Bush BR08DAB User manual

1
DAB+ Digital Radio
BR08DAB
The Gold Technical Support Line: 1902 215 259
(Charges will apply at $2.95 per minute)
www.bushaustralia.com.au

Bush BR08DAB
1
Introduction
Thank you for buying this Bush product, which is designed to
give you many years of trouble-free service.
You may already be familiar with using a similar unit, but
please take the time to read these instructions.
Safety is important
Your safety and the safety of others is very important.
Therefore, please ensure you read the “Safety
Instructions carefully” before you operate this unit.
Warranty
In the unlikely event that your product fails to work
normally, please call the below free phone numbers to
discuss the problem with one of our qualified service
engineers.
Australia
Bush Warranty: 1800 509 394
New Zealand
Bush Warranty: 0800 450 259
1

Bush BR08DAB
Contents
Safety Instructions………………………………………….……………….……..3
What is DAB+………………………………………………………………………4
Unit Overview……………………………………………………………………....5
Getting Started……………………………………………………………………..6
Troubleshooting…………………………………………………………………….9
Specification………………………………………………………………………...9
Warranty…………………………………………………………………………….10
2

Bush BR08DAB
Safety Instructions
Ensure that you read all of these safety instructions
carefully, before operating this unit.
Safety Considerations
Position the power cable and other connected cables
so that they are not likely to be walked on, pinched or
where items can be placed on or against them.
Do not use the unit in humid or damp conditions.
Do not allow the unit to get wet.
Never allow children to insert foreign objects into the
holes or slots on the unit.
Do not cover the ventilation holes with items such as;
tablecloths or curtains, this may cause overheating.
No naked flame sources, such as lit candles, should
be placed on or near the unit.
Do not expose the unit to dripping or splashing water,
and no objects filled with liquids, such as vases,
should be placed on or near the radio.
Do not place the radio in a closed cabinet without
proper ventilation during operation.
Cleaning
Disconnect the radio from the mains supply before
cleaning.
Do not use any liquids or aerosol cleaners, as this
may damage the radio. Use a soft, dust free cloth.
Servicing
There are no user serviceable parts in the unit. When
servicing, refer to a qualified service professional.
Consult your retailer if you are ever in doubt about the
installation / operation / safety of the product.
3

Bush BR08DAB
What is DAB+
DAB+ was developed in Europe by a consortium of
broadcasters and manufacturers. DAB+ uses digital
compression techniques to transform the source material,
i.e. music and speech, into better quality audio.
Interference Free Reception
Analogue systems suffer from an effect called „multipath
distortion‟. This is because waves do not behave in an
orderly fashion, but bounce and reflect off buildings etc.
DAB+ sees this as an advantage and uses the directed
and reflected signals to reinforce the end result, allowing
for better service more of the time.
No Need to Re-tune
A single DAB+ frequency can be used to cover the whole
of the Australia, so solving many problems experienced
with the earlier analogue system. DAB+ scans
automatically and tunes-in all of the available stations in
your area.
Scrolling Text
Broadcasters can transmit text to your radio. This way
you can read the name of the DJ, artist, song title or any
other information they choose.
DAB+ Coverage
Check your local coverage at
www.digitalradioplus.com.au, or alternatively text
0409-DRPLUS to receive an SMS confirming whether
you reside in a DAB+ broadcast area.
4

Bush BR08DAB
Unit Overview
FRONT VIEW
TOP VIEW
5. MENU: Press to enter the main menu
6. and : Press to scroll through the
DAB+, FM or menu options.
6. Volume ‘+’and ‘-’: Press to increase or
decrease the volume level.
6. :Press to confirm any menu or settings
options.
7. PRESETS: Press to store up to 20
DAB+/FM Stations for easy access.
8. INFO: Press to view the station information
provided by the broadcaster.
SIDE VIEW
BACK VIEW
1. Display Screen: The display will
show your station information and
radio menu options.
2. Power : Press and release
the Power Button to turn on and
press again to turn off.
3. Telescopic Aerial: Extend the
aerial for the best radio
reception.
4. MODE: Press to switch between
DAB+ and FM.
9. Headphone
Socket
10. Power Socket
11. Battery Door
5

Bush BR08DAB
Getting Started
Carefully remove your Radio from the box. We recommend
keeping the packaging for future reference.
Setting up
It is important that you consider carefully in advance where
your radio will be situated and make sure that it is:
On a flat and stable surface
Note: Never place your radio on antique or polished surfaces.
Within 1.5 metres of a power socket
Where you can fully extend the telescopic aerial
Step 1: Connect the mains power lead into the socket on the
right hand side of the radio and plug the power adaptor into the
mains power wall socket and switch on.
Step 2: Fully extend the telescopic radio aerial in a vertical
position to obtain the maximum signal strength.
Step 3: Press the power switch on the front of the radio, to the
right of the display. The display will switch on and for the initial
use; it will automatically begin to scan for DAB+ radio stations.
A progress bar will show the progress of the scan and the
number of stations found during the scan will be displayed.
When the scan is complete your radio will select the first
available station and begin to play. Stations are listed in
numerical and then alphabetical order by default.
Note: The DAB+ radio station list is stored in the memory and
so the next time you switch your radio on, the station search
does not take place.
Step 4: Inserting the batteries (optional). Before installing the
batteries (not included) please ensure that the DAB+ Radio is
unplugged from the mains power supply.
On the back of the radio, press in and push down on the two
ribbed triangle areas to remove the battery cover. Insert 4 x
1.5V AA-size batteries, making sure to note the „+‟ and
„-„markings and position the batteries the correct way around.
Replace the battery cover, making sure it „clicks‟ shut.
6

Bush BR08DAB
If used continuously on battery power, your Radio has an
approximate battery life of 4 hours when using good quality
batteries.
Note: For battery operation, please switch off the mains
adaptor and remove the mains power plug from the radio back.
Switching on and off
Press and release the button to switch on or off.
Switching between DAB+ and FM mode
Press the „MODE‟ button on the top of the radio to switch
between DAB+ and FM mode.
Adjusting the volume
Press the „+‟ or „-‟ buttons on the top of the radio to increase or
decrease the volume level.
Info button
Press the „INFO‟ button on the top of the radio repeatedly, in
DAB+ or FM mode, to display the available station information.
Changing DAB+ Stations
Press the or buttons to scroll through the station list. When
you pause on a station, the radio will tune to that station and
begin to play.
Scanning for DAB+ Stations
With DAB+ radio, it‟s a good idea to carry out a scan every
now and then to make sure that you have the most up to date
station list stored within the memory of your radio.
1. Press the „MENU‟ button on the top of the radio.
2.Press the button until „Full scan‟ is displayed. Press the
round „SELECT‟ button to confirm. „Auto Tune Full scan‟ will
be displayed, followed by „Searching...‟. A progress bar will
show the progress of the scan and the number of stations
found during the scan.
Tuning to an FM station
Press and hold the or buttons to scan the FM frequency
for the next available station. The RDS information for each
station will be displayed, if available.
Note: You can press and release the or to move through
the frequency in 0.05MHz steps.
7

Bush BR08DAB
Storing station presets
You can store up to 10 DAB+ and 10 FM stations in the preset
memories.
1. Press the „MODE‟ button to change to the mode that you
would like to store presets in (DAB+ or FM).
2. Tune your radio to the station that you would like to save to
a preset.
3. Press and hold the „PRESETS‟ button on the top of the radio
until you see the presets number flashing.
4. Press the or buttons to select the preset number that
you would like to store. Press the round „SELECT‟ button to
confirm.
Tune to a radio station preset
1. Press the „MODE‟ button to change to the mode that the
preset was stored in (DAB+ or FM).
2. Press the „PRESETS‟ button and press the or buttons to
scroll through the station preset stations.
3. Press „SELECT‟ when you see the station that you would to
listen to. The radio will instantly tune to that station and
begin to play.
Note: If no DAB+ or FM station has been stored under the preset,
the display will change to ‘Preset X empty’ and then revert to
the previously selected station.
Software version
The helpdesk may ask you for the software version of your
product.
1. Press the „MENU‟ button on the top of the radio.
2. Press the or buttons to scroll to „SW Version‟. Press
the round „SELECT‟ button to display the software version.
Factory Reset
You may need to carry out a reset to factory defaults. Please
note that all of your station presets will be deleted when you
reset your radio.
1. Press the „MENU‟ button on the top of the radio.
2. Press the or buttons to scroll to „RESET‟. Press the
round „SELECT‟ button to reset your radio.
8

Bush BR08DAB
1
Troubleshooting
If a fault occurs, first check the points listed below before taking the radio for repair. If you are unable to solve a problem by following the
below hints we suggest you consult you retailer or service professional.
WARNING: Under no circumstances should you try to repair the unit yourself, as this would invalidate the warranty.
PROBLEM
POSSIBLE CAUSE
SOLUTION
No Sound
The volume may have been set to low.
Adjust the Volume level of the radio.
The Buttons on the Unit
are not Responding
Electrostatic discharge or interference from
other electrical equipment.
Turn the unit off and wait for 5 –10 seconds
and turn the unit back on
Radio Poor Reception
There is weak aerial signal or there may be
interference from other electrical equipment.
Keep the unit away from other electrical
equipment, where possible.
SPECIFICATIONS
Model number ………………….........……
BR08DAB
Power Supply…………………..................
AC Power Input: 100-240Vac, 50-60Hz
AC Power output: DC6V/500mA
(please use our provided adapter)
Frequency range (DAB+) ………............
DAB+ (174-240MHz)
FM (87.5-108MHz)
Audio Output……….......…..........….........
0.5Wrms
LCD Display………........….......................
High resolution display
Dimensions……….......…..............…........
127mm x 57mm x 134mm
9
6

Bush BR08DAB
1
Warranty
Please keep your receipt as proof of purchase. This product is
warranted for any defect in materials or workmanship for one
year after the original date of purchase. This product is for
normal domestic and office use only. This warranty does not
cover damage from misuse or neglect, accidental damage,
vermin infestation, excessive voltages such us lightning or
power surges or any alternation that affects the performance
or reliability of the product.
In the unlikely event that your product fails to work normally,
please contact the Bush Warranty on 1800 509 394 (Australia)
or 0800 450 259 (New Zealand) and have your receipt of
purchase on hand.
This warranty is subject to the following provisions:
It is only valid within boundaries of the country of purchase;
The product must be correctly assembled and operated in
accordance with the instructions contained in the manual;
This product must be used solely for domestic purposes;
The warranty does not cover accidental damage;
The warranty will be rendered invalid if the product is
resold or has been damaged by inexpert repair;
The manufacturer disclaims any liability for incidental or
consequential damaged.
This warranty is in addition to, and does not diminish,
your statutory or legal rights.
PO BOX 6287
Silverwater NSW 1811
Bush Warranty: 1800 509 394 Australia
Bush Warranty: 0800 450 259 New Zealand
www.bushaustralia.com.au
10

Bush BR08DAB
PO BOX 6287
Silverwater NSW 1811
www.bushaustralia.com.au
