BT Lab Systems BT907 User manual

A Geno Technology, Inc. (USA) brand name
1-800-628-7730 ♦ 1-314-991-6034 ♦ [e-mail]
Rocking Shaker
Cat. No. BT907

Page 2of 7
Thanks for choosing BT Lab Systems’ BT907 Rocking Shaker. This operation manual describes the
function and operation of the instrument. In order to use the instrument properly, please read this
manual carefully.
Please check the instrument with the packing list when you first open the packing case. If items do not
match the packing list, please contact BT Lab Systems.
IMPORTANT SAFETY INFORMATION
Users should understand how to use the instrument properly before operating it. Please read this
operation manual carefully before using the instrument.
The operation, maintenance and repair of the instrument should comply with the basic guidelines and
warning below. Ignoring these instructions will affect the life of the Instrument and safety precautions.
•This product is an indoor Instrument which conforms to Standard B style- I type- GB9706.1.
•Before operation, read the manual carefully. These units are designed for using in laboratory
environments by persons knowledgeable in safe laboratory practices.
•The operator should never open or repair the instrument. Opening or repairing the instrument will
void the guarantee and can cause accidents.
•The power plug is designed to safeguard against an electric shock. The 3-pin plug supplied with
BT907 Rocking Shaker’s power cable is a safety device that should be matched with a suitable
grounded socket.
•The instrument should be used in an area with low temperature, little dust, no water, no sunshine
or hard light and with good air circulation. Do not use where there is corrosive gas or a strong
magnetic field. Keep far away from central heating, camp stove and other hot sources. Do not put
the instrument in a wet and dusty area. The vent on the instrument is designed for aeration. Do not
wall up or cover the vent.
•Power off when not in use. If the instrument will not be used for a long period, unplug, and cover
with a piece of cloth to protect it from dust.
•In case of the following, unplug the instrument at once and contact BT Lab Systems.
oThe instrument comes into contact with liquid
oThe instrument gets soaked or burned
oThe instrument emits an abnormal sound or smell
oThe instrument is dropped or the outer shell damaged
oThe instrument functions abnormally.
MAINTENANCE
The instrument and the accessories should be cleaned with a cloth dampened by alcohol.
If there are smudges on the instrument, clean it with a dry cloth.

Page 3of 7
INTRODUCTION
BT Lab Systems’ BT907 Rocking Shaker is used in the immobilization of running gels, shaking for dyeing
or fading Coomassie blue, immobilization, dyeing and developing of silver-staining, developing and
fixation of X-ray film in autoradiography experiments, and further processing of cellulose membrane
after gel shift such as molecular hybridization or staining with antigen-antibody. It is also used for cell
culture and cell membrane transfer.
KEY FEATURES
•Platform made of stainless steel and natural rubber, alkali-resistant, easy to clean and prevents
spilling.
•Speed display shows current speed and time display counts down time.
•The instrument uses articulated rotation that is stable and long-wearing, suitable for prolonged use.
•Compact design, takes up very little space.
•Brushless DC motor, maintenance-free.
NORMAL OPERATING CONDITIONS
•Ambient Temperature: 4-45°C
•Relative Humidity: ≤70%
•Power: AC100-240V~1.5A
TECHNICAL SPECIFICATIONS
Speed Range: 10~80rpm
Swing Cycloid: 25mm (up and down)
Time Range: 1min ~ 99h59min
Max. Load: 5.0kg
Power: 50W
Dimension: 284 x 264 x 100 mm
Net Weight: 5.0kgs

Page 4of 7
Power Switch
Power Connector
Non-slip mat
EQUIPMENT OVERVIEW
This chapter describes the instrument’s mechanical structure, the keyboard and functions of each key as
well as operation. Please learn this chapter before the instrument is operated for the first time.
Platform
Keyboard

Page 5of 7
KEYBOARD AND DISPLAY PANEL
OPERATION
Decreases the time value or speed value.
Increases the time value or speed value.
Press Start/Stop key to start or stop the program.
OPERATION GUIDE
Setting Speed and Timing
1. Switch on the instrument, the LED will display 8. The instrument will beep.
2. Press or of speed key to adust the speed value. It displays last running speed. Continuously
pressing increases or decreases the unit from, tens to hundreds.
3. Press or of time key to adust the timing value. It displays last setting time.. Continously
pressing leads the value increse or decrease in X10 speed.
Stop / Start
1. Press the start/stop key to start or stop the program.
2. Press “start/stop” to run the program after speed and timing are set.When the time is up the
instrument stops running and sounds an alert.
3. Press “stop/start” to stop the program.
4. When the program completes, or the instrument is stopped it in start mode. In start mode, press 
or of speed key or timing key to reset speed and timing.
5. Press “start/stop” without adjusting speed or timing, the instrument will operate the program the
same as the previous setting.

Page 6of 7
TROUBLE SHOOTING
Issue Possible Causes Processing Procedure
No signal display when power on.
No power Check the power
Broken switch Contact BT Lab Systems
Others Contact BT Lab Systems
Shaking heavily
Samples placed
unbalanced
Place the samples
evenly
Actual speed and displayed speed are not
matching Broken controller Contact BT Lab Systems
Err displays Speed not working Contact BT Lab Systems
WARRANTY
BT Lab Systems’ BT907 Rocking Shaker is warranted against defects in materials and workmanship for 1
year. If any defects occur in the instrument or accessories during this warranty period, BT Lab Systems
will repair or replace the defective parts at its discretion without charge. The following defects,
however, are specifically excluded:
1. Defects caused by improper operation.
2. Repair or modification done by anyone other than BT Lab Systems or an authorized agent.
3. Damage caused by substituting alternative parts.
4. Use of fittings or spare parts supplied by anyone other than BT Lab Systems.
5. Damage caused by accident or misuse.
6. Damage caused by disaster.
7. Corrosion caused by improper solvent or sample.
This warranty does not apply to parts listed below:
1. Fuses
2. Lamps
3. Starters
For any inquiry or request for repair service, contact your local BT Lab Systems office. Inform BT Lab
Systems of the model and serial number of your instrument.

Page 7of 7
REGULATORY NOTICE
IMPORTANT: This BT Lab Systems instrument is designed and certified to meet safety standards and
EMC regulations. Certified products are safe to use when operated in accordance with the instruction
manual. This instrument should not be modified or altered in any way. Alteration of this instrument
will:
1. Void the manufacturer’s warranty
2. Void the safety and EMC certification
3. Create a potential safety hazard
BT Lab Systems is not responsible for any injury or damage caused by the use of this instrument for
purposes other than those for which it is intended, or by modifications of the instrument not performed
by BT Lab Systems or an authorized agent.
TECHNICAL SUPPORT
BT Lab Systems offers technical support for all of its products. If you have any questions about the
product’s use or, operation, please contact BT Lab Systems at the following:
E-Mail: [e-mail]
