ADVANCED
USER’S GUIDE
MFC-J425W
MFC-J430W
MFC-J435W
Version 0
USA/CAN

i
User's Guides and where do I find it?
1Visit us at http://solutions.brother.com/.
Which manual? What's in it? Where is it?
Product Safety Guide Read this Guide first. Please read the Safety
Instructions before you set up your machine.
See this Guide for trademarks and legal
limitations.
Printed / In the box
Quick Setup Guide Follow the instructions for setting up your
machine and installing the drivers and software
for the operating system and connection type
you are using.
Printed / In the box
Basic User's Guide Learn the basic Fax, Copy and Scan operations
and how to replace consumables. See
troubleshooting tips.
Printed / In the box
Advanced User's Guide Learn more advanced operations: Fax, Copy,
security features, printing reports and
performing routine maintenance.
PDF file / CD-ROM
Software User's Guide Follow these instructions for Printing, Scanning,
Network Scanning, PC-Fax Send, Web
Services (Scan), and using the Brother
ControlCenter utility.
PDF file / CD-ROM
Network Glossary This Guide provides basic information about
advanced network features of Brother
machines along with explanations about
general networking and common terms.
PDF file / CD-ROM
Network User's Guide This Guide provides useful information about
wireless network settings and security settings
using the Brother machine. You can also find
supported protocol information for your
machine and detailed troubleshooting tips.
PDF file / CD-ROM
Mobile Print/Scan Guide This Guide provides useful information about
printing data from your mobile phone and
transmitting scanned data from the Brother
machine to your mobile phone.
PDF file / Brother
Solutions Center 1

ii
Table of Contents
1 General setup 1
IMPORTANT NOTE...............................................................................................1
Memory storage.....................................................................................................1
Volume Settings.....................................................................................................1
Ring Volume .................................................................................................... 1
Beeper Volume................................................................................................2
Speaker Volume ..............................................................................................2
Automatic Daylight Saving Time............................................................................3
Sleep Mode ........................................................................................................... 3
LCD screen............................................................................................................ 4
LCD Contrast...................................................................................................4
Setting the backlight brightness....................................................................... 4
Setting the Dim Timer for the backlight ...........................................................4
Mode Timer............................................................................................................5
2 Security features 6
TX Lock .................................................................................................................6
Setting and changing the TX Lock password ..................................................6
Turning TX Lock on/off ....................................................................................7
3 Sending a fax 8
Additional sending options.....................................................................................8
Sending faxes using multiple settings .............................................................8
Stop faxing....................................................................................................... 8
Contrast ...........................................................................................................8
Changing fax resolution...................................................................................9
Setting your changes as the new default.........................................................9
Restoring fax settings to the factory settings...................................................9
Additional sending operations.............................................................................. 10
Sending a fax manually .................................................................................10
Sending a fax at the end of a conversation ...................................................10
Dual Access (Black & White only) .................................................................10
Broadcasting (Black & White only) ................................................................ 11
Real Time Transmission................................................................................ 12
Overseas Mode .............................................................................................13
Checking and canceling waiting jobs............................................................. 13
4 Receiving a fax 14
Additional receiving operations............................................................................14
Printing a reduced incoming fax .................................................................... 14
Receiving a fax at the end of a conversation................................................. 14
Receiving faxes into memory when paper tray is empty ...............................14

iii
5 Dialing and storing numbers 15
Voice operations ..................................................................................................15
Tone or Pulse (Canada only).........................................................................15
Fax/Tel mode.................................................................................................15
Caller ID.........................................................................................................15
Special line considerations ............................................................................16
Additional dialing operations................................................................................18
Outgoing Call.................................................................................................18
Caller ID history .............................................................................................18
Dialing access codes and credit card numbers .............................................19
Additional ways to store numbers ........................................................................20
Storing Speed Dial numbers from Outgoing Calls.........................................20
Storing Speed Dial numbers from the Caller ID history.................................20
Setting up Groups for Broadcasting ..............................................................21
6Printingreports 23
Fax reports...........................................................................................................23
Transmission Verification Report...................................................................23
Fax Journal (activity report) ...........................................................................23
Reports ................................................................................................................24
How to print a report ......................................................................................24
7 Making copies 25
Copy settings .......................................................................................................25
Stop copying..................................................................................................25
Changing copy quality ...................................................................................25
Enlarging or reducing the copied image ........................................................26
Making N in 1 copies or a poster (Page Layout) ...........................................27
2 in 1 ID Copy ................................................................................................28
Sorting copies using the ADF ........................................................................29
Adjusting Density...........................................................................................29
Setting your changes as the new default.......................................................29
Restoring all settings to the factory settings ..................................................30
A Routine maintenance 31
Cleaning and checking the machine....................................................................31
Cleaning the outside of the machine .............................................................31
Cleaning the machine’s printer platen ...........................................................32
Cleaning the paper pick-up rollers................................................................. 32
Checking the ink volume ...............................................................................33
Packing and shipping the machine ......................................................................34
B Glossary 37
C Index 40

1
1
1
IMPORTANT NOTE 1
In this manual, the LCD messages of the MFC-J430W are used unless specified.
Most of the illustrations in this User’s Guide show the MFC-J430W.
Memory storage 1
Even if there is a power failure, you will not
lose the settings you have chosen using the
Menu key because they are stored
permanently. Also, you will not lose your
settings in the FAX and COPY mode key
menus if you have chosen
Set New Default. You may have to reset
the date and time.
Volume Settings 1
Ring Volume 1
You can choose a range of ring volume
levels, from High to Off.
While the machine is idle, press dor c
to adjust the volume level. The LCD shows
the current setting, and each key press will
change the volume to the next level. The
machine will keep the new setting until you
change it.
You can also change the volume through the
menu, by following the instructions below:
Setting the Ring Volume from the
menu 1
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose Volume.
Press OK.
dPress aor bto choose Ring.
Press OK.
ePress aor bto choose Low, Med, High
or Off.
Press OK.
fPress Stop/Exit.
General setup 1

Chapter 1
2
Beeper Volume 1
When the beeper is on, the machine will beep
when you press a key, make a mistake, or
after you send or receive a fax.
You can choose a range of beeper volume
levels, from High to Off.
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose Volume.
Press OK.
dPress aor bto choose Beeper.
Press OK.
ePress aor bto choose Low, Med, High
or Off.
Press OK.
fPress Stop/Exit.
Speaker Volume 1
You can choose a range of speaker volume
levels, from High to Off.
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose Volume.
Press OK.
dPress aor bto choose Speaker.
Press OK.
ePress aor bto choose Low, Med, High
or Off.
Press OK.
fPress Stop/Exit.
You can also adjust the speaker volume by
pressing Hook.
aPress Hook.
bPress dor c.
Each key press changes the volume to
the next setting. This setting will stay
until you change it again.
cPress Hook.

General setup
3
1
Automatic Daylight
Saving Time 1
You can set the machine to change
automatically for daylight saving time. It will
reset itself forward one hour in the Spring and
backward one hour in the Fall. Make sure you
have set the correct date and time in the
Date&Time setting.
The factory setting is Off, so you will have to
turn on Automatic Daylight Saving Time as
follows.
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose
Auto Daylight.
Press OK.
dPress aor bto choose On (or Off).
Press OK.
ePress Stop/Exit.
Sleep Mode 1
You can choose how long the machine must
be idle (up to 60 minutes) before it goes into
Sleep Mode. The timer will restart if any
operation is carried out on the machine.
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose Sleep Mode.
Press OK.
dPress aor bto choose 1Min, 2Mins,
3Mins, 5Mins, 10Mins, 30Mins or
60Mins to choose which is the length of
time the machine is idle before entering
sleep mode.
Press OK.
ePress Stop/Exit.

Chapter 1
4
LCD screen 1
LCD Contrast 1
You can adjust the LCD contrast. If you are
having difficulty reading the LCD, try
changing the contrast setting.
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose LCD Settings.
Press OK.
dPress aor bto choose LCD Contrast.
Press OK.
ePress dto increase the contrast or press
cto decrease the contrast.
Press OK.
fPress Stop/Exit.
Setting the backlight
brightness 1
You can adjust the brightness of the LCD
backlight. If you are having difficulty reading
the LCD, try changing the brightness setting.
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose LCD Settings.
Press OK.
dPress aor bto choose Backlight.
Press OK.
ePress aor bto choose Light, Med or
Dark.
Press OK.
fPress Stop/Exit.
Setting the Dim Timer for the
backlight 1
You can set how long the LCD backlight stays
on after you go back to the Ready screen.
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose LCD Settings.
Press OK.
dPress aor bto choose Dim Timer.
Press OK.
ePress aor bto choose 10Secs,
20Secs, 30Secs or Off.
Press OK.
fPress Stop/Exit.

General setup
5
1
Mode Timer 1
The machine has three temporary mode keys
on the control panel: FAX, SCAN and COPY.
You can change the amount of time the
machine takes after the last Scan or Copy
operation before it returns to FAX mode. If
you choose Off, the machine stays in the
mode you used last.
aPress Menu.
bPress aor bto choose
General Setup.
Press OK.
cPress aor bto choose Mode Timer.
Press OK.
dPress aor bto choose 0Sec, 30Secs,
1Min, 2Mins, 5Mins or Off.
Press OK.
ePress Stop/Exit.

6
2
TX Lock 2
TX Lock lets you prevent unauthorized
access to the machine.
While TX Lock is On, the following operations
are available:
Receiving faxes
While TX Lock is On, the following operations
are NOT available:
Sending faxes
Copying
PC printing
Scanning
Operation from the control panel
Note
If you forget the TX Lock password,
please call Brother Customer Service.
(uuBasic User’s Guide: Brother
numbers)
Setting and changing the
TX Lock password 2
Note
If you have already set the password, you
will not need to set it again.
Setting the password 2
Make a careful note of your password.
aPress Menu.
bPress aor bto choose Fax.
Press OK.
cPress aor bto choose
Miscellaneous.
Press OK.
dPress aor bto choose TX Lock.
Press OK.
eEnter a 4-digit number for the password.
Press OK.
fWhen the LCD shows Verify:
re-enter the password.
Press OK.
gPress Stop/Exit.
Security features 2

Security features
7
2
Changing the password 2
aPress Menu.
bPress aor bto choose Fax.
Press OK.
cPress aor bto choose
Miscellaneous.
Press OK.
dPress aor bto choose TX Lock.
Press OK.
ePress aor bto choose Set Password.
Press OK.
fEnter the 4-digit number of the current
password.
Press OK.
gEnter a 4-digit number for the new
password.
Press OK.
hWhen the LCD shows Verify:
re-enter the new password.
Press OK.
iPress Stop/Exit.
Turning TX Lock on/off 2
Turning TX Lock on 2
aPress Menu.
bPress aor bto choose Fax.
Press OK.
cPress aor bto choose
Miscellaneous.
Press OK.
dPress aor bto choose TX Lock.
Press OK.
ePress aor bto choose Set TX Lock.
Press OK.
fEnter the registered 4-digit password.
Press OK.
The machine goes offline and the LCD
shows TX Lock Mode.
Turning TX Lock off 2
aPress Menu.
bEnter the registered 4-digit password.
Press OK.
TX Lock is automatically turned off.
Note
If you enter the wrong password, the LCD
shows Wrong Password and stays
offline. The machine will stay in TX Lock
mode until the registered password is
entered.

8
3
Additional sending
options 3
Sending faxes using multiple
settings 3
When you send a fax you can choose a
combination of settings, such as
Fax Resolution, Contrast,
Glass ScanSize, and Real Time TX.
You can also choose: Outgoing Call,
Caller ID hist., Overseas Mode,
Speed Dial, Broadcasting,
Set New Default, and Factory Reset.
Some settings are only available when
sending black & white faxes.
aPress (FAX).
The LCD shows:
bPress aor bto choose the setting you
want to change.
Press OK.
cPress aor bto choose an option.
Press OK.
dRepeat steps bto cto change more
settings.
Note
• Most settings are temporary and the
machine returns to its default settings after
you send a fax.
• You can save some of the settings you
use most often by setting them as the
default. These settings will stay until you
change them again. (See Setting your
changes as the new default uu page 9.)
Stop faxing 3
To stop faxing, press Stop/Exit.
Contrast 3
If your document is very light or very dark, you
may want to change the contrast. For most
documents the factory setting Auto can be
used. It automatically chooses the suitable
contrast for your document.
Choose Light when sending a light
document. Choose Dark when sending a
dark document.
aPress (FAX).
bPress aor bto choose Contrast.
Press OK.
cPress aor bto choose Auto, Light or
Dark.
Press OK.
Note
Even if you choose Light or Dark, the
machine will send the fax using the Auto
setting in any of the following conditions:
• When you send a color fax.
• When you choose Photo as the Fax
Resolution.
Sending a fax 3

Sending a fax
9
3
Changing fax resolution 3
The quality of a fax can be improved by
changing the fax resolution.
aPress (FAX).
bPress aor bto choose
Fax Resolution.
Press OK.
cPress aor bto choose the resolution
you want.
Press OK.
Note
You can choose four different resolution
settings for black & white faxes and two for
color faxes.
If you choose S.Fine or Photo and then
use the Color Start key to send a fax, the
machine will send the fax using the Fine
setting.
Setting your changes as the
new default 3
You can save the fax settings for
Fax Resolution, Contrast,
Glass ScanSize and Real Time TX you
use most often by setting them as default.
These settings will stay until you change
them again.
aPress (FAX).
bPress aor bto choose the setting you
want to change, and press OK. Then
press aor bto choose your new option.
Press OK.
Repeat this step for each setting you
want to change.
cAfter changing the last setting, press
aor bto choose Set New Default.
Press OK.
dPress 1to choose Yes.
ePress Stop/Exit.
Restoring fax settings to the
factory settings 3
You can restore the fax settings
Fax Resolution, Contrast,
Glass ScanSize, and Real Time TX,
that you have changed, to the factory
settings. These settings will stay until you
change them again.
aPress (FAX).
bPress aor bto choose
Factory Reset.
Press OK.
cPress 1to choose Yes.
dPress Stop/Exit.
Black & White
Standard Suitable for most typed
documents.
Fine Good for small print and
transmits a little slower than
Standard resolution.
S.Fine Good for small print or artwork
and transmits slower than Fine
resolution.
Photo Use when the document has
varying shades of gray or is a
photograph. Photo has the
slowest transmission.
Color
Standard Suitable for most typed
documents.
Fine Use when the document is a
photograph. The transmission
time is slower than Standard
resolution.

Chapter 3
10
Additional sending
operations 3
Sending a fax manually 3
Manual transmission lets you hear the
dialing, ringing and fax-receiving tones while
sending a fax.
Note
To send a multiple page fax, use the ADF.
aPress (FAX).
bLoad your document.
cTo listen for a dial tone, press Hook.
dDial the fax number.
eWhen you hear the fax tone, press
Black Start or Color Start.
If you are using the scanner glass
press 1to send the fax.
Sending a fax at the end of a
conversation 3
At the end of a conversation, you can send a
fax to the other party before you both hang
up.
aAsk the other party to wait for fax tones
(beeps) and then to press the Start or
Send key before hanging up.
bPress (FAX).
cLoad your document.
dPress Black Start or Color Start.
If you are using the scanner glass,
press 1to send a fax.
eReplace the handset of the external
phone.
Dual Access
(Black & White only) 3
You can dial a number and start scanning the
fax into memory—even when the machine is
sending from memory, receiving faxes or
printing PC data. The LCD shows the new job
number.
The number of pages you can scan into the
memory will vary depending on the data that
is printed on them.
Note
If the Out of Memory message appears
while scanning a document, press
Stop/Exit to cancel or Black Start to send
the scanned pages.

Sending a fax
11
3
Broadcasting
(Black & White only) 3
Broadcasting is when the same fax message
is automatically sent to more than one fax
number. You can include Groups, Speed Dial
numbers, and up to 50 manually dialed
numbers in the same broadcast.
After the broadcast is finished, a Broadcast
Report will be printed.
Before you begin the broadcast 3
Speed Dial numbers must be stored in the
machine's memory before they can be used
in a broadcast. (uuBasic User’s Guide:
Storing Speed Dial numbers)
Group numbers must also be stored in the
machine's memory before they can be used
in a broadcast. Group numbers include many
stored Speed Dial numbers for easier dialing.
(See Setting up Groups for Broadcasting
uu page 21.)
How to broadcast a fax 3
aPress (FAX).
bLoad your document.
cPress aor bto choose
Advanced Settings.
Press OK.
dPress aor bto choose Broadcasting.
Press OK.
eYou can add numbers to the broadcast
in the following ways:
Press aor bto choose Add Number
and press OK. Enter a number using
the dial pad.
Press OK.
Press aor bto choose Speed Dial
and press OK.
Press aor bto choose
Alphabetical Order or
Numerical Order and press OK.
Press aor bto select a number and
press OK.
fAfter you have entered all the fax
numbers by repeating step e, press
aor bto choose Complete.
Press OK.
gPress Black Start.
Faxing from the ADF
The machine starts scanning and
sending the document.
Faxing from the scanner glass
When the LCD asks you Next Page?,
do one of the following:
To send a single page, press 2(or
press Black Start again).
The machine starts sending the
document.
To send more than one page, press
1and place the next page on the
scanner glass.
Press OK.
The machine starts scanning the
page. (Repeat this step for each
additional page.)

Chapter 3
12
Note
• If you did not use up any of the numbers
for Groups, you can broadcast faxes to as
many as 90 different numbers.
• The machine’s available memory will vary
depending on the types of jobs in the
memory and the number of locations used
for broadcasting. If you broadcast to the
maximum number available, you will not
be able to use dual access.
• If the Out of Memory message
appears, press Stop/Exit to stop the job.
If more than one page has been scanned,
press Black Start to send the portion that
is in the machine’s memory.
Canceling a broadcast in progress 3
aPress Menu.
bPress aor bto choose Fax.
Press OK.
cPress aor bto choose
Remaining Jobs.
Press OK.
The LCD will show the fax number being
dialed and the Broadcasting job
number.
dPress OK.
The LCD will ask you the following
question:
Cancel Job?
Yes iPress 1
No iPress 2
ePress 1to cancel the fax number being
dialed.
The LCD will then show the
Broadcasting job number.
fPress OK.
The LCD will ask you the following
question:
Cancel Job?
Yes iPress 1
No iPress 2
gTo cancel the broadcast, press 1.
hPress Stop/Exit.
Real Time Transmission 3
When you are sending a fax, the machine will
scan the document into the memory before
sending it. Then, as soon as the telephone
line is free, the machine will start dialing and
sending.
Sometimes, you may want to send an
important document immediately, without
waiting for memory transmission. You can do
this by turning on Real Time TX.
aPress (FAX).
bLoad your document.
cPress aor bto choose
Advanced Settings.
Press OK.
dPress aor bto choose Real Time TX.
Press OK.
ePress aor bto choose On (or Off).
Press OK.
fPress Clear so you can continue
sending your fax.
Note
• If you are sending a color fax or if the
memory is full and you are sending a black
& white fax from the ADF, the machine will
send the document in real time (even if
Real Time TX is set to Off).
• In Real Time Transmission, the automatic
redial feature does not work when you are
using the scanner glass.

Sending a fax
13
3
Overseas Mode 3
If you are having difficulty sending a fax
overseas due to possible interference on the
telephone line, we recommend that you turn
on Overseas Mode. After you send a fax
using this feature, the feature will turn itself
off.
aPress (FAX).
bLoad your document.
cPress aor bto choose
Advanced Settings.
Press OK.
dPress aor bto choose
Overseas Mode.
Press OK.
ePress aor bto choose On (or Off).
Press OK.
fPress Clear so you can continue
sending your fax.
Checking and canceling
waiting jobs 3
You can check which jobs are still waiting in
the memory to be sent and cancel a job.
(If there are no jobs, the LCD shows
No Jobs Waiting.)
aPress Menu.
bPress aor bto choose Fax.
Press OK.
cPress aor bto choose
Remaining Jobs.
Press OK.
Any waiting jobs appear on the LCD.
dPress aor bto scroll through the jobs
and choose the job you want to cancel.
Press OK.
eDo one of the following:
To cancel, press 1to choose Yes.
If you want to cancel another job go
to step d.
To exit without canceling, press 2to
choose No.
fRepeat steps dand efor each job you
want to cancel.
gWhen you are finished, press Stop/Exit.

14
4
Additional receiving
operations 4
Printing a reduced incoming
fax 4
If you choose On, the machine automatically
reduces each page of an incoming fax to fit on
one page of Letter, Legal or A4 size paper.
The machine calculates the reduction ratio by
using the page size of the fax and your Paper
Size setting. (uuBasic User’s Guide: Paper
Size)
aPress Menu.
bPress aor bto choose Fax.
Press OK.
cPress aor bto choose
Setup Receive.
Press OK.
dPress aor bto choose
Auto Reduction.
Press OK.
ePress aor bto choose On (or Off).
Press OK.
fPress Stop/Exit.
Receiving a fax at the end of a
conversation 4
At the end of a conversation, you can ask the
other party to fax you information before you
both hang up.
aAsk the other party to place the
document in their machine and to press
the Start or Send key.
bWhen you hear the other machine's
CNG tones (slowly repeating beeps),
press Black Start or Color Start.
cPress 2to choose Receive to receive
the fax.
dReplace the handset of the external
telephone.
Receiving faxes into memory
when paper tray is empty 4
As soon as the paper tray becomes empty
during fax reception, the LCD shows
No Paper Fed. Put some paper in the
paper tray. (uuBasic User’s Guide: Loading
paper and other print media)
If you don't put paper in the paper tray, the
machine will carry on receiving the fax, with
the remaining pages being stored in memory,
if enough memory is available.
Further incoming faxes will also be stored in
memory until the memory is full. When the
memory is full the machine will stop
automatically answering calls. To print the
faxes, put fresh paper in the tray.
Receiving a fax 4

15
5
5
Voice operations 5
Voice calls can be made with an external
telephone by dialing manually.
Tone or Pulse (Canada only) 5
If you have a Pulse dialing service, but need
to send tone signals (for example, for
telephone banking), follow the instructions
below:
aPress Hook.
bPress #on the machine’s control panel.
Any digits dialed after this will send tone
signals.
When you are finished with the call, the
machine will return to the Pulse dialing
service.
Fax/Tel mode 5
When the machine is in Fax/Tel mode, it will
use the F/T Ring (pseudo/double-ringing) to
alert you to pick up a voice call.
If you are at the extension telephone, you'll
need to lift the handset during the F/T Ring
and then press #51between the
pseudo/double-rings. If no one is on the line,
or if someone wants to send you a fax, send
the call back to the machine by pressing
l51.
If you are at the machine, lift the external
telephone’s handset, and then press Hook to
answer.
Caller ID 5
The Caller ID feature lets you use the Caller
ID subscriber service offered by many local
telephone companies. This service shows the
telephone number, or name if it is available,
of your caller as the line rings. Call your
telephone company for details.
Once you answer a call, the Caller ID
information disappears from the LCD, but the
call information stays stored in the Caller ID
memory.
You can view the list or choose one of these
numbers to fax to, add to Speed Dial, or
delete from the history. (See Caller ID history
uu page 18.)
You can see the number (or name).
The # Unavailable message means
the call originated outside your Caller ID
service area.
The Private Call message means the
caller has intentionally blocked
transmission of Caller ID information.
You can print a list of the Caller ID information
received by your machine. (See How to print
a report uu page 24.)
Note
• This feature may not be available in
certain areas of the USA and Canada.
• The Caller ID service varies with different
carriers. Call your local telephone
company to find out about the kind of
service available in your area.
Dialing and storing numbers 5

Chapter 5
16
Setting up your area code (USA only) 5
When returning calls from the Caller ID
history your machine will automatically dial
“1” plus the area code for all calls. If your local
dialing plan requires that the “1” not be used
for calls within your area code, enter your
area code in this setting. With the area code
setting, calls returned from the Caller ID
history to numbers within your area code will
be dialed using 10 digits (area code + 7-digit
number). If your dialing plan does not follow
the standard 1 + area code + 7-digit number
dialing system for calling outside your area
code, you may experience problems
returning calls automatically from the Caller
ID history. If this is not the procedure followed
by your dialing plan, you will not be able to
return calls automatically.
aPress Menu.
bPress aor bto choose Fax.
Press OK.
cPress aor bto choose
Miscellaneous.
Press OK.
dPress aor bto choose Caller ID.
Press OK.
eUse the dial pad to enter your area code.
Press OK.
fPress Stop/Exit.
Special line considerations 5
Roll-over telephone lines 5
A roll-over telephone system is a group of two
or more separate telephone lines that pass
incoming calls to each other if they are busy.
The calls are usually passed down or “rolled
over” to the next available telephone line in a
preset order.
Your machine can work in a roll-over system
as long as it is the last number in the
sequence so the call cannot roll away. Do not
put the machine on any of the other numbers;
when the other lines are busy and a second
fax call is received, the fax call will be sent to
a line that does not have a fax machine. Your
machine will work best on a dedicated
line.
Two-line telephone system 5
A two-line telephone system is nothing more
than two separate telephone numbers on the
same wall outlet. The two telephone numbers
can be on separate jacks (RJ11) or mixed into
one jack (RJ14). Your machine must be
plugged into an RJ11 jack. RJ11 and RJ14
jacks may be equal in size and appearance
and both may contain four wires (black, red,
green, yellow). To test the type of jack, plug in
a two-line telephone and see if it can access
both lines. If it can, you must separate the line
for your machine.
