Burstner Premio User manual

Instruction manual
Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
© 2013 Bürstner GmbH Kehl
Instruction manual
Dear Reader ...
We would like to congratulate you on the purchase of your new caravan. You have selected a top-quality
vehicle which will afford you many years of enjoyment.
To enable you to always use and operate your caravan properly and easily, your Bürstner dealer will first pro-
vide you detailed instructions for all important functions when you take delivery.
This manual, as well as the instruction manuals from the appliance manufacturers are your constant travelling
companions and will help answer any questions you may have regarding your caravan.
Before your first journey
Please familiarise yourself with this manual rather than relying on it strictly for reference.
Fill in the warranty cards for the appliances and special equipment in the individual instructions and send these
cards to the respective manufacturers. This ensures your warranty claim for each appliance.

Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Instruction manual

3Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Contents
1Introduction. . . . . . . . . . . . . . . . . . . 7
1.1 General . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2 Environmental tips. . . . . . . . . . . . . . . . . 8
2Safety. . . . . . . . . . . . . . . . . . . . . . . . 11
2.1 Fire prevention . . . . . . . . . . . . . . . . . . 11
2.1.1 Avoidance of fire risks. . . . . . . . . . . . . 11
2.1.2 Fire-fighting . . . . . . . . . . . . . . . . . . . . . 11
2.1.3 In case of fire. . . . . . . . . . . . . . . . . . . . 11
2.2 General . . . . . . . . . . . . . . . . . . . . . . . . 12
2.3 Road safety. . . . . . . . . . . . . . . . . . . . . 12
2.4 Towing. . . . . . . . . . . . . . . . . . . . . . . . . 13
2.5 Gas system . . . . . . . . . . . . . . . . . . . . . 14
2.5.1 General instructions . . . . . . . . . . . . . . 14
2.5.2 Gas bottles . . . . . . . . . . . . . . . . . . . . . 15
2.6 Electrical system . . . . . . . . . . . . . . . . . 16
2.7 Water system . . . . . . . . . . . . . . . . . . . 16
3 Before the journey . . . . . . . . . . . 17
3.1 Keys . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.2 Registration. . . . . . . . . . . . . . . . . . . . . 17
3.3 Connecting . . . . . . . . . . . . . . . . . . . . . 18
3.4 Detaching . . . . . . . . . . . . . . . . . . . . . . 19
3.5 Caravan couplings . . . . . . . . . . . . . . . 19
3.5.1 AKS 1300 stabiliser. . . . . . . . . . . . . . . 19
3.5.2 AKS 3004 stabiliser. . . . . . . . . . . . . . . 20
3.6 Caravan control system (ATC)
(special equipment). . . . . . . . . . . . . . . 20
3.7 Manoeuvring system (special
equipment) . . . . . . . . . . . . . . . . . . . . . 21
3.8 Payload . . . . . . . . . . . . . . . . . . . . . . . . 23
3.8.1 Terms . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.8.2 Calculating the payload. . . . . . . . . . . . 25
3.8.3 Loading the caravan correctly. . . . . . . 26
3.8.4 Caravan load, nose weight and
axle load . . . . . . . . . . . . . . . . . . . . . . . 27
3.8.5 Roof rail and rear ladder (Averso
Nature) . . . . . . . . . . . . . . . . . . . . . . . . 28
3.8.6 Bike rack (special equipment). . . . . . . 29
3.9 External mirrors. . . . . . . . . . . . . . . . . . 30
3.10 TV unit (special equipment) . . . . . . . . 31
3.11 Securing components . . . . . . . . . . . . . 31
3.12 Road safety. . . . . . . . . . . . . . . . . . . . . 32
4 During the journey . . . . . . . . . . . 35
4.1 Driving with the caravan . . . . . . . . . . . 35
4.2 Brakes. . . . . . . . . . . . . . . . . . . . . . . . . 35
4.3 Driving in reverse . . . . . . . . . . . . . . . . 35
5 Pitching the caravan . . . . . . . . . 37
5.1 Handbrake. . . . . . . . . . . . . . . . . . . . . . 37
5.2 Wheel chocks . . . . . . . . . . . . . . . . . . . 37
5.3 Corner steadies (partially special
equipment) . . . . . . . . . . . . . . . . . . . . . 37
5.4 Entrance step (free-standing) . . . . . . . 39
5.5 Waste water tank, mobile (special
equipment) . . . . . . . . . . . . . . . . . . . . . 39
5.6 230 V connection . . . . . . . . . . . . . . . . . 39
5.7 Refrigerator . . . . . . . . . . . . . . . . . . . . . 39
5.8 Satellite unit (special equipment). . . . . 40
5.8.1 Equipment with automatic antenna
alignment (Alden). . . . . . . . . . . . . . . . . 40
5.8.2 Equipment with semi-automatic
antenna alignment (Alden). . . . . . . . . . 41
5.8.3 Equipment with automatic antenna
alignment (Oyster) . . . . . . . . . . . . . . . . 42
6Living. . . . . . . . . . . . . . . . . . . . . . . . 43
6.1 Conversion door . . . . . . . . . . . . . . . . . 43
6.1.1 Conversion door, outside. . . . . . . . . . . 43
6.1.2 Conversion door, inside . . . . . . . . . . . . 44
6.1.3 Window conversion door (special
equipment). . . . . . . . . . . . . . . . . . . . . . 44
6.1.4 Folding insect screen on the
conversion door (special
equipment). . . . . . . . . . . . . . . . . . . . . . 45
6.2 External flaps . . . . . . . . . . . . . . . . . . . . 45
6.2.1 Flap lock, elliptical-shaped. . . . . . . . . . 46
6.2.2 Flap lock with recessed handle . . . . . . 47
6.2.3 Flap lock, rectangular . . . . . . . . . . . . . 47
6.2.4 Flap for toilet cassette . . . . . . . . . . . . . 48
6.2.5 Flap for the 230 V connection,
square . . . . . . . . . . . . . . . . . . . . . . . . . 48
6.2.6 Cap for the drinking water filler
neck (only for water tank 40 l) . . . . . . . 49
6.3 Furniture flaps . . . . . . . . . . . . . . . . . . . 49
6.3.1 Furniture flaps with push button. . . . . . 49
6.3.2 Furniture flaps with handle. . . . . . . . . . 50
6.3.3 Furniture flaps with release handle . . . 50
6.4 Light switch . . . . . . . . . . . . . . . . . . . . . 51
6.4.1 Entrance area . . . . . . . . . . . . . . . . . . . 51
6.4.2 Living area . . . . . . . . . . . . . . . . . . . . . . 51
6.4.3 Recessed light with LED . . . . . . . . . . . 52
6.5 Spotlight. . . . . . . . . . . . . . . . . . . . . . . . 52
6.6 Spotlight (moveable) . . . . . . . . . . . . . . 53
6.7 Holder for flat screen . . . . . . . . . . . . . 53
6.7.1 Holder on the column. . . . . . . . . . . . . . 54
6.7.2 Rail-mounted holder . . . . . . . . . . . . . . 54
6.7.3 Holder in the TV cabinet . . . . . . . . . . . 55
6.7.4 Holder in the TV compartment. . . . . . . 55
6.8 Heating . . . . . . . . . . . . . . . . . . . . . . . . 56
6.9 Ventilation . . . . . . . . . . . . . . . . . . . . . . 56
6.10 Windows . . . . . . . . . . . . . . . . . . . . . . . 57
6.10.1 Hinged window with rotary hinges . . . . 58
6.10.2 Hinged window with automatic
hinges . . . . . . . . . . . . . . . . . . . . . . . . . 60
6.10.3 Blind and insect screen . . . . . . . . . . . . 61
6.10.4 Blind and insect screen . . . . . . . . . . . . 62
6.10.5 Roman shade and insect screen . . . . . 63
6.11 Skylights . . . . . . . . . . . . . . . . . . . . . . . 64
6.11.1 Heki skylight (mini and midi)
(partially special equipment) . . . . . . . . 64
6.11.2 Heki skylight (special equipment) . . . . 66
6.12 Tables . . . . . . . . . . . . . . . . . . . . . . . . . 67

Contents
4Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
6.12.1 Suspension table with folding leg. . . . . 67
6.12.2 Swivel table . . . . . . . . . . . . . . . . . . . . . 68
6.12.3 Suspension table and swivel table. . . . 68
6.12.4 Lift-off table . . . . . . . . . . . . . . . . . . . . . 69
6.12.5 Suspension table and lift-off table . . . . 69
6.13 Beds. . . . . . . . . . . . . . . . . . . . . . . . . . . 70
6.13.1 Bunk bed . . . . . . . . . . . . . . . . . . . . . . . 70
6.13.2 Fixed bed (manual setup) . . . . . . . . . . 70
6.13.3 Fixed bed (spring release lever) . . . . . 71
6.13.4 Pull-down bed, manually operated
(Averso Plus) . . . . . . . . . . . . . . . . . . . . 71
6.13.5 Widening single beds (special
equipment) . . . . . . . . . . . . . . . . . . . . . . 73
6.14 Converting seating groups for
sleeping . . . . . . . . . . . . . . . . . . . . . . . . 74
6.14.1 Bench and central seating group
without additional cushion . . . . . . . . . . 75
6.14.2 Bench and central seating group
with additional cushion. . . . . . . . . . . . . 76
6.14.3 Round seating group with additional
cushion (foldable). . . . . . . . . . . . . . . . . 77
6.14.4 Round seating group without
additional cushion . . . . . . . . . . . . . . . . 78
6.14.5 Round seating group with additional
cushion. . . . . . . . . . . . . . . . . . . . . . . . . 79
6.14.6 Round seating group with bed
widening. . . . . . . . . . . . . . . . . . . . . . . . 80
6.14.7 L-seating group with additional
cushion. . . . . . . . . . . . . . . . . . . . . . . . . 81
6.15 Shower connection point for external
shower (special equipment) . . . . . . . . . 82
7 Gas system. . . . . . . . . . . . . . . . . . . 83
7.1 General . . . . . . . . . . . . . . . . . . . . . . . . 83
7.2 Gas bottles. . . . . . . . . . . . . . . . . . . . . . 84
7.3 Changing gas bottles . . . . . . . . . . . . . . 85
7.4 Gas isolator taps . . . . . . . . . . . . . . . . . 86
7.5 External gas connection (special
equipment) . . . . . . . . . . . . . . . . . . . . . . 86
7.6 Crash protection unit switching
facility (special equipment). . . . . . . . . . 87
8 Electrical system . . . . . . . . . . . . . 91
8.1 General safety instructions . . . . . . . . . 91
8.2 Terms. . . . . . . . . . . . . . . . . . . . . . . . . . 91
8.3 12 V power supply . . . . . . . . . . . . . . . . 91
8.3.1 Power supply unit CSV 300 . . . . . . . . . 92
8.4 Electric kit (special equipment) . . . . . . 93
8.4.1 Living area battery . . . . . . . . . . . . . . . . 93
8.4.2 Power supply unit CSV 409 . . . . . . . . . 94
8.4.3 Panel LT 408 . . . . . . . . . . . . . . . . . . . . 96
8.4.4 Connection diagrams . . . . . . . . . . . . . . 98
8.5 230 V power supply . . . . . . . . . . . . . . 100
8.5.1 230 V connection . . . . . . . . . . . . . . . . 100
8.5.2 Connecting 230 V power supply . . . . 101
8.6 Fuses . . . . . . . . . . . . . . . . . . . . . . . . . 102
8.6.1 12 V fuses . . . . . . . . . . . . . . . . . . . . . 102
8.6.2 230 V fuse . . . . . . . . . . . . . . . . . . . . .104
8.7 Thirteen-pin plug connection
diagram. . . . . . . . . . . . . . . . . . . . . . . .105
8.8 External socket (special
equipment) . . . . . . . . . . . . . . . . . . . . .106
8.9 Circuit diagrams . . . . . . . . . . . . . . . . .107
8.9.1 Circuit diagram, interior . . . . . . . . . . .107
8.9.2 Circuit diagram, exterior . . . . . . . . . . .108
9 Appliances. . . . . . . . . . . . . . . . . . .109
9.1 General. . . . . . . . . . . . . . . . . . . . . . . .109
9.2 Heater. . . . . . . . . . . . . . . . . . . . . . . . .110
9.2.1 Models with waste gas vent on the
right-hand side of the vehicle . . . . . . .110
9.2.2 To heat properly . . . . . . . . . . . . . . . . .110
9.2.3 Trumatic S 3004/S 5004 hot-air
heater . . . . . . . . . . . . . . . . . . . . . . . . .111
9.2.4 Airmix comfort package (special
equipment) . . . . . . . . . . . . . . . . . . . . .113
9.2.5 Ultraheat additional electric heater
(special equipment) . . . . . . . . . . . . . .114
9.2.6 Warming unit for waste water pipes
(special equipment) . . . . . . . . . . . . . .115
9.2.7 Electrical floor warming unit (special
equipment) . . . . . . . . . . . . . . . . . . . . .116
9.3 Air conditioning unit (special
equipment) . . . . . . . . . . . . . . . . . . . . .117
9.3.1 Dometic . . . . . . . . . . . . . . . . . . . . . . .117
9.3.2 Telair. . . . . . . . . . . . . . . . . . . . . . . . . .118
9.3.3 Truma . . . . . . . . . . . . . . . . . . . . . . . . .120
9.4 Boiler . . . . . . . . . . . . . . . . . . . . . . . . .121
9.4.1 Models with waste gas vent on the
right-hand side of the vehicle . . . . . . .122
9.4.2 Truma boiler (special equipment) . . . .122
9.4.3 Hot water source (partially special
equipment) . . . . . . . . . . . . . . . . . . . . .124
9.5 Cooker . . . . . . . . . . . . . . . . . . . . . . . .126
9.5.1 Gas cooker . . . . . . . . . . . . . . . . . . . . .126
9.5.2 Gas oven (Dometic) (special
equipment) . . . . . . . . . . . . . . . . . . . . .128
9.5.3 Microwave oven (special
equipment) . . . . . . . . . . . . . . . . . . . . .130
9.5.4 Extractor hood (special
equipment) . . . . . . . . . . . . . . . . . . . . .131
9.6 Refrigerator. . . . . . . . . . . . . . . . . . . . .131
9.6.1 Refrigerator ventilation grill. . . . . . . . .132
9.6.2 Operation (Dometic 8 series with
manual ignition) . . . . . . . . . . . . . . . . .133
9.6.3 Operation (Dometic 8 series with
manual power selection MES) . . . . . .134
9.6.4 Operation (Thetford N3000) . . . . . . . .136
9.6.5 Refrigerator door locking
mechanism . . . . . . . . . . . . . . . . . . . . .139
10 Sanitary fittings . . . . . . . . . . . . . .141
10.1 Water supply, general. . . . . . . . . . . . .141
10.2 Water tank . . . . . . . . . . . . . . . . . . . . .142

5Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Contents
10.2.1 Water tank 16 l . . . . . . . . . . . . . . . . . 142
10.2.2 Water tank 22 l with external flap
(special equipment). . . . . . . . . . . . . . 142
10.2.3 Water tank 40 l (partially special
equipment) . . . . . . . . . . . . . . . . . . . . 143
10.3 Waste water tank (special
equipment) . . . . . . . . . . . . . . . . . . . . 144
10.4 Warming unit of waste water pipes
(special equipment). . . . . . . . . . . . . . 145
10.5 Filling the water system. . . . . . . . . . . 145
10.6 Emptying the water system. . . . . . . . 146
10.7 Toilet compartment . . . . . . . . . . . . . . 147
10.8 Toilet . . . . . . . . . . . . . . . . . . . . . . . . . 147
10.8.1 Preparing toilet . . . . . . . . . . . . . . . . . 148
10.8.2 Swivel toilet . . . . . . . . . . . . . . . . . . . . 149
10.8.3 Toilet with fixed seat . . . . . . . . . . . . . 150
10.8.4 Emptying the sewage tank . . . . . . . . 151
11 Care. . . . . . . . . . . . . . . . . . . . . . . . . 153
11.1 External care. . . . . . . . . . . . . . . . . . . 153
11.1.1 General . . . . . . . . . . . . . . . . . . . . . . . 153
11.1.2 Washing with a high-pressure
cleaner . . . . . . . . . . . . . . . . . . . . . . . 153
11.1.3 Washing the vehicle . . . . . . . . . . . . . 154
11.1.4 Windows of acrylic glass . . . . . . . . . . 154
11.1.5 Hot galvanized chassis . . . . . . . . . . . 154
11.1.6 Underbody. . . . . . . . . . . . . . . . . . . . . 155
11.2 Interior care. . . . . . . . . . . . . . . . . . . . 155
11.3 Water system . . . . . . . . . . . . . . . . . . 156
11.3.1 Cleaning the waste water tank . . . . . 156
11.3.2 Cleaning the water tank . . . . . . . . . . 156
11.3.3 Cleaning the water pipes. . . . . . . . . . 157
11.3.4 Disinfecting the water system . . . . . . 157
11.4 Extractor hood. . . . . . . . . . . . . . . . . . 158
11.5 Air conditioning unit. . . . . . . . . . . . . . 158
11.5.1 Dometic . . . . . . . . . . . . . . . . . . . . . . . 158
11.5.2 Telair . . . . . . . . . . . . . . . . . . . . . . . . . 158
11.5.3 Truma . . . . . . . . . . . . . . . . . . . . . . . . 159
11.6 Winter care . . . . . . . . . . . . . . . . . . . . 159
11.6.1 Preparations . . . . . . . . . . . . . . . . . . . 159
11.6.2 Winter operation . . . . . . . . . . . . . . . . 160
11.6.3 At the end of the winter season. . . . . 160
11.7 Lay-up . . . . . . . . . . . . . . . . . . . . . . . . 160
11.7.1 Temporary lay-up . . . . . . . . . . . . . . . 160
11.7.2 Winter lay-up. . . . . . . . . . . . . . . . . . . 162
11.7.3 Starting up the vehicle after a
temporary lay-up or after lay-up
over winter. . . . . . . . . . . . . . . . . . . . . 163
12 Maintenance . . . . . . . . . . . . . . . . 165
12.1 Inspection work . . . . . . . . . . . . . . . . . 165
12.2 Maintenance work. . . . . . . . . . . . . . . 165
12.3 Stabilisers . . . . . . . . . . . . . . . . . . . . . 165
12.3.1 General . . . . . . . . . . . . . . . . . . . . . . . 165
12.3.2 AKS 1300 . . . . . . . . . . . . . . . . . . . . . 166
12.3.3 AKS 3004 . . . . . . . . . . . . . . . . . . . . . 166
12.4 Manoeuvring system . . . . . . . . . . . . . 167
12.5 Braking system . . . . . . . . . . . . . . . . . 167
12.6 Doors . . . . . . . . . . . . . . . . . . . . . . . . . 167
12.7 Replacing bulbs, external . . . . . . . . . 168
12.7.1 Front lights . . . . . . . . . . . . . . . . . . . . . 169
12.7.2 Rear lights . . . . . . . . . . . . . . . . . . . . . 169
12.7.3 Side lights . . . . . . . . . . . . . . . . . . . . . 170
12.7.4 Types of bulbs for exterior
lighting . . . . . . . . . . . . . . . . . . . . . . . . 170
12.8 Replacing bulbs, internal . . . . . . . . . . 170
12.8.1 Ceiling lamp (cover with clips) . . . . . . 171
12.8.2 Ceiling lamp . . . . . . . . . . . . . . . . . . . . 171
12.8.3 Recessed halogen light . . . . . . . . . . . 172
12.8.4 Recessed halogen light (flat) . . . . . . . 172
12.8.5 Recessed light with LED . . . . . . . . . . 173
12.8.6 Spotlight with flexible arm . . . . . . . . . 173
12.8.7 Halogen spotlight (swivelling) . . . . . . 174
12.8.8 Halogen spotlight (movable) . . . . . . . 174
12.8.9 Garage light . . . . . . . . . . . . . . . . . . . . 175
12.9 Spare parts . . . . . . . . . . . . . . . . . . . . 175
12.10 Vehicle identification plate . . . . . . . . . 176
12.11 Warning and information stickers . . . 176
13 Wheels and tyres . . . . . . . . . . . . 177
13.1 General . . . . . . . . . . . . . . . . . . . . . . . 177
13.2 Tyre selection . . . . . . . . . . . . . . . . . . 178
13.3 Tyre specifications . . . . . . . . . . . . . . . 179
13.4 Handling of tyres . . . . . . . . . . . . . . . . 179
13.5 Changing wheels . . . . . . . . . . . . . . . . 179
13.5.1 General instructions. . . . . . . . . . . . . . 179
13.5.2 Tightening torque. . . . . . . . . . . . . . . . 180
13.5.3 Changing a wheel . . . . . . . . . . . . . . . 182
13.5.4 Changing a wheel at alloy wheel
rims . . . . . . . . . . . . . . . . . . . . . . . . . . 183
13.6 Spare wheel support . . . . . . . . . . . . . 184
13.6.1 Spare wheel support in gas bottle
compartment . . . . . . . . . . . . . . . . . . . 184
13.6.2 Spare wheel support under the
vehicle (special equipment) . . . . . . . . 184
13.6.3 Spare wheel support at the rear
of the vehicle (Averso nature) . . . . . . 185
13.7 Tyre pressure. . . . . . . . . . . . . . . . . . . 185
14 Troubleshooting. . . . . . . . . . . . . 187
14.1 Chassis . . . . . . . . . . . . . . . . . . . . . . . 187
14.2 Braking system . . . . . . . . . . . . . . . . . 187
14.3 Caravan control system (ATC) . . . . . 188
14.4 Manoeuvring system . . . . . . . . . . . . . 189
14.5 Electrical system . . . . . . . . . . . . . . . . 189
14.6 Gas system . . . . . . . . . . . . . . . . . . . . 190
14.7 Cooker . . . . . . . . . . . . . . . . . . . . . . . . 191
14.7.1 Gas cooker/gas oven. . . . . . . . . . . . . 191
14.7.2 Microwave oven. . . . . . . . . . . . . . . . . 191
14.8 Heater, boiler and hot water
source . . . . . . . . . . . . . . . . . . . . . . . . 192
14.8.1 Trumatic S hot-air heater . . . . . . . . . . 192
14.8.2 Truma boiler. . . . . . . . . . . . . . . . . . . . 192
14.8.3 Truma hot water source. . . . . . . . . . . 193

Contents
6Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
14.9 Refrigerator . . . . . . . . . . . . . . . . . . . . 193
14.9.1 Dometic 8 series and Thetford. . . . . . 193
14.9.2 Dometic 8 series with MES . . . . . . . . 194
14.10 Air conditioning unit . . . . . . . . . . . . . . 195
14.10.1 Dometic . . . . . . . . . . . . . . . . . . . . . . . 195
14.10.2 Telair . . . . . . . . . . . . . . . . . . . . . . . . . 196
14.10.3 Truma. . . . . . . . . . . . . . . . . . . . . . . . . 196
14.11 Water supply . . . . . . . . . . . . . . . . . . . 196
14.12 Body. . . . . . . . . . . . . . . . . . . . . . . . . . 198
15 Special equipment. . . . . . . . . . . 199
15.1 Weight details for special
equipment . . . . . . . . . . . . . . . . . . . . . 199
16 Technical data . . . . . . . . . . . . . . . 201
16.1 Table of linear measures . . . . . . . . . . 201
16.2 Power supply . . . . . . . . . . . . . . . . . . . 202
17 Helpful notes . . . . . . . . . . . . . . . . 203
17.1 Traffic rules in foreign countries. . . . . 203
17.2 Help on Europe's roads . . . . . . . . . . . 203
17.3 Speed limits . . . . . . . . . . . . . . . . . . . . 205
17.4 Driving with low beam in European
countries . . . . . . . . . . . . . . . . . . . . . . 207
17.5 Sleeping in the vehicle away from
camping areas . . . . . . . . . . . . . . . . . . 207
17.6 Gas supply in European
countries . . . . . . . . . . . . . . . . . . . . . . 209
17.7 Toll regulations in European
countries . . . . . . . . . . . . . . . . . . . . . . 210
17.8 Tips on staying overnight safely
during travel . . . . . . . . . . . . . . . . . . . . 210
17.9 Tips for winter campers . . . . . . . . . . . 210
17.10 Travel checklists . . . . . . . . . . . . . . . . 211
18 Inspection plan . . . . . . . . . . . . . . 213

7Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Introduction 1
1Introduc tion
Please read this instruction manual completely before
using the vehicle for the first time!
Always keep this instruction manual in the vehicle. Also inform all other users
of the safety regulations.
This instruction manual contains sections which describe model-spe-
cific equipment or special equipment. These sections are specially
marked. It may be that your vehicle has not been fitted with this special
equipment. In some cases, the actual equipment of your vehicle may
therefore be different from that shown in some illustrations and descrip-
tions.
However, your vehicle may be fitted with other special equipment not
described in this instruction manual.
Special equipment is described when an explanation is required.
Adhere to the instruction manuals which are separately enclosed.
Should the vehicle be subjected to damage due to a failure to follow the
instructions in this instruction manual, then the guarantee claim is deemed
invalid.
Our vehicles are subjected to continuous development. Please understand
that we reserve the right to alter the form, equipment and technology. There-
fore, no claims can be made against the manufacturer as a result of the con-
tents of this instruction manual. The equipment which was known and included
at the time of going to press is described.
The reprinting, translation and copying, including extracts is not permitted
without prior written authorisation from the manufacturer.
XThe non-observance of this symbol can lead to personal injury.
ZThe non-observance of this symbol can lead to damage being caused to,
or inside the vehicle.
ZThis symbol indicates recommendations or special aspects.
ZThis symbol indicates actions which lead to environmental awareness.
ZThe details "right", "left", "front" and "rear" always refer to the vehicle in
direction of travel.
ZAll dimensions and weight details are "approximate".
ZThe vehicle comes without a wheelbrace and vehicle jack. We suggest you
obtain a commercially available wheelbrace before you first use your car-
avan, in case of an emergency. If no AL-KO vehicle jack (special equip-
ment for AL-KO chassis) is present, obtain a conventional commercial
scissor-type jack or an hydraulic vehicle jack, in order to have it ready in
the case of mishap or emergency. Our authorised dealers and service cen-
tres will be happy to advise you.

8Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Introduction
1
1.1 General
The vehicle is constructed in accordance with the latest technology and the
recognised safety regulations. Nevertheless, personal injury may result and
the vehicle may be damaged if the safety instructions in this instruction manual
are not followed.
Only use the vehicle in a technically impeccable condition. Follow the instruc-
tions in the instruction manual.
Malfunctions which impair the safety of persons or the vehicle should be
immediately remedied by qualified personnel.
Have the vehicle's braking and gas systems inspected and repaired by an
authorised specialist workshop only.
Alterations to the body are only to be carried out with the authorisation of the
manufacturer.
Luggage and accessories may only be transported up to the maximum permis-
sible gross weight.
Observe the test and inspection periods stipulated by the manufacturer.
1.2 Environmental tips
ZBe considerate of the environment.
ZRemember that: All kinds of waste water and household waste are not to
be disposed of in drains or in the open countryside.
ZOn board, collect waste water only in the waste water tank or – if
necessary – in other containers designed for that purpose.
ZOnly empty the waste water tank and toilet cassette or sewage tank at dis-
posal stations at the camping or caravan sites, which are especially pro-
vided for this purpose. When stopping in towns and communities, observe
the instructions at caravan sites or ask where there are disposal stations.
ZEmpty waste water tank as often as possible, even when it is not com-
pletely full (hygiene).
If possible, flush out waste water tank and, if necessary, drainage pipe with
fresh water every time it is emptied.
ZNever allow the toilet cassette or sewage tank to become too full. Empty
the toilet cassette or sewage tank frequently, at the latest as soon as the
level indicator lights up.
ZSeparate household waste according to glass, tin cans, plastic and wet
waste also when on a journey. Enquire at the town or community authority
about disposal points. Household waste is not to be disposed of in waste
paper baskets which are situated at car parks.
ZEmpty waste bins as often as possible into the containers provided for this
purpose. This helps to avoid unpleasant smells and an accumulation of
rubbish on board.
ZWhen parked, do not allow the engine of the towing vehicle to run more
than necessary. When running idle, a cold engine releases more contami-
nants than usual. The running temperature of the engine is achieved more
quickly whilst the vehicle is in motion.
ZUse an environmentally-friendly WC chemical agent for the WC which can
also be biologically degraded and only use small doses.

9Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Introduction 1
ZWhen staying in towns and communities for long periods, search for
parking areas which are specially reserved for caravans and towing vehi-
cles. Enquire at the town or community authority about parking spaces.
ZAlways leave the parking places in a clean condition.

10 Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Introduction
1

11Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Safety 2
2Safety
Chapter overview
This chapter contains important safety instructions. The safety instructions are
for the protection of persons and property.
The instructions address the following topics:
zfire prevention and what to do in case of fire
zgeneral care of the vehicle
zroad safety of the vehicle
ztowing
zgas system of the vehicle
zelectrical system of the vehicle
zwater system of the vehicle
2.1 Fire prevention
2.1.1 Avoidance of fire risks
2.1.2 Fire-fighting
2.1.3 In case of fire
XNever leave children in the vehicle unattended.
XKeep flammable materials clear of heating and cooking appliances.
XLights can get very hot. When the light is switched on, there must always
be a safety distance of 30 cm between light and flammable objects. Fire
hazard!
XNever use portable heating or cooking appliances.
XOnly authorised qualified personnel may make changes to the electrical
system, gas system or appliances.
XAlways carry a dry powder fire extinguisher in the vehicle. The fire extin-
guisher must be approved, tested and close at hand.
XThe fire extinguisher is not included in the scope of delivery.
XHave the fire extinguisher tested at regular intervals by authorised qual-
ified personnel. Observe the date of testing.
XAlways keep a fire blanket near the cooker.
XEvacuate all passengers.
XCut off the electrical power supply and disconnect from the mains.
XClose regulator tap on the gas bottle.
XSound the alarm and call the fire brigade.
XFight the fire if this is possible without risk.
ZAcquaint yourself with the position and operation of the emergency exits.
ZKeep escape routes clear.
ZObserve the fire extinguisher instructions for use.

12 Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Safety
2
All windows and doors which meet the following requirements are considered
as emergency exits:
zOpen to the outside or can be shifted in horizontal direction
zOpening angle at least 70°
zMinimum diameter of clearance = 450 mm
zMaximum distance from the vehicle floor = 950 mm
2.2 General
2.3 Road safety
XThe oxygen in the vehicle interior is used up by breathing and the use of
gas operated appliances. That is why the oxygen needs to be replaced
on a constant basis. For this purpose, forced ventilation options (e.g.
skylights with forced ventilation, mushroom-shaped vents or floor vents)
are fitted to the vehicle. Never cover or block forced ventilations from the
inside or outside with objects such as e.g. a winter mat. Keep forced ven-
tilations clear of snow and leaves. There is a danger of suffocation due
to increased CO2levels.
XObserve the headroom of the doors.
ZAs far as the appliances (heater, cooker, refrigerator, etc.) are concerned,
the instruction manuals are authoritative. It is imperative that they be
observed.
ZFitting accessories or special equipment can alter the dimensions, weight
and road behaviour of the vehicle. Some of the parts must be entered in
the vehicle papers.
ZOnly use wheel rims and tyres which are approved for the vehicle. Informa-
tion concerning the size of the approved wheel rims and tyres is included
in the vehicle documents or can be obtained from authorised dealers and
service centres.
ZFirmly apply the handbrake when parking the vehicle.
ZWhen leaving the vehicle, it is imperative that all doors, external flaps and
windows are closed.
ZThe vehicle may only be driven by drivers who hold a driving licence which
is valid for the respective vehicle class.
ZWhen selling the vehicle, hand over all instruction manuals for the vehicle
and the fitted appliances.
XBefore commencing the journey, carry out a functional check of indi-
cating and lighting equipment and the brakes.
XIf the vehicle has been stationary for a long period (approx. 10 months)
have the braking and gas systems checked by an authorised specialist
workshop.
XBefore commencing the journey, secure the hinged pull-down bed.
XBefore commencing the journey, store the television securely.
XBefore commencing the journey, place and secure the flat screen and
screen support in the initial position. If the screen holder is installed in a
TV cabinet: Close TV cabinet.
XDuring the journey, no persons are to travel inside the caravan.

13Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Safety 2
2.4 Towing
XIn case of underpasses, tunnels or similar obstacles, note the total
height of the vehicle (including the roof load).
XIn winter, the roof must be free of snow and ice before commencing the
journey.
XBefore commencing the journey, empty the waste water tank.
XCheck tyre pressure before a journey or every 2 weeks. Wrong tyre
pressure causes excessive wear and can lead to damage or even to tyre
burst. You can lose control of the vehicle.
ZBefore commencing the journey, distribute the payload evenly within the
vehicle (see chapter 3).
ZWhen loading the vehicle and when taking a rest from driving, in order to
load luggage or food, for example, observe the maximum permissible
gross weight and axle loads (refer to vehicle documents).
ZDo not exceed the maximum permissible nose weight on the caravan cou-
pling and do not let the weight fall below the minimum nose value. Load the
caravan accordingly.
ZWhile driving with your caravan, the towing vehicle must be equipped with
two external mirrors.
ZBefore commencing the journey, ensure that all cupboard doors, the toilet
compartment door and all drawers and flaps are secure. Engage the refrig-
erator door securing device.
ZBefore commencing the journey, close windows and skylights.
ZBefore commencing the journey, close all external flaps and lock them.
ZBefore commencing the journey, remove the external supports and retract
the corner steadies or steady legs, which are fitted to the vehicle.
ZBefore commencing the journey, crank the jockey wheel up as far as pos-
sible.
ZBefore commencing the journey, put the antenna in park position.
ZDuring the initial journey and each time after changing a wheel, re-tighten
the wheel bolts/wheel nuts after 50 km (30 miles). Subsequently inspect
them at regular intervals in order to ensure that they are firmly seated.
ZTyres may not be older than 6 years as the material becomes brittle over
time (see chapter 13).
XCare is to be taken when connecting and detaching a trailer. Risk of acci-
dent and injury!
XNo persons are to be between the towing vehicle and the trailer during
positioning for connecting and detaching.

14 Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Safety
2
2.5 Gas system
2.5.1 General instructions
XBefore commencing the journey, when leaving the vehicle or when gas
equipment is not in use, close all gas isolator taps and the main isolator
tap on the gas bottle.
XNo appliance operated by a naked flame (e.g. heater or refrigerator) may
be in operation when filling the tank, on ferries or in the garage. Danger
of explosion!
XDo not use appliances operated with a naked flame in closed spaces
(e.g. garages). Danger of poisoning and suffocation!
XOnly have the gas system maintained, repaired or altered by an author-
ised specialist workshop.
XHave the gas system checked by an authorised specialist workshop
according to the national regulations before commissioning. This also
applies for not registered vehicles. For modifications to the gas system
have the gas system immediately checked by an authorised specialist
workshop.
XThe gas pressure regulator and exhaust gas pipes must also be
inspected. The gas pressure regulator has to be replaced after 10 years
at the latest. The vehicle owner is responsible for seeing that this is car-
ried out.
XIn case of a defect of the gas system (gas odour, high gas consumption)
there is danger of explosion! Close regulator tap on the gas bottle imme-
diately. Open doors and windows and ventilate well.
XIf the gas system is defective: Do not smoke; do not ignite any open
flames, and do not operate electric switches (light switches etc.).
XBefore using the cooker make sure that there is sufficient ventilation.
Open windows or the skylight.
XDo not use the gas cooker or gas oven for heating purposes.
XIf there are several gas devices, each gas device must have its own gas
isolator tap. If individual gas devices are not in use, close the respective
gas isolator tap.
XIgnition safety valves must close within 1 minute after the gas flame has
extinguished. A clicking sound is audible. Check function from time to
time.
XThe built-in gas devices are exclusively meant for use with propane or
butane gas or a mixture of both. The gas pressure regulator as well as
all built-in gas devices are designed for a gas pressure of 30 mbar.
XPropane gas is capable of gasification up to -42 °C, whereas butane gas
gasifies at 0 °C. Below these temperatures no gas pressure is available.
Butane gas is unsuitable for use in winter.
XRegularly inspect the gas tube fitted to the gas bottle connection for
tightness. The gas tube must not have any tears and must not be
porous. Have the gas tube replaced by an authorised specialist work-
shop no later than ten years after the manufacturing date. The operator
of the gas system must see to it that the parts are replaced.
XDue to its function and construction, the gas bottle compartment is a
space which is open to the exterior. Never cover or block up the standard
forced ventilations. Otherwise gas that is emitted can not be diverted to
the outside.

15Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Safety 2
2.5.2 Gas bottles
XThe gas bottle compartment must not be used as storage space.
XSecure the gas bottle compartment against unauthorised access. To do
this, lock the compartment.
XThe regulator tap on the gas bottle must be accessible.
XOnly connect gas-operated devices (e.g. gas grill) which have been
designed for a gas pressure of 30 mbar.
XThe exhaust gas pipe must be fitted tightly to the heating system and to
the vent and must be sealed. The exhaust gas pipe must not show any
evidence of damage.
XExhaust fumes must be able to escape into the atmosphere unhindered
and fresh air must be able to enter unhindered. For this reason, keep the
exhaust pipe and intake openings clean and unobstructed (e.g. free from
snow and ice). For this reason, no snow walls or aprons may lie against
the vehicle.
XGas bottles are only to be transported within the designated gas bottle
compartment.
XPlace the gas bottles in vertical position in the gas bottle compartment.
XFasten the gas bottles so that they are unable to turn or tilt.
XIf the gas bottles are not connected to the gas tube, always place the
protective cap on top.
XClose the regulator tap on the gas bottle before the gas pressure regu-
lator or gas tube are removed from the gas bottle.
XUse your hands only to connect the gas pressure regulator or the gas
tube to the gas bottles. Do not use any tools.
XOnly use special gas pressure regulators with a safety valve designed
for vehicle use. Other gas pressure regulators are not permitted and
cannot meet the demanding requirements.
XUse the gas pressure regulator defroster if the temperature falls below
5°C.
XUse only 11 kg or 5 kg gas bottles. Camping gas bottles with built-in
check valve (blue bottle with max. 2.5 or 3 kg content) are can be used
in exceptional cases with a safety valve.
XUse the shortest possible tube lengths (150 cm max.) for external gas
bottles.
XNever block the floor ventilation openings below the gas bottles.

16 Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Safety
2
2.6 Electrical system
2.7 Water system
XOnly allow qualified personnel to work on the electrical system.
XPrior to carrying out work on the electrical system, switch off all devices
and lights, disconnect the battery and disconnect the vehicle from the
mains.
XOnly use original fuses with the stipulated values.
XOnly replace defective fuses when the cause of the defect is known and
has been remedied.
XNever bridge or repair fuses.
XWater left standing in the water tank or in the water pipes becomes
undrinkable after a short period. Therefore, before each use of the
vehicle, thoroughly clean the water pipes and the water tank. After each
use of the vehicle completely empty the water tank and the water pipes.
XIn the case of lay-ups lasting more than a week disinfect the water
system before using the vehicle (see chapter 11).
ZIf the vehicle is not used for several days or if it is not heated when there is
a risk of frost, empty the entire water system. Make sure that the 12 V
power supply on the panel is switched off. Otherwise, the water pump will
overheat and may get damaged. Leave the water taps on in central posi-
tion. Leave the safety/drainage valve (if there is one) and all drain cocks
open. Frost damage to appliances, frost damage to the vehicle and
deposits in water-carrying components can be avoided in this way.

17Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Before the journey 3
3Before the jou rney
Chapter overview
This chapter contains important information which has to be noted before com-
mencing your journey or carrying out any tasks before the journey.
The instructions address the following topics:
zkeys
zregistration
zconnecting and detaching to the towing vehicle
zcaravan coupling
zcaravan control system
zmanoeuvring system
zcalculating the payload
zcorrect loading of the caravan
zexternal mirrors
zstoring the television
zsecuring components
At the end of the chapter there is a checklist which once again summarises the
most important points.
3.1 Keys
Two keys (Fig. 1) are included with the caravan.
The keys fit the:
zConversion door
zService flaps
zToilet flap
zGas bottle compartment flap
Always deposit a replacement key outside the vehicle. Make a note of the key
number. Our authorised dealers and workshops can offer assistance in case
of loss.
3.2 Registration
Your caravan is a vehicle which must be registered. Observe national regula-
tions on registration.
Please remember that certain countries require a separate national code
sticker in addition to the EU plate.
Fig. 1 Keys

18 Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Before the journey
3
3.3 Connecting
Connecting: Connect the caravan (see section 3.5). The coupling jaw and the ball must
interlock and are not to be loosely superposed. The coupling jaw must
completely surround the ball.
Connect the breakaway brake cable with a loop to a suitable anchorage
point on the vehicle, do not attach to the tow ball. Thereby, observe the
cable length: The cable must not trail on the ground or trigger the braking
function around corners.
Crank the jockey wheel up as far as possible. Adjust the running role in par-
allel to the direction of travel and to the draw box.
Insert the connector plug of the caravan in the socket of the towing vehicle.
Ensure that the hooks of the safety cover engage with the plug. The hooks
prevent the plug from becoming loose during the journey.
Put the connection cable in a loose loop across the drawbar. Make sure
that it does not touch the ground.
Check whether the caravan coupling is mounted correctly on the coupling
ball. Pay attention to the safety indicator.
XCare is to be taken when connecting and detaching a trailer. Risk of acci-
dent and injury!
XNo persons are to be between the towing vehicle and the trailer during
positioning for connecting and detaching.
XObserve the permissible nose weight and rear axle load of the towing
vehicle. Nose weight and rear axle load must not be exceeded. The
values of the nose weight and rear axle load are included in the docu-
ments of the vehicle and the caravan coupling.
XEnsure that the interior of the coupling is not soiled and that the movable
parts of the coupling (not the ball retainer) are lubricated.
XThe tow ball is not to be lubricated when using a stabiliser. The friction
pads are pressed against the coupling ball and thereby generate an anti-
rolling moment. This anti-rolling effect is only guaranteed when the
towing vehicle coupling head is free of lubricant and other residues.
When lubricating the stabiliser ensure that no lubricant is on the friction
pads.
ZCaravan with an overrun brake: Do not connect or detach caravan with the
overrun brake on.
ZCaravan coupling with detachable ball neck: If the ball neck is mounted
incorrectly, there is the danger of the trailer breaking away. Observe the
instruction manual for the caravan coupling.
ZDo not climb onto the drawbar covering – risk of breakage!
ZIn order to connect the vehicle, crank the supporting jockey wheel down
and set it down on the ground.
ZDo not use the stabilising lever of the stabiliser as a maneuvering aid.
ZCheck whether the caravan's connector plug fits into the socket of the
towing vehicle. If connector plug and socket do not match, ask your author-
ised dealers and workshops for adapting options.
ZFurther information about the stabiliser can be obtained in the manufac-
turer's instruction manual.

19Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Before the journey 3
Check whether corner steadies and jockey wheel are raised.
Check the caravan lighting system whilst the towing vehicle is connected.
3.4 Detaching
Detaching: Apply the caravan handbrake.
Place the wheel chocks behind both of the wheels.
Remove the connector plug of the caravan from the towing vehicle socket
and insert it in the holder on the drawbar.
Remove the breakaway cable from the towing vehicle.
Crank the jockey wheel down until it is set firmly on the ground. Now loosen
the caravan coupling.
Using the jockey wheel, lift the drawbar until the towing vehicle can be
driven away without risk.
3.5 Caravan couplings
3.5.1 AKS 1300 stabiliser
Connecting: Pull up the stabilising lever (Fig. 2,1) as far as possible.
Turn the handwheel (Fig. 2,2) in an anticlockwise direction as far as pos-
sible in the open position.
Pull the coupling handle (Fig. 2,3) upwards.
Place the opened stabiliser on the caravan coupling. The coupling handle
must audibly lock back into its initial position.
XCare is to be taken when connecting and detaching a trailer. Risk of acci-
dent and injury!
XIn addition, observe the safety instructions with respect to connecting
included in this instruction manual.
ZDo not climb onto the drawbar covering – risk of breakage!
ZBefore connecting, ensure that the tow ball of the coupling device is free of
dirt and grease.
Fig. 2 AKS 1300 stabiliser

20 Premio/Averso - 13/14 - Ausgabe 09/13 - 2354619 - BUE-0048-12EN
Before the journey
3
In addition, push the coupling handle downwards by hand (not with your
foot). Closing and securing is carried out automatically.
Conduct a visual inspection: The green cylinder on the safety indicator
(Fig. 2,4) must be visible.
Turn handwheel in a clockwise direction until it can be felt and heard that
the torque limiting mechanism grates.
Push the stabilising lever down until the marking on the stabilising lever is
aligned with that on the stabilising housing (Fig. 2,5).
3.5.2 AKS 3004 stabiliser
Connecting: Pull up the stabilising lever (Fig. 3,1) as far as possible.
Pull the coupling handle (Fig. 3,2) upwards.
Place the opened stabiliser on the caravan coupling. The coupling handle
must audibly lock back into its initial position.
In addition, push the coupling handle downwards by hand (not with your
foot). Closing and securing is carried out automatically.
Conduct a visual inspection: The green cylinder on the safety indicator
(Fig. 3,3) must be visible.
Activate the stabilising mechanism. Push the stabilising lever (Fig. 3,1)
down to its stop limit.
Conduct a visual inspection: The arrow (Fig. 4,2) must point to "2"
(Fig. 4,1).
3.6 Caravan control system (ATC) (special equipment)
Fig. 3 AKS 3004 stabiliser Fig. 4 Check "AKS closed"
XThe steady plus on the connection socket on the towing vehicle must be
protected with 15 A or 20 A fuses. Fire hazard!
XThe caravan control system cannot override the physically preset limits.
Do not exceed the maximum speed of 100 km/h intended by the
designers, and always adapt your speed to suit the weather, road and
traffic conditions.
ZAlso read the manufacturer's instruction manual.
