Bresser Translucidus NV User manual

Weather Station · Wetterstation ·
Translucidus NV
EN Instruction manual
DE Bedienungsanleitung

DE
Besuchen Sie unsere Website über den folgenden QR Code oder Weblink um weitere
Informationen zu diesem Produkt oder die verfügbaren Übersetzungen dieser Anleitung zu
nden.
GB
Visit our website via the following QR Code or web link to nd further information on this
product or the available translations of these instructions.
FR
Si vous souhaitez obtenir plus d’informations concernant ce produit ou rechercher ce mode
d’emploi en d’autres langues, rendez-vous sur notre site Internet en utilisant le code QR ou le
lien correspondant.
NL
Bezoek onze internetpagina via de volgende QR-code of weblink, voor meer informatie over
dit product of de beschikbare vertalingen van deze gebruiksaanwijzing.
ES
¿Desearía recibir unas instrucciones de uso completas sobre este producto en un idioma
determinado? Entonces visite nuestra página web utilizando el siguiente enlace (código QR)
para ver las versioneAs disponibles.
IT
Desidera ricevere informazioni esaustive su questo prodotto in una lingua specica? Venga a
visitare il nostro sito Web al seguente link (codice QR Code) per conoscere le versioni disponibili.
www.bresser.de/P7007610
www.bresser.de/warranty_terms
GARANTIE · WARRANTY · GARANTÍA · GARANZIA
Le produit est recyclable, soumis à une responsabilité élargie du producteur
et fait l’objet d’une collecte sélective. Lors de l’élimination, il convient de
respecter les règles d’élimination complémentaires applicables en France :
DE
Besuchen Sie unsere Website über den folgenden QR Code oder Weblink um weitere
Informationen zu diesem Produkt oder die verfügbaren Übersetzungen dieser Anleitung zu
nden.
GB
Visit our website via the following QR Code or web link to nd further information on this
product or the available translations of these instructions.
FR
Si vous souhaitez obtenir plus d’informations concernant ce produit ou rechercher ce mode
d’emploi en d’autres langues, rendez-vous sur notre site Internet en utilisant le code QR ou le
lien correspondant.
NL
Bezoek onze internetpagina via de volgende QR-code of weblink, voor meer informatie over
dit product of de beschikbare vertalingen van deze gebruiksaanwijzing.
ES
¿Desearía recibir unas instrucciones de uso completas sobre este producto en un idioma
determinado? Entonces visite nuestra página web utilizando el siguiente enlace (código QR)
para ver las versioneAs disponibles.
IT
Desidera ricevere informazioni esaustive su questo prodotto in una lingua specica? Venga a
visitare il nostro sito Web al seguente link (codice QR Code) per conoscere le versioni disponibili.
www.bresser.de/P7007610
www.bresser.de/warranty_terms
GARANTIE · WARRANTY · GARANTÍA · GARANZIA
Le produit est recyclable, soumis à une responsabilité élargie du producteur
et fait l’objet d’une collecte sélective. Lors de l’élimination, il convient de
respecter les règles d’élimination complémentaires applicables en France :

English ............................. 4
Deutsch ........................... 20

4 / 40
1 Imprint
Bresser GmbH
Gutenbergstr. 2
46414 Rhede
Germany
www.bresser.de
For any warranty claims or service inquiries, please refer to
the information on "Warranty" and "Service" in this docu-
mentation. We ask for your understanding that unsolicited
returns cannot be processed.
Errors and technical changes excepted.
© 2023 Bresser GmbH
All rights reserved.
The reproduction of this documentation - even in extracts -
in any form (e.g. photocopy, print, etc.) as well as the use
and distribution by means of electronic systems (e.g. image
file, website, etc.) without the prior written permission of
the manufacturer is prohibited.
The designations and brand names of the respective com-
panies used in this documentation are generally protected
by trade, trademark and/or patent law in Germany, the
European Union and/or other countries.
2 Validity note
This documentation is valid for the products with the follow-
ing article numbers:
7007610
Manual version: 0823
Manual designation:
Manual_7007610_Translucidus-NV_en-
de_BRESSER_v082023a
Always provide information when requesting service.

5 / 40
3 About this Instruction Manual
NOTICE
These operating instructions are to be considered a
component of the device.
Read the safety instructions and the instruction manual
carefully before using this device.
Keep these instruction manual in a safe place for future ref-
erence. If the device is sold or passed on, the instruction
manual must be passed on to any subsequent owner/user
of the product.
4 General safety instructions
DANGER
Danger of suffocation!
Improper use of this product may result in suffocation, es-
pecially for children. It is therefore imperative that you ob-
serve the following safety information.
• Keep packaging materials (plastic bags, rubber bands,
etc.) away from children! There is a danger of choking!
• This product contains small parts that can be swal-
lowed by children! Choking hazard!
DANGER
Risk of an electric shock!
This device contains electronic parts that are powered by a
power source (AC adapter and/or batteries). Improper use
of this product may result in electric shock. Electric shock
can cause serious or fatal injuries. It is therefore imperative
that you observe the following safety information.

6 / 40
• Never leave children unattended when handling the
device! Follow the instructions carefully and do not at-
tempt to power this device with anything other than
power sources recommended in this instruction
manual, otherwise there is a danger of an electric
shock!
DANGER
Explosion hazard!
Improper use of this product may result in fire. It is essen-
tial that you observe the following safety information in or-
der to avoid fires.
• Do not expose the device to high temperatures. Use
only the recommended batteries. Do not short-circuit
the device or batteries, or throw them into a fire! Ex-
cessive heat or improper handling could trigger a
short-circuit, a fire or an explosion!
NOTICE
Danger of material damage!
Improper handling may result in damage to the unit and/or
accessories. Therefore, use the device only in accordance
with the following safety information.
• Do not disassemble the device! In the event of a defect,
please contact your dealer. They will contact the Service
Center and can arrange the return of this device for re-
pair if necessary.
• Do not immerse the unit in water!
• Do not expose the device to impacts, vibrations, dust,
constant high temperatures or excessive humidity. This
can result in malfunctions, short-circuits or damage to
the batteries and components.

7 / 40
• Use only the recommended batteries. Always replace
weak or empty batteries with a new, complete set of
batteries at full capacity. Do not use batteries from dif-
ferent brands or types or with different capacities. Re-
move batteries from the device if it is not to be used for
a longer period of time!
NOTICE
Risk of voltage damage!
The manufacturer is not liable for damage related to im-
properly installed batteries!
5 Parts overview and scope of delivery
AAA/LR03 1.5V
AAA/LR03 1.5V
9
3
4
5
6
78
14
15
16
17
18
12
13
10
11
2
1
A
B
Illustration1: All parts of the weather station (top) and the outdoor
sensor (bottom)
1 Display 2 Base

8 / 40
3 [SET] button 4 [UP] button
5 [DOWN] button 6 [ALERT] button
7 [ALARM] button 8 [SNZ] button (SNOOZE/
LIGHT)
9 Speaker 10 Battery compartment
11 Battery compartment
cover
12 Display
13 Function indicator 14 Wall mount hole
15 CH slider switch 16 °C/°F button
17 Battery compartment 18 Battery compartment cover
Scope of delivery:
Base station (A), wireless sensor (B)
Also required (not included):
2 x AAA/LR03 1.5V batteries (station), 2 x AAA/LR03 1.5V bat-
teries (sensor)
6 Screen display
D1 D5
D6
D7
D8
D9
D10
D12
D18
D14
D17
D16
D15
D19
D21
D20
D22
D25
D4
D27
D26
D23
D30
D11
D31
D29
D28
D32
D33
D2
D3
D13
D24
Illustration2: Screen display of the base station
D1 Outdoor temperature (de-
pending on D5)
D2 Trend arrow (outdoor tem-
perature, depending on
D5)

9 / 40
D3 Temperature unit (°C or °F
selectable)
D4 Humidity symbol
D5 Channel indicator (1-3) with
signal strength symbol
D6 Symbol for automatic chan-
nel change
D7 Temperature alarm sym-
bol
D8 Symbol for highest or low-
est value to D7
D9 Weather trend display D10 Frost warning symbol
D11 Trend arrow (outdoor hu-
midity, depending on D5)
D12 Barometric pressure
D13 Barometric pressure unit
(mB/hPa)
D14 Weekday
D15 Date (month:day or
day:month selectable)
D16 AM/PM information in 12-
hour time mode
D17 Alarm time (hours :
minutes)
D18 Symbol for active alarm
D19 Time (hours:minutes) D20 AM/PM information in 12-
hour time mode
D21 Symbol for time signal
transmission with daylight
saving time (DST)
D22 Trend arrow (indoor hu-
midity)
D23 Climate indicator D24 Indoor humidity (in %)
D25 Humidity symbol D26 Trend arrow (indoor tem-
perature)
D27 Indoor temperature D28 Temperature symbol
D29 Battery level indicator
(base station)
D30 Temperature unit (°C or °F
selectable)
D31 Humidity D32 Temperature symbol
D33 Battery level indicator
(wireless sensor, depend-
ing on D5)

10 / 40
7 Before commissioning
NOTICE
Avoid connection faults!
In order to avoid connection problems between the devices,
the following points must be observed during commission-
ing.
1. Place the base unit (receiver) and sensor (transmitter)
as close together as possible.
2. Connect the power supply to the base unit and wait un-
til the indoor temperature is displayed.
3. Establish power supply for the sensor.
4. Set up/operate the base unit and sensor within the ef-
fective transmission range.
5. Make sure that the base unit and the radio sensor are
set to the same channel.
When changing the batteries, always remove the batteries
from both the base unit and the sensor and reinsert them in
the correct order so that the radio link can be re-estab-
lished. If one of the two devices is operated via a mains
power connection, the power connection must also be
briefly disconnected for this device when the batteries are
changed. If, for example, only the batteries in the sensor
are replaced, the signal may subsequently not be received
at all or not be received correctly.
Note that the actual range depends on the respective con-
struction materials used for the buildings as well as the re-
spective position of the base unit and the outdoor sensor.
External influences (various radio transmitters and other
sources of interference) can greatly reduce the possible
range. In such cases, we recommend finding other locations
for both the base unit and the outdoor sensor. Sometimes
moving the sensor by just a few centimeters is enough!

11 / 40
8 Setting up power supply
Base unit
1. Remove the battery compartment cover.
2. Insert batteries into the battery compartment. Make
sure that the batteries are correctly aligned (+/- poles).
3. Replace the battery compartment cover.
4. Wait until indoor temperature is displayed on the base
unit.
Wireless sensor
5. Remove the battery compartment cover.
6. Move the CH slider switch to the position for the de-
sired transmission channel (1, 2 or 3). The correspond-
ing channel is shown on the sensor display.
7. Insert batteries into the battery compartment. Make
sure that the batteries are correctly aligned (+/- poles).
8. Replace the battery compartment cover.
Battery replacement
9. Always replace all batteries in the base unit and/or
wireless sensor with a completely new set of the same
type. Proceed as described above.
10. After the battery replacement, press the DOWN button
on the base unit for approx. 3 seconds to reactivate the
wireless connection.
NOTICE!This weather station can be operated with up to 3
wireless sensors. Each connected wireless sensor must be
operated on a different channel. If only one wireless sensor
is connected, it should be operated on channel 1.

12 / 40
9 Battery level indicator
1. When the level of the batteries in the base station or in
the wireless sensor reaches a critical level, the battery
level symbol appears in the appropriate area on the
display.
2. When replacing a set of batteries, always remove the
batteries from the other part of the device and reinsert
the batteries in the order intended (see chapter "Estab-
lishing the power supply"). Replace the batteries to be
replaced in the corresponding part of the device with a
completely new set with full capacity. This ensures that
the connection between the devices is re-established
correctly.
NOTICE!The symbol for the battery level indicator is only
displayed when the batteries are empty. If the battery level
is sufficient, the icon will not be displayed.
10 Automatic time setting
After power supply has been established, the unit automat-
ically searches for the radio signal. It takes approximately 3
to 8 minutes for this process to be completed.
If the radio signal is correctly received, the time is set auto-
matically and the reception symbol is displayed.
If the radio clock signal is not received, press the UP button
for approx. 3 seconds to initiate signal reception.
If still no radio signal is received, the time must be set
manually.
11 Manual time setting
1. Press the [SET] button for approx. 3 seconds to enter
the time setting mode.
2. Digits to be set are flashing.
3. Press [UP] or [DOWN] button to change the value.

13 / 40
4. Press the [SET] button to confirm and switch to the next
setting.
5. Sequence of settings: 12/24 > time zone > hours >
minutes > day/month display change > year > month >
day > language
6. Finally, press the [SET] button to save the settings and
exit settings mode.
NOTICE!If no button has been pressed for 20 seconds, the
setting mode is automatically exited. The changes made up
to that point are saved.
12 Time zone setting
The time zone is set as part of the manual time setting. Fur-
ther information can also be found in the chapter “Manual
Time Adjustment”.
1. Press the SET button for approx. 3 seconds to enter the
time setting mode.
2. Possibly press the SET button several times until the
display shows the setting for the time zone (the factory
setting is '00').
3. Press UP or DOWN button to select the desired time de-
viation in hours (-12 to +12 hours).
4. Finally, press SET button for approx. 3 seconds to con-
firm the set time deviation.
13 Alarm setting
NOTICE!The alarm setting cannot be made when the time
signal search is active (the corresponding icon is flashing).
Wait until the time signal search is completed to set the
alarm manually.
1. Press the [SET] button to display the alarm time.
2. Press the [ALARM] button for approx. 2 seconds to
enter the alarm time settings mode.

14 / 40
3. Digits to be set are flashing.
4. Press [UP] or [DOWN] button to change the value.
5. Press the [ALARM] button to confirm the entry and
move to the next setting.
6. Order of the settings: hours > minutes
7. Finally, press the [ALARM] button to save the settings
and exit the settings mode.
Activate/deactivate the alarm
8. In normal display mode, press the [ALARM] button to
activate the wake-up call. The icon appears.
9. In normal display mode, press the [ALARM] button
again to deactivate the wake-up call. The icon is no
longer displayed.
10. In normal display mode, press the [ALARM] button to
display the currently set alarm time.
14 Snooze function
1. When the alarm sounds, press SNZ button to activate
the snooze function. The alarm will sound again in 5
minutes.
2. Press any other button when the alarm sounds to inter-
rupt the alarm until the alarm time will be reached
again.
15 Receiving measurements automatically
Once the power supply is enabled, the base station will dis-
play the measurement readings. Readings from the remote
sensor will be displayed within 3 minutes after powering it
on.
Read the detailed manual for more information about read-
ings (see download information on page 2).

15 / 40
16 Display change °C/°F
In normal display mode, press the UP button to toggle
between °C and °F.
17 Weekday display
On the display of the weather station, the first two letters of
the respective weekday are shown in the selected language.
Example: MO = Monday, TU = Tuesday etc
18 HI/LO Alert
Set highest/lowest value alarm
1. If necessary, press the [DOWN] button several times to
select the desired channel.
2. In normal display mode, press the [ALERT] button for
about 3 seconds to enter the temperature alarm set-
tings mode.
3. Press the [UP] or [DOWN] button to set the desired
temperature value.
4. Press the [ALERT] button to confirm and switch to the
next setting.
5. Sequence of settings: Outside temperature maximum >
outdoor temperature minimum
Enable or disable highest/lowest value alarm
6. In normal display mode, press the [ALERT] button to ac-
tivate the temperature alarm.
7. The temperature alarm sounds as soon as the preset
maximum or minimum temperature is reached.
8. Press the [ALERT] button to end the alarm.

16 / 40
19 Climate indicator
Based on the recorded temperature and humidity values for
indoors, the weather station calculates a climate indicator
and shows a corresponding symbol on the display.
1 2 3 4
Illustration3: Graphic symbols for the indoor climate
1 Humidity is between 40%
and 70%, temperature is in
the range of 20°C to 28°C
2 Humidity is higher than
71%
3 Humidity is below 39% 4 Humidity is between 40%
and 70%, temperature is
not in the range of 20°C to
28°C
20 Weather trend
The weather station calculates a weather trend forecast for
the next 12 hours based on the recorded measurement val-
ues. These are represented with the following symbols.
1 2 3 4
Illustration4: Graphical weather trend forecast
1 Sunny 2 Partly Cloudy
3 Cloudy 4 Rain
5 Snow

17 / 40
21 Trend arrow indicators
123
1 Rising 2 Steady
3 Falling
The temperature and humidity trend indicator shows the
trends of changes in the forthcoming few minutes. Arrows
indicate a rising, steady or falling trend.
22 Connecting remote sensors
The weather station can display the readings from up to 3
wireless sensors* of the same type. Each wireless sensor
must be set to a separate channel. Proceed as follows to set
the channel.
1. Remove the battery compartment cover of the wireless
sensor.
2. Set the CH slider switch to the desired channel (1, 2 or
3).
3. Re-attach the battery compartment cover.
4. Press the [DOWN] button on the base station several
times to display the readings of the individual channels
one after the other or automatically alternate. The se-
lected channel is shown on the display.
5. Press the [DOWN] button for approx. 3 seconds to initi-
ate the search for a sensor.
NOTICE!Each connected wireless sensor must be set to a
different channel. If only one wireless sensor is connected,
it should be set to channel 1.
*one wireless sensor included, more optionally available

18 / 40
23 Ice pre-alert
1. When the outdoor temperature drops to the range
between -1°C and 3°C (30°F to 37°F), the frost warning
symbol will appear on the display and will flash
continuously.
2. The frost warning symbol disappears as soon as
the temperature exceeds 6°C (42°F).
24 Barometric pressure display
The barometric pressure is displayed with the measurement
units ‘mB’ (Milibar) and ‘hPa’ (Hectopascal).
25 Disposal
Dispose of the packaging materials according to its type. In-
formation on proper disposal can be obtained from the muni-
cipal waste disposal service provider or environmental agency.
Do not dispose of electronic devices in the household
garbage!
According to the European Directive 2012/19/EU on Waste
Electrical and Electronic Equipment and its transposition into
national law, used electrical equipment must be collected sep-
arately and recycled in an environmentally sound manner.
Batteries and rechargeable batteries must not be disposed of
with household waste. You are legally obliged to return used
batteries and accumulators and can return them after use
either at our sales outlet or in the immediate vicinity (e.g. in the
trade or in municipal collection points) free of charge.
Batteries and accumulators are marked with a crossed-out
dustbin and the chemical symbol of the pollutant, "Cd" stands
for cadmium, "Hg" stands for mercury and "Pb" stands for lead.

19 / 40
26 Technical data
Base station
Radio clock signal: DCF
Power supply: 3V
Battery operation: 2 x AAA/LR03 batteries 1.5V
Temperature unit: °C or °F selectable
Temperature range: -9.9°C to +50°C
Humidity range: rH 20% to 95%
Wireless sensor
Power supply: 3V
Battery operation: 2 x AAA/LR03, 1.5V
Temperature unit: °C or °F selectable
Temperature range: -40°C to +60°C
Transmission frequency: 433Mhz
Maximum transmitting power: less than 10mW
Transmission range: up to 80 m (in interference-free terrain)
27 Warranty
The regular warranty period is 2 years and starts on the day
of purchase. To benefit from an extended voluntary war-
ranty period as indicated on the gift box, registration on our
website is required.
You can consult the full guarantee terms as well as informa-
tion on extending the guarantee period and details of our
services at www.bresser.de/warranty_terms.
28 EC declaration of conformity
Bresser GmbH hereby declares that the radio equipment
type with item number 7007610 is in compliance with Direct-
ive 2014/53/EU. The full text of the EC Declaration of Con-
formity is available at the following web address:
www.bresser.de/download/7007610/CE/7007610_CE.pdf

20 / 40
1 Impressum
Bresser GmbH
Gutenbergstr. 2
46414 Rhede
Germany
www.bresser.de
Für etwaige Gewährleistungsansprüche oder Serviceanfra-
gen verweisen wir auf die Informationen zu „Garantie“ und
„Service“ in dieser Dokumentation. Wir bitten um Verständ-
nis, dass unaufgeforderte Rücksendungen nicht bearbeitet
werden können.
Irrtümer und technische Änderungen vorbehalten.
© 2023 Bresser GmbH
Alle Rechte vorbehalten.
Die Reproduktion dieser Dokumentation – auch auszugs-
weise – in irgendeiner Form (z.B. Fotokopie, Druck, etc.) so-
wie die Verwendung und Verbreitung mittels elektronischer
Systeme (z.B. Bilddatei, Website, etc.) ohne eine vorherige
schriftliche Genehmigung des Herstellers ist nicht gestattet.
Die in dieser Dokumentation verwendeten Bezeichnungen
und Markennamen der jeweiligen Firmen sind im Allgemei-
nen in Deutschland, der Europäischen Union und/oder wei-
teren Ländern waren-, marken- und/oder patentrechtlich
geschützt.
2 Gültigkeitshinweis
Diese Dokumentation ist gültig für die Produkte mit den
nachfolgend aufgeführten Artikelnummern:
7007610
Anleitungsversion: 0823
Bezeichnung dieser Anleitung:
Manual_7007610_Translucidus-NV_en-de_BRES-
SER_v082023a
