Bresser Vent Air 7007402 User manual

GB
INSTRUCTION MANUAL
DE
BEDIENUNGSANLEITUNG
VentAir
Thermo-Hygrometer
with wireless Sensor
Thermo-/Hygrometer
mit Funksensor
Art. No. 7007402
Manual_7007402_Thermo-Hygrometer-VentAir_en-de_BRESSER_v012021a.indb 1 04.01.2021 16:38:47

2
GB
INSTRUCTION MANUAL..................................... 5
DE
BEDIENUNGSANLEITUNG................................. 16
Fig. 1
A B
FR
Vous souhaitez un mode d’emploi détaillé pour ce produit dans une langue spécifique ? Alors
consultez notre site Internet à l’aide du lien suivant (code QR) pour voir les versions disponibles.
NL
U wenst een uitvoerige gebruikshandleiding voor dit product in een specifieke taal? Bezoek dan onze
website via deze link (QR Code) voor alle beschikbare versies.
IT
Desidera ricevere informazioni esaustive su questo prodotto in una lingua specifica? Venga a visitare il
nostro sito Web al seguente link (codice QR Code) per conoscere le versioni disponibili.
PT
Deseja um manual detalhado deste produto numa determinada língua? Visite a nossa Website
através da seguinte ligação (QR Code) das versões disponíveis.
ES
¿Desearía recibir unas instrucciones de uso completas sobre este producto en un idioma determinado?
Entonces visite nuestra página web utilizando el siguiente enlace (código QR) para ver las versiones
disponibles.
www.bresser.de/P7007402
Manual_7007402_Thermo-Hygrometer-VentAir_en-de_BRESSER_v012021a.indb 2 04.01.2021 16:38:48

3
Fig. 2





  



3 x AAA/LR03
Batteries not included.
Batterien nicht enthalten.





a b c

Manual_7007402_Thermo-Hygrometer-VentAir_en-de_BRESSER_v012021a.indb 3 04.01.2021 16:38:49

4





Fig. 3


2 x AAA/LR03
Batteries not included.
Batterien nicht enthalten.
Manual_7007402_Thermo-Hygrometer-VentAir_en-de_BRESSER_v012021a.indb 4 04.01.2021 16:38:51

5
GB
ABOUT THIS INSTRUCTION MANUAL
These operating instructions are to be considered a component of the
device. Please read the safety instructions and the operating instructions
carefully before use. Keep these instructions for renewed use at a later date.
When the device is sold or given to someone else, the instruction manual
must be provided to the new owner/user of the product.
This product is intended only for private use. It was developed as an electronic
medium for the use of multimedia services.
GENERAL WARNINGS
RISK OF CHOKING!
Keep packaging material, like plastic bags and rubber bands, out of the reach
of children, as these materials pose a choking hazard.
RISK of ELECTRIC SHOCK!
This device contains electronic components that operate via a power source
(batteries). Children should only use the device under adult supervision. Only
use the device as described in the manual; otherwise, you run the risk of an
electric shock.
RISK OF CHEMICAL BURN!
Leaking battery acid can lead to chemical burns. Avoid contact of battery acid
with skin, eyes and mucous membranes. In the event of contact, rinse the
affected region immediately with a plenty of water and seek medical attention.
RISK of FIRE/EXPLOSION!
Use only the recommended batteries. Do not short-circuit the device or
batteries, or throw them into a fire. Excessive heat or improper handling could
trigger a short-circuit, a fire or an explosion.
NOTE!
Do not disassemble the device. In the event of a defect, please contact your
dealer. The dealer will contact the Service Centre and can send the device in
to be repaired, if necessary.
Do not immerse the unit in water.
Manual_7007402_Thermo-Hygrometer-VentAir_en-de_BRESSER_v012021a.indb 5 04.01.2021 16:38:52

6
Do not subject the unit to excessive force, shock, dust, extreme temperature
or high humidity, which may result in malfunction, shorter electronic life span,
damaged batteries and distorted parts.
Use only the recommended batteries. Always replace weak or empty batteries
with a new, complete set of batteries at full capacity. Do not use batteries
from different brands or with different capacities. Remove the batteries from
the unit if it has not been used for a long time.
The manufacturer is not liable for damage related to improperly installed
batteries!
SCOPE OF DELIVERY (Fig. 1)
Main unit (A), outdoor sensor (B), instruction manual
PARTS OVERVIEW
Main unit (Fig. 2)
(1) Outdoor temperature
(2) Outdoor humidity
(3) Low battery indicator (main unit)
(4) MIN/MAX value for outdoors
(5) LIGHT button
(6) Indoor humidity indicator
(7) Atmospheric change indicator
(8) Ventilation indicator (Window)
(9) Low battery indicator (outdoor sensor)
(10) Current time
(11) AM/PM information on 12-hours time display mode
(12) Touch controls (a) MEM/ (b) AL/SET (c) CH/
(13) Sensor channel
(14) Indoor temperature
(15) MIN/MAX value for indoors
(16) Indoor humidity
(17) Wall mount hanger
(18) Fold-out stand
(19) Battery compartment
(20) Battery compartment cover
Outdoor sensor (Fig. 3)
(21) Outdoor temperature and humidity
(23) Wall mount hanger
Manual_7007402_Thermo-Hygrometer-VentAir_en-de_BRESSER_v012021a.indb 6 04.01.2021 16:38:52

7
(24) CH switch
(25) Battery compartment
(26) Battery compartment cover
BEFORE YOU START
IMPORTANT!
1. Insert batteries for remote units before doing so for the main unit.
2. Place the main unit as close as possible to the remote unit.
3. Position the remote unit and main unit within the effective transmission
range.
When changing batteries always change batteries in the main unit as well
as all remote units and replace them in the correct order, so the remote
connection can be re-established. If batteries are exchanged in only one of
the devices (i.e. the remote sensor) the signal can’t be received or can’t be
received correctly.
Note, that the effective range is vastly affected by building materials and
position of the main and remote units. Due to external influences (various RC
devices and other sources of interference), the maximum distance can be
greatly reduced. In such cases we suggest to position the main unit and the
outdoor sensorat other places. Sometimes all it takes is a relocation of one of
these components of a few inches!
Though the remote unit is weather proof, it should be placed away from direct
sunlight, rain or snow.
POWER SUPPLY
Main unit (Weather station)
1. Remove the battery compartment cover (20).
2. Install 3 batteries (AAA size 1.5V) strictly according to the polarities shown.
3. Reinsert the battery compartment cover.
Outdoor sensor
1. Remove the battery compartment cover (26).
2. Move the CH switch (24) to the position (1-3) that corresponds with the
channel which will be used for transmission (select channel 1 if only one
sensor is connected).
3. Install 2 batteries (AAA size 1.5V) strictly according to the polarities shown.
4. Reinsert the battery compartment cover.
Low battery indication
When batteries need to be replaced the respective low battery indicator
Manual_7007402_Thermo-Hygrometer-VentAir_en-de_BRESSER_v012021a.indb 7 04.01.2021 16:38:52

8
for the main unit (3) or the outdoor sensor (9) will be shown on the display
of the main unit.
USING TABLE STAND OR WALL MOUNTING
The main unit can be placed on a flat surface (e.g. table) with the fold-out
stand (18).
The main unit and the outdoor sensor can be mounted on walls using the
recessed wall mount hanger (17, 23).
OPERATION
Receiving measurements
Once batteries are installed to the outdoor sensor, it will start transmitting
temperature readings at roughly 60 second intervals. As soon as batteries
are installed in the main unit it will start searching for a signal from the outdoor
sensor for about 3-4 minutes. Upon successful reception of the signal, the
outdoor temperature will be displayed on the main unit. The main unit will
automatically update its readings at about 60 second intervals.
NOTE!
When the outdoor temperature is above or below the measurement range,
the display will show HHH (high) or LLL (low).
Manual time setting and other settings
To make manual settings, proceed as follows:
1. In normal time mode press the CF/SET touch control (12b) for approx. 3
seconds to enter the settings mode. The value to be set is flashing. Value
settings order: hours > minutes > 12/24 hours > On/Off
2. Press MEM/ or CH/ to set the hours for the current time.
3. Press CF/SET to switch to the next setting.
4. Press MEM/ or CH/ to set minutes for the current time.
5. Press CF/SET to switch to the next setting.
6. Press MEM/ or CH/ to select 12 or 24 hours time mode.
7. Press CF/SET to switch to the next setting.
8. Press MEM/ or CH/ to switch between ON or OF to enable or disable
24 hour measurement data storage.
9. Press CF/SET to save and exit settings mode. If there is no operation for
20 seconds, the existing setting will be saved and the device returns to
normal display mode.
NOTE!
When choosing ON for 24 hour measurement data storage all stored MIN/
MAX values for temperature and humidity will be deleted daily at 0:00h!
Manual_7007402_Thermo-Hygrometer-VentAir_en-de_BRESSER_v012021a.indb 8 04.01.2021 16:38:52

9
When choosing OFF the data will be stored indefinitely until a battery
change is required.
Temperature and humidity
1. Once the batteries are installed the main unit will start displaying the interior
measurement information. The main unit will display the information from
the outdoor sensor for the first time approximately 3-4 minutes after the
power supply was established.
2. Press CF/SET touch control (12b) to switch screen display between °C
or °F. Screen display will change for outdoor temperature as well as for
indoor temperature.
Indoor humidity indicator
The indoor humidity indicator (6) displays the following conditions:
COMFORT DRY
WET WET Indoor humidity between 66% and 95%
COMFORT DRY WET
COMFORT I ndoor humidity between 45% and 65%
COMFORT
DRY
WET
DRY Indoor humidity between 20% and 44%
NOTE!
Read chapter "Ventilation indicator" for more information.
Temperature and humidity MAX/MIN records
1. Press the touch control MEM/ (12a) several times to switch between the
values for current, minimum (MIN) and maximum (MAX) temperature and
humidity. The display will change for the indoor temperature as well as for
the outdoor temperature.
2. The MIN/MAX temperature and humidity values will be recorded
automatically.
NOTE!
Depending on the selected type for measurement data storage the MIN/
MAX values will be saved for 24 hours or until batteries need to be changed
(Read chapter "Manual time setting and other settings").
3. Press MEM/ touch control for approx. 3 seconds to delete MIN/MAX
values manually.
Atmospheric change
The device uses the measurement data to calculate the absolute humidity.
The icons indicate how the ventilation would affect the indoor climate:
Manual_7007402_Thermo-Hygrometer-VentAir_en-de_BRESSER_v012021a.indb 9 04.01.2021 16:38:53

10
COMFORT DRY WET
Moister. Expected increase in humidity by 5% or more.
COMFORT DRY WET
Constant. Expected increase or decrease in humidity by a maximum
of 4%.
COMFORT DRY WET
Dryer. Expected decrease in humidity by 5% or more.
NOTE!
Read chapter "Ventilation indicator" for more information.
Ventilation indicator
The ventilation indicator (8) relies on the information of the atmospheric
change (7) and the indoor humidity indicator (6). It is shown on the display
as follows:
COMFORT DRY WET
Ventilation recommended. Open your window.
COMFORT DRY WET
No ventilation recommended.
NOTE!
To ensure the ventilation indicator can function as required, the outdoor
sensor must be placed outdoors, otherwise the result can not be
calculated properly.
IMPORTANT!
Windows should be opened wide for a short time (a few minutes) for
effective ventilation. If possible, open windows on opposite sides of the
apartment (full ventilation).
Even if ventilation is not recommended by the weather station due to the
humidity, the apartment should be ventilated regularly. This contributes to the
reduction of pollutants and other volatile compounds in the room air.
Manual_7007402_Thermo-Hygrometer-VentAir_en-de_BRESSER_v012021a.indb 10 04.01.2021 16:38:55
