking pictures at night, adjust the brightness
by pressing the IR button. Press the photo button
to take a picture.
Recording a video: Turn the device on by pressing the
power button . Adjust the focus by turning the focus
wheel . When recording at night, adjust the brightness
by pressing the IR button. Press this record button
to start recording a video and press it again to stop
recording.
LCD display information
Photo Mode
Press the photo button to take pictures.
① Number of recorded files (including
photos and videos).
② SD card installed and ready to save photos. When
is displayed, turn the device off
and then insert the SD card.
③ Battery status indicator
Video Mode
Press the video record button to start recording a
video.
① Display video mode
② Minutes of recorded videos
③ SD card installed and ready to save videos.
If is displayed, turn the device off
and then insert the SD card.
④ Battery status indicator
⑤ Indicator of screen brightness (0-9)
①
②
③
②
③
④
①
⑤
5
www.bresser.de · Digital Night Vision Device 3x Nightlux 200 Pro
Troubleshooting
Turned off device:
• If the device does not turn on, check whether the
batteries are defective, missing or not inserted correctly.
Replace the batteries or insert them correctly. Be sure to
use only alkaline batteries.
Poor image quality:
•If you wear glasses, please leave them on while using
the device.
•When using the device during the day, please make
sure the infrared is turned off. At night, make sure that
the infrared function is turned on.
•Adjust the focus by slowly turning the focus wheel at
the bottom of the binoculars' front side. Make sure it's
focused.
Why does the message “No SD Card” appear on the
screen while the micro SD card is inserted?
•Please turn the device off, insert the card, and check the
screen again.
•If the problem persists, please check the micro SD card.
In some cases, micro SD cards cannot be read due to
compatibility issues. Try inserting a different micro SD
card.
INSTRUCTIONS for cleaning
Before cleaning, disconnect the device from the power
supply (remove batteries)! Only use a dry cloth to clean
the exterior of the device. To avoid damaging the elec-
tronics, do not use any cleaning fluid. Clean the eyepieces
and/or lenses only with a soft, lint-free cloth (such as a
microfiber cloth). To avoid scratching the lenses, apply
only gentle pressure with the cleaning cloth. Protect the
device from dust and moisture. Keep it in the supplied
bag or transport packaging. Remove the batteries from
the device if it is not in use for a long time.
Specifications
Viewnder EVF mode
Aspect ratio 4:3
Aperture F1.4
with adjustable aperture
day and night dual mode
Operating mode Preview
Visual distance 200 m at night,
500 m during the day
Objective lens focus Manually adjustable
Visual angle 6.8° degrees
Brightness IR LED
External memory 4GB to 32GB micro SD card
Power supply 8 × alkaline AA battery
Working time Up to 10 hours in daytime
mode, 6 hours in nighttime
mode
Video recordings Yes
Weight 450 g
Dimensions
(height×width×depth) 159 mm × 149 mm × 68 mm
6Digital Night Vision Device 3x Nightlux 200 Pro · www.bresser.de www.bresser.de · Digital Night Vision Device 3x Nightlux 200 Pro
EC DECLARATION OF CONFORMITY
A "Declaration of conformity" in accordance
with the applicable directives and
corresponding standards has been prepared
by Bresser GmbH. This can be viewed at:
www.bresser.de/download/1877492/CE/1877492.pdf
UKCA DECLARATION OF CONFORMITY
Bresser GmbH has issued a „Declaration of
Conformity“ in accordance with applicable
guidelines and corresponding standards. The
full text of the declaration of conformity is
available at the following internet address:
www.bresser.de/download/1877492/UKCA/1877492_
UKCA.pdf
Bresser UK Ltd. • Suite 3G, Eden House, Enterprise Way,
Edenbridge, Kent TN8 6HF, Great Britain
DISPOSAL
Dispose of the packaging materials properly,
according to their type, such as paper or
cardboard. Contact your local waste-disposal service or
environmental authority for information about the proper
disposal.
Do not dispose of electronic devices in the
household garbage!
According to the European Directive 2012/19/
EU on Waste Electrical and Electronic Equipment and
its transposition into national law, used electrical
equipment must be collected separately and recycled in
an environmentally sound manner.
Batteries and rechargeable batteries must not be
disposed of with household waste. You are legally
obliged to return used batteries and accumulators and
can return the batteries after use either at our sales
outlet or in the immediate vicinity (e.g. in the trade or
in municipal collection points) free of charge. Batteries
and accumulators are marked with a crossed-out dustbin
and the chemical symbol of the pollutant, "Cd" stands
for cadmium, "Hg" stands for mercury and "Pb" stands
for lead.
WARRANTY & SERVICE
The regular guarantee period is 5 years and begins on
the day of purchase.
You can consult the full guarantee terms as well as
information on extending the guarantee period and
details of our services at www.bresser.de/warranty_
terms.
Would you like detailed instructions for this product in a
particular language? Then visit our website via the link
below (QR code) for available versions.
Alternatively you can also send an email to manuals@
bresser.de or leave a message on +49 (0) 28 72 – 80
74-220*. Please always state your name, precise address,
a valid phone number and email address, as well as the
article number and product name.
*Number charged at local rates in Germany (the amount you will
be charged per phone call will depend on the tari of your phone
provider); calls from abroad will involve higher costs.
Errors and technical changes excepted.
DOWNLOAD INSTRUCTION MANUAL
http://www.bresser.de/1877492
SERVICE AND WARRANTY
www.bresser.de/warranty_terms
Please be prepared for service requests:
Art. No.: 1877492
Product name:
BRESSER Digital Night Vision Device
3x Nightlux 200 Pro
Instruction manual:
Manual_1877492_Digital-Nightvision-3x-Nightlux-200-
Pro_de_BRESSER_v042021a.pdf
7
www.bresser.de · Digital Night Vision Device 3x Nightlux 200 Pro
SERVICE
DE
AT
CH
BE
Bei Fragen zum Produkt und eventuellen
Reklamationen nehmen Sie bitte zunäch mit dem
Service-Center Kontakt auf, vorzugsweise per E-Mail.
E-Mail: service@bresser.de
Phone*: +49 28 72 80 74 210
BRESSER GmbH
Kundenservice
Gutenbergr. 2
46414 Rhede
Deutschland
*Lokale Rufnummer in Deutschland (Die Höhe der Gebühren je
Telefonat i abhängig vom Tarif Ihres Telefonanbieters); Anrufe aus
dem Ausland sind mit höheren Koen verbunden.
GB
IE
Please contact the service centre r for any
queions regarding the product or claims,
preferably by e-mail.
Telephone*: +44 1342 837 098
Bresser UK Ltd.
Suite 3G, Eden House
Enterprise Way
Edenbridge, Kent TN8 6HF
United Kingdom
*Number charged at local rates in the UK (the amount you will be
charged per phone call will depend on the tari of your phone
provider); calls from abroad will involve higher cos.
FR
BE
Si vous avez des queions concernant ce produit
ou en cas de réclamations, veuillez prendre contact
avec notre centre de services (de préférence via
e-mail).
E-Mail: sav@bresser.fr
Téléphone*: 00 800 6343 7000
BRESSER France SARL
Pôle d’Activités de Nicopolis
314 Avenue des Chênes Verts
83170 Brignoles
France
*Prix d'un appel local depuis la France ou Belgique
NL
BE
Als u met betrekking tot het product vragen of
eventuele klachten heeft kunt u contact opnemen
met het service centrum (bij voorkeur per e-mail).
Telefoon*: +31 528 23 24 76
BRESSER Benelux
Smirnoraat 8
7903 AX Hoogeveen
The Netherlands
*Het telefoonnummer wordt in het Nederland tegen lokaal tarief
in rekening gebracht. Het bedrag dat u per gesprek in rekening
gebracht zal worden, is afhankelijk van het tarief van uw telefoon
provider; gesprekken vanuit het buitenland zullen hogere koen met
zich meebrengen.
ES
IT
PT
Si desea formular alguna pregunta sobre el
producto o alguna eventual reclamación, le
rogamos que se ponga en contacto con el centro de
servicio técnico (de preferencia por e-mail).
Teléfono*: +34 91 67972 69
BRESSER Iberia SLU
c/Valdemorillo,1 Nave B
P.I. Ventorro del Cano
28925 Alcorcón Madrid
España
*Número local de España (el importe de cada llamada telefónica
dependen de las tarifas de los distribuidores); Las
llamadas des del extranjero están ligadas a costes
suplementarios..
www.bresser.de · Digital Night Vision Device 3x Nightlux 200 Pro
Bresser GmbH
Gutenbergstr. 2
46414 Rhede · Germany
www.bresser.de
@BresserEurope
Errors and technical changes reserved.
Manual_1877492_Digital-Nightvision-3x-Nightlux-200-Pro_en_BRESSER_v072022a
This manual suits for next models
1
Table of contents
