1. Install Support Planks
At the start of every floor, cut two support planks of flooring to about
3 inches (75mm) wide and about 20 inches (500mm) long.
Set the support planks about 1/4” (6mm) from the blade, with the
tongue sides facing toward the center of the table and spaced apart
by at least the width of material you are installing.
Clamp the support planks in place using the clamp knobs. (A)
Paladin Hardwood Cutter MS93-1009
QuickStart Guide
WARNING:
DO NOT OPERATE WITH
AIR PRESSURE ABOVE
125PSI (8.6 Bar)!
2. Air Supply
Connect compressed air to the air
inlet. Ensure that the pressure is
regulated to between 80 and 125 PSI.
Disconnect air supply before
servicing and when not in use.
a
CAUTION
Hydraulics can
easily crush bone!
Keep all
appendages
clear of moving
components.
High pressure
hydraulic fluid can
cut through skin!
Cut power and
depressurize
hydraulic system
before servicing
hoses or fittings.
The blade is
extremely sharp!
Keep hands clear
of blade when
operating or
servicing.
1/4” (6mm)
From
Blade

Adjustments:
Blade Depth
To increase the cut depth, rotate the
adjustment knobs clockwise. Ensure that
both knobs are rotated an equal amount. (C)
Hydraulic Fluid Levels
Approximately every 90 days, refill your
hydraulic cylinders using 0W30 motor oil or
ISO32 oil. (This is included in the Paladin 9”
Maintenance Kit #1009SMK.)
1. Tip shear so blade is on top. (You should
have a helper hold it.)
2. Remove fill plugs with 7/16” socket.
3. Carefully top off hydraulic cylinders.
NOTE: It will not take much.
4. Coat plug threads with PTFE tape or
thread sealant. Replace fill plugs.
5. Set shear back on it’s feet.
DANGER
HIGH PRESSURE
HYDRAULIC FLUID
c
www.BulletTools.com • 208-772-0175
PRT-INS-1009_A ©2017 Bullet Tools
Wear ANSI approved safety
glasses, gloves, coveralls,
and steel-toed boots when
operating or bystanding.
3. Operation
Insert plank to desired cut position. Ensure that groove is
seated against the tongue of one of the support planks.
Pull actuation toggle until cut is complete. (B)
Note: The ‘drop’ piece is cut with a steep bevel, while the ‘keep’
piece is cut squarely.
b

All hydraulic/pneumatic parts are covered
separately by a 90 day warranty.
THE FOLLOWING PALADIN PARTS WEAR DURING NORMAL OPERATION
AND ARE NOT COVERED BY THE BULLET TOOLS WARRANTY:
GEN-AIR-0375 .........................................................................................3/8” Tubing
GEN-ORN-0010........................................................................................-010 O ring
GEN-ORN-0012........................................................................................-012 O ring
GEN-ORN-0021........................................................................................-021 O ring
GEN-ORN-0248........................................................................................-248 O ring
GEN-VLV-0162................................................................................Pneumatic Valve
MB93-P009....................................................................................................9” Blade
CON-BST-B909......................................................................................9” Bladestop
You may purchase a full set of these parts by ordering a Paladin 9” Maintenance Kit #1009SMK
More info at BulletTools.com
BULLET TOOLS WARRANTY INFO
30 DAY SATISFACTION GUARANTEE
Bullet Tools™ is condent that you will be absolutely pleased with the purchase of our product. If, for any
reason, you are not completely satised with your tool, we will refund your purchase price at any time
within 30 days of your original purchase (receipt required). If you want to return your product under our
30-day no risk trial oer (valid only for purchases made in the US), please contact us at 1-800-406-8998 or
208-772-0175 for return instructions.
BULLETPROOF WARRANTY GOLD 5 YEAR
Bullet Tools™ warrants only to the original purchaser of this product, when purchased from an authorized
reseller or distributor, that this product will be free from defects in material and workmanship under normal
use and service for ve (5) years from initial purchase. This warranty includes all parts except the blade,
items in the Notice above, and cosmetic appearance (chips, dings, scratches) caused by normal use and
wear. This warranty does not cover any damage due to accident, misuse, abuse or negligence. Further, it
is valid only if the product is used with the cut products specied in the cut guide. Please refer to the User
Guide for details or call Bullet Tools™ technical support. In order to recover under this limited warranty, the
purchaser must make claim to Bullet Tools™ within 60 days of occurrence and must present acceptable
proof of original ownership (such as original receipt, warranty card registration, online registration, or other
documentation Bullet Tools™ deems acceptable) for the product. Bullet Tools™, at its option, shall repair or
replace the defective unit covered by this warranty.
Bullet Tools™ disclaims all warranties, express or implied, including all warranties of merchantability and/or
tness for a particular purpose. Additional rights may be available under the laws of your state or province.
Any and all warranties, written or implied, are void with any alterations to the product. Note: Bullet Tools™
shall not be liable for any special, incidental or consequential damages, including but not limited to lost
revenue, lost prots, rental or replacement equipment, downtime, damage to property and third-party
claims, arising out of any theory of recovery, including warranty, contract, statutory or tort.
For warranty service, please visit www.BulletTools.com/warranty-claim, or contact Bullet Tools™ at 1-800-
406-8998 or 1-208-772-0175, for pre-authorization and further instructions.
