Britax EMBLEM User manual

Tel.: [phone]
Tel.: [phone]
www.Britax.ca
Britax Child Safety, Ltd.
P.O. Box 7289,
RPO Brunswick Square,
Saint John NB E2L 4S6
A Britax Childcare Group Limited
company
Une société de Britax Childcare
Group Limited
EMBLEM®
ALLEGIANCE®
Canadian User Guide
Guide d'utilisation canadien

1
ALLEGIANCE®, EMBLEM®, BRITAX®, and EZ-BuckleTM are trademarks
owned by Britax Child Safety, Inc. All rights reserved. ©2021 Britax Child
Safety, Inc. This product and its components are subject to change without
notice. Printed in USA. P14165200_A:04.21
Table of Contents
Child Seat Features��������������������������������������� 2
Safety Information����������������������������������������� 4
Warnings.................................................................. 4
Important Notes....................................................... 5
Certification.............................................................. 6
Registration.............................................................. 6
Child Fit Information ................................................ 7
Rear-Facing Installation�������������������������������� 8
LUAS Installation...................................................... 8
Lap-Shoulder Belt Installation ............................... 10
Lap Belt Installation ............................................... 12
Forward-Facing Installation������������������������ 14
LUAS Installation.................................................... 14
Lap-Shoulder Belt Installation ............................... 16
Lap Belt Installation ............................................... 18
Securing Your Child������������������������������������� 20
Child Seat Functions ����������������������������������� 22
Adjusting the Harness Height ................................ 22
Adjusting the Harness Buckle Position.................. 22
Using the Harness Buckle ..................................... 23
Using the Chest Clip ............................................. 23
Using a Lock-O.................................................... 24
Infant Positioning Pillow......................................... 24
Seat Positions ........................................................ 24
Anti-Rebound Bar .................................................. 26
Using the Lower Universal Anchorage System
(LUAS) and Top Tether ........................................... 27
Using the Lower Connectors ................................. 28
Impact Absorbing Tether ....................................... 29
Vehicle Compatibility ���������������������������������� 31
Vehicle Seating Positions....................................... 31
Incompatible Vehicle Seat Belts ............................ 32
Maintenance ������������������������������������������������ 33
Seat Cover ............................................................. 33
Harness Buckle...................................................... 36
Impact Absorbing Chest Pads............................... 38
Cleaning ������������������������������������������������������� 41
Warranty ������������������������������������������������������� 42
Notes ������������������������������������������������������������ 43

2
BRITAX Child Safety, Inc.
Child Seat Features
Front
Rear
14
15
16
17
18
19
20
1
2
3
5
4
6
7
9
10
11
12
13
21
8
22
29
35
34
36
37
24
23
26
27
25
28
31
33
32
30

3
EMBLEM/ALLEGIANCE Canadian User Guide
Description
1. Cover
2. Harness Height Adjuster
3. Head Restraint (EMBLEM)
Head Pad (ALLEGIANCE)
4. Comfort Pads
5. Infant Positioning Pillow
6. Harness Holder
7. Rear-Facing Lock-Os (Blue – under cover)
8. Lower Connector Bar
9. Lower Connector Strap (LUAS component)
10. Lower Connector Adjuster Release Button (LUAS
component)
11. Lower Connector Adjuster (LUAS component)
12. Lower Connector Release Button (LUAS component)
13. Lower Connector (LUAS component)
14. User Guide Storage (in pocket behind cover)
15. Impact Absorbing Chest Pads
16. Chest Clip
17. Harness Buckle
18. EZ-Buckle™ Belly Pad
19. Harness Adjuster Lever (under cover)
20. Harness Adjuster Strap
21. Recline Adjustment Handle
22. Anti-Rebound Bar
23. Serial Number & Manufactured Date Label
24. Shell
25. Harness Slots
26. Forward-Facing Belt Slot
27. Forward Facing Lock-Os (Green – under cover)
28. Rear-Facing Belt Slot
29. Recline Angle Guide for Rear Facing Installations
30. Impact Absorbing Base
31. Impact Absorbing Tether (Top Anchorage Strap)
32. Impact Absorbing Tether Storage Pouch
33. National Safety Mark
34. Harness Yoke
35. Harness Straps
36. Lower Connector Storage
37. Tether Carry Clip

4
BRITAX Child Safety, Inc.
Safety Information
Failure to follow all warnings and instructions could
result in SERIOUS INJURY or DEATH.
FIT REQUIREMENTS
• Use rear-facing for children who weigh between
2.3 and 18 kg (5 and 40 lbs) and whose height is
124.5 cm (49 in.) or less. Use forward-facing for
children who weigh between 10 and 29.4 kg (22 and
65 lbs) and whose height is 124.5 cm (49 in.) or less
AND are able to walk unassisted.
• Snugly adjust the belts provided with this child
restraint around your child.
INSTALLATION
• Secure the top tether strap provided with this child
restraint.
• This child restraint system must be used only in a
forward-facing vehicle seating position equipped with
a vehicle seat belt or a lower universal anchorage
system (LUAS).
• The provided infant positioning pillow must be used
for children weighing 10 kg (22 lbs) or less in a rear-
facing position. Do not use over 10 kg (22 lbs) or in a
forward-facing position. See page 24.
• This child seat must be reclined to position 3 when
installed rear facing (see page 24).
• When installing in forward facing mode this child seat
must be in position 1 or position 2 (see page 24).
• Use the buckle slot closest to, but not under the child.
GENERAL USAGE
• Follow all instructions on this child restraint and in the
written instructions.
• Britax strongly recommends that children should
remain in a child seat with a 5-point harness until
reaching the maximum weight or height allowed
• Register your child restraint with the manufacturer.
• This child seat can only be used in the following
classes of vehicles: multi-purpose passenger vehicles,
passenger cars, or trucks.
• In a vehicle with rear designated seating positions,
vehicle owners should be alerted that, according to
accident statistics, children are safer when properly
restrained in the rear seating positions than in the
front seating positions. To ensure your child’s safety,
please study Vehicle Seating Positions on page 31
and consult your vehicle owner’s manual.
• Always make sure the child restraint system is
secured to the vehicle, even when unoccupied, since
in a crash an unsecured child restraint system may
injure occupants.

5
EMBLEM/ALLEGIANCE Canadian User Guide
• To prevent injury due to deterioration or hidden
damage, discontinue use of this child seat if it is
older than seven years or has been in a moderate
or severe crash (see below). See Serial Number and
Manufactured Date Label on child seat (page 2).
• The use of non-Britax covers, inserts, toys,
accessories, or tightening devices is not approved
by Britax. Their use could cause this child seat not to
perform as intended in a crash.
• The primary protection for occupants of a vehicle in a
collision is the body of the vehicle itself; a child seat
will not protect a child when a vehicle is seriously
impacted. However, correctly installed, a child seat
will substantially improve chances for survival in most
crashes. Make sure all users fully understand the
correct ways to use this child seat in a vehicle.
Important Notes
• Before each use, check this child seat and its
components to make sure they are in good condition
and good working order.
• Do not install with LUAS for a child weighing more than
18 kg (40 lbs) rear facing or 22.7 kg (50 lbs) forward
facing.
• Discontinue use of this child seat if it has been in a
moderate or severe crash. It is not necessary to replace a
car seat after a minor crash, defined by the US National
Highway Trac Safety Administration (NHTSA) as:
a. The vehicle is drivable from the crash site; and
b. The vehicle door nearest the child seat was not
damaged; and
c. No vehicle occupants were injured; and
d. There is no visible damage to the child seat; and
e. The airbags (if present) did not deploy.
• When the anti-rebound bar is installed on your child seat,
keep fingers away from the connection points to avoid
entrapment or pinching.
• Cover the child seat when the vehicle is parked in direct
sunlight. Metal parts of child seat could become hot
enough to burn a child.
• Store the child seat in a safe place when it is not being
used. Avoid placing heavy objects on top of it.
• Do not, except as described in this booklet, attempt to
disassemble any part of the child seat or change the way
the harness or vehicle’s seat belts are used.
• Never use the harness adjuster strap to lift or carry this
child seat. Doing so could cause damage to harness
adjuster and webbing. Always carry this child seat by its
shell or tether straps.
• Third party recommendations are subject to change, so
we recommend you visit their websites for the most up
to date recommendations.

6
BRITAX Child Safety, Inc.
Registration
Child restraints could be recalled for safety reasons. You
must register this restraint to be reached in a recall. Send
your name, address, e-mail address if available and the
restraint’s model number and manufacturing date to Britax
Child Safety, Ltd., P.O. Box 7289, RPO Brunswick Square,
Saint John NB E2L 4S6, or call 1-888-427-4829, or register
online at us.britax.com/registration.
For your convenience, record all the information about your
child seat below. Refer to the Serial Number & Manufactured
Date Label for all information (see page 2).
Model Name and Number: ______________________________
Serial Number: ________________________________________
Batch Number: ________________________________________
Date of Manufacture:___________________________________
Certification
This Restraint is Certified For Use in Motor
Vehicles and Aircraft�
Motor Vehicles
This child seat system conforms to all applicable Canadian
Motor Vehicle Safety Standards (CMVSS 213 and 213.1).
Aircraft
This child seat is certified for aircraft use. Most airlines in the
U.S. and Canada will allow the use of a child seat as long as
it is labeled as an approved child seat for use in aircraft and
fits properly on the aircraft seat. Contact the airline about
their policy prior to traveling.
Install your child seat in a window seat to avoid
blocking the aisle� For rear-facing aircraft installation,
see “Rear-Facing Lap Belt Installation” on pages 12-13.
For forward-facing installation, follow “Forward-Facing
Lap Belt Installation” on pages 18.
– If the aircraft lap belt is too short, ask a flight
attendant for a belt extender.
– Your child may experience discomfort if the buckle
is located in the seating area of the child seat after
installation.
– Inflatable aircraft lap belts are NOT compatible with
this child seat.

7
EMBLEM/ALLEGIANCE Canadian User Guide
Child Fit Information
Rear Facing: 2�3 – 18 kg (5 – 40 lbs)
Britax strongly recommends that children ride rear facing to
the highest weight or height specified.
Use rear facing:
• with harness straps in the closest
position at or below the child’s
shoulders and
• with children who weigh 2.3 – 18 kg
(5 – 40 lbs) and
• who are 124.5 cm (49 in.) or less in
height and
• when the top of the child’s head is at
least 2.5 cm (1 in.) below the top of
the head restraint/head pad.
IMPORTANT: The infant positioning pillow must be used
to achieve better fit and support for infants weighing up to
10 kg (22 lbs) in a rear-facing position. Do not use over 10
kg (22 lbs) or in a forward-facing position. See page 24.
Forward Facing: 10 – 29�4 kg (22 – 65 lbs) and are able to
walk unassisted
Britax strongly recommends that children should be secured
with a harness system until they exceed the weight or height
limits specified.
Use forward facing:
• with harness straps in the closest
position at or above the child’s
shoulders, parallel to level ground
and
• with children who weigh 10 – 29.4 kg
(22 – 65 lbs) and
• who are able to walk unassisted and
• who are 124.5 cm (49 in.) or less in
height and
• when the top of the ears are below
the top of the head restraint/head
pad.
IMPORTANT: Do not use the infant positioning pillow
with a forward-facing installation.
2.5 cm
1 inch
Shoulder
Level
Shoulder
Level

8
BRITAX Child Safety, Inc.
Rear-Facing Installation
1. Remove the lower
connectors from the
storage slots in the base.
Press the adjuster release
button and pull the strap
to full length. Repeat for
the second strap.
2. The anti-rebound bar is
required for rear facing
installations. Attach the
anti-rebound bar (see
page 26).
IMPORTANT: Keep
fingers away from the anti-
rebound bar connection
points to avoid finger
entrapment or pinching.
3. Recline the unoccupied
child seat to position 3
and place rear-facing on
the vehicle seat (see page
24). Ensure that no more
than 7.5 cm (3 in.) of the
base hangs over the edge
of the vehicle seat .
4. Firmly press the lower
connectors onto the
adjacent lower anchors.
A click helps confirm
attachment.
5. Push the child seat
down while pulling each
lower connector strap to
tighten.
1
7.5 cm
LUAS Installation
IMPORTANT: The provided infant positioning pillow must
be used for children weighing 10 kg (22 lbs) or less in a
rear-facing position. Do not use over 10 kg (22 lbs) or in a
forward-facing position.
IMPORTANT: The anti-rebound bar is required for rear
facing installations.

9
EMBLEM/ALLEGIANCE Canadian User Guide
Rear-Facing Installation with LUAS
9All connections are secure and straps are not twisted.
9No more than 7.5 cm (3 in.) of the base hangs over the
edge of the vehicle seat.
9The anti-rebound bar is properly installed (see page 26).
9The child seat cannot be moved front to back or side to
side more than 2.5 cm (1 in.) at the belt path. If the child
seat is not secure, repeat installation or use a dierent
seating location.
9The child seat is correctly installed when angle guide line
is parallel to the ground when the car is parked on a level
surface. After the child is secured, the recline angle of the
child seat should be 30° – 45° from vertical (not to exceed
45°) when the car is parked on a level surface. See “Seat
Positions” on pages 24 - 25.
9Tether webbing is stored in storage pouch. See page 30.

10
BRITAX Child Safety, Inc.
Lap-Shoulder Belt Installation
1. Loosen the harness.
a. Lift harness adjuster
lever and pull both
harness straps
forward.
b. Remove the infant
positioning pillow
and unbuckle the
harness.
2. The anti-rebound bar is
required for rear facing
installations. Attach the
anti-rebound bar (see
page 26).
IMPORTANT: Keep
fingers away from the anti-
rebound bar connection
points to avoid finger
entrapment or pinching.
3. Recline the unoccupied
child seat to position 3
and place rear-facing on
the vehicle seat (see page
24). Ensure that no more
than
7.5 cm (3 in.) of the
base hangs over the edge
of the vehicle seat .
4. Pull the head restraint/
head pad cover up,
then pull the seat cover
forward to access the
rear-facing belt path.
5. If applicable, open the
blue lock-o closest to
where the vehicle belt will
be buckled (see page 24).
a. Open the locking tab.
b. Open the clamp.
6. Route the vehicle belt
through the rear-facing
belt slots.
7. Buckle the seat belt.
NOTE: Ensure the vehicle
belt is not twisted.
5b
5a
Locking
Tab
Clamp
IMPORTANT• ALWAYSposition the buckle in the inner
slotfor rear-facing use. • The
vehiclebelt must pass in front
ofthe buckle strap for
rear-facinguse.
•NEVER leave the buckle in the
adjustmentslot. • Use the outer
buckleslot when installing the
childseat forward-facing with a child weighing 30 lbs
(13.6kg) and above or if the buckle is under the child in
INNERSLOT
OUTERSLOT
P405600_R1.05.10
ADJUSTMENT
SLOT
IMPORTANTE•Coloquelahebillaenla ranurainternaSIEMPREque
sevayaautilizarel asientoorientado
haciadetrás.•Cuandoelasientose
colocaorientadohaciadetrás,el
cinturóndelvehículodebepasarpor
delantedelacorreade la hebilla.• La
hebillaNUNCAdebedejarseenla
ranuradeajuste.
•Utilicelaranuraexternade la hebillasi se va a instalarelasiento
orientadohaciadelanteyesteva a serocupadopor un niñocon
RANURAINTERNA
RANURAEXTERNA
P452800_R1.01.11
RANURA
DEAJUSTE
7.5 cm

11
EMBLEM/ALLEGIANCE Canadian User Guide
8. Push down into the
middle of the child
seating area with
moderate force while
removing all slack from
the bottom (lap) part of
the vehicle belt and close
the lock-o (see page 24).
IMPORTANT: Both the
vehicle lap and shoulder
belts must be routed
through the lock-o.
9. Push down into the middle
of the child seating area
with moderate force while
pulling the top (shoulder)
part of the belt between
the belt slots to remove
any remaining slack
through the lock-o.
10. Replace the seat cover
and infant positioning
pillow, if required (see
page 24).
Rear-Facing Installation with Lap-Shoulder Belt
9All connections are secure and straps are not twisted.
9No more than 7.5 cm (3 in.) of the base hangs over the
edge of the vehicle seat.
9The anti-rebound bar is properly installed (see page 26).
9The child seat cannot be moved front to back or side to
side more than 2.5 cm (1 in.) at the belt path. If the child
seat is not secure, repeat installation or use a dierent
seating location.
9The child seat is correctly installed when angle guide line
is parallel to the ground when the car is parked on a level
surface. After the child is secured, the recline angle of the
child seat should be 30° – 45° from vertical (not to exceed
45°) when the car is parked on a level surface. See “Seat
Positions” on pages 24 - 25.
9Tether webbing is stored in storage pouch. See page 30.

12
BRITAX Child Safety, Inc.
Lap Belt Installation
1. Loosen the harness.
a. Lift harness adjuster
lever and pull both
harness straps
forward.
b. Remove the infant
positioning pillow
and unbuckle the
harness.
2. The anti-rebound bar is
required for rear facing
installations. Attach the
anti-rebound bar (see
page 26).
IMPORTANT: Keep
fingers away from the anti-
rebound bar connection
points to avoid finger
entrapment or pinching.
3. Recline the unoccupied
child seat to position 3
and place rear-facing on
the vehicle seat (see page
24). Ensure that no more
than
7.5 cm (3 in.) of the
base hangs over the edge
of the vehicle seat .
4. Pull the head restraint/
head pad cover up,
then pull the seat cover
forward to access the
rear-facing belt path.
5. Route the vehicle belt
through the rear-facing
belt slots.
IMPORTANT: Do not
use lock-os for lap belt
installations.
6. Buckle the seat belt.
NOTE: Ensure the vehicle
belt is not twisted.
IMPORTANT• ALWAYSposition the buckle in the inner
slotfor rear-facing use. • The
vehiclebelt must pass in front
ofthe buckle strap for
rear-facinguse.
•NEVER leave the buckle in the
adjustmentslot. • Use the outer
buckleslot when installing the
childseat forward-facing with a child weighing 30 lbs
(13.6kg) and above or if the buckle is under the child in
INNERSLOT
OUTERSLOT
P405600_R1.05.10
ADJUSTMENT
SLOT
IMPORTANTE•Coloquelahebillaenla ranurainternaSIEMPREque
sevayaautilizarel asientoorientado
haciadetrás.•Cuandoelasiento se
colocaorientadohaciadetrás,el
cinturóndelvehículodebepasarpor
delantedelacorreade la hebilla.• La
hebillaNUNCAdebedejarseenla
ranuradeajuste.
•Utilicelaranuraexternade la hebillasi se va a instalarelasiento
orientadohaciadelanteyesteva a serocupadopor un niñocon
RANURAINTERNA
RANURAEXTERNA
P452800_R1.01.11
RANURA
DEAJUSTE
7.5 cm

13
EMBLEM/ALLEGIANCE Canadian User Guide
7. Push down on the middle
of the child seat while
pulling the vehicle belt to
remove all slack.
NOTE: Ensure that the
vehicle belt is locked as
directed by your vehicle
owner’s manual.
8. Replace the seat cover
and infant positioning
pillow, if required (see
page 24).
Rear-Facing Installation with Lap Belt
9All connections are secure and straps are not twisted.
9No more than 7.5 cm (3 in.) of the base hangs over the
edge of the vehicle seat.
9Ensure that the anti-rebound bar is properly installed
(see page 26).
9The child seat cannot be moved front to back or side to
side more than 2.5 cm (1 in.) at the belt path. If the child
seat is not secure, repeat installation or use a dierent
seating location.
9The child seat is correctly installed when angle guide line
is parallel to the ground when the car is parked on a level
surface. After the child is secured, the recline angle of the
child seat should be 30° – 45° from vertical (not to exceed
45°) when the car is parked on a level surface. See “Seat
Positions” on pages 24 - 25.
9Tether webbing is stored in storage pouch. See page 30.

14
BRITAX Child Safety, Inc.
LUAS Installation
IMPORTANT: Do not install forward-facing with LUAS for
a child weighing more than 22.7 kg (50 lbs).
Forward-Facing Installation
1. Remove the lower
connectors from the
storage slots in the
base. Press the adjuster
release button and pull
the lower connector
strap to full length.
Repeat for the second
strap.
2. Remove the tether from
the pouch and place it
up and over the child
seat back.
3. Adjust this child seat to
position 1 or 2 and place
forward-facing on the
vehicle seat (see page
24).
NOTE: Ensure that no
more than 7.5 cm (3 in.) of
the base hangs over the
edge of the vehicle seat.
IMPORTANT: Your child
seat may not perform as
intended if the base of the
child seat is not flat on
the vehicle seat.
4. Firmly press the lower
connectors onto the
adjacent lower anchors.
a. A click helps confirm
attachment.
b. Verify that the lower
connector strap is
not twisted.
5. Push the child seat down
while pulling each lower
connector strap to tighten.
7.5 cm
IMPORTANT: Do NOT use the infant positioning pillow in
a forward-facing position.
IMPORTANT: Do NOT use the anti-rebound bar in a
forward-facing position.

15
EMBLEM/ALLEGIANCE Canadian User Guide
6. Attach the tether to a
designated anchor (see
vehicle owner’s manual)
and remove slack (see
page 29).
7. Wrap excess webbing in
the elastic strap and store
in tether storage pouch.
Forward-Facing Installation with LUAS
9All connections are secure and straps are not twisted.
9Car seat base MUST be flat on vehicle seat and MUST be
parallel to vehicle seat.
9No more than 7.5 cm (3 in.) of the base hangs over the
edge of the vehicle seat.
9The child seat cannot be moved front to back or side to
side more than 2.5 cm (1 in.) at the belt path. If the child
seat is not secure, repeat installation or use a dierent
seating location.
9Any excess tether webbing is contained within your
vehicle and secured in the elastic strap.
9The anti-rebound bar is removed.

16
BRITAX Child Safety, Inc.
5b
5a
Locking
Tab
Clamp
Lap-Shoulder Belt Installation
1. Remove the tether from
the pouch and place it up
and over the child seat
back.
2. Adjust this child seat to
position 1 or 2 and place
forward-facing on the
vehicle seat (see page 24).
NOTE: Ensure that no
more than 7.5 cm (3 in.) of
the base hangs over the
edge of the vehicle seat.
IMPORTANT: Your child
seat may not perform as
intended if the base of the
child seat is not flat on the
vehicle seat.
3. Loosen the harness.
a. Lift harness adjuster
lever and pull both
harness straps
forward.
b. Remove the infant
positioning pillow and
unbuckle the harness .
4. Pull the head restraint/
head pad cover up,
then pull the seat cover
forward to access the
forward-facing belt path .
5. If applicable, open the
green lock-o closest to
where the vehicle belt will
be buckled (see page 24).
a. Open the locking tab.
b. Open the clamp.
6. Route the vehicle belt
through the forward-facing
belt slots, ensuring the
vehicle belt is not twisted,
then buckle.
7. Push down into the rear
of the child seating area
with moderate force while
removing all slack from
the bottom (lap) part of the
vehicle belt and close the
lock-o, if used.
IMPORTANT: Both the
vehicle lap and shoulder
belts must be routed
through the lock-o.
7.5 cm

17
EMBLEM/ALLEGIANCE Canadian User Guide
8. Push down into the middle
of the child seating area
with moderate force while
pulling the top (shoulder)
part of the belt between
the belt slots to remove
any remaining slack
through the lock-o.
9. Attach the tether to a
designated anchor (see
vehicle owner’s manual)
and remove all slack (see
page 29). Wrap excess
webbing in the elastic
strap and store in tether
storage pouch .
10. Replace the seat cover.
Forward-Facing Installation with Lap-Shoulder Belt
9All connections are secure and straps are not twisted.
9Car seat base MUST be flat on vehicle seat and MUST be
parallel to vehicle seat.
9No more than 7.5 cm (3 in.) of the base hangs over the
edge of the vehicle seat.
9The child seat cannot be moved front to back or side to
side more than 2.5 cm (1 in.) at the belt path. If the child
seat is not secure, repeat installation or use a dierent
seating location.
9Any excess tether webbing is contained within your
vehicle and secured in the elastic strap.
9The anti-rebound bar is removed.

18
BRITAX Child Safety, Inc.
Lap Belt Installation
1. Remove the tether from the
pouch and place it up and
over the child seat back.
2. Adjust this child seat to
position 1 or 2 and place
forward-facing on the
vehicle seat (see page 24).
NOTE: Ensure that no
more than 7.5 cm (3 in.) of
the base hangs over the
edge of the vehicle seat.
IMPORTANT: Your child
seat may not perform as
intended if the base of the
child seat is not flat on the
vehicle seat.
3. Loosen the harness.
a. Lift harness adjuster
lever and pull both
harness straps
forward.
b. Remove the infant
positioning pillow and
unbuckle the harness .
4. Pull the head restraint/
head pad cover up,
then pull the seat cover
forward to access the
forward-facing belt path.
5. Route the vehicle seat
belt through the forward-
facing belt slots, ensuring
the vehicle belt is not
twisted, then buckle.
IMPORTANT: Do not
use lock-os for lap belt
installations.
6. Push down on the middle
of the child seat while
pulling the vehicle belt to
remove all slack.
NOTE: Ensure that the
vehicle belt is locked as
directed by your vehicle
owner’s manual.
7.5 cm
