Brother MFC-7450 User manual

STEP 1
STEP 2
Setup is Complete!
Quick Setup Guide
Setting Up the Machine
Installing the Driver & Software
MFC-7340
MFC-7440N
MFC-7450
MFC-7840N
Before you can use the machine, you must set up the hardware and install the driver. Please read
this ‘Quick Setup Guide’ for proper set up and installation instructions.
Keep this ‘Quick Setup Guide’ and the supplied CD-ROM in a convenient place for quick and easy
reference at all times.
Version 0
ARL/ASA/NZ

1 Symbols used in this guide
Warning
Caution Improper Setup
Warnings tell you what to do to prevent
possible personal injury.
Cautions specify procedures you must
follow or avoid to prevent possible
damage to the machine or other objects.
Improper Setup icons alert you to
devices and operations that are not
compatible with the machine.
Note
User's Guide, Software User's Guide or
Network User's Guide
Notes tell you how you should respond
to a situation that may arise or give tips
about how the current operation works
with other features.
Indicates reference to the User's Guide,
Software User's Guide or Network
User's Guide which is on the CD-ROM
we have supplied.

Table of Contents
1
Getting Started
Carton components...................................................................................................................................... 2
Control panel................................................................................................................................................ 4
STEP 1 – Setting Up the Machine
Installing the drum unit and toner cartridge assembly.................................................................................. 5
Loading paper in the paper tray ................................................................................................................... 6
Install the power cord and phone line .......................................................................................................... 7
Set Your Country (For Australia / New Zealand Customer Only)................................................................. 8
Setting the date and time ............................................................................................................................. 8
Setting your station ID.................................................................................................................................. 9
Tone and pulse dialling mode (Not available in New Zealand) .................................................................. 10
Selecting a receive mode........................................................................................................................... 10
Dial Prefix................................................................................................................................................... 11
Setting the LCD contrast ............................................................................................................................ 11
STEP 2 – Installing the Driver & Software
Windows®
For USB Interface Cable Users
(For Windows®2000 Professional/XP/XP Professional x64 Edition/Windows Vista®) ............................. 14
For Wired Network Interface Users (MFC-7440N and MFC-7840N only)
(For Windows®2000 Professional/XP/XP Professional x64 Edition/Windows Vista®) ............................. 17
For Windows Server®2003, see the Network User’s Guide on the CD-ROM.
Macintosh®
For USB Interface Cable Users................................................................................................................. 20
For Mac OS®X 10.2.4 or greater......................................................................................................... 20
For Wired Network Interface Users (MFC-7440N and MFC-7840N only)................................................. 22
For Mac OS®X 10.2.4 or greater......................................................................................................... 22
For Network Users
BRAdmin Light utility (For Windows®users).............................................................................................. 25
Installing the BRAdmin Light configuration utility .................................................................................. 25
Setting your IP address, Subnet Mask and Gateway using BRAdmin Light ........................................ 25
BRAdmin Light utility (For Mac OS®X users) ............................................................................................ 26
Setting your IP address, Subnet Mask and Gateway using BRAdmin Light ........................................ 26
Web Based Management (web browser)................................................................................................... 27
Restoring the network settings to factory default ....................................................................................... 27
Print the Network Configuration List........................................................................................................... 27
Consumables and Options
Consumables ............................................................................................................................................. 28

Getting Started
2
1
1 Carton components
Carton components may vary from one country to another.
Save all packing materials and the carton in case for any reason you must ship your machine.
Warning
Plastic bags are used in the packaging of your machine. To avoid danger of suffocation, keep these bags away
from babies and children.
1 Automatic Document Feeder (ADF)
2 Control Panel
3 Face-down Output Tray Support
4 Manual Feed Slot
5 Paper Tray
6FrontCover
7 Power Switch
8 ADF Document Output Support Flap
9 Document Cover
The interface cable is not a standard accessory. Please purchase the appropriate interface cable for the interface
you intend to use (USB or Network). Do NOT connect the interface cable at this time. Connecting the interface
cable is done during the software installation process.
USB interface cable
Please make sure you use a USB 2.0 interface cable that is no longer than 6 feet (2 metres). When you use a
USB cable, make sure you connect it to the USB port of your computer and not to a USB port on a keyboard
or non-powered USB hub.
Network cable (MFC-7840N only)
Use a straight-through Category 5 (or greater) twisted-pair cable for 10BASE-T or 100BASE-TX Fast Ethernet
Network.
To ensure safe operation the supplied plug must be inserted only into a standard power outlet that is properly
grounded through the standard electrical wiring. Non grounded equipment may cause an electrical shock
hazard, and may cause excessive electrical noise radiation.
1
2
5
9
3
4
8
7
6
CD-ROMs
For Windows®
For Macintosh®
User’s Guide
Quick Setup Guide
Telephone Line Cord
Adapter
(For Australia only)
AC Power Cord
Telephone Line Cord
Drum Unit Assembly
(including Toner Cartridge)

Getting Started
3
Australia & New Zealand users: Hong Kong, Malaysia & Singapore users:
The mains pulg supplied with this machine is a grounded three pin pulg. Make sure that the AC socket will accept this
grounded three pin pulg. This machine must be grounded, If in doubt, call a qualified electrician.
Philippines & Thailand users:
The mains pulg supplied with this machine is a side grounded two pin pulg. Make sure
that the AC socket will accept this side grounded two pin pulg. This machine must be
grounded, If in doubt, call a qualified electrician.

Getting Started
4
2 Control panel
MFC-7440N and MFC-7840N have the same keys.
MFC-7340 and MFC-7450 have the same keys.
1 Copy keys
2 Print key(s)
3 One Touch keys
4 Shift key
5 Mode keys
6 Menu keys
7 Dial Pad
8 Start key
9 Stop/Exit key
10 LCD (Liquid Crystal Display)
11 Fax and Telephone keys
For the details of the control panel, see Control panel overview in Chapter 1 of the User’s Guide.
Note
When you move the machine, grasp the side handholds that are under the scanner. Do NOT carry the machine
by holding it at the bottom.
Illustration in this Quick Setup Guide are based on MFC-7840N.

Setting Up the Machine
5
1
1 Installing the drum unit and
toner cartridge assembly
Improper Setup
DO NOT connect the interface cable.
Connecting the interface cable is done when
installing the driver.
1Open the front cover.
2Unpack the drum unit and toner cartridge
assembly.
3Gently shake it from side to side several times
to distribute the toner evenly inside the
assembly.
4Put the drum unit and toner cartridge assembly
into the machine.
5Close the front cover of the machine.

Setting Up the Machine
6
STEP 1
2 Loading paper in the paper
tray
1Pull the paper tray completely out of the
machine.
2While pressing the green paper-guide release
lever, slide the paper guides to fit the paper
size you are using. Make sure that the guides
are firmly in the slots.
Note
For Legal size paper, press the release button in
the bottom of the paper tray and pull out the back
of the paper tray. (Legal size paper is not available
in some regions.)
3Fan the stack of paper well to avoid paper jams
and misfeeds.
4Put paper in the paper tray. Make sure that the
paper is flat in the tray and below the maximum
paper mark (1).
Caution
Make sure the paper guides touch the sides of the
paper so it will feed properly. If you do not this, it
may cause damage to your machine.
5Put the paper tray firmly back into the machine.
Make sure that it is completely inserted into the
machine.
1

Setting Up the Machine
7
3 Install the power cord and
phone line
1Make sure that the machine’s power switch is
off. Connect the AC power cord to the machine.
2Plug the AC power cord into an AC outlet. Turn
the power switch on.
3Connect one end of the telephone line cord to
the socket on the machine marked LINE and
the other end to a modular wall socket.
Warning
• The machine must be fitted with an earthed plug.
• Since the machine is grounded through the power
outlet, you can protect yourself from potentially
hazardous electrical conditions on the telephone
network by keeping the power cord connected to
your machine when you connect it to a telephone
line. Similarly, you can protect yourself when you
want to move your machine by disconnecting the
telephone line first and then the power cord.
Note
If you are sharing one phone line with an external
telephone, connect it as shown below.
Note
If you are sharing one phone line with an external
telephone answering device, connect it as shown
below.
Please set the receive mode to
External TAD.
For more details, see Selecting a receive
mode on page 10 and Connecting an
external TAD in Chapter 7 of the User’s
Guide.
(Example
for Australia)
(Example
for Australia)

Setting Up the Machine
8
STEP 1
4 Set Your Country
(For Australia / New Zealand
Customer Only)
You must set your country so that the machine works
correctly on local telecommunication lines in each
country.
1Check that the power is turned on by plugging
in the power cord and turn the power switch on.
Press OK.
Set Country
Press OK Key
2Press or to choose the country
(Australia, or New Zealand).
Australia
Select ab or OK
3Press OK when the LCD shows your country.
4The LCD prompts you to make sure of the
country again.
Australia?
1.Yes 2.No
5If the LCD shows the correct country, press 1
to go to step 6.
Or press 2to go back to step 2to choose the
country again.
6After the LCD shows Accepted, the machine
will restart automatically. After the restart, the
LCD shows Please Wait.
5 Setting the date and time
The machine displays the date and time, and if you
set up the station ID, the date and time displayed on
your machine will be printed on every fax you send.
1Press Menu.
2Press 0.
3Press 2.
4Enter the last two digits of the year on the dial
pad, and then press OK.
Date&Time
Year:2008
(e.g. Enter 0, 8for 2008.)
5Enter the two digits for the month on the dial
pad, and then press OK.
Date&Time
Month:03
(e.g. Enter 0, 3for March.)
6Enter the two digits for the day on the dial pad,
and then press OK.
Date&Time
Day:25
(e.g. Enter 2, 5.)
7Enter the time in 24-hour format on the dial
pad, and then press OK.
Date&Time
Time:15:25
(e.g. Enter 1, 5, 2, 5for 3:25 P.M.)
8Press Stop/Exit.
Note
If you make a mistake and want to start again,
press Stop/Exit and go back to step 1.
