Bryant DURAPAC 580F036-150 User manual

580F units are a single piece, gas heating/electric
cooling unit, with a low profile, pre-wired, tested
and charged at the factory. The units have the
capability for convertible supply and return open-
ings and are intended for installation on an acces-
sory curb (ordered separately), or for slab mounting
(for horizontal duct connections). Units are
designed to accept a field-installed economizer,
enthalpy control, manual or 2-position outside air
damper, roof curb, as well as up to 3 choices of gas
heat. Refer to accessory chart for full listing.
FEATURES
• Standard one-year full product warranty.
• Five-year protection plan for the motor-
compressor.
• Five-year protection plan on heat exchangers.
• Outdoor ambient cooling operation from 25 F
(–4 C) to 115 F (46 C).
• Units are tested and certified by ARI and certi-
fied by UL and CSA. Factory-run test printout
included in each rooftop.
• 24-volt control circuit, with resettable breaker.
• Two-inch disposable-type return air filters in ded-
icated rack.
• Hermetic compressor on independent circuit with
internal line break and overload protection, self-
lubricating with internal discharge muffler.
• Refrigeration circuit contains a filter drier to trap
dirt and particles.
• Two-speed direct-drive evaporator fan on
sizes 036-060. All other sizes are belt driven.
Adjustable belt-drive fans are optional on 036-
060 sizes.
• Non-corrosive condensate pan with self-draining
design with both bottom and side drain
connections.
• Thru-the-bottom power, control and gas entry
capability.
• Indoor and outdoor coils constructed of alumi-
num fins mechanically bonded to seamless
copper tubes.
• Single point electrical and gas connections.
• Direct-drive propeller condenser fan totally
enclosed with permanently lubricated bearings.
• Pre-painted, insulated cabinet with primed inner
panels, certified 500-hr salt spray test and non-
corrosive screws.
• Large, easily removable panels provide ready
access to unit components for rapid removal or
maintenance.
S U B M I T TA L DATA
Job Name ______________________________________
Architect _______________________________________
Engineer _______________________________________
Contractor _____________________________________
Unit Designation _________________________________
PERFORMANCE DATA
Cooling
Net Total Cap. ________________________________Btuh
Net Sensible Cap. _____________________________Btuh
Compressor Power Input _________________________ kW
_______________________________ F Outdoor Air Temp.
Indoor Entering Air db_________ F wb _________ F
CFM ____________ Ext. Static Pressure ____ (in. wg)
Fan RPM ____________________________________ Bhp
SEER/EER______________________________________
Heating
Input: Stage 1 ______________ Total ___________Btuh
Output: Stage 1 ______________ Total ___________Btuh
AFUE _________________________________________ %
Steady State ___________________________________ %
Operating Weight ________ lbs. (unit) _______ lbs. (curb)
ELECTRICAL DATA
Power Supply to Unit ______ Volts _____ Phase _____ Hz
Minimum Circuit Amps ______________
Maximum Overcurrent Protection (Fuse Only) ___________
HEATING & COOLING SUBMITTAL
DuraPac Series
Unit 580F036-150
3 to 121/2NOMINAL TONS
COMMERCIAL SINGLE-PACKAGE
ROOFTOP GAS HEATING/
ELECTRIC COOLING UNITS

2
• Filter access door for filter access and maintenance
that requires no tools.
• Induced draft (negative pressure) combustion sys-
tem with Hall effect sensor to detect proper opera-
tion of induced-draft motor.
• 3 to 6-ton units have one stage of cooling and 71/2
to 121/2-ton units have two stages of cooling. Units
will have either one stage or two stages of gas heat-
ing depending on unit size, voltage, and heating
capacity.
• Heavy Alumagard™ coated heat exchangers, with
aluminized steel burners.
• Heating controls with direct spark ignition and
redundant gas valve. Fan switch, high temperature
limit switch and flame rollout switch standard.
• Fixed orifice metering device precisely controls
refrigerant flow to each circuit individually.
• Reliable accurate control circuit with color coded
wires and easily accessible terminal board.
• Integrated gas control board with built-in diagnostics
to determine error codes and control indoor fan on/
off delays.
• Integrated gas control board provides anti-cycle pro-
tection for gas heat operation.
• Loss of charge (low pressure), freeze protection,
and high pressure switches standard.
FACTORY-INSTALLED OPTIONS
 EconoMi$er — Fully Modulating, Gear Driven
 Copper/Copper Coils — Evaporator, Condenser, Both
 Pre-Coated Condenser Coil
 E-Coat (Post-Coated) Condenser Coil
 Unit-Mounted Non-Fused Disconnect Switch
 115-Volt Convenience Outlet
 Alternate Motor and Drive (except 072 and 102 size)
 High-Static Motor (except 150 size)
 25% Manual Air Damper
FIELD-INSTALLED ACCESSORIES
 EconoMi$er — Fully Modulating, Gear Driven
 EconoMi$er with 4 to 20 mA Actuator — Fully Modulating,
Gear Driven
 Power Exhaust for EconoMi$er
 EconoMi$er/Power Exhaust
 25% Open Two-Position Damper
 25% Open Manual Air Damper
 100% Open Two-Position Damper
 Durablade Economizer
 Solid-State Enthalpy Control
 Differential Enthalpy Control
 Roof Curb (14- or 24-in. Height)
 Thru-the-Bottom/Roof Curb Electrical and
Gas Connection Kit
 Time Guard® II Compressor Anti-Cycle Control
 Condenser Coil Hail Guard
 Condenser Coil Protector
 –20 F Motormaster® Low Ambient Control Kit
 Programmable Set-Back Thermostat
 Liquid Propane (LP) Gas Kit
 Flue Hood Protector Kit
 Flue Discharge Deflector
 Indoor Fan/Filter Status Indicator
 Other ____________________

3
CUT ALONG DOTTED LINE CUT ALONG DOTTED LINE
CERTIFIED DIMENSION PRINT

4
CERTIFIED DIMENSION PRINT

5
CUT ALONG DOTTED LINE CUT ALONG DOTTED LINE
CERTIFIED DIMENSION PRINT

6
CERTIFIED DIMENSION PRINT

7
CUT ALONG DOTTED LINE CUT ALONG DOTTED LINE
CERTIFIED ROOF CURB DIMENSION PRINT

Copyright 2002 Bryant Heating & Cooling Systems Performance Data Certified by______________________________________________________
FORM NO. SUB 580F.36.2 SUPERSEDES SUB 580F.36.1 2-02 (5158-002)
