For the Administrator (For Windows®users only)
Print Configuration page
Factory default setting
Install the BRAdmin Professional Configuration utility
Quick Network Setup Guide
Laser Printer HL-1650/1670N/2460
Follow the instructions for Setting Up the Printer in the "Quick Setup Guide" first.
If you are going to connect the printer to a network, we recommend you contact your system administrator prior
to installation.
If you are an Administrator: Configure your printer referring to the following instructions.
If you are installing the driver on your PC refer to the reverse side of this sheet once the administrator has
configured the printer.
To configure the print server refer to the Network Guide
To access the Network Guide, insert the CD-ROM supplied with the printer,
click the Manual icon and select the Network Guide.
Peer-to-Peer Printing
NetBIOS Peer-to-Peer Printing
How to Configure Internet Printing
Novell Netware Printing
TCP/IP Printing
NetBIOS Peer-to-Peer Printing
DLC Printing
How to Configure Internet Printing
Novell Netware Printing
TCP/IP Printing
NetBIOS Peer-to-Peer Printing
DLC Printing
TCP/IP Printing
How to Configure Internet Printing
Novell Netware Printing
UNIX Printing
Macintosh Printing
Macintosh Printing
TCP/IP Printing
NetBIOS Peer-to-Peer Printing
LAT Network Configuration
Banyan VINES Network Configuration
Web Based Management
BRAdmin Configuration
BRAdmin Configuration
Chapter 3
Chapter 4
Chapter 5
Chapter 6
Chapter 2
Chapter 4
Chapter 8
Chapter 5
Chapter 6
Chapter 2
Chapter 4
Chapter 8
Chapter 2
Chapter 5
Chapter 6
Chapter 1
Chapter 7
Chapter 7
Chapter 2
Chapter 4
Chapter 9
Chapter 10
Chapter 11
Chapter 12
Chapter 12
TCP/IP
NetBIOS
TCP/IP
IPX/SPX
TCP/IP
NetBIOS
DLC/LLC
TCP/IP
IPX/SPX
TCP/IP
NetBIOS
DLC/LLC
TCP/IP
TCP/IP
IPX/SPX
TCP/IP
AppleTalk
TCP/IP
TCP/IP
NetBIOS
DEC_LAT
VINES
TCP/IP
TCP/IP
IPX/SPX
Peer-to-Peer
Brother Internet Print
Netware
Peer-to-Peer
Brother Internet Print (NT®4.0 only)
Netware
Peer-to-Peer
IPP (Internet Printing Protocol)
Brother Internet Print
Netware
Windows®95/98/Me
Windows NT®
Windows®2000
UNIX/Linux
Macintosh®
OS2 Warp Server
LAN Server
DEC (Non UNIX)
Banyan VINES
Web Browser Management Function
BRAdmin Professional
Windows®Macintosh®
Use the Brother Network Printer Driver Wizard software to automate the installation of Brother networked
printers in a TCP/IP environment. The Wizard can create an Executable file that can be sent to other network
users, when run, the Executable file installs the appropriate printer driver and network printing software
directly on the remote PC.
Network Printer Driver Wizard: Useful Utility for Peer-to-Peer users
The BRAdmin Professional software provides sophisticated network and printer management capabilities for
Brother. By identifying potential problems before they arise, and by addressing important IT requirements
such as streamlined printer configuration, mass configuration and enterprise-wide upgrades, the BRAdmin
Professional software plays an important role in Printer network management.
An exapmple of a Shared printer*1,
printing through a queue, or sharename.
Printer
LAN
ClientClient
Client
Windows Server
Netware Server
Windows Workstation
*1 A shared printer can been seen in the Network Neighborhood.
Novell Netware, Windows®
95/Windows NT®4.0 does not
support USB printing.
USB Parallel
Printer Printer
An exapmple of a printer
in a Peer-to-Peer network.
Printer
ClientClient
Client
LAN (Network)
LAN (Network)
To access the Network Printer Driver Wizard, insert the
CD-ROM supplied with the printer, click the Install
Software icon and select the Network Printer Driver
Wizard.
HL-1650/1670N Test Button
LJ5631001 Printed in China
Type of Network Printer
Network Guide Chapter Map
Press the Network Test Button for less than 5
seconds to print a configuration page.
If you wish to reset the print server back to its
default factory settings (resetting all information
such as the password and IP address information)
hold down the Network Test Button for more than 5
seconds.
©2000 Brother Industries, Ltd. ©1998-2000 TROY XCD Inc. ©1983-2000 PACIFIC SOFTWORKS INC. ALL RIGHTS RESERVED ©Copyright 2000 by Brother Industries, Ltd. Originaly Based
on: ItIs - ITRON Implementation by Sakamura Lab (Phase3 Release1.3.2) ©Copyright 1989-2000 by Sakamura Lab, the University of Tokyo, JAPAN
Windows®and Windows NT®are registered trademarks of Microsoft Corporation in the U.S.and other countries. HP,HP/UX, JetDirect and JetAdmin are trademarks of Hewllet-Packard Company.
UNIX is a trademark of UNIX Systems Laboratories. PostScript is trademark of Adobe Systems Incorporated. Netware is a trademark of Novell, Inc. Apple Macintosh, iMac, LaserWriter, and
AppleTalk are trademarks of Apple Computer, Inc. BRAdmin Professional are trademark of Brother Industries, Ltd.
All other brand and product names mentioned in this Quick Network Setup Guide and user's guide are registered trademarks or trademarks of respective companies.
1Insert the CD-ROM. 2Select the appropriate language. 3Click the Install Software icon. 4Select BRAdmin Professional.
Install the BRAdmin
Professional utility referring to
the on-screen instructions.
Network port
Some illustration and screens are based on the HL-1600 series.
HL-2460 Test Button
Network port

OFF ON
OI
OFF ON
OI
OFF ON
OI
OFF ON
OI
2Enter a unique your port name (ex.BLP1),
and then click the OK button.
1Select "LPR (Recommended)", and
then click the Next button.
Step 5 Connect the Printer to your Macintosh®& Install the BR-Script PPD file
Step 5 Connect the Printer toYour Network
& Install the Driver
Step 6 Configuring the NetBIOS port
Step 6 Select the appropriate printer Queue or 'Sharename'
Step 6 Configuring the LPR port
For Windows® 95/98/Me users only For Windows NT® 4.0/ Windows®2000 users only
3Specify the printer's IP Address (or
click the Browse button to see a list of
printers), and click the OK button.
4Click the Finish button and restart your PC.
After your PC has restarted, setup is
complete.
2Click the Next button.
2Enter a unique your port name (ex.
BNT1), and then click the OK button. 3Enter the path name (or click the Browse... button to see a list of printer's), and then
click the OK button.
4Click the Finish button and restart your PC.
After your PC has restarted, setup is
complete.
4Click the Finish button and restart your PC.
After your PC has restarted, setup is
complete.
1Select "LPR
(Recommended)", and
then click the Next button.
1Select NetBIOS, and click the Next
button.
For Brother Peer-to-Peer network printer users (LPR- Recommended Peer to Peer printing Method)
For Brother Peer-to-Peer network printer users (NetBIOS)
For Macintosh®users only
3Connect the cable to your printer, and then
connect it to a free port on your hub.
1Double click the BR-Script PPD
Installer icon and then follow the
instructions on the screen.
4Turn the printer power
switch on. 5Open the Chooser from the Apple®
menu on the Macintosh®.6Click the LaserWriter8 *2 icon (if you need to change the network zone, select which zone you
want to use from the AppleTalk®zones list).
7Click on the appropriate print server,
and close the Chooser.
The setup is now complete.
*2 If the Apple®LaserWriter8 Driver is not already installed on your system, you can download it from http://www.apple.com.
Turn the printer power
switch off.
2
Step 1 to 4
Follow the instructions in the Quick Setup Guide first.
Before you continue, please ensure that the administrator has configured the network printer
settings correctly.
Installing the Driver for Network users
For Windows®users only
For Network shared printer users
5Turn the printer power
switch on.
4Connect the cable to your printer, and then
connect it to a free port on your hub.
3Turn the printer power switch
off.
1Click the "Connect the interface cable
and install the printer driver / utilities".
1Select your printer's queue, and then click the OK button. 2Once the appropriate queue is specified, the printer driver will be installed.
Note: In the Chooser you will see the
name BRN_xxxxxx_P1_AT, where
"xxxxxx" is the last six digits of the
Ethernet address.
See Chapter 7 of the Network User's
Guide for more information.
6Click the Next button.
7Select the "Network shared printer" or
the "Brother peer-to-peer network
printer", and then click the Next button.
2Select the Network cable.
3Enter the printer's IP Address and the
port name BINARY_P1, then click the
Next button.
Note: If this screen appears, insert
the Windows NT®4.0 CD-ROM
into your CD-ROM drive.
The setup is now complete.
Select the Network connection style and go to
Step 6.
You can refer to the figure "Type of Network Printer" on the reverse side of
this sheet.
Hub
