Bresser 7008000CM3000 User manual

Weather Station · Wetterstation ·
ClimaTrend Life H
EN Instruction manual
DE Bedienungsanleitung

DE
Besuchen Sie unsere Website über den folgenden QR Code oder Weblink um weitere Informationen
zu diesem Produkt oder die verfügbaren Übersetzungen dieser Anleitung zu finden.
EN
Visit our website via the following QR Code or web link to find further information on this product or the
available translations of these instructions.
FR
Si vous souhaitez obtenir plus d’informations concernant ce produit ou rechercher ce mode d’emploi en
d’autres langues, rendez-vous sur notre site Internet en utilisant le code QR ou le lien correspondant.
NL
Bezoek onze internetpagina via de volgende QR-code of weblink, voor meer informatie over dit product
of de beschikbare vertalingen van deze gebruiksaanwijzing.
ES
¿Desearía recibir unas instrucciones de uso completas sobre este producto en un idioma determinado?
Entonces visite nuestra página web utilizando el siguiente enlace (código QR) para ver las versiones
disponibles.
IT
Desidera ricevere informazioni esaustive su questo prodotto in una lingua specifica? Venga a visitare il
nostro sito Web al seguente link (codice QR Code) per conoscere le versioni disponibili.
www.bresser.de/P7008000000000
www.bresser.de/warranty_terms
GARANTIE · WARRANTY · GARANTÍA · GARANZIA
DE
Besuchen Sie unsere Website über den folgenden QR Code oder Weblink um weitere Informationen
zu diesem Produkt oder die verfügbaren Übersetzungen dieser Anleitung zu finden.
EN
Visit our website via the following QR Code or web link to find further information on this product or the
available translations of these instructions.
FR
Si vous souhaitez obtenir plus d’informations concernant ce produit ou rechercher ce mode d’emploi en
d’autres langues, rendez-vous sur notre site Internet en utilisant le code QR ou le lien correspondant.
NL
Bezoek onze internetpagina via de volgende QR-code of weblink, voor meer informatie over dit product
of de beschikbare vertalingen van deze gebruiksaanwijzing.
ES
¿Desearía recibir unas instrucciones de uso completas sobre este producto en un idioma determinado?
Entonces visite nuestra página web utilizando el siguiente enlace (código QR) para ver las versiones
disponibles.
IT
Desidera ricevere informazioni esaustive su questo prodotto in una lingua specifica? Venga a visitare il
nostro sito Web al seguente link (codice QR Code) per conoscere le versioni disponibili.
www.bresser.de/P7008000000000
www.bresser.de/warranty_terms
GARANTIE · WARRANTY · GARANTÍA · GARANZIA

English ............................. 4
Deutsch ........................... 26

4 / 52
1 Imprint (German)
Bresser GmbH
Gutenbergstr. 2
46414 Rhede
Germany
www.bresser.de
For any warranty claims or service inquiries, please refer to
the information on "Warranty" and "Service" in this docu-
mentation. We ask for your understanding that unsolicited
returns cannot be processed.
Errors and technical changes excepted.
© 2022 Bresser GmbH
All rights reserved.
The reproduction of this documentation - even in extracts -
in any form (e.g. photocopy, print, etc.) as well as the use
and distribution by means of electronic systems (e.g. image
file, website, etc.) without the prior written permission of
the manufacturer is prohibited.
The designations and brand names of the respective com-
panies used in this documentation are generally protected
by trade, trademark and/or patent law in Germany, the
European Union and/or other countries.
2 Validity note
This documentation is valid for the products with the follow-
ing article numbers:
7008000000000
Manual version: 0722
Manual designation:
Manual_7008000000000_ClimaTrend-Life-H_en-
de_BRESSER_v072022a
Always provide information when requesting service.

5 / 52
3 About this Instruction Manual
NOTICE
These operating instructions are to be considered a
component of the device.
Read the safety instructions and the instruction manual
carefully before using this device.
Keep these instruction manual in a safe place for future ref-
erence. If the device is sold or passed on, the instruction
manual must be passed on to any subsequent owner/user
of the product.
4 General safety instructions
DANGER
Risk of an electric shock!
This device contains electronic parts that are powered by a
power source (AC adapter and/or batteries). Improper use
of this product may result in electric shock. Electric shock
can cause serious or fatal injuries. It is therefore imperative
that you observe the following safety information.
• Never leave children unattended when handling the
device! Follow the instructions carefully and do not at-
tempt to power this device with anything other than
power sources recommended in this instruction
manual, otherwise there is a danger of an electric
shock!
• Disconnect the power supply by pulling the mains plug
when the appliance is not in use, in case of a longer in-
terruption of operation and before any maintenance
and cleaning work.

6 / 52
• Place your device so that it can be disconnected from
the power supply at any time. The power outlet should
always be near your appliance and should be easily ac-
cessible, as the plug of the power cord serves as a dis-
connect device from the mains supply.
• To disconnect the unit from the mains, always pull the
mains plug and never pull the cable!
• Check this device, cables and connections for damage
before use.
• Never attempt to operate a damaged device, or a
device with damaged electrical parts! Damaged parts
must be replaced immediately by an authorized service
agent.
• Operate the device only in a completely dry environ-
ment and do not touch the device with wet or damp
body parts.
DANGER
Danger of suffocation!
Improper use of this product may result in suffocation, es-
pecially for children. It is therefore imperative that you ob-
serve the following safety information.
• Keep packaging materials (plastic bags, rubber bands,
etc.) away from children! There is a danger of choking!
• This product contains small parts that can be swal-
lowed by children! Choking hazard!
DANGER
Explosion hazard!
Improper use of this product may result in fire. It is essen-
tial that you observe the following safety information in or-
der to avoid fires.

7 / 52
• Do not expose the device to high temperatures. Use
only the supplied AC adapter or the recommended bat-
teries. Do not short-circuit the device or batteries or
dispose of in fire! Excessive heat and improper hand-
ling can cause short circuits, fires and even explosions!
NOTICE
Danger of material damage!
Improper handling may result in damage to the unit and/or
accessories. Therefore, use the device only in accordance
with the following safety information.
• Do not disassemble the device! In the event of a defect,
please contact your dealer. They will contact the Service
Center and can arrange the return of this device for re-
pair if necessary.
• Do not expose the device to high temperatures and
protect it from water and high humidity.
• Do not immerse the unit in water!
• Do not subject the device to excessive vibrations.
• Only use accessories and spare parts for this device
that comply with the technical specifications.
• Use only the recommended batteries. Always replace
weak or empty batteries with a new, complete set of
batteries at full capacity. Do not use batteries from dif-
ferent brands or types or with different capacities. Re-
move batteries from the device if it is not to be used for
a longer period of time!
• Do not use rechargeable batteries (accumulators).

8 / 52
NOTICE
Danger of voltage damage!
The manufacturer accepts no liability for voltage damage as
a result of incorrectly inserted batteries, or the use of an un-
suitable mains adapter!

9 / 52
5 Parts overview and scope of delivery
12/24
1
2
3
4
5
6
26
27
20
910 11
812
13 18
A
B
C
16 17
14
15
19
23
24
25
22
7
21
Illustration1: Parts overview for base station and remote sensor
1 ALARM/SNOOZE button (snooze
function)
2 LCD Display
3 Colour loop - humidity (Press
button again to stop at current
colour).
4 Colour loop - temperature (Press
button again to stop at current
colour).

10 / 52
5 Automatic colour change when
temperature or humidity
changes.
6 DC connection socket for coaxial/
barrel connector
7 Battery compartment (Base sta-
tion) (Backup)
8 TIME SET button
9 ALARM button 10 ALERT button
11 CH button (Channel selection)
and UP button (+)
12 MEM button (switch between
maximum/minimum weather
data records) and DOWN button
(-)
13 HISTORY button (retrieve meas-
urements for the past 24 hours)
14 RESET button (reset all settings)
15 °C/°F switch (display change
between °C or °F)
16 SENSOR button (initializing
sensor data reception)
17 12/24 hours time mode 18 INDEX button (display change
between current temperature and
heat index)
19 HI/LO/OFF button (Backlight
brightness)
20 Function indicator
21 RCC button (initialize time signal
reception)
22 RESET button (reset all settings)
23 Wall mount 24 Channel selector switch
25 Battery compartment (Remote
sensor)
26 DC power adapter with EU mains
plug.
27 DC coaxial/barrel connector
Scope of delivery
Base station (A), remote sensor (B), power adapter (C)
Also required (not included):
2 pcs. Mignon batteries (1.5V, AA type), 1 pcs. CR2032 but-
ton cell (as backup)

11 / 52
6 Screen display
1
9
7
6
10
8
3
4
5
2
23
22
17
18
19
20
12
14
13
15
11
16
21
Illustration2: Parts overview for base station
1 Graphical weather trend display 2 Remote sensor signal strength
3 Indoor area and outdoor channel
1-8 Symbol
4 Automatic Channel loop
5 Battery level indicator (remote
sensor)
6 AM/PM information in 12-hour
time mode
7 Current time 8 Alarm symbol (bell)
9 Symbol for active daylight saving
time (DST)
10 Time signal transmission symbol
11 Date 12 Humidity value
13 Mould alert symbol (will be dis-
played when upper limit value is
exceeded)
14 Humidity trend arrow indicator
15 Humidity Level 16 Alarm symbol for high (HIGH) or
low (LOW) humidity
17 Heat alert 18 Ice alert
19 Temperature Level 20 Temperature trend arrow indic-
ator
21 Heat index 22 Temperature value
23 Alarm symbol for high (HIGH) or
low (LOW) temperature (indoor)

12 / 52
7 Before commissioning
NOTICE
Avoid connection faults!
In order to avoid connection problems between the devices,
the following points must be observed during commission-
ing.
1. Place the base unit (receiver) and sensor (transmitter)
as close together as possible.
2. Connect the power supply to the base unit and wait un-
til the indoor temperature is displayed.
3. Establish power supply for the sensor.
4. Set up/operate the base unit and sensor within the ef-
fective transmission range.
5. Make sure that the base unit and the radio sensor are
set to the same channel.
When changing the batteries, always remove the batteries
from both the base unit and the sensor and reinsert them in
the correct order so that the radio link can be re-estab-
lished. If one of the two devices is operated via a mains
power connection, the power connection must also be
briefly disconnected for this device when the batteries are
changed. If, for example, only the batteries in the sensor
are replaced, the signal may subsequently not be received
at all or not be received correctly.
Note that the actual range depends on the respective con-
struction materials used for the buildings as well as the re-
spective position of the base unit and the outdoor sensor.
External influences (various radio transmitters and other
sources of interference) can greatly reduce the possible
range. In such cases, we recommend finding other locations
for both the base unit and the outdoor sensor. Sometimes
moving the sensor by just a few centimeters is enough!

13 / 52
Though the remote unit is weather proof, it should be
placed away from direct sunlight, rain or snow.
8 Power supply
Base unit
1. Insert the DC plug into the connection socket on the
base unit.
2. Insert the Euro plug into the mains power socket.
3. The device is powered on directly.
4. Wait until indoor temperature is displayed on the base
unit.
NOTICE!For permanent operation, mains power supply
is recommended. Alternatively, operation using batter-
ies is also possible to maintain the time setting in the
event of a power failure. In battery operation, the sta-
tion is set to power saving mode after 6 seconds and
the display indication is deactivated. The display can be
reactivated by pressing the snooze button.
For battery operation, proceed as follows:
5. Remove the battery compartment cover.
6. Insert batteries into the battery compartment. Make
sure that the batteries are correctly aligned (+/- poles).
7. Replace the battery compartment cover.
8. Wait until indoor temperature is displayed on the base
unit.
NOTICE!When changing the type of power supply
(mains power or batteries), the power supply is tem-
porarily interrupted for technical reasons. All previ-
ously made settings will be lost.
Wireless sensor
9. Remove the battery compartment cover.

14 / 52
10. Insert batteries into the battery compartment. Make
sure that the batteries are correctly aligned (+/- poles).
11. Move the channel slider to the desired channel.
NOTICE!This weather station can be operated with one
or more wireless sensors. Each connected wireless
sensor must be operated on a different channel. If only
one wireless sensor is connected, it should be operated
on channel 1.
12. Replace the battery compartment cover.
9 Finding and connecting a sensor
Normally, the connection between the base station and the
sensor is established automatically. However, after a battery
change or in the event of a connection fault, the sensor
search can be triggered manually and thus the connection
re-established.
NOTICE!Before establishing the connection, make sure that
the identical channels are set on the desired sensor and on
the base station.
In normal display mode, press the [SENSOR] button once to
activate the reception of the sensor signal for the displayed
channel. The signal icon will flash.
NOTICE!For example, if CH 1 is displayed, pressing the
[SENSOR] button will start reception for channel 1 only.
The signal symbol flashes until the reception is successful. If
no signal is received within 5 minutes, the symbol disap-
pears.
10 Automatic time setting
NOTICE!The reception of the radio signal for automatic
time and date setting is done via the outdoor sensor. There-
fore, the connection between the outdoor sensor and the
base station must first be established.

15 / 52
The current time and date are automatically received and
shown on the display of base station after proper synchron-
ization of the outdoor sensor and base station. This process
may take a few minutes.
Note:
• The outdoor sensor searches for the time signal at 2:00
and 17:00 every day to update the time and date in-
formation.
• Do not place the outdoor sensor and base station near
sources of interference such as TVs, computers, etc.
• Do not place the components near metal plates
• The use in enclosed spaces such as airport buildings,
high-rise buildings or factories is not recommended.
• Reception can be significantly disturbed in vehicles due
to constant movement.
If the automatic reception of the radio signal does not work,
perform a re-synchronization of the base station with the
outdoor sensor to re-initiate the reception of the radio sig-
nal. Please also read the chapter "Finding and connecting a
sensor" for more detailed information. If necessary, find a
new location for the individual components. When doing so,
observe the above notes on reception.
If the reception of the radio signal fails even after several at-
tempts of synchronization, the time and date must be set
manually. To do this, follow the instructions in the corres-
ponding chapter.
11 Manual time setting
1. Press and hold TIME SET button for approx. 3 seconds
to change to time setting mode.
2. Digits to be set are flashing.
3. Press +/CHANNEL or -/MEM button to change the value.

16 / 52
4. Press TIME SET button to confirm and continue to the
next setting.
5. Settings order: 12/24-hours mode > Hours > Minutes >
Year > Month (M) and Day (D) / Day (D) and Month (M) >
Month > Day > Time offset > Time signal reception
(RCC) ON/OFF > DST (Daylight Saving Time) AUTO/OFF >
Weather forecast animation ON/OFF
6. Finally press the TIME SET button to save the settings
and exit the setting mode.
12 Alarm setting
1. Press and hold ALARM button for approx. 3 seconds to
enter the alarm time setting mode.
2. Digits to be set are flashing.
3. Press CH/+ (UP) or MEM/- (DOWN) button to change the
value.
4. Press ALARM button to confirm and continue to the
next setting.
5. Settings order: Hours > Minutes
6. Finally press the ALARM button to save the settings and
exit the setting mode. Alarm will be activated automat-
ically. The symbol will be displayed.
7. Press ALARM button in normal display mode to display
the alarm time.
8. Press ALARM button during the alarm time display to
disable the alarm.
13 Snooze function
1. When the alarm sound starts, press the ALARM/
SNOOZE button to activate the Snooze function. The
Alarm will sound again after 5 minutes.

17 / 52
2. When the alarm sound starts, press the ALARM button
or press and hold the ALARM/SNOOZE button for ap-
prox. 3 seconds, to stop the alarm.
3. The alarm will be turned off automatically if no button
is pressed within 2 minutes.
14 Receiving measurements automatically
Once the power supply is enabled, the base station will dis-
play the measurement readings. Readings from the remote
sensor will be displayed within 3 minutes after powering it
on.
Read the detailed manual for more information about read-
ings (see download information on page 2).
15 HI/LO Alert
HI/LO alert are used to alert you of certain weather con-
ditions. Once activated, an alarm sound is trigger and the
alert icon flashes as soon as a set value is reached.Suppor-
ted areas and alarm types:
Area Type of alert available
Indoor temperature HI AL / LO AL
Outdoor temperature HI AL / LO AL
Indoor humidity HI AL / LO AL
Outdoor humidity HI AL / LO AL
HI AL = High alert / LO AL = Low alert
HI/LO alert setting
1. Press the ALERT button for approx. 2 seconds and the
current channel symbol starts flashing.
2. Press the +/CH- or -/MEM button to select IN (indoor) or
CHANNEL 1-8.
3. Press ALERT button to confirm and continue to the next
setting.

18 / 52
4. Settings order: Channel > HI temperature > LO temper-
ature > HI humidity > LO humidity
5. Press the +/CH or -/MEM button to modify the value by
0.1 °C/°F for temperature or 1% for humidity. Press and
hold to quick adjust the value.
6. Press the ALARM button to activate or deactivate the
Alarm for the currently selected HI/LO Alert.
7. Then finished, press the ALERT button for approx. 2
seconds to return to normal mode.
Silence the alarm
8. When alert is triggered, press the ALARM/SNOOZE,
ALARM or ALERT button to stop the alert.
9. If you ignore the alarm, it will stop after 2 minutes by it-
self.
16 Weather trend
The weather station will calculate a weather trend for the
next 12 hours on basis of the measured values.
12345
1 Sunny 2 Partly cloudy
3 Cloudy 4 Rain
5 Snow

19 / 52
17 Trend arrow indicators
123
1 Rising 2 Steady
3 Falling
The temperature and humidity trend indicator shows the
trends of changes in the forthcoming few minutes. Arrows
indicate a rising, steady or falling trend.
18 Mould alert
The mould icon is an indication which is based on in-
door and outdoor air temperature and humidity in an at-
tempt to determine risk of mould. It allows you to monitor
some key areas in the home, that can lead to mould, dust
mites and bacteria.
Note:
The mould indication is just a reference for you to monitor
your living environment and remind you of the risk of
mould.
19 Ice pre-alert
1. When the outdoor temperature hits the range of -2 ° C
to 3 ° C (28 ° F to 37 ° F) the ice pre-alert symbol will
appear on the display, flashing continuously.
2. The ice pre-alert symbol will disappear as soon as
the outdoor temperature leaves this range again.

20 / 52
20 Heat index
Press the INDEX button to display the Heat index
Heat index Warning Meaning
Above 46.1°C Extreme danger Strong risk of dehyd-
ration / sun stroke
39.5°C ~ 46.1°C Danger Heat exhaustion likely
32.8°C ~ 39.4°C Extreme caution Possibility of dehyd-
ration
26.7°C ~ 32.7°C Caution Possibility of heat ex-
haustion
Heat index is only calculated when room temperature is
between 26 ~ 50°C.
21 History record for the past 24 hours
The base station automatically stores the weather data of
indoor and outdoor temperatures and humidity for the past
24 hours.
1. Press the HISTORY button to check history records of
the last hour for the current channel.
2. Press the HISTORY button several times to display the
history records of the hours 2,3,4,5 ...... 24.
22 MAX/MIN Weather data
The base station preserves the MAX/MIN weather data re-
cords until the next manual reset. To retrieve the data:
1. Press MEM button several times to display the saved
values one after another.
2. Display order: maximum temperature > minimum tem-
perature > maximum humidity > minimum humidity
3. When the MAX/MIN Weather data records are shown,
the display will return to normal mode after 6 seconds.
