Broan HRV100H User guide

VB0065
vänEE Canadian Model Numbers
1001 ERV
1001 HRV*
2001 ERV
2001 HRV*
Broan U.S.A. Model Numbers
HRV100H
HRV200H
ERV100HC
ERV200HC
03119 rev. 09
*These products earned the ENERGY STAR®by meeting strict energy efficiency
guidelines set by Natural Resources Canada and the US EPA. They meet
ENERGY STAR requirements only when used in Canada.
READ AND SAVE THESE INSTRUCTIONS
INSTALLER MANUAL
VENTILATION SYSTEMS

2
1. S ERVICE........................................................................................................................................................3-4
1.1 3-D DRAWING ............................................................................................................................................................3
1.2 PARTS ORDERING CHART .............................................................................................................................................4
1.3 TECHNICAL SUPPORT ...................................................................................................................................................4
2. UNIT TYPE & DEFROST SETTING VS GEOGRAPHICAL LOCATION.................................................................................. 5
3. TECHNICAL DATA .............................................................................................................................................6-7
3.1 AIR DISTRIBUTION (NORMAL OPERATION) ........................................................................................................................6
3.2 AIR DISTRIBUTION (DEFROST MODE) ..............................................................................................................................6
3.3 DEFROST CYCLE TABLE..................................................................................................................................................6
3.4 DIMENSIONS ...............................................................................................................................................................7
3.5 CONTROLS AND FURNACE LINK OPTION...........................................................................................................................7
3.6 SPECIFICATIONS...........................................................................................................................................................7
4. TYPICAL INSTALLATIONS ....................................................................................................................................... 8
4.1 FULLY DUCTED SYSTEM................................................................................................................................................8
4.2 EXHAUST DUCTED SYSTEM (SOURCE POINT VENTILATION) .................................................................................................8
4.3 SIMPLIFIED (VOLUME VENTILATION).................................................................................................................................8
5. INSTALLATION ................................................................................................................................................ 9-14
5.1 LOCATING AND MOUNTING THE UNIT ...............................................................................................................................9
5.2 PLANNING OF THE DUCTWORK .......................................................................................................................................9
5.3 CALCULATING THE DUCT SIZE...................................................................................................................................... 10
5.3.1 EXAMPLE OF CALCULATION...................................................................................................................................................10
5.3.2 EXAMPLE OF ADESIGN FOR AFULLY DUCTED SYSTEM .............................................................................................................10
5.4 INSTALLING THE DUCTWORK AND REGISTERS .................................................................................................................. 11
5.4.1 FULLY DUCTED SYSTEM.......................................................................................................................................................11
5.4.2 EXHAUST DUCTED SYSTEM (SOURCE POINT VENTILATION) ........................................................................................................11
5.4.3 SIMPLIFIED INSTALLATION (VOLUME VENTILATION).....................................................................................................................12
5.5 CONNECTING DUCT TO THE UNIT .................................................................................................................................13
5.6 INSTALLING EXTERIOR HOODS......................................................................................................................................14
5.7 CONNECTING THE DRAIN.............................................................................................................................................14
6. CONTROL DEVICES...................................................................................................................................... 15-16
6.1 MAIN CONTROLS .......................................................................................................................................................15
6.2 OPTIONAL CONTROLS.................................................................................................................................................16
6.3 OTHER FEATURES......................................................................................................................................................16
6.4 MAIN AND OPTIONAL CONTROLS AVAILABLE FOR YOUR UNIT .............................................................................................16
7. I NSTALLATION OF THE CONTROLS.....................................................................................................................17-20
7.1 DIMENSIONS AND SPECIFICATIONS (MAIN CONTROLS) ......................................................................................................17
7.2 INSTALLATION OF THE MAIN CONTROL....................................................................................................................... 17-19
7.2.1 PLATINUM MAIN CONTROL INSTALLATION .................................................................................................................................17
7.2.2 DECO-TOUCH MAIN CONTROL INSTALLATION ...........................................................................................................................18
7.2.3 DEHUMIDISTAT, DH100W, VT1W AND VT2W MAIN CONTROL INSTALLATION ..............................................................................18
7.2.4 MAIN CONTROL ELECTRICAL CONNECTION..............................................................................................................................19
7.3 ELECTRICAL CONNECTION TO OPTIONAL CONTROLS ........................................................................................................19
7.4 ELECTRICAL CONNECTION TO THE FURNACE ...................................................................................................................20
8. WIRING DIAGRAMS ...................................................................................................................................... 21-22
9. AIR FLOW BALANCING .................................................................................................................................23-24
9.1 WHAT YOU NEED TO BALANCE THE UNIT .......................................................................................................................23
9.2 PRELIMINARY STAGES TO BALANCE THE UNIT .................................................................................................................23
9.3 INSTALLATION OF FLOW COLLARS OR "FLOW MEASURING STATIONS"...................................................................................23
9.4 BALANCING PROCEDURE .............................................................................................................................................24
10. OVERALL VERIFICATION ................................................................................................................................25-26
10.1 MAIN CONTROLS .......................................................................................................................................................25
10.2 OPTIONAL CONTROL ..................................................................................................................................................26
11. MAINTENANCE/INSTRUCTIONS FOR USER .............................................................................................................. 26
12. TROUBLESHOOTING...................................................................................................................................... 27-28
13. REFERENCES .................................................................................................................................................. 28
TABLE OF CONTENTS

3
This manual uses the following symbols to emphasize particular information:
NOTE: Indicates supplementary information needed to fully complete an instruction.
WARNING
Identifies an instruction which, if not followed, might cause serious personal injuries including possibility of
death.
!
CAUTION
Denotes an instruction which, if not followed, may severely damage the unit and/or its components.
WARNING
Installation work and electrical wiring must be done by a qualified person(s) in accordance with all applicable
codes and standards, including fire-rated construction codes and standards.
!
1. S ERVICE
ABOUT THIS MANUAL
6
1
2
3
4
5
7
8
910
11
12
13
14
15
16
17
18
19
20
21
22 3
23
23
24
25
26
VL0016
1.1 3-D DRAWING
DAMPER ASSEMBLY (REAR VIEW)

4
REPLACEMENT PARTS AND REPAIRS
In order to ensure your ventilation unit remains in good working condition, you must use the manufacturer genuine replacement parts
only. The manufacturer replacement parts are specially designed for each unit and are manufactured to comply with all the applicable
certification standards and maintain a high standard of safety. Any third party replacement part used may cause serious damage and
drastically reduce the performance level of your unit, which will result in premature failing. The manufacturer recommends to contact a
certified service depot for all replacement parts and repairs.
NO.DESCRIPTION 1001
HRV
1001
ERV
2001
HRV
2001
ERV
HRV
100H
ERV
100HC
HRV
200H
ERV
200HC
1DOUBLE COLLAR PORT NO. 2 00866 00866 00866 00866 00866 00866 00866 00866
2W
ING NUT NO. 10-32 00874 00874 00874 00874 00874 00874 00874 00874
3B
ALANCING DOUBLE COLLAR PORT 02256 02256 02256 02256 02256 02256 02256 02256
4INLET RING 12913 12913 12913 12913 12913 12913 12913 12913
5T
OP WHEEL 14307 03093 14308 03093 14307 03093 14308 03093
6ELECTRONIC BOARD V99 13507 13507 13507 13507 13508 13507 13508 13507
7MOTOR ASSEMBLY 13504 13555 13556 13506 13504 13555 13505 13506
8BOTTOM WHEEL 02015 02015 03093 03093 02015 02015 03093 03093
9SQUARE BALANCING DAMPER 12645 12645 12645 12645 12645 12645 12645 12645
10 DOOR LATCHES (LATCH) 00886 00886 00886 00886 00886 00886 00886 00886
11 DRAIN CONNECTOR 02418 02418 02418 02418 02418 02418 02418 02418
12 DRAIN GASKET 0.625" D 02419 02419 02419 02419 02419 02419 02419 02419
13 WASHER 5/8" ID X1" OD 03117 03117 03117 03117 03117 03117 03117 03117
14 NUT 5/8-18 02420 02420 02420 02420 02420 02420 02420 02420
15 RECOVERY CORE 03132 03136 03133 03137 03134 03136 03135 03137
16 DOOR ASSEMBLY 12644 12644 12644 12644 12648 12648 12648 12648
17 DOOR LATCHES (KEEPER) 00887 00887 00887 00887 00887 00887 00887 00887
18 HINGE ASSEMBLY 00672 00672 00672 00672 00672 00672 00672 00672
19 FILTER 03096 03096 03097 03097 03096 03096 03097 03097
20 SWITCH E69 10A 01825 01825 01825 01825 01825 01825 01825 01825
21 DAMPER ASSEMBLY NO. 2 12643 12643 12649 12649 12643 12643 12649 12649
22 PLASTIC BALANCING DAMPER 02253 02253 02253 02253 02253 02253 02253 02253
23 DAMPER ROD 12620 12620 12620 12620 12620 12620 12620 12620
24 DOUBLE COLLAR PORT NO. 5 02021 02021 02021 02021 02021 02021 02021 02021
25 DAMPER NO. 1 12459 12459 12459 12459 12459 12459 12459 12459
26 DAMPER ACTUATOR ASSEMBLY 03124 03124 03124 03124 03124 03124 03124 03124
Please note that parts not listed are not available; those parts require assembly knowledge that only manufacturer can guarantee.
1. S ERVICE (CONT'D)
1.2 PARTS ORDERING CHART
1.3 TECHNICAL SUPPORT (FOR ASSISTANCE)
For assistance, call on weekdays, from 8:30 a.m. to 5:00 p.m. (Eastern Standard Time).
NOTE: Do not call these numbers for ordering parts.
Technical Support Department
Canada: 1-888-908-2633 (for distributors only)
U.S.A.: 1-800-637-1453
TO ORDER PARTS: Contact your local distributor.

5
2. UNIT TYPE AND DEFROST SETTING VS GEOGRAPHICAL LOCATION
ANCHORAGE
WHITEHORSE
JUNEAU
HAY RIVER
YELLOWKNIFE
Prince Rupert GRANDE PRAIRIE
FORT MCMURRAY
ZONE A
FORT SMITH
EDMONTON
PRINCE ALBERT
SASKATOON
JASPER
KAMLOOPS
CALGARY
PENTICTON REGINA
LETHBRIDGE
HELENA
VICTORIA
OLYMPIA
WINNIPEG
SALEM
BOISE
BISMARCK
SALT LAKE CITY
SAULT STE MARIE
ST. PAUL
DES MOINES
MADISON
TIMMINS
HARRISBURG
SACRAMENTO
DENVER
TOPEKA
SUDBURY
TORONTO
DETROIT
INDIANAPOLIS
SANTA FE
SPRINGFIELD
OKLAHOMA CITY
PHOENIX
COLUMBUS
NASHVILLE
ATLANTA
BATON ROUGE
AUSTIN
COLUMBIA
RALEIGH
WASHINGTON
OTTAWA
NORTH BAY
VAL-DOR
CHICOUTIMI
HARTFORD
CHIBOUGAMAU
MONTRÉAL
QUEBEC
BOSTON
GOOSE BAY
LABRADOR CITY
SEPT-ILES
MATANE
GASPÉ
BATHURST
ST-JOHN HALIFA X
CHARLOTTETOWN
ST JOHN'S
ZONE C
ZONE B
ZONE D
RENO
VN0002
ZONE C SELECTION CHART SYMPTOM
(CONDENSATION)SOLUTION
INDOOR AIR QUALITY PROBLEM ERV AND/OR EXCESS MOISTURE PROBLEM ERV AND/OR IMPORTANT EXCESS MOISTURE PROBLEM HRV
ZONE A (HRVs only) • Set Extended Defrost according to section 7.2.3, point 4 • MODELS: 1001 HRV, 2001 HRV, HRV100H, HRV200H ZONE B (HRVs only) • Extended Defrost setting not required (factory defrost
strategy pre-set)
• MODELS: 1001 HRV, 2001 HRV, HRV100H, HRV200H
ZONE C (HRV or ERV according to your client’s
particular problems)
See ZONE C SELECTION CHART at right. • HRV MODELS: 1001 HRV, 2001 HRV, HRV100H, HRV200H • ERV MODELS: 1001 ERV, 2001 ERV, ERV100HC, ERV200HC ZONE D (ERVs recommended) • ERV MODELS: 1001 ERV, 2001 ERV, ERV100H, ERV200H

6
3.1 AIR DISTRIBUTION (NORMAL OPERATION)
STALE AIR
TO OUTSIDE
FRESH AIR
FROM OUTSIDE
FRESH AIR
TO BUILDING
STALE AIR
FROM BUILDING
OUTSIDE TEMPERATURE DEFROST CYCLES EXTENDED DEFROST CYCLE
CELCIUS (°C) FAHRENHEIT (°F) DEFROSTING (MIN.) OPERATION TIME (MIN.)
BETWEEN EACH DEFROST CYCLE DEFROSTING (MIN.) OPERATION TIME (MIN.) BETWEEN EACH DEFROST CYCLE
-5 23 6 32 10 30
-1556 321020
-27 -17 6 20 10 15
NOTE: The unit performance charts are listed on their own specification sheets. To access those documents,
visit: www.vanee-ventilation.com (Canadian units) or www.broan.com (U.S.A. units).
3. TECHNICAL DATA
VF0013
VF0020
3.2 AIR DISTRIBUTION (DEFROST MODE)
3.3 DEFROST CYCLE TABLE
FRESH AIR
TO BUILDING
STALE AIR
FROM BUILDING

7
3.4 DIMENSIONS
3. TECHNICAL DATA (CONT'D)
13¾" (349mm)
20"
(508mm)
6" (152mm)
2½" (63mm)
30¼" (768mm)
VK0040A
19" (483mm)
20"
(508mm)
6" (152mm) 30¼" (768mm)
2½" (63mm)
VK0039A
Models:
• 1001 ERV
• 1001 HRV
• HRV100H
• ERV100HC
Models:
• 2001 ERV
• 2001 HRV
• HRV200H
• ERV200HC
3.5 CONTROLS AND FURNACE LINK OPTION
Main controls:
• Platinum (Canada only)
• Deco-Touch (Canada only)
• VT1W (U.S.A. only)
• VT2W (U.S.A. only)
Optional controls:
• 20-minute push-button (for HRV100H and
HRV200H models only)
• 20/40/60-minute push-button
(for all other models)
• 60-minute crank timer
• Dehumidistat
Link option:
• Furnace interlock
(use with forced air systems)
3.6 SPECIFICATIONS
MODELS 1001 ERV, 1001 HRV, HRV100H, ERV100HC 2001 ERV, 2001 HRV, HRV200H, ERV200HC
WEIGHT 65 LB. (30 KG) 73 LB. (33 KG)
PORT DIAMETER 6” (152 MM) 6” (152 MM)
DRAIN DIAMETER 1/2” (12 MM) 1/2” (12 MM)
INSTALLATION CHAINS, SPRING AND HOOKS (PROVIDED WITH U.S.A. UNITS)
STRAPS AND WASHERS (PROVIDED WITH CANADIAN UNITS)
MOTOR SPEED HIGH AND LOW SPEEDS FACTORY SET (OPTIONAL INCREASED LOW SPEED - BLUE WIRE)
ELECTRICAL SUPPLY 120 V, 60 HZ120 V, 60 HZ
POWER CONSUMPTION 150 WATTS 225 WATTS

8
4.1 FULLY DUCTED SYSTEM
(Primarily for homes with radiant hot water or electric baseboard heating. See
Figure at right.)
Moist, stale air is exhausted from the high humidity areas in the home, such as
bathrooms, kitchen and laundry room. Fresh air is supplied to bedrooms and
principal living areas.
If required, bathroom fans and a range hood may be used to better exhaust stale
air.
Homes with more than one level require at least one exhaust register at the
highest level.
VH0024
See 5.4.1
for details
4.2 EXHAUST DUCTED SYSTEM (SOURCE POINT VENTILATION)
(For homes with forced air heating. See Figure at right.)
Moist, stale air is exhausted from the high humidity areas in the home, such as
bathrooms, kitchen and laundry room. Fresh air is supplied to the cold air return or
the supply duct of the furnace.
If required, bathroom fans and a range hood may be used to better exhaust stale air.
Homes with more than one level require at least one exhaust register at the highest
level.
NOTE: For this type of installation, it is not essential that the furnace blower runs
when the unit is in operation, but we recommend it.
VH0025
See 5.4.2
for details
4.3 SIMPLIFIED (VOLUME VENTILATION)
(For homes with forced air heating. See Figures A and B below.)
Fresh air and exhaust air flow through the furnace ducts which simplifies the installation.
The use of bathroom fans and range hood is suggested to better exhaust stale air.
NOTE: For the installation type shown in Figure B, furnace blower should be running when the unit is in operation.
VH0027 VH0026
See 5.4.3
for details
See 5.4.3
for details
OR
AB
4. TYPICAL INSTALLATION
There are three common installation methods.

9
WARNING
When applicable local regulations comprise more restrictive installation and/or certification requirements, the
aforementioned requirements prevail on those of this document and the installer agrees to conform to these at
his own expenses.
!
INSPECTING THE BOX CONTENT
• Inspect the exterior of the unit for shipping damage. Ensure that there is no damage to the door, door latches, door hinges, dampers,
duct collars, cabinet, etc.
• Inspect the interior of the unit for damage. Ensure that the fan motor assembly, recovery core, insulation, dampers, damper actuator
and drain pan are all intact.
• If the unit was damaged during shipping, contact your local distributor. (Claims must be made within 24 hours after delivery.)
• Use checklist included with the unit to ensure that no parts are missing.
5.1 LOCATING AND MOUNTING THE UNIT
Choose an appropriate location for the unit:
• Within an area of the house where the temperature is kept above 10°C/50°F and below
40°C/104°F
• Away from living areas (dining room, living room, bedroom), if possible.
• So as to provide easy access to the interior cabinet for every three months and annual
maintenance, and to the control panel on the right hand side of the unit.
• Close to an exterior wall, so as to limit the length of the insulated flexible duct to and from
the unit.
• Close to a drain. If no drain is close by, use a pail to collect run-off.
• Away from hot chimneys, electrical panel and other fire hazards.
• Allow for a power source (110 V standard outlet).
CAUTION
Make sure the unit is level.
5.2 PLANNING THE DUCTWORK
a) Follow the instructions in Section 5.3 on next page to determine the appropriate duct diameters for your system.
b) Keep it simple. Plan for a minimum number of bends and joints. Keep the length of insulated duct to a minimum.
c) Do not use wall cavities as ducts. Do not use branch lines smaller than 4” (102 mm) Ø.
d) Do not ventilate crawl spaces or cold rooms. Do not attempt to recover the exhaust air from a dryer or a range hood. This would cause
clogging of the recovery module. Use sheet metal for the kitchen exhaust duct.
e) Be sure to plan for at least one exhaust register on the highest lived-in level of the house if it has 2 floors or more.
5. INSTALLATION
WARNING
When performing installation, servicing or cleaning the unit, it is recommended to wear safety glasses and gloves.
!
VD0064
For vänEE Canadian models 1001 VRE, 1001 VRC, 2001 VRE and 2001 VRC,
hang the unit to ceiling joists with washers and 4 straps (included) (see figure
at right).
For Broan U.S.A. models HRV100H, HRV200H, ERV100HC, and ERV200HC,
hang the unit to ceiling joists with the 4 chains, springs and hooks (included)
(see figure at right).
VD0212
VÄNEE CANADIAN MODELS
1001 ERV, 1001 HRV,
2001 ERV AND 2001 HRV
BROAN U.S.A. MODELS
HRV100H, HRV200H,
ERV100HC AND ERV200HC

10
5.3 CALCULATING DUCT SIZE
Use the table below to ensure that the ducts you intend to install will be carrying air flows at or under the recommended values.
Avoid installing ducts that will have to carry air flows near the maximum values and never install a duct if its air flow exceeds
the maximum value.
NOTE: Examples 5.3.1 and 5.3.2 use imperial measures.
The same calculation applies to metric measures.
5.3.1 EXAMPLE OF CALCULATION:
Problem: My installation requires two exhaust registers (one for the kitchen, one for the bathroom). I will connect these
registers to a main duct which will connect to the unit (high speed performance value of 140 cfm).What size of duct
should I use for the main exhaust duct and for the two end branches leading to the registers? (See Figure above.)
Solution: Simplified method. (For a more detailed method of calculating duct size refer to the ASHRAE or HRAI HANDBOOK.)
Main duct: Table above indicates a 6” Ø duct: Recommended air flow: 120 cfm; maximum air flow: 180 cfm.The high speed air
flow of 140 cfm is close enough to the recommended value (120) and far enough away from the maximum value
(180). Therefore a 6” Ø duct or larger is an appropriate choice for the main exhaust duct.
End branches: Each end branch will have to transport an air flow of 70 cfm (140 divided by 2). Table above indicates a 5” Ø
duct: Recommended air flow: 75 cfm; maximum air flow: 110 cfm. The high speed air flow of 70 cfm is close
enough to the recommended value (75) and far enough away from the maximum value (110). Therefore a
5” Ø duct or larger is an appropriate choice for both end branches.
NOTE: A 4" Ø duct would have been too small because the maximum acceptable value for a 4"Ø duct is 60 cfm.
5.3.2 EXAMPLE OF ADESIGN FOR AFULLY DUCTED SYSTEM FOR AUNIT HAVING AHIGH SPEED PERFORMANCE OF 222 CFM
VI0003
END
BRANCHES
5" Ø,
70 CFM
MAIN BRANCH
6" Ø, 140 CFM
140 CFM
VI0004
5" 5" 4"
4"
4"
4"
6" 6"
6"
6"
7"
7"
6" Ø, 93 CFM
6" Ø, 129 CFM
5" Ø, 65 CFM
5" Ø, 64 CFM
4" Ø, 42 CFM
4" Ø, 42 CFM
6" Ø, 84 CFM
7" Ø, 222 CFM
6" Ø, 138 CFM
6" Ø, 96 CFM
DUCT DIAMETER RECOMMENDED AIRFLOW MAXIMUM AIRFLOW
4" 40 CFM 19 L/S68 M³/H60 CFM 28 L/S102 M³/H
5" 75 CFM 35 L/S127 M³/H110 CFM 52 L/S187 M³/H
6" 120 CFM 57 L/S204 M³/H180 CFM 85 L/S306 M³/H
7" 185 CFM 87 L/S314 M³/H270 CFM 127 L/S459 M³/H
8" 260 CFM 123 L/S442 M³/H380 CFM 179 L/S645 M³/H
5. INSTALLATION (CONT'D)

11
WARNING
When performing duct connection to the furnace, installation must be done in accordance with all applicable
codes and standards. Please refer to your local building code.
!
There are two methods for connecting the unit to the furnace:
Method 1: Supply side connection
• Cut an opening into the furnace supply duct at least 18" (0.5 m) from the furnace.
• Connect this opening to the fresh air distribution port of the HRV/ERV (use metal
duct, see Figure at right).
• Make sure that the HRV/ERV duct forms an elbow inside the furnace ductwork.
• If desired, interlock (synchronize) the furnace blower operation with the HRV/ERV
operation. (See Section 7.4.)
Method 2: Return side connection
• Cut an opening into the furnace return duct not less than 10 feet (3.1 m) from the
furnace (A + B).
• Connect this opening to the fresh air distribution port of the HRV/ERV (see Figure at
right).
NOTE: For Method 2, it is not essential that the furnace blower runs when the
HRV/ERV is in operation, but we recommend it. If desired, synchronize the
furnace blower operation (see Section 7.4).
CAUTION
Whenperformingconnectiontothefurnacesupplyduct,thisductmustbesizedtosupporttheadditionalairflowproduced
by the HRV/ERV. Also, use a metal duct with a backdraft damper to prevent the risk of overheating the HRV/ERV.
A+B= NOT LESS
THAN 10' (3.1 M)
B
A
VD0041
5. INSTALLATION (CONT'D)
5.4 INSTALLING THE DUCTWORK AND REGISTERS
WARNING
Never install a stale air exhaust register in a room where a combustion device is, such as a gas furnace or a gas
water heater or a fireplace.
!
CAUTION
The ductwork is intended to be installed in compliance with all applicable codes.
5.4.1 FULLY DUCTED SYSTEM (AS ILLUSTRATED IN SECTION 4.1)
Stale air exhaust ductwork:
• Install registers in areas where contaminants are produced: kitchen, bathrooms, laundry room, etc.
• Install registers 6" to 12" (152 mm to 305 mm) from the ceiling on an interior wall OR install them in the ceiling.
• Install the kitchen register at least 4 feet (1.2 m) from the range top.
• If possible, measure the velocity of the air flowing through the registers. If the velocity is higher than 400 ft/min. (122 m/min),
then the register type is too small. Replace with a larger one.
Fresh air distribution ductwork:
• Install registers in bedrooms, dining room, living room and basement.
• Install registers either in the ceiling or high on the walls with air flow directed toward the ceiling. (The cooler air will then cross
the upper part of the room, and mix with room air before descending to occupant's level.)
• If a register must be floor installed, direct the airflow up the wall.
5.4.2 EXHAUST DUCTED SYSTEM (SOURCE POINT VENTILATION) (AS ILLUSTRATED IN SECTION 4.2)
Stale air exhaust ductwork:
(same as for Fully Ducted System, described in Section 5.4.1)
Fresh air distribution:
VD0040
MINIMUM 18"
(0.5 M)
METAL DUCT WITH
BACKDRAFT DAMPER

12
5.4 INSTALLING THE DUCTWORK AND REGISTERS (CONT'D)
5.4.3 SIMPLIFIED INSTALLATION (VOLUME VENTILATION) (AS ILLUSTRATED IN SECTION 4.3)
WARNING
When performing duct connection to the furnace, installation must be done in accordance with all applicable
codes and standards. Please refer to your local building code.
!
CAUTION
When performing connection to the furnace ducts (Method 1), these ducts must be sized to support the additional
airflow produced by the HRV/ERV. Also, the supply duct must be a metal duct with a backdraft damper to prevent
the risk of overheating HRV/ERV.
Stale air intake:
• Cut an opening into the furnace return duct not less than 10 feet (3.1 m) from the furnace (A + B).
• Connect this opening to the stale air intake port on the HRV/ERV as shown.
Fresh air distribution: (Same instructions as for Method 1 or Method 2, section 5.4.2).
For method 2 (return-return) make sure there is a distance of at least 3 feet (0.9 m) between both connections to the furnace.
There are two methods (Figures below) for connecting the unit to the furnace:
Method 1: Return-supply Method 2: Return-return
MINIMUM 18"
(0.5 M)
METAL DUCT WITH
BACKDRAFT DAMPER
VD0042
A
B
VD0043
A
B
A + B = NOT LESS
THAN 10’ (3.1 M)
A + B = NOT LESS
THAN 10’ (3.1 M)
3' (0.9 M)
MINIMUM
CAUTION
If using Method 2, make sure the furnace blower operation is synchronized with the HRV/ERV operation! See
Section 7.4.
5. INSTALLATION (CONT'D)
NOTE: For Method 1, it is not essential to synchronize the furnace blower operation with the HRV/ERV operation, but we
recommend it.

13
Rigid duct:
Use duct tape to connect the rigid ducts to the ports.
Make sure that both balancing dampers are left in a fully open position
before connecting the ducts to these ports (fresh air distribution port and
stale air exhaust port as shown on figure at right).
5.5 CONNECTING DUCTS TO THE UNIT
Insulated flexible duct:
Use the following procedure for connecting the insulated flexible duct to the ports on the unit (exhaust to outside and fresh air from outside).
a) Pull back the insulation to expose the flexible duct.
b) Connect the interior flexible duct to the port using a duct tie.
c) Carefully seal the connection with duct tape.
d) Pull the insulation over the joint and tuck it between the inner and outer rings of the double collar.
e) Pull the vapor barrier over the insulation and over the outer ring of the double collar.
f) Apply duct tape to the joint making an airtight seal. Avoid compressing the insulation when you pull the tape tightly around the joint.
Compressed insulation loses its R value and causes water dripping due to condensation on the exterior surface of the duct.
CAUTION
Make sure that the vapor barrier on the insulated ducts does not tear during installation to avoid condensation
within the duct.
VJ0001 VJ0002 VJ0003 VJ0004 VJ0005
CAUTION
Do not use screws to connect rigid ducts to the ports.
5. INSTALLATION (CONT'D)
VJ0009
a) b) c) d), e) f)

14
VO0011
5.6 INSTALLING THE EXTERIOR HOODS
Choose an appropriate location to install the exterior hoods:
• There must be a minimum distance of 6' (1.8 m) between the
hoods to avoid cross-contamination
• There must be a minimum distance of 18" (457 mm) from the
ground
Refer to Figure at right to connect the insulated duct to the hoods.
Place the “FRESH AIR INTAKE” sticker, provided in the installation
kit, on corresponding hood. An anti-gust intake hood should be
installed in regions where a lot of snow is expected to fall.
Make sure the intake hood is at least 6' (1.8 m) away
from any of the following:
• Dryer exhaust, high efficiency furnace vent, central
vacuum vent
• Gas meter exhaust, gas barbecue-grill
• Any exhaust from a combustion source
• Garbage bin and any other source of contamination
WARNING
!
5.7 CONNECTING THE DRAIN
Attach both plastic drain fittings to the
unit using the gaskets, washers and
nuts as shown.
TIE WRAP
VO0003 VO0005A
± 12"
(± 305 mm)
± 12"
(± 305 mm)
VD0231A
± 1”
Cut 2 sections of plastic tubing, about
12" (305 mm) long and attach them to
each drain fitting. Join these 2 short
sections to the “T” junction and main
tube as shown.
Make a water trap loop in the tube
to prevent the unit from drawing
unpleasant odors from the drain
source. Make sure this loop is located
BELOW the “T” as shown. This will
prevent water from being drawn back
up into the unit in case of negative
pressure. Run the tube to the floor
drain or to an alternative drain pipe or
pail. Be sure there is a slight slope for
the run-off.
TODRAIN
If using a pail to collect water, locate
the tube end approximately 1" from the
top of the pail in order to prevent water
from being drawn back up into the unit.
5. INSTALLATION (CONT'D)
VD0028
EXHAUST HOOD
INTAKE HOOD
TAPE AND DUCT TIE
18"
(457 MM)
6'
(1.8 M)
18"
(457 MM)
18"
(457 MM)
6'
(1.8 M)
OPTIONAL DUCT
LOCATION
6"
(152 MM)
CAULKING
CAUTION
All models require an exhaust hood with a backdraft
damper. This damper closes when the unit is off and
prevents unwanted cold air from entering the house.

15
6. CONTROL DEVICES
6.1 MAIN CONTROLS
CAUTION
All models require a main control.
Platinum model
(Canada)
Deco-Touch model
(Canada)
VT1W model
(U.S.A.)
VT2W model
(U.S.A.)
SMART
SET
MODE
PREF
CONDENSATION CONTROL
AIR SUPPLY CONTROL
MIN.
MAX.
OFF
AIR
EXCHANGE
-20°C
-4°F
-5°C
23°F
5°C
41°F
C
O
M
F
O
R
T
Z
O
N
E
S
U
M
M
E
R
-20°C
-4°F
-5°C
23°F
5°C
41°F
CONDENSATION CONTROL
AIR SUPPLY CONTROL
CONDENSATION CONTROL
MAXIMUM SPEED
AIR EXCHANGE IN PROGRESS
MIN. MAX.
CONTINUOUS INTERMITTENT
20 MIN.
ON
40 MIN.
OFF
C
O
M
F
O
R
T
Z
O
N
E
S
U
M
M
E
R
Dehumidistat
Designed primarily for use with our low price HRV (Heat Recovery
Ventilator) units, the dehumidistat helps control indoor maximum
humidity level during fall, winter and spring. This control should not
be installed in a house already equipped with other main controls
(except the 3-position switch). You will find a relative humidity %
scale instead of a temperature scale meant to reduce the window
condensation problems.
3-position switch
Some model may come with a 3-position mounted switch on the
electrical box on the exterior lower right front side. It is basically
an airflow control that gives the customer the choice between the
low and high speed or the OFF (REMOTE) position. This OFF
(REMOTE) position does not deactivate the optional controls.
U.S.A. MODELS DH100W VT1W VT2W
CANADIAN MODELS DEHUMIDISTAT DECO-TOUCH PLATINUM
MODES
OFF Position X X X X X
Intermittent exchange (TBI) 20 ON - 40 OFF X
Intermittent exchange OR OFF (ON - OFF or ON - Recirculation) X X
Low speed continuous exchange X X X X
High speed continuous exchange X X X X
SMART (entirely automatic mode optimizing ventilation) X
Program (programs the desired ventilation according to the period of the day) X
Recirculation (manual mode performing air recirculation inside the house) X X
DETECTOR
TYPES
Humidity control (Relative humidity scale %) X
Indoor condensation control (Temperature scale) X X
Outdoor temperature X
Indoor relative humidity X
INDICATORS
Mode indicator XX X X
Air exchange indicator XX X
Condensation/Polluant control max speed indicator X
Maintenance indicator XX X
Day and hour indicators X
SWITCHES
Sliding button X
Push button XX X

16
6.2 OPTIONAL CONTROLS
Lighted Push-Button Remote 20-minute Switch:
This remote illuminated switch is typically installed in bathrooms, kitchen and laundry room to provide 20 minutes of high speed ventilation
at the push of a button. The switch is supplied and mounted on a white single gang wall plate. This push-button is available only for
HRV100H and HRV200H units.
20/40/60-Minute Push-Button Timer:
This remote illuminated switch is typically installed in bathrooms, kitchen and laundry room to provide 20, 40 or 60 minutes of high speed
ventilation at the push of a button. The switch is supplied and mounted on a white single gang wall plate.This push-button is not available
for HRV100H and HRV200H units.
Mechanical Timer:
This timer allows up to 60 minutes of high speed operation to be selected from a remote location.
6. CONTROL DEVICES (CONT'D)
6.3 OTHER FEATURES
Furnace Interlock (for forced air heating system)
The furnace fan can be interlocked so that it will run simultaneously with the ERV or HRV to ensure proper distribution of fresh air
throughout the house (see table section 6.4, to see if it is available on your unit).
Permanent Memory
Our electronic controls have a default memory feature in the event of a power outage. Even the date of the last service reminder is
maintained as a convenience to the homeowner.
NOTE: For Platinum control only, if the power failure duration is more than 4 hours, the day and hour settings must be reprogrammed.
Control Upgrades
All controls can be used on any ERV, so a VT1W control can be upgraded to a VT2W in the future (see table in Section 6.4 below for
control availability according to the units).
6.4 MAIN AND OPTIONAL CONTROLS AVAILABLE FOR YOUR UNIT
MAIN CONTROLS
MODEL NUMBER DH100W
DEHUMIDISTAT VT1W VT2W DECO-TOUCH PLATINUM
100 ERV X X X
ERV100HC X X
1001 HRV X X X
2001 ERV X X X
ERV200HC X X
2001 HRV X X X
HRV100H / HRV200H X X
OPTIONAL CONTROLS
MODEL NUMBER 20/40/60-MINUTE
PUSH-BUTTON TIMER
20-MINUTE
PUSH-BUTTON TIMER
60-MINUTE
CRANK TIMER FURNACE INTERLOCK
100 ERV X X INTEGRATED
ERV100HC X X INTEGRATED
1001 HRV X X INTEGRATED
2001 ERV X X INTEGRATED
ERV200HC X X INTEGRATED
2001 HRV X X INTEGRATED
HRV100H / HRV200H X X OPTIONAL KIT PART NO. 12658

17
7.2.1PLATINUM MAIN CONTROL INSTALLATION
WARNING
Always disconnect the unit before making any connections. Failure in disconnecting power could result in electric
shock or damage of the control or electronic module inside the unit.
!
CAUTION
Failure to comply with the following can cause erratic operation of the unit:
• Never install more than one optional control per unit.
• Keep control low voltage wiring at least 1 foot (305 mm) away from motors, lighting ballast, light dimming circuit
and power distribution panel. Do not route control wiring alongside house power wiring.
• Ensure the wires are securely connected.
1. Route the cable from the unit to a convenient location for
the wall control.
2. Detach the front module
from the mounting plate by
pulling the bottom part.
3. Run the cable (4 wires)
through the central opening
of the mounting plate and
mount this plate to the wall
using screws (not included).
If needed, use wall anchors
(not included).
VC0102
VC0103
4. Splice back the end of the
cable to access the 4 wires.
Strip the end of each wire.
Connect each wire to its
corresponding terminal on
the back of the front module:
YELLOW wire to “Y”, RED
wire to “R”, GREEN wire to
“G” and BLACK wire to “B”.
5. Reinstall the front module over the back plate.
VE0173
RED
WIRE
GREEN
WIRE
YELLOW
WIRE
BLACK
WIRE
CAUTION
Be careful not to pinch wires when reinstalling
the front module on its back plate.
7. I NSTALLATION OF THE CONTROLS
7.1 DIMENSIONS AND SPECIFICATIONS (MAIN CONTROLS)
DEHUMIDISTAT, DH100W, VT1W,
AND VT2W
VOLTAGE: 12 volts DC
PLATINUM
VOLTAGE: 12 volts DC
DECO-TOUCH
VOLTAGE: 12 volts DC
5" (127 mm)
VC0016A
5" (127 mm)
1³/8"
(35 mm)
FRONT VIEW SIDE VIEW
VC0105A
1"
(26 mm)
4¼" (107 mm)
4" (102 mm)
FRONT VIEW SIDE VIEW
VC0118A
2¾" (70 mm)
4½" (114 mm)
7.2 INSTALLATION OF THE MAIN CONTROL

18
1. Cut a 27∕8" x 1³∕8" hole in wall
at a convenient location for
the wall control. Route the
cable from the unit to this
hole.
NOTE: Dimensions shown
are for an installation
without wall box.
2. Temporarily place the
switch over the hole and
mark both mounting screw
hole positions.
3. Remove the switch, drill
both screw holes (Ø 3/16")
in wall and insert wall
anchors (included).
4. Strip the end of the cable to
access the 4 wires. Strip the
end of each wire. Using a
small flat blade screwdriver,
connect each wire to its
corresponding terminal on
the back of the wall control:
YELLOW wire to “Y”, RED
wire to “R”, GREEN wire to
“G” and BLACK wire to “B”.
5. Mount the wall control to
the wall.
VC0116A
Ø 3/16”, typ.
Y
B
G
R
VE0243
VC0115
7.2.2DECO-TOUCH MAIN CONTROL INSTALLATION
7. I NSTALLATION OF THE CONTROLS (CONT'D)
7.2 INSTALLATION OF THE MAIN CONTROL (CONT'D)
1. Determine the location of the control. The control must be installed in a central location on the main floor. Typical locations for
these controls are kitchen, main hallways and family room.
2. Remove the button(s) and the cover plate of the control.
3. Install the control 60" (1.5 m) from the floor and leave a free space of at least
2" (5 cm) to the right of the control to allow user to slide out the control
instructions (see figure at right).
Use the template provided in the control box to position the wire hole and the
screw holes. Use the screws and the plastic anchors provided in the installation
kit to secure the control.
7.2.3DEHUMIDISTAT, DH100W, VT1W, AND VT2W MAIN CONTROLS INSTALLATION
DEHUMIDISTAT
OR VT2W
VC0026
VT1W
60" (1.5 m)
2"
(5 cm)
VD0025A

19
7.2 INSTALLATION OF THE MAIN CONTROL (CONT’D)
7.3 ELECTRICAL CONNECTION TO OPTIONAL CONTROLS
9
8
7
6
5
4
3
2
1
OL
OC
I
1 4 7
2 5 8
3 6 9
J3
MAIN PC BOARD
PUSH-BUTTON SWITCHES
(HRV100H and HRV200H :
5 switches maximum)
J1
0L 0C I
VE0164A
REAR VIEW
7. I NSTALLATION OF THE CONTROLS (CONT'D)
4. Connect the wires to the main control.
(See figures at right)
NOTE: For HRV100H and HRV200H only,
To install VT1W, only connect GREEN and BLACK wires to main
control.
5. Make sure the instruction pull-out is in the occupant’s language. If not, turn it to the
other side (see figure at right).
6. Reinstall the cover plate and the button(s).
7.2.3DEHUMIDISTAT, DH100W, VT1W, AND VT2W MAIN CONTROLS INSTALLATION (CONT'D)
YRGB
VE0124
VC0068
DEHUMIDISTAT
VT1W AND VT2W
VC0061
7.2.4MAIN CONTROL ELECTRICAL CONNECTION (ALL MODELS)
FFIOCOL YR GBFF IOCOL YRGB
YR GBG
B
VE0038A
FF IOCOL YRGB
GB
SWITCH
VENTILATION
Proper switch
Position
REMOTE
ARRÊT
LOW SPEED
BASSE VITESSE
HIGH SPEED
HAUTE VITESSE
VT2W / PLATINUM /
DECO-TOUCH DEHUMIDISTAT VT1W
1. Connect the wires to their corresponding
position inside the electrical compartment.
Make sure the connections of the unit and
of the control correspond exactly. (See
figure at right.)
2. Connect the optional control (if applicable) by referring to Section 7.3.
3. Do the appropriate connection to the furnace (if applicable) by referring to Section 7.4.
4. NOTE: If the unit is installed in a cold region (Zone A, as defined in Section 2), set up “extended defrost” by removing jumper
JU1F on the main circuit board inside the electrical compartment (see Section 8).
5. Plug in the unit and do the “overall verification” of the system as described in Section 10.

20
WARNING
Never connect a 120-volt AC circuit to the terminals of the furnace interlock (standard wiring). Only use the low
voltage class 2 circuit of the furnace blower control.
!
For a furnace connected to a cooling system:
On some older thermostat, energizing the “R” and “G” terminals at the furnace has the effect of energizing “Y” terminal at the thermostat
and thereby turning on the cooling system. If you identify this type of thermostat, you must use the ALTERNATE FURNACE INTERLOCK WIRING. An
additional control relay will then have to be installed.
NOTE: For HRV100H and HRV200H units, always use the ALTERNATE FURNACE INTERLOCK WIRING.
STANDARD FURNACE INTERLOCK WIRING ALTERNATE FURNACE INTERLOCK WIRING
W R G Y
W
R
G
C
Y
9 8 7 6 5 4 3 2 1
UNIT CONTROL CONNECTOR
THERMOSTAT
TERMINALS
FOUR
WIRES
I OC OL Y R G BF F
J3
TWO WIRES
heating only
FURNACE
24-VOLT
TERMINAL BLOCK
TWO WIRES COOLING SYSTEM
VE0010A
WRGY
W
R
Y
R
G
Y
C
J1 1
2
4
5
6
8
93
*FURNACE INTERLOCK
RELAY
NC NO
7
COM
7
THERMOSTAT
TERMINAL
Unit Control Module
4 WIRES
2 WIRES
(heating only) wiring
nuts
FURNACE
24-VOLT
TERMINAL BLOCK 2 WIRES COOLING SYSTEM
GRAY BROWN
RED
GREEN
BLUE
9-PIN AMP PLUG
*FURNACE INTERLOCK RELAY, PART NO. 12658
VE0009A
7. I NSTALLATION OF THE CONTROLS (CONT'D)
7.4 ELECTRICAL CONNECTION TO THE FURNACE
