FACSIMILE EQUIPMENT
PARTS REFERENCE LIST
MODEL: MFC-740 / 730
( For Germany / United Kingdom / France /
Norway / Belgium / Netherlands /
Switzerland / Italy / Sweden / Euro Generic )

©Copyright Brother 1998
All rights reserved
No part of this publication may be reproduced in any form
or by any means without permission in writing from the
publisher.
Specifications are subject to change without prior notice.

NOTES FOR USING THIS PARTS REFERENCE LIST
1. In the case of ordering parts, it needs mentioning the following items:
(1) Code
(2) Q' ty
(3) Description
Note: No orders without Parts Code or Tool No. can be accepted.
[Example] (1) (2) (3)
REF.NO. CODE Q' TY DESCRIPTION REMARKS
2. Parts change will be informed by the technical information.
COUNTRIES
GERMANY ----- GER
UNITED KINGDOM ----- UK
FRANCE ----- FRA
NORWAY ----- NOR
BELGIUM ----- BEL
NETHERLANDS ----- NLD
SWITZERLAND ----- CHE
ITALY ----- ITA
SWEDEN ----- SWE
EURO GENERIC ----- GNR

To replace those marked with an asterisk(*), you need the special adjustment
jig set. If your service center has no special adjustment jig set, you cannot
handle those parts as spare parts.
RefNo CODE Q'TY DESCRIPTION REMARKS
1MAIN FRAME ATTACHMENT
2SCANNER FRAME ATTACHMENT
3 087311016 2 TAPTITE, CUP B M3X10
4UU1016001 1TOP COVER
5UU1022001 1TOP COVER SPRING
*6 087411216 3 TAPTITE, CUP B M4X12
7UU1482001 1BIN, WHITE(1138), (A4)
8UU1197001 1LOWER COVER, WHITE(1138)
9UU1198001 2UPPER INK ABSORBER
10 UU1380001 2LOWER INK ABSORBER
*11 UU1448001 1INK ABSORBERS PACK
12 UU1199001 1LOWER FLUSHING FOAM
13 UU1200001 1UPPER FLUSHING FOAM
*14 UU1449001 1FLUSHING FOAMS PACK
15 UU1311001 1PROTECTION FILM
16 UU1201001 1BIN COVER SENSOR ACTUATOR
17 UU1202001 1RESISTORATION SENSOR ACTUATOR
18 UU1203001 1PAPER WIDTH SENSOR ACTUATOR
19 UU1204001 1PAPER EJECTION SENSOR ACTUATOR
20 UU1205001 1COVER SENSOR ACTUATOR 1
21 UH3245001 1SPRING
22 UU1206001 1COVER SENSOR ACTUATOR 2
23 UU1492001 1BOTTOM PLATE
24 UU1210001 1GROUNDING PLATE
25 000300606 1 SCREW, BIND M3X6
26 UL5600001 4RUBBER FOOT
27 UU1466001 1SHIELD PLATE B
28 087320616 1 TAPTITE, CUP S M3X6
29 087320616 2 TAPTITE, CUP S M3X6
30 UU1306001 1SPONGE B
31 UU1468001 1NCU SHIELD FILM
32 UG5543001 1VIDEO PCB ASSY
FOR GER/UK/NOR/BEL/NLD/CHE/ITA/SWE/GNR
33 UU1213001 1VIDEO FILM
FOR GER/UK/NOR/BEL/NLD/CHE/ITA/SWE/GNR
34 UG3732001 1BATTERY ASSY FOR MFC740
35 087320616 5 TAPTITE, CUP S M3X6
FOR GER/UK/NOR/BEL/NLD/CHE/ITA/SWE/GNR
35 087320616 4 TAPTITE, CUP S M3X6 FOR FRA
36 UF6559001 1SCREW, PAN (WASHER) M4X8DB
37 002300615 2 SCREW, PAN M3X6
38 087320616 3 TAPTITE, CUP S M3X6
39 087311016 5 TAPTITE, CUP B M3X10
40 UU1218001 1INNER COVER L, WHITE(1138)
41 LE0042001 1INNER COVER R, WHITE(1138)
42 UU1220001 1COVER L, WHITE(1138)
43 0A5400806 1SCREW, PAN (S/P WASHER) M4X8
44 UU1221001 1HANDSET HOLDER ASSY
45 087311016 2 TAPTITE, CUP B M3X10
MFC730, MFC740/Ver. K

To replace those marked with an asterisk(*), you need the special adjustment
jig set. If your service center has no special adjustment jig set, you cannot
handle those parts as spare parts.
RefNo CODE Q'TY DESCRIPTION REMARKS
46 UU1224001 1COVER R, WHITE(1138)
47 0A5400806 1SCREW, PAN (S/P WASHER) M4X8
48 UG5559001 1SPEAKER
49 UU1225001 2TAPTITE, CUP B M4X10
50 UU1226001 1SPACER R, WHITE(1138)
51 UU1227001 1SPACER L, WHITE(1138)
52 UU1411001 1FRONT COVER ASSY
53 087411216 2 TAPTITE, CUP B M4X12
54 UU1229001 1ROM COVER, WHITE(1138)
55 UU1230001 1REAR COVER, WHITE(1138)
56 087411216 2 TAPTITE, CUP B M4X12
57 UU1195001 1PURGE GEAR 3
58 UU1291001 1SPRING, COMPRESSION
59 UD6190001 1SPACER
60 087311016 1 TAPTITE, CUP B M3X10
61 UU1236001 1PAPER THK INSTRUCTION LABEL
62 UU1460001 1TRAY CAUTION LABEL
63 UU1320001 1COLOR MARK FOR MFC740
63 UU1522001 1COLOR MARK FOR MFC730
64 ----- NOT USED
65 ----- NOT USED
66 UU1351001 1VIDEO MYLAR LABEL
FOR GER/UK/NOR/BEL/NLD/CHE/ITA/SWE/GNR
67 UU1261001 1CONTROL PANEL ASSY, WHITE(1138) FOR MFC740
67 UU1480001 1CONTROL PANEL ASSY, WHITE(1138) FOR MFC730
67-1 UU7003001 1CONTROL PANEL COVER, WHITE(1138)
67-2 UF4393003 1KEY, TEL, WHITE(1138)
67-3 UU7099001 1KEY, VOLUME, WHITE(1138)
67-4 UF4576003 1KEY, SHIFT, WHITE(1138)
67-5 UF8176003 3KEY, ONE TOUCH, WHITE(1138)
67-6 UF8173002 1KEY, STOP, ORANGE(3172)
67-7 UF8172004 1KEY, START, BLUE(6238)
67-8 UU7100001 1KEY, COPY AREA, WHITE(1138)
67-9 UF9118001 3KEY, FUNCTION 1, WHITE(1138)
67-10 UF5581005 1KEY, FUNCTION 2, WHITE(1138)
67-11 UG5547001 1PANEL PCB ASSY FOR MFC740
67-11 UG4519001 1PANEL PCB ASSY FOR MFC730
67-12 UG4552000 1LCD
67-13 UG4553001 1FPC KEY
67-14 UG5575001 1MICROPHONE FOR MFC740
67-15 UU7004001 1PANEL REAR COVER
67-16 UU7101001 1DOCUMENT PRESSURE BAR ASSY
67-17 UU7147001 1DOCUMENT PRESSURE BAR SPRING
67-18 UU7521001 1SEPARATION RUBBER
67-19 UU7105001 1SPRING PLATE B
67-20 UU7106001 1SPRING PLATE A
67-21 UF6116001 1TAPTITE, PAN B M3X6
67-22 UU7107001 1DOCUMENT FRONT SENSOR ACTUATOR
67-23 UU7108001 1DOCUMENT REAR SENSOR ACTUATOR
MFC730, MFC740/Ver. K

To replace those marked with an asterisk(*), you need the special adjustment
jig set. If your service center has no special adjustment jig set, you cannot
handle those parts as spare parts.
RefNo CODE Q'TY DESCRIPTION REMARKS
67-24 UU7505001 1ANTISTATIC BRUSH 1
67-25 UF7187001 1GEAR SHIELD FILM
67-26 UU7285001 1ANTIVIBRATION RUBBER
67-29 UU7506001 1ANTISTATIC BRUSH 2
67-27 UU1477001 1CIS SHIELD FILM 1
67-28 087310815 2 TAPTITE, CUP B M3X8
68 UU7110001 1KEY, COPY, WHITE(1138)
69 UU7110003 1KEY, COPY, GREEN(5180)
70 UU7111001 3KEY, MC, WHITE(1138) FOR MFC740
71 UU1329001 1PANEL SHEET, MFC740 FOR GER
71 UU1526001 1PANEL SHEET, MFC730 FOR GER
71 UU1330001 1PANEL SHEET, MFC740 FOR UK/CHE/GNR
71 UU1526001 1PANEL SHEET, MFC730 FOR UK
71 UU1331001 1PANEL SHEET FOR FRA
71 UU1332001 1PANEL SHEET FOR NOR
71 UU1352001 1PANEL SHEET FOR BEL
71 UU1333001 1PANEL SHEET FOR NLD
71 UU1334001 1PANEL SHEET FOR ITA
71 UU1335001 1PANEL SHEET FOR SWE
72 UU7139001 1ADDRESS LABEL, WHITE(1138)
73 UG5562001 1PANEL-MAIN HARNESS FOR MFC740
73 UG5561001 1PANEL-MAIN HARNESS FOR MFC730
74 LE0429001 1MAIN PCB SUPPLY ASSY FOR MFC740
74 LE0431001 1MAIN PCB SUPPLY ASSY FOR MFC730
75 UG5578003 1NCU PCB ASSY FOR GER
75 UG5579004 1NCU PCB ASSY FOR UK/GNR
75 UG5583005 1NCU PCB ASSY FOR FRA
75 UG5580007 1NCU PCB ASSY FOR NOR
75 UG5581008 1NCU PCB ASSY FOR BEL
75 UG5582009 1NCU PCB ASSY FOR NLD
75 UG5578010 1NCU PCB ASSY FOR CHE
75 UG5581016 1NCU PCB ASSY FOR ITA
75 UG5579026 1NCU PCB ASSY FOR SWE
(75-1) UG6776000 1ARRESTER:RA102 (LOCATION:A1)
(75-2) UG6775000 1ARRESTER:RA311 (LOCATION:A2)
(75-3) UG6798000 2PHOTO COUPLER:TLP621 (LOCATION:PH2,PH4)
(75-4) UG3272000 1IC:THS-65 (LOCATION:T3)
(75-5) ----- NOT USED
(75-6) ----- NOT USED
76 UG5585000 1EXTENTION CONNECTOR, 18P
77 ----- NOT USED
77-1 UG5573001 1POWER SUPPLY PCB ASSY
77-2 UG3156001 1AC CORD ASSY
FOR GER/FRA/NOR/BEL/NLD/ITA/SWE/GNR
77-2 UG3152001 1AC CORD ASSY FOR UK
77-2 UG3154001 1AC CORD ASSY FOR CHE
78 LE5498003 1HANDSET, WHITE(1138)
FOR GER/FRA/NOR/BEL/NLD/CHE/ITA/SWE/GNR
78 LE5497003 1HANDSET, WHITE(1138) FOR UK
MFC730, MFC740/Ver. K

To replace those marked with an asterisk(*), you need the special adjustment
jig set. If your service center has no special adjustment jig set, you cannot
handle those parts as spare parts.
RefNo CODE Q'TY DESCRIPTION REMARKS
79 UL8230001 1TELEPHONE LINE CORD FOR GER
79 UL8211001 1TELEPHONE LINE CORD FOR UK
79 UL8290001 1TELEPHONE LINE CORD FOR FRA
79 UL8384001 1TELEPHONE LINE CORD FOR NOR
79 UL8219001 1TELEPHONE LINE CORD FOR BEL
79 UL8231001 1TELEPHONE LINE CORD FOR NLD
79 UG4169001 1TELEPHONE LINE CORD FOR CHE
79 UL8289001 1TELEPHONE LINE CORD FOR ITA
79 UL8218001 1TELEPHONE LINE CORD FOR SWE
79 UG3409001 1TELEPHONE LINE CORD FOR GNR
80 UG4558001 1I/F CABLE FOR GER/UK
81 UF7204009 1HANDSET CURLED CORD ASSY, WHITE(1255)
82 UU1248001 1DOCUMENT EJECTION TRAY ASSY
83 UU1289001 1PAPER TRAY
84 UU1481001 1DUST COVER ASSY
85 UU1309001 2TRAY EXTENSION
(86) UU0456001 1PROTECTION PAPER
(87) UD6246001 1STARTER COATED PAPER ASSY (A4)
(88) UU1336004 1CD-ROM ASSY FOR MFC740
(89) UU1365001 1OWNER'S MANUAL ASSY, MFC740 FOR GER
(INCLUDING OWNER'S MANUAL(REF.NO.(89-1)),
MULTI FUNCTION LINK MANUAL(REF.NO.(89-4)),
WARRANTY CARD, LICENSE GUIDE,
TRAY EXTENSION(REF.NO.85))
(89) UU1524001 1OWNER'S MANUAL ASSY, MFC730 FOR GER
(INCLUDING OWNER'S MANUAL(REF.NO.(89-1)),
WARRANTY CARD, TRAY EXTENSION(REF.NO.85))
(89) UU1366001 1OWNER'S MANUAL ASSY FOR UK
(INCLUDING OWNER'S MANUAL(REF.NO.(89-1)),
MULTI FUNCTION LINK MANUAL(REF.NO.(89-4)),
WARRANTY CARDS, LICENSE GUIDE,
TRAY EXTENSION(REF.NO.85))
(89) LE0424001 1OWNER'S MANUAL ASSY FOR UK
(INCLUDING OWNER'S MANUAL(REF.NO.(89-1)),
WARRANTY CARDS, TRAY EXTENSION(REF.NO.85))
(89) UU1367001 1OWNER'S MANUAL ASSY FOR FRA
(INCLUDING OWNER'S MANUAL(REF.NO.(89-1)),
MULTI FUNCTION LINK MANUAL(REF.NO.(89-4)),
WARRANTY CARDS, LICENSE GUIDE,
TRAY EXTENSION(REF.NO.85))
(89) UU1368001 1OWNER'S MANUAL ASSY FOR NOR
(INCLUDING OWNER'S MANUAL(REF.NO.(89-1)),
MULTI FUNCTION LINK MANUAL(REF.NO.(89-4)),
WARRANTY CARDS, LICENSE GUIDE,
TRAY EXTENSION(REF.NO.85))
(89) UU1369001 1OWNER'S MANUAL ASSY FOR BEL
(INCLUDING OWNER'S MANUALS(REF.NO.(89-1)),
MULTI FUNCTION LINK MANUAL(REF.NO.(89-4)),
WARRANTY CARD, LICENSE GUIDE,
MFC730, MFC740/Ver. K

To replace those marked with an asterisk(*), you need the special adjustment
jig set. If your service center has no special adjustment jig set, you cannot
handle those parts as spare parts.
RefNo CODE Q'TY DESCRIPTION REMARKS
TRAY EXTENSION(REF.NO.85))
(89) UU1370001 1OWNER'S MANUAL ASSY FOR NLD
(INCLUDING OWNER'S MANUAL(REF.NO.(89-1)),
MULTI FUNCTION LINK MANUAL(REF.NO.(89-4)),
WARRANTY CARD, LICENSE GUIDE,
TRAY EXTENSION(REF.NO.85))
(89) UU1371001 1OWNER'S MANUAL ASSY FOR CHE
(INCLUDING OWNER'S MANUALS(REF.NO.(89-1)),
MULTI FUNCTION LINK MANUAL(REF.NO.(89-4)),
WARRANTY CARD, LICENSE GUIDE,
TRAY EXTENSION(REF.NO.85))
(89) UU1372001 1OWNER'S MANUAL ASSY FOR ITA
(INCLUDING OWNER'S MANUAL(REF.NO.(89-1)),
MULTI FUNCTION LINK MANUAL(REF.NO.(89-4)),
WARRANTY CARD, LICENSE GUIDE,
TRAY EXTENSION(REF.NO.85))
(89) UU1373001 1OWNER'S MANUAL ASSY FOR SWE
(INCLUDING OWNER'S MANUAL(REF.NO.(89-1)),
MULTI FUNCTION LINK MANUAL(REF.NO.(89-4)),
WARRANTY CARDS, LICENSE GUIDE,
TRAY EXTENSION(REF.NO.85))
(89) UU1374001 1OWNER'S MANUAL ASSY FOR GNR
(INCLUDING OWNER'S MANUAL(REF.NO.(89-1)),
MULTI FUNCTION LINK MANUAL(REF.NO.(89-4)),
LICENSE GUIDE, TRAY EXTENSION(REF.NO.85))
(89-1) UU1362003 1OWNER'S MANUAL, MFC740 FOR GER
(89-1) UU1525003 1OWNER'S MANUAL, MFC730 FOR GER
(89-1) UU1362004 1OWNER'S MANUAL FOR UK/GNR
(89-1) UU1362005 1OWNER'S MANUAL FOR FRA
(89-1) UU1362007 1OWNER'S MANUAL FOR NOR
(89-1) UU1362008 1OWNER'S MANUAL FOR BEL (DUTCH)
(89-1) UU1363008 1OWNER'S MANUAL FOR BEL/CHE (FRENCH)
(89-1) UU1362009 1OWNER'S MANUAL FOR NLD
(89-1) UU1362010 1OWNER'S MANUAL FOR CHE (GERMAN)
(89-1) UU1362016 1OWNER'S MANUAL FOR ITA
(89-1) UU1362026 1OWNER'S MANUAL FOR SWE
(89-2) ----- NOT USED
(89-3) ----- NOT USED
(89-4) UU7361003 1MULTI FUNCTION LINK MANUAL, MFC740
FOR GER/UK/FRA/BEL/NLD/CHE/GNR
(89-4) UU7361007 1MULTI FUNCTION LINK MANUAL
FOR NOR/ITA/SWE
(90) UE1974003 1CARTON, BROTHER, MFC740 FOR GER
(90) UE3109003 1CARTON, BROTHER, MFC730 FOR GER
(90) UE1974004 1CARTON, BROTHER, MFC740 FOR UK/CHE/GNR
(90) LE0426004 1CARTON, BROTHER, MFC730 FOR UK
(90) UE1974005 1CARTON, BROTHER FOR FRA
(90) UE1974007 1CARTON, BROTHER FOR NOR/BEL/NLD/ITA/SWE
(91) UE1956001 1STYROFORM
MFC730, MFC740/Ver. K

To replace those marked with an asterisk(*), you need the special adjustment
jig set. If your service center has no special adjustment jig set, you cannot
handle those parts as spare parts.
RefNo CODE Q'TY DESCRIPTION REMARKS
(92) UE3102001 1SHEET, 230X300 FOR GER/UK/FRA/CHE/GNR
<Eliminated>
(93) UE3031001 1BAG, 800X900H
(93) UE3031002 1BAG, 800X900H, ONLY FOR FRA
(94) UE1959001 1PAD FOR MANUAL
(95) UE1960001 1PAD FOR ACCESSORY
(96) UE3030001 2SPACER
(97) UU1350003 1POP FOR GER
<Eliminated>
(97) UU1350004 1POP FOR UK/CHE/GNR
<Eliminated>
(97) UU1350005 1POP FOR FRA
<Eliminated>
(98) UE3042001 1SHEET, 170X550
(99) UF9258001 1CONTRAST CHECK SHEET CTC-001
(100) ZA0310001 1HEAD CLEANER STICK ASSY
(101) ZA0304001 1INITIAL LIQUID ASSY
(INCLUDING INITIAL LIQUID (120CC) AND SYRINGE (25CC))
(102) ZA0509001 1INITIAL LIQUID CARTRIDGE ASSY
(INCLUDING 4 EMPTY CARTRIDGES)
(103) LE0026001 1FOAM EMPTY CARTRIDGE FOR INK SENSOR ADJUSTMENT
(104) LE0025001 1EMPTY CARTRIDGE FOR INK SENSOR ADJUSTMENT
(105) ZA0492001 1BLACK CARTRIDGES (INCLUDING 100PCS)
<Eliminated>
(106) ZA0495001 1CYAN CARTRIDGES (INCLUDING 100PCS)
<Eliminated>
(107) ZA0498001 1MAGENTA CARTRIDGES (INCLUDING 100PCS)
<Eliminated>
(108) ZA0501001 1YELLOW CARTRIDGES (INCLUDING 100PCS)
<Eliminated>
(109) LK0045001 1PRINT HEADS HD002 (INCLUDING 10PCS)
110 UU1486001 1UNDERFILM L
111 UU1485001 1UNDERFILM R
112 UG5596001 1GROUNDING WIRE, MFC740
113 0A5300605 1SCREW, PAN (S/P WASHER) M3X6
114 UG5603000 1FERRITE CORE
115 UU1506001 1VC COVER FOR FRA
116 UF5745000 1MJ COVER, EXT
FOR UK/GER/FRA/BEL/NLD/ITA/SWE/GNR
(117) LE0019001 1FERRITE CORE BAG ASSY, MFC740
FOR FRA/NOR/BEL/NLD/CHE/ITA/SWE/GNR
(118) UU1518001 1WASHER, 4
(119) UU1513001 1NCU INSULATION FILM
(120) UU1527001 1FLOPPY DISK ASSY, MFC730 FOR GER
(120) LE0419001 1FLOPPY DISK ASSY, MFC730 FOR UK
(121) UU1381001 1SPONGE A
(122) UU1020001 1BLIND FILM
MFC730, MFC740/Ver. K

To replace those marked with an asterisk(*), you need the special adjustment
jig set. If your service center has no special adjustment jig set, you cannot
handle those parts as spare parts. 1.MAIN FRAME ATTACHMENT
REF.NO. CODE Q'TY DESCRIPTION REMARKS
*1 UU1493001 1MAIN FRAME ASSY
1-1 LE3940001 1 CARRIAGE MOTOR
1-2 0A5300605 2SCREW, PAN (S/P WASHER) M3X6
*1-3 UU1047001 1PAPER EJECTION ROLLER
1-4 UU1049001 1PAPER EJECTION ROLLER GEAR
*1-5 UU1290001 1BUSHING
1-6 0A5260805 1SCREW, PAN (S/P WASHER) M2.6X8
1-7 UU1050001 1PAPER EJECTION IDLE GEAR
*1-8 LE0159001 1CARRIAGE ASSY
(1-8-1) UU1454001 1CARRIAGE TIMING BELT
1-9 UU1313001 1INK COLOR LABEL
*1-10 UU1077001 1CARRIAGE RAIL
*1-11 UU1078001 1ECCENTRIC BUSHING L
*1-12 UU1079001 1ECCENTRIC BUSHING R
1-13 UU1080001 1RAIL PRESSURE SPRING
1-14 0A5300805 2SCREW, PAN (S/P WASHER) M3X8
1-15 UU1081001 1IDLE PULLEY HOLDER
1-16 UD6023000 1IDLE PULLEY
1-17 UD6025001 1IDLE PULLEY SHAFT
1-18 UU1082001 1TENSION SPRING
1-19 UD6014001 1ENCODER STRIP
1-20 UD6012001 1ENCODER STRIP SPRING
1-21 UU1088001 1FFC HOLDER
1-22 UU1286001 1IDLE PULLEY STOPPER
1-23 0A5300805 1SCREW, PAN (S/P WASHER) M3X8
1-24 UU1107001 1ANTISTATIC BRUSH
1-25 UU1476001 2BUSHING LOCK
1-26 UG5569000 1UPPER FLAT CORE
1-27 UU1459001 1CORE SUPPORT
1-28 UU1238001 1CAUTION LABEL
*2 UU1089001 1PAPER FEED ROLLER ASSY
3 048080345 2 RETAINING RING, E8
4UU1094001 1PAPER FEED ROLLER GEAR L
5UU1428001 1IDLE GEAR 720
6UU1096001 1GEAR FRAME ASSY
7UU1105001 1PAPER FEED IDLE GEAR
8UU1275001 1PF ARM ASSY
9 087311016 2 TAPTITE, CUP B M3X10
10 UU1092001 1SPACER
11 UU1108001 1STAR WHEEL HOLDER ASSY
12 UU1111001 3PAPER PRESSURE HOLDER ASSY
13 UU1115001 5PRESSURE HOLDER SPRING
14 UU1116001 1PLATEN
15 UU1117001 1PLATEN FRAME
16 087320616 1 TAPTITE, CUP S M3X6
17 UU1119001 1PURGE LEVER COVER
18 UU1120001 1GEAR COVER
19 087320616 1 TAPTITE, CUP S M3X6
20 UU1381001 1SPONGE A
MFC730, MFC740/Ver.C

To replace those marked with an asterisk(*), you need the special adjustment
jig set. If your service center has no special adjustment jig set, you cannot
handle those parts as spare parts. 1.MAIN FRAME ATTACHMENT
REF.NO. CODE Q'TY DESCRIPTION REMARKS
21 UU1315001 1FLUSHING SUPPORT PLATE
22 UU1418001 1PAPER PRESSURE HOLDER L
23 UU1419001 1PAPER PRESSURE HOLDER R
24 UU1452001 1PAPER FEED MOTOR ASSY
25 UU1465001 1MOTOR SHIELD
26 0A5300805 2SCREW, PAN (S/P WASHER) M3X8
27 UU1446001 1PF TIMING BELT
28 UU1450001 1TENSION PLATE ASSY
29 UU1444001 1TENSION SPRING
30 048030345 1 RETAINING RING, E3
31 048040345 1 RETAINING RING, E4
32 0A5300805 1SCREW, PAN (S/P WASHER) M3X8
*33 UU1502001 1PURGE UNIT ASSY
*34 0A5300605 2SCREW, PAN (S/P WASHER) M3X6
35 UU1152001 1GROUNDING PLATE
36 087320616 1 TAPTITE, CUP S M3X6
37 UG5577000 1LOWER FLAT CORE
38 087411216 2 TAPTITE, CUP B M4X12
39 087320616 2 TAPTITE, CUP S M3X6
40 087411216 2 TAPTITE, CUP B M4X12
41 087320616 1 TAPTITE, CUP S M3X6
42 UU1375001 1COATING CLIP
43 087320616 1 TAPTITE, CUP S M3X6
44 UU1196001 1GROUNDING PLATE R
45 087411216 1 TAPTITE, CUP B M4X12
46 087320616 2 TAPTITE, CUP S M3X6
47 UU1046001 1COVER LOCK LEAF SPRING
48 0A5300605 1SCREW, PAN (S/P WASHER) M3X6
49 UU1217001 1FRAME COVER, WHITE(1138)
50 UU1235001 1INK REPLACE INSTRUCTION LABEL
51 ZA0424001 1HEAD FILTER SEALS (INCLUDING 10PCS)
52 ZA0423001 1HEAD NOZZLE SEALS (INCLUDING 10PCS)
MFC730, MFC740/Ver.C

To replace those marked with an asterisk(*), you need the special adjustment
jig set. If your service center has no special adjustment jig set, you cannot
handle those parts as spare parts. 2.SCANNER FRAME ATTACHMENT
REF.NO. CODE Q'TY DESCRIPTION
1UU7002001 1SCANNER FRAME
2UU7012001 1CIS SIDE SPRING
3UU7013001 2CONTROL PANEL LOCK LEAF SPRING
4 087310815 2 TAPTITE, CUP B M3X8
5UF4369000 1PINCH ROLLER SHAFT
6UF9009001 2PRESSURE ROLLER
7UU7032001 2PRESSURE ROLLER LEAF SPRING
8UF4369000 1PINCH ROLLER SHAFT
9UL6244002 2PINCH ROLLER
10 UU7033001 1PINCH ROLLER LEAF SPRING
11 087310815 1 TAPTITE, CUP B M3X8
12 UU7364001 1ADF FILM
13 UU7030001 1SEPARATIONROLLER GEAR
14 UU1013001 1GEAR 19/72
15 UU7026001 1ARM ASSY
16 UU7024001 1SCANNER MOTOR
17 0A4300605 1SCREW, PAN (S/P WASHER) M3X6
18 UG5551001 1SCANNER MOTOR HARNESS
19 UU1021001 1SCANNER GROUNDING LEAF SPRING
20 087320616 1 TAPTITE, CUP S M3X6
21 UU7031001 1SPARATION ROLLER
22 087310815 2 TAPTITE, CUP B M3X8
23 UG5552001 1CIS UNIT, COLOR
24 UU1478001 1CIS SHIELED FILM 2
25 UU7035001 2CIS LEAF SPRING
26 UU7036001 1CIS FILM
27 UG5554001 1CIS HARNESS
28 UU7037001 1DOCUMENT FEED ROLLER
29 UU7039001 2DOCUMENT FEED ROLLER GEAR
30 UU7284001 2BUSHING
31 UU1479001 1DOCUMENT EJECTION ROLLER
32 UF7187001 1GEAR SHIELD FILM
33 UU1507001 1HARNESS STOPPER
MFC730, MFC740/Ver.A

PL5XA235 Ver.H
