Broan BN200 Operating instructions

DELUXE ELECTRIC
POWER BRUSH
HOMEOWNERS OPERATING INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
AB0008
MODEL: BN200
FOR HOUSEHOLD USE ONLY
Broan-NuTone Canada Inc.; Mississauga, Ontario www.broan.ca or www.nutone.ca
1-888-882-7626
Register your product online at: www.broan.ca or www.nutone.ca
!
!
BN200d110809

- 2 -
When using an electric appliance, basic precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS BEFORE USING THE POWER BRUSH.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY:
1. Always turn power off and unplug before cleaning or servicing the power brush.
2. Do not pick up the following items: Sharp objects, flammable liquids, hot
ashes, burning matches, cigarettes, etc.
3. Never use, connect or disconnect the power brush with wet hands.
4. Do not use with damaged power plug or plug pins. If the power brush is not
working properly, contact your local supplier or service agent. The problem
may be covered under the warranty.
5. Do not put objects into the brush opening.
6. Do not use with brush opening or air channel blocked. Keep free of dust, hair, etc.
7. Keep hair, loose clothing, fingers or any other parts of the body away from
moving parts.
8.Never
leave electric power brush unattended while it is plugged in.
9. This is not a toy. Do not let children play with power brush. Children should
be supervised when near the power brush.
10. Use only manufacturer’s recommended attachments.
11. Do not use outdoors or on wet surfaces.
12. Do not use to pick up water.
13. Use extra care when cleaning stairs.
14. Always check underside of product for any obstructions prior to use.
15. Do not use without dust bag or cyclonic filter in place in power unit.
16. Motor shaft can become hot during normal use. To prevent burns, avoid
touching the motor shaft when servicing the drive belt.
17. Keep your work area well lighted.
18. When servicing or cleaning the unit, it is recommended to wear safety glasses
and gloves.
19. Store your cleaner indoors in a clean, dry area.
!
IMPORTANT SAFETY INSTRUCTIONS
The instructions given in this booklet serve as a guide to routine maintenance. To
obtain the most satisfying years of service, read through these instructions and
keep them handy for future reference.

HOSE HANDLE TO WAND CONNECTION
1. HOW TO ASSEMBLE POWER BRUSH/WAND/HANDLE
1. Read important safety instructions before installing power brush.
2. Ensure hose is disconnected from power
supply before installing power brush.
3. Push wand into power brush neck so that
the lock button snaps in place.
4. Connect hose handle into wand quick
connector and ensure that the prongs are
aligned with the receptacle holes. Push
until lock button snaps in place.
HOSE
HANDLE
POWER
BRUSH
LOCK
BUTTON
LOCK BUTTON
POWER BRUSH
NECK
WAND TO POWER BRUSH CONNECTION
HEIGHT
ADJUSTMENT
PEDAL
PRONGS
LOCK
BUTTON
LOCK
BUTTON
HOSE
HANDLE
PRONGS
WAND
WAND
- 3 -
RECEPTACLE
RECEPTACLE
WAND
GRIP
WAND
RELEASE
PEDAL
POWER BRUSH
NECK RELEASE
PEDAL
HOSE HANDLE
RELEASE BUTTON
QUICK
CONNECTOR
AO0019
AO0020
AO0021
WAND & HOSE COMPATIBILITY
See section 5 on page 7
for wand and hose
compatibility table. ?

2. HOW TO USE POWER BRUSH/WAND
2.1 WAND RELEASE
The power brush is not recommended for use
on bare floors.Wand release pedal (A) on power
brush allows you to quickly disconnect wand
and switch to combination floor/rug tool for use
on bare floors.
2.2 POWER BRUSH NECK RELEASE
Push down power brush neck release pedal (B)
to unlock brush neck. Return the neck to the
upright position for storage.
2.3 POWER BRUSH HEIGHT ADJUSTMENT
The icons (D) refer to the carpet pile height. Select height
by depressing height adjustment pedal (C) to desired position:
(Extra-Low), (Low), (Medium) or (High).
HEIGHT ADJUSTMENT LED INDICATORS
The LEDs show the carpet pile covered by the selected
height, e.g.: when (High) is selected, all LEDs will be
lit, since this height covers all pile heights. So if
(Extra-Low) is selected, only the lowest LED will be lit.
2.4 WAND LENGTH ADJUSTMENT
Extend (E) or shorten (F) the wand to comfortable
work position by holding the wand grip (G) in
one hand and sliding the upper section (the one
with the prongs) with the other hand.
2.5 EDGE CLEANER
Brush extends full width for effective edge cleaning along both sides of nozzle. To
operate, simply run cleaner along edge board. Rubber bumper protects furniture
and baseboards.
FLOOR HEIGHT
- 4 -
B
C
D
F
E
A
G
CAUTION
Always pick up hard or sharp objects by hand before using your power
brush. Items such as pins, hairpins, tacks, crayons, etc., may damage the
brush roll or may break the belt.
CAUTION
Always unlock brush neck before use.
AO0020
AD0022
AD0023
AD0024

- 5 -
3. CLEANING AND STORAGE
3.1 CLEANING BRUSH ROLL
In order to keep high cleaning efficiency and to prevent damage to your vacuum
cleaner, the brush roll must be cleaned every time the belt is changed.
The brush roll must also be cleaned according to the following schedule:
VACUUM CLEANER USE CLEAN BRUSH ROLL
Heavy (used daily) Every week
Moderate (2-3 times per week) Every month
Light (1 time per week) Every 2 months
Check and remove hair, string and lint build-up frequently in the brush roll and end
cap areas. Remove any dirt or debris in the belt path and in the brush roll areas.
3.2 CLEANING HOUSING
To keep the power brush housing clean, it can be wiped with a damp cloth and a
mild soap solution, then thoroughly dried. Never use any type of chemical as they
can damage the housing.
3.3 STORAGE
1. Ensure that hose and power cord are disconnected from wall inlet before
unplugging power brush.
2. Disconnect hose handle from wand.
3. Always keep hose neatly coiled when not in use.
4. When not in use, the power brush should be stored in a clean, dry place.
WARNING
Disconnect electrical supply before servicing or cleaning the unit. Failure
to do so can result in electrical shock or personal injury from cleaner
suddenly starting.
!
2. HOW TO USE POWER BRUSH/WAND (CONT’D)
2.6 ELECTRONIC CIRCUIT BREAKER
The power brush is equipped with an electronic circuit breaker that protects the
motor and the belt if a too large object is picked up accidentally.
If the power brush stops while vacuuming, turn the
power unit off using handle. Release the power
brush from the wand and turn it over to see if there
is an obstruction. When brush roll jam has been
cleared, press the reset button (H) and connect
the power brush back to the wand. Finally, turn the
power unit/power brush back on. If it fails to restart
or continues to trip without any apparent reason,
the power brush must be serviced by an authorized
service center.
AD0030
H

- 6 -
4. MAINTAINING THE POWER BRUSH
4.1 HOW TO CHANGE BELT
1. Turn power brush over and using a Phillips no. 2
screwdriver, remove the 3 brush roll cover retaining
screws (Fig. 1) and set aside.
2. Remove brush roll cover. (Fig. 2)
3. To free brush roll from base, start by sliding the
belt side end and pull brush roll sideways (1).
Once disengaged from housing, lift brush roll (2)
out of its compartment (Fig. 3).
4. Disengage brush roll from worn belt and extract
the belt from motor shaft by a twisting motion in
the enlarge area (I) specifically made for that
purpose (Fig. 4).
5. Install new belt by reversing steps 4to 1.
NOTE: To ease belt replacement, start by inserting
one end around the motor shaft in the
enlarged area (I). Insert brush roll through
belt until belt is seated in its place. Push
down brush roll back in place.
4.2 HOW TO CHANGE BRUSH ROLL
Replace brush roll when brush roll brissles
are worn to the base support bars level.
1. Turn power brush over and using a Phillips
no. 2 screwdriver, remove the 3 brush roll
cover retaining screws (Fig. 1) and set
aside.
2. Remove brush roll cover. (Fig. 2)
3. To free brush roll from base, start by sliding the
belt side end and pull brush roll sideways (1).
Once disengaged from housing, lift brush roll (2)
out of its compartment (Fig. 3).
4. Disengage brush roll from belt. Discard worn
brush roll.
5. Insert new brush roll through belt until belt is seated
in its place. Push down brush roll back in place.
6. Finalise the installation by reversing steps 2to 1.
WARNING
Disconnect electrical supply before servicing or cleaning the unit. Failure
to do so can result in electrical shock or personal injury from cleaner
suddenly starting.
!
AB0011
FIG. 1
FIG. 2
FIG. 3
FIG. 4
BELT BRUSH ROLL
1
2
I
2
RETAINING
SCREWS
AB0010
AB0012
AB0013

5. WAND AND HOSE COMPATIBILITY
WAND PART NO. 08949 VACUUM HOSE PART NOS. 09007, 09008 & BN32DV
6. SERVICE PARTS
KEY NO. PART NO. DESCRIPTION
109234 Belt
209233 Brush roll
309236 Brush roll cover with screws
409235 Wand release pedal
5 18651 Wand
Order Service Parts by “Part No.”, not by “Key No.”
- 7 -
HOSE HANDLE
1
2
AA0002
4
5
3
NOTE: If your dual voltage hose is not compatible with your new BN200 power
brush, please contact Broan-NuTone customer service at 1-888-882-7626
to receive a free electrical cord (part no. CRD400-01) that will enable you
to connect your new power brush to your hose.
IMPORTANT: Do not return the brush to your retail store.
REPLACEMENT PARTS AND REPAIRS
In order to ensure your ventilation unit remains in good working condition, you must use Broan-Nutone genuine
replacement parts only. Broan-Nutone genuine replacement parts are specially designed for each unit and are
manufactured to comply with all the applicable certification standards and maintain a high standard of safety.
Any third party replacement part used may cause serious damage and drastically reduce the performance level
of your unit, which will result in premature failing. Broan-Nutone recommends to contact a certified service depot
for all replacement parts and repairs.

BROAN-NUTONE CANADA INC.
ONE YEAR LIMITED WARRANTY
Broan-NuTone Canada warrants to the original consumer purchaser of its products that such
products will be free from defects in materials and workmanship for a period of one (1) year from
the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESSED OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE.
During this one-year period, Broan-NuTone Canada will, at its option, repair or replace, without
charge, any product or part which is found to be defective under normal use and service. THIS
WARRANTY DOES NOT APPLY TO CONSUMABLES SUCH AS BELT OR BRUSH ROLL. This
warranty does not cover (a) normal maintenance and service or (b) any products or parts which
have been subject to misuse, negligence, accident, improper maintenance or repair (other than by
Broan-NuTone Canada or an authorized representative), faulty installation or installation contrary to
recommended installation instructions.
The duration of any implied warranty is limited to the one-year period as specified for the express warranty.
BROAN-NUTONE CANADA’S OBLIGATION TO REPAIR OR REPLACE, AT BROAN-NUTONE
CANADA’S OPTION, SHALL BE THE PURCHASER'S SOLE AND EXCLUSIVE REMEDY UNDER
THIS WARRANTY. BROAN-NUTONE CANADA SHALL NOT BE LIABLE FOR INCIDENTAL,
CONSEQUENTIAL OR SPECIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH
PRODUCT USE OR PERFORMANCE. This warranty supersedes all prior warranties.
Warranty service is to be completed by an authorized Service Center designated by Broan-NuTone
Canada. Where applicable, in home service will be made available only in areas where a contracted
service provider offers service. If in home service is not available, the product will be repaired or
replaced, at Broan-NuTone Canada’s discretion, by the nearest authorized service provider. The
unit removal and reinstallation works are under the customer responsibility, and Broan-NuTone
Canada cannot be charged for them.
To qualify for warranty service, you must (a) notify Broan-NuTone Canada at the address or
telephone number stated below (b) give the model number and part identification and (c) describe
the nature of any defect in the product or part. At the time of requesting warranty service, you must
present evidence of the original purchase date.
IF YOU NEED ASSISTANCE OR SERVICE:
For the location of your nearest Broan-NuTone Canada Inc. dealer:
Dial Toll Free: 1-888-882-7626
Please be prepared to provide:
Product model number • Date and proof of purchase • The nature of the difficulty
Broan-NuTone Canada Inc.
1140 Tristar Drive, Mississauga, Ontario L5T 1H9
www.broan.ca www.nutone.ca
Product specifications subject to change without notice.
- 8-
7. SERVICE INFORMATION
To avoid unnecessary service calls, check the belt and brush roll often. Replace
the belt if it is stretched or cracked. Clean the brush roll bristles when they are
wrapped with thread and hairs. Build-up could cause the brush to rotate unevenly.
The model number and serial number are indicated on the rating label located
underneath the power brush. Always refer to these numbers when inquiring about
service.
NOTE: The motor is permanently lubricated and sealed. Do not oil the motor at
any time.
8. WARRANTY
Released August 2011
