Daheng Imaging MERCURY2 USB3 User manual

MERCURY2 USB3 Vision Cameras
User Manual
Version: V2.0.4
Date: 2023-10-09
China Daheng Group, Inc. Beijing Image Vision Technology Branch

All rights reserved. No parts of this manual may be used or reproduced, in any forms or by any means,
without prior written permission of China Daheng Group, Inc. Beijing Image Vision Technology Branch.
The right is also reserved to modify or change any parts of this manual in the future without prior notification.
All other trademarks are the properties of their respective owners.
© 2023 China Daheng Group, Inc. Beijing Image Vision Technology Branch
Web:
www.daheng-imaging.com/en
Sales Email:
[e-mail]
Sales Tel:
[phone]-8081
Support Email:
[e-mail]

Preface
We really appreciate your choosing of DAHENG IMAGING products.
The MERCURY2 USB3 Vision camera is DAHENG IMAGING's latest area scan industrial digital camera
with large and high-quality sensor, featuring high resolution, high definition and extremely low noise. The
MERCURY2 USB3 Vision cameras are include standard version (MER2-U3(-L) series), Pro version
(ME2P-U3 series), Lite version (ME2L-U3(-L) series) and Super version (ME2S-U3 series). The camera
is equipped with standard USB3.0 interface, is easy to install and use.
The MERCURY2 USB3 Vision cameras are especially suitable for machine vision applications such as
industrial inspection, medical, scientific research, education, security and so on.
This manual describes in detail on how to install and use the MERCURY2 USB3 Vision digital cameras.

© 2023 China Daheng Group, Inc. Beijing Image Vision Technology Branch I
