Britax FRONTIER User manual

PLEASE READ
INSTRUCTIONS
STORE UNDER
COVER
Frontier
For Children 2 years and 25 lbs and up

Contents
This product and its components are subject to change without notice.
© 2008 Britax Child Safety, Inc. All rights reserved. Printed in U.S.A. P319300_R2:07.08
Registration and Certification Information ..............................................................2
General Warnings ....................................................................................................3
Child Size: Height and Weight Limitations..............................................................4
Harness Mode......................................................................................................4
Booster Mode ......................................................................................................5
Child Seat features Overview ..................................................................................6
Harness Height Adjustment .................................................................................8
Head Restraint Adjustment ..................................................................................9
Adjusting Buckle Position .....................................................................................10
Fastening the Buckle ............................................................................................12
Releasing the Buckle ............................................................................................12
Using the LATCH Connectors ..............................................................................12
Using the Versa-Tether.........................................................................................13
Using the Chest Clip ...........................................................................................15
Using the Recline Block........................................................................................15
Using the Cup Holders.........................................................................................16
Using the Arm Rests.............................................................................................16
Vehicle Compatibility...............................................................................................17
Vehicle Seating Positions......................................................................................17
Understanding Vehicle Seat Belts.........................................................................18
General Information.................................................................................................20
Harness Mode: Installing Your Child Seat ...............................................................22
Harness Mode......................................................................................................22
LATCH – Short Path .......................................................................................22
Selecting a Belt Path.............................................................................................24
Lap-Shoulder Belt – Short Path ......................................................................26
Lap Shoulder Belt – Long Path .......................................................................28
Lap Belt –Short Path.......................................................................................30
Switching Between Modes...................................................................................32
Booster Mode: Positioning Your Child Seat ............................................................36
Booster Mode ......................................................................................................36
LATCH............................................................................................................36
Lap-Shoulder Belt...........................................................................................38
Securing Your Child..................................................................................................39
Harness Mode......................................................................................................40
Booster Mode ......................................................................................................42
Care and Maintenance.............................................................................................44
Cover Removal ...................................................................................................44
Replacing the Cover.............................................................................................47
Cleaning the Cover ..............................................................................................49
Cleaning the Harness ...........................................................................................50
Cleaning the Shell ................................................................................................50
Cleaning the Buckle .............................................................................................50
Versa-Tether as Crash Indicator ...............................................................................53
Troubleshooting .......................................................................................................54
Warranty...................................................................................................................55

2
Registration and Certification Information
Child seats could be recalled for safety reasons. You must register this
child seat to be reached in a recall. Please complete and return the
attached registration card to Britax Child Safety, Inc., 13501 South
Ridge Drive, Charlotte, NC 28273, or call 1-888-4BRITAX, or register
online at www.BritaxUSA.com/registration.
For recall information, call the U.S. Government’s Vehicle Safety
Hotline at 1-888-327-4236 (TTY:1-800-424-9153), or go to http://
www.NHTSA.gov
Certification
This child restraint system conforms to all applicable Federal
Motor Vehicle Safety Standards.
This Restraint is Certified for Use in Motor Vehicles and
Aircraft; when Used in Harness Mode.
This Restraint is Not Certified for Use in Aircraft; when
Used in Booster Mode.
Follow Lap-Belt installation method found on page 26, for
installation of child seat in aircraft.
NOTE: Versa-Tether cannot be used on aircraft.
Install your child seat in a window seat to avoid
blocking the aisle.
If the aircraft lap belt is too short, ask the flight
attendant for a belt extender.

3
General Warnings
This child seat must not be used in the home, in boats, or other•
non-certified applications.
To prevent injury due to deterioration or hidden damage,•
discontinue use of this child seat that is older than nine years or
has been in a moderate or severe crash. See date of manufacture
and expiration date located on child seat shell.
The primary protection for occupants of a vehicle in a collision•
is the body of the vehicle itself; a child seat will not protect a
child when the vehicle is seriously impacted. However, correctly
installed, a child seat will substantially improve the chances for
survival in most crashes.
Cover the child seat when the vehicle is parked in direct sunlight.•
Parts of the child seat can become hot enough to burn a child.
Secure this child seat even when it is not occupied. In a crash, an•
unsecured child seat may injure vehicle occupants.
Store the child seat in a safe place when it is not being used. Avoid•
placing heavy objects on top of the child seat.
Never use the harness or adjuster strap to lift or carry this child•
seat. Doing so could damage the harness adjuster and webbing.
Always carry this child seat by the shell or tether straps.
Do not allow children to play with this child seat.•

4
This child seat is for use forward-facing only with children who meet
all of the following fit requirements.
Harness Mode:
Children must:
be at least two years of age1 and
weigh between 25 – 80 lbs. (11.3 – 36.3 kg.)
2 and
stand 30 – 53 in. (76.2 – 134.6 cm) in height
3 and
Child Size: Height and Weight Limitations
IMPORTANT: If your child does not meet all of the above fit requirements
because they are too small, another type of child seat must be used such as
an infant carrier or convertible child seat which can be installed rear-facing.
If your child does not meet all of the above fit requirements because they are
too large, you may need to use this child seat in booster mode. See page 5
for booster fit requirements.
the top of the child’s ears must be
4
below the top of the head restraint
when seated and
the harness straps must be located
5
at or above the child’s shoulders
when seated.
Shoulder level
Above Shoulder Level
Below Shoulder Level

5
Child Size: Height and Weight Limitations
Booster Mode:
Children must:
stand 42 – 60 in. (106.7 – 152.4 cm) in height1 and
the top of the child’s ears must be below the top of the head restraint
2 and
the vehicle belt must be appropriately positioned at or above the child’s
3
shoulder through the shoulder belt guide.
NOTE: This child seat must only be used in booster mode with children 40
lbs (18.1 kg) or more and meet all of the above fit requirements.
Store this user guide behind the cover in the lumbar region of the
child seat.

6
Head Restraint1
Head Restraint Cover2
Harness Slot3
Comfort Pads4
HUGS™ Chest pads5
Harness Straps6
Chest Clip7
Arm Rest8
Lap Belt Guide9
Buckle10
2
1
14
13
15
20
21
17
16
19
18
8
9
10
11
12
4
3
7
5
6
Belly Pad11
Harness Adjuster Strap12
Cover13
Shoulder Belt Guide14
User Guide Storage (under cover)15
LATCH Strap16
LATCH Adjuster Release Button17
LATCH Adjuster18
LATCH Connector Release Button19
LATCH Connector20
Cup Holder21
Child Seat features Overview

7
LATCH Connector Storage Slot22
Harness Yoke23
Head Restraint Adjuster Lock24
Head Restraint Adjuster Release25
Manufactured Date and26
Expiration Date Label
Harness Height Adjuster27
22
23
25
35
26
24
27
29
28
30
31
32 34
33
Versa-Tether28 ®Adjuster
Versa-Tether29
Shell30
Belt Shield31
Harness Yoke Storage (on belt32
shield)
Versa-Tether33 ®Storage Clip
Recline Block34
Child Seat features Overview

8
Harness Height Adjustment
NOTE: The harness height adjuster also adjusts the height for the head
restraint in harness mode. The head restraint will be properly adjusted once
the harness is placed appropriately at or above your child’s shoulders.
Loosen the Harness.
1 Pull the harness adjuster and slide2
into the nearest position at or slightly
above your child’s shoulders.
NOTE: The harness adjuster will lock into place once released.
Child Seat features Overview

9
Head Restraint Adjustment
WARNING: The head restraint adjuster is for booster mode
only. DO NOT use the head restraint adjuster when the harness
is still attached.
Remove the screw from the head3
restraint adjuster and store in a safe
place. The screw will be needed to
convert back to harness mode.
Lift the head restraint adjuster
4
release to move the head
restraint.
The vehicle belt must be
5
appropriately positioned at or
above the child’s shoulder through
the shoulder belt guide.
NOTE: The head restraint adjuster will lock into place once released.
Child Seat features Overview

10
Adjusting Buckle Position
Removing the Buckle
Unbuckle the harness.1 Locate the metal buckle strap2
retainer on the bottom of the
child seat.
Pull the retainer through the slots
5
in the child seat shell and cover to
the top of the child seat.
Pull the retainer away from the3
child seat to loosen
Turn and push the retainer so that
4
the short side will pass through the
slot in the child seat shell
Child Seat features Overview

11
Re-threading the Buckle
IMPORTANT: Select the slot closest to, but not under the child.
Turn and push the buckle retainer
1
so that the short side will pass
through the slot in the cover and
child seat shell.
Pull through the slots in the cover
2
and child seat shell to the bottom
of the child seat.
Pull the buckle away from
3
the child seat until tight.
Verify that the buckle
retainer lies flat against
the child seat shell. Ensure
that the buckle strap is not
twisted and that the button
faces out.
NOTE: The belly pad must be pulled over the metal retainer to remove.
Child Seat features Overview

12
Fastening the Buckle
Insert one tongue at a time into the buckle.
NOTE: Proper connection is confirmed with a positive click after inserting
each buckle tongue.
Releasing the Buckle
NOTE: Periodically clean the buckle to ensure proper operation.
Using the LATCH Connectors
Disconnect the LATCH1
connectors from the LATCH
connector storage slots.
Press the release button to eject the tongues from the buckle.
1
1
2
2
Child Seat features Overview

13
Locate the LATCH anchors in your2
vehicle.
Verify that the LATCH connector
3
is right-side up and that the
LATCH strap is not twisted before
connecting.
NOTE: The LATCH connectors will click when properly attached.
IMPORTANT: Refer to your vehicle owner’s manual or contact the vehicle
manufacturer for the maximum weight rating for their LATCH anchors.
Use the vehicle belt (not LATCH) for installations with children who weigh
more than the vehicle LATCH anchor limit. Unless specified otherwise by
the vehicle manufacturer, assume a 40 pound (18.1 kg.) child is the vehicle
LATCH anchor limit. Only use the vehicle’s designated tether anchor for the
chosen seating position.
Using the Versa-Tether
WARNING:
Attach the Versa-Tether only to tether anchors identified by your vehicle•
manufacturer as tether anchorage points.
If your vehicle does not currently have a tether anchor attachment, refer to your•
vehicle owner’s manual or contact your vehicle manufacturer for assistance. DO
NOT modify your vehicle without advice from your vehicle manufacturer.
When using the child seat in harness mode:
Britax recommends that the tether be used at all times when installing the child•
seat. Using the tether will improve the stability of your child seat and reduce
the risk of injury.
Always use the Versa-Tether for children weighing 65 – 80 lbs (29.5 – 36.3 kg).•
IMPORTANT: You must use the Versa-Tether if installing the child seat
using the LATCH connectors.
Child Seat features Overview
Top

14
Remove the Versa-Tether from the1
storage clip.
Loosen the tether and place over
2
the child seat back.
Tilt the tether adjuster tab and pull
3
to fully extend the tether.
Locate the tether hook on the
4
strap.
Attach the tether hook to a
5
designated anchor point.
Tighten the tether.
6
NOTE: Anchor point locations in vehicles vary. Consult your vehicle owner’s manual to
help identify the anchor location.
IMPORTANT: Ensure any excess Versa-Tether®webbing is contained within your
vehicle.
To Attach the Versa-Tether:
Child Seat features Overview

15
Using the Chest Clip
Opening the chest clip.1
IMPORTANT: The correct height for
the chest clip is at the middle of the
chest at armpit level.
Using the Recline Block
IMPORTANT: Set the recline block position BEFORE installing into your
vehicle.
Booster Position
1 Harness Position2
NOTE: The default position of the recline block is booster position. You
must unhook the Versa-Tether from the storage clip (if connected) before
moving the recline block.
Fastening the chest clip
2
Child Seat features Overview
Recline
block

16
Using the Cup Holders
Pull the handle up and out to open1
the cup holder.
Push the base of the cup holder
2
down to lock into place.
Push the base of the cup holder up
3
to unlock.
Push the cup holder in to return to
4
the stowed position.
IMPORTANT: Do not put containers of hot liquids in the cup holders. Stow
the cup holders when not in use.
Using the Arm Rests
The arm rests can be rotated
up and down. They also can
be used to hold the harness
when securing your child.
IMPORTANT: The arm rests
must be in the down position
during travel.
Child Seat features Overview

17
Based on crash statistics, the National Highway Traffic Safety
Administration recommends that parents select a rear seating position
as the safest location for a properly installed child seat. The back seat
is the safest place for children 12 and under.
Please study Understanding Vehicle Seat Belts on page 18 of this
booklet to ensure the child’s safety. If in doubt about installing the
child seat, consult the vehicle owner’s manual.
Vehicle Compatibility
WARNING:
A forward-facing child seat in the front seat of a vehicle with a•
passenger air bag is not recommended. DEATH or SERIOUS INJURY
can occur.
When using this child seat in a vehicle with air bags, refer to the•
vehicle owner’s manual for child seat installation instructions and
precautions.
WARNING: Forward-facing vehicle seats MUST be
used with this child seat. Side-facing or rear-facing seats
CANNOT be used.
See your vehicle owner's
manual for child seat
installation instructions.
The back seat is the safest
place for children 12 and
under.
Vehicle Seating Positions

18
Vehicle seat belts and LATCH
anchor locations vary. Consult
your vehicle owner’s manual
for details on what type of
seat belts your vehicle has and
where to find your LATCH
anchors (if available).
Vehicle Compatibility
IMPORTANT: Refer to your vehicle owner’s manual or contact the vehicle
manufacturer for the maximum weight rating for their LATCH anchors.
Use the vehicle belt (not LATCH) for installations with children who weigh
more than the vehicle LATCH anchor limit. Unless specified otherwise by
the vehicle manufacturer, assume a 40 pound (18.1 kg.) child is the vehicle
LATCH anchor limit. Only use the vehicle’s designated tether anchor for the
chosen seating position. Do not connect more than one LATCH anchor or
tether hook to a single vehicle anchor.
Understanding Vehicle Seat Belts
NOTE: The information in this section only applies to installation with
vehicle safety belts.
This child seat can fit securely in most vehicles using existing vehicle
belts; however, some vehicle designs prevent a secure fit of the child
seat due to the position of the vehicle belt lower anchorage points.
WARNING: Use only the vehicle’s lap and shoulder belt system
when restraining a child in booster mode. Never restrain a child
with a lap belt only in booster mode.
