ADVANCED
USER’S GUIDE
MFC-7360N
MFC-7460DN
MFC-7860DW
Not all models are available in all countries.
Version 0
UK/IRE/SAF

i
User's Guides and where do I find it?
Which manual? What's in it? Where is it?
Safety and Legal Read this Guide first. Please read the
Safety Instructions before you set up your
machine. See this Guide for trademarks
and legal limitations.
Printed / In the Box
Quick Setup Guide Follow the instructions for setting up your
machine and installing the drivers and
software for the operating system and
connection type you are using.
Basic User's Guide Learn the basic Fax, Copy and Scan
operations and how to replace
consumables. See troubleshooting tips.
Printed / In the Box
For
HUN/BUL/ROM/POL/SVK/CZE:
PDF file /
Documentation CD-ROM /
In the box
Advanced User's Guide Learn more advanced operations: Fax,
Copy, security features, printing reports
and performing routine maintenance.
PDF file /
Documentation CD-ROM /
In the Box
Software User’s Guide Follow these instructions for Printing,
Scanning, Network Scanning, Remote
Setup, PC-Fax and using the Brother
ControlCenter utility.
Network Glossary This Guide provides basic information
about advanced network features of
Brother machines along with explanations
about general networking and common
terms.
Network User’s Guide This Guide provides useful information of
wired and wireless network settings and
security settings using the Brother
machine. You can also find supported
protocol information for your machine and
detailed troubleshooting tips.

ii
Table of Contents
1 General Setup 1
Memory Storage .................................................................................................... 1
Automatic daylight savings time ............................................................................ 1
Ecology features .................................................................................................... 2
Toner Save ...................................................................................................... 2
Sleep Mode .....................................................................................................2
Deep Sleep mode............................................................................................ 2
Toner Settings .......................................................................................................3
Toner Setting (Continue Mode) ....................................................................... 3
Receiving faxes in Continue Mode .................................................................. 3
Toner End in Continue Mode........................................................................... 3
LCD Contrast ......................................................................................................... 4
Mode Timer............................................................................................................ 4
2 Security features 5
Security.................................................................................................................. 5
TX Lock (MFC-7360N and MFC-7460DN) ...................................................... 5
Setting up the password .................................................................................. 5
Secure Function Lock 2.0 (MFC-7860DW) ..................................................... 6
Setting Lock..................................................................................................... 9
Restricting dialling ......................................................................................... 10
3 Sending a fax 12
Additional sending options...................................................................................12
Sending faxes using multiple settings ...........................................................12
Contrast .........................................................................................................12
Changing Fax Resolution ..............................................................................13
Additional sending operations..............................................................................13
Sending a fax manually ................................................................................. 13
Dual access ................................................................................................... 13
Broadcasting.................................................................................................. 14
Real Time Transmission................................................................................ 15
Overseas Mode .............................................................................................15
Delayed Fax .................................................................................................. 15
Delayed batch transmission ..........................................................................16
Checking and cancelling waiting jobs............................................................ 16
Electronic cover page ....................................................................................16
Polling overview...................................................................................................18
Polled transmit............................................................................................... 18

iii
4 Receiving a fax 20
Remote Fax Options............................................................................................20
Fax Forwarding..............................................................................................20
Fax Storage ...................................................................................................20
PC-Fax Receive ............................................................................................20
Changing Remote Fax Options .....................................................................22
Remote retrieval ............................................................................................23
Remote fax commands..................................................................................25
Additional receiving operations............................................................................26
Printing a reduced incoming fax ....................................................................26
Duplex (2-sided) printing for Fax mode
(MFC-7460DN and MFC-7860DW) ...........................................................26
Setting the Fax Receive Stamp .....................................................................26
Receiving faxes into memory (MFC-7360N and MFC-7460DN) ...................27
Setting the Print Density ................................................................................27
Printing a fax from the memory .....................................................................27
Out of Paper Reception .................................................................................28
Polling overview...................................................................................................28
Polling receive ...............................................................................................28
Stop polling....................................................................................................29
5 Dialling and storing numbers 30
Telephone line services .......................................................................................30
Caller ID.........................................................................................................30
Setting the telephone line type ......................................................................31
BT Call Sign (U.K. only).................................................................................32
Additional dialling operations ...............................................................................32
Combining quick dial numbers ......................................................................32
Additional ways to store numbers........................................................................33
Setting up Groups for Broadcasting ..............................................................33
Options for Setting Up Groups ......................................................................34
Changing Group numbers .............................................................................36
Deleting Group numbers ...............................................................................38
6 Printing reports 39
Fax reports...........................................................................................................39
Transmission verification report.....................................................................39
Fax Journal....................................................................................................39
Reports ................................................................................................................40
How to print a report ......................................................................................40

iv
7 Making copies 41
Copy settings ....................................................................................................... 41
Stop copying.................................................................................................. 41
Enlarging or reducing the image copied ........................................................41
Using the Options key ...................................................................................43
Improving copy quality................................................................................... 44
Sorting copies using the ADF ........................................................................44
Adjusting Contrast and Brightness ................................................................ 44
Making N in 1 copies (page layout) ...............................................................45
2 in 1 ID Copy................................................................................................ 47
Duplex Copying (1-sided to 2-sided) (MFC-7460DN and MFC-7860DW)........... 48
Duplex Copy (long edge flip) ......................................................................... 48
Advanced Duplex Copy (short edge flip) .......................................................48
A Routine maintenance 49
Cleaning the machine ..........................................................................................49
Checking the machine ......................................................................................... 49
Checking the Page Counters......................................................................... 49
Checking the remaining life of parts ..............................................................49
Packing and shipping the machine ......................................................................50
B Glossary 52
C Index 56

v

1
1
1
Memory Storage 1
Your menu settings are stored permanently,
and in the event of a power failure will not be
lost. Temporary settings (for example,
Contrast, Overseas Mode) will be lost.
(For MFC-7860DW)
During a power failure the machine will retain
the date and time and programmed fax timer
jobs (fx. Delayed Fax) for approximately 60
hours. Other fax jobs in the machine’s
memory will not be lost.
(For MFC-7360N and MFC-7460DN)
During a power failure the machine will retain
the date and time for approximately 2 hours.
The fax jobs in the machine’s memory will be
lost.
Automatic daylight
savings time 1
You can set the machine to change
automatically for Daylight Savings Time. It
will set itself forward one hour in the Spring,
and back one hour in the Autumn.
aPress Menu, 0, 2, 2.
bPress aor bto choose On or Off.
Press OK.
cPress Stop/Exit.
General Setup 1

Chapter 1
2
Ecology features 1
Toner Save 1
You can save toner using this feature. When
you set Toner Save to On, prints appear
lighter. The default setting is Off.
aPress Menu, 1, 4, 1.
bPress aor bto choose On or Off.
Press OK.
cPress Stop/Exit.
Note
We do not recommend Toner Save for
printing Photo or Greyscale images.
Sleep Mode 1
The Sleep Mode Setting can reduce power
consumption. When the machine is in Sleep
Mode (Power Save mode) it acts as though it
were turned off. Receiving data or starting an
operation wakes up the machine from Sleep
mode to Ready mode.
You can choose how long the machine must
be idle before it goes into sleep mode. When
the machine receives a fax, computer data or
makes a copy, the timer will be reset. The
default setting is 3 minutes.
While the machine is in sleep mode the LCD
will show Sleep.
aPress Menu, 1, 4, 2.
bEnter the length of time the machine is
idle before entering sleep mode.
Press OK.
cPress Stop/Exit.
Deep Sleep mode 1
If the machine is in Sleep mode and does not
receive any jobs for a certain length of time,
the machine will automatically enter Deep
Sleep mode, and the LCD will show Deep
Sleep. Deep Sleep mode uses less power
than Sleep mode. The machine will wake up
and start warming up when the machine
receives computer data or when you press a
key on the control panel.
(For MFC-7860DW)
If a wireless network is enabled, the machine
does not enter Deep Sleep mode. To disable
the wireless network, see Chapter 3 in the
Network User’s Guide.

General Setup
3
1
Toner Settings 1
Toner Setting (Continue Mode) 1
You can set the machine to continue printing
after the LCD shows Replace Toner.
The machine will continue printing until the
LCD shows Toner Ended.
The default setting is Stop.
aPress Menu, 1, 8.
bPress aor bto choose Continue or
Stop.
Press OK.
cPress Stop/Exit.
Note
• If you continue printing in the Continue
mode, we cannot guarantee the print
quality.
• While using Continue mode the print may
appear faint.
• After replacing the toner cartridge with a
new one, the Continue mode will go back
to the default setting (Stop).
Receiving faxes in Continue
Mode 1
The machine can store received faxes in the
memory if you choose Continue mode when
the LCD shows Replace Toner. When
received faxes are printed in Continue mode
the LCD will ask if the print quality of the fax
is OK. If the quality is not good, choose 2.No.
The machine will keep the faxes stored in the
memory so you can reprint them after you
replace the toner cartridge with a new one. If
the print quality is good, choose 1.Yes. The
LCD will ask if you want to delete the printed
faxes from the memory. If you choose not to
delete them, you will be asked again after you
replace the toner cartridge with a new one.
Note
• The MFC-7360N and MFC-7460DN can
store up to 400 faxes in memory and the
MFC-7860DW can store up to 500 faxes
in memory.
• (MFC-7360N and MFC-7460DN)
If you turn off the power switch faxes in
memory will be lost.
• The machine will keep faxes stored in
Continue Mode even if you change the
Continue setting to Stop.
• If you install a new toner cartridge when
the LCD shows Toner Ended, the
machine will ask if you want to print the
stored faxes. Choose 1. Print to print
stored faxes.
Toner End in Continue Mode 1
When the LCD shows Toner Ended the
machine will stop printing. If the memory is full
and you want to continue receiving faxes, you
must install a new toner cartridge.

Chapter 1
4
LCD Contrast 1
You can change the contrast to make the
LCD look lighter or darker.
aPress Menu, 1, 5.
bPress cto make the LCD darker. Or,
press dto make the LCD lighter.
Press OK.
cPress Stop/Exit.
Mode Timer 1
The machine has three mode keys on the
control panel: FAX, SCAN, and COPY.
You can set how much time the machine
takes after the last Copy or Scan operation to
return to Fax mode. If you choose Off, the
machine will stay in the mode you used last.
This setting also sets the time the machine
will change from individual user to the Public
mode when using Secure Function Lock.
(See Switching Users on page 8.)
aPress Menu, 1, 1.
bPress aor bto choose 0 Sec, 30
Secs, 1 Min, 2 Mins, 5 Mins or Off.
Press OK.
cPress Stop/Exit.
