Bushnell Medalist 201354 User manual

Model: 201354/201355
Lit. #: 98-0840/07-11
LA
SER RANGEFINDERS

1
English 2
French 12
Spanish 22
German 32
Italian 42
Portuguese 52

2
The #1 choice of players who play for a living – Bushnell®laser rangefinders, now legal for tournament
play, the new MEDALIST™deploys PinSeeker®technology for better shot making and course management.
On any course, anywhere, any time of day. Bushnell®Medalist. Because every swing counts.
Congratulations on your purchase of the Bushnell®MEDALIST™ Laser Rangefinder. The MEDALIST™ is
a precision Laser Rangefinding optical instrument designed to provide many years of enjoyment. This
booklet will help you achieve optimum performance by explaining its adjustments and features as well
as how to care for this precise laser rangefinding optical instrument. To ensure optimal performance and
longevity, please read these instructions before using your MEDALIST™.
INTRODUCTION
Your Bushnell®MEDALIST™ is an advanced premium laser rangefinder comprised of Digital Technology
allowing range readings from 5-1000 yards / 5-914 meters. Measuring 1.7 x 4.5 x 3.8 inches, the 9-
ounce MEDALIST™ delivers superb and accurate range performance to +/- one yard. The MEDALIST™
features PinSeeker®technology, SCAN Mode, 4x Magnification, and Multi-Coated Optics for enhanced
viewing.

3
HOW OUR DIGITAL TECHNOLOGY WORKS
The MEDALIST™ emits invisible, eye safe, infrared energy pulses. The MEDALIST’s™ advanced Digital
microprocessor and ASIC chip (Application-Specific Integrated Circuit) results in instantaneous and
accurate readings every time. Sophisticated digital technology instantaneously calculates distances by
measuring the time it takes for each pulse to travel from the rangefinder, to the target, and back.
RANGING ACCURACY
The ranging accuracy of the MEDALIST™ is plus or minus one yard / meter under most circumstances.
The maximum range of the instrument depends on the reflectivity of the target. The maximum distance for
most objects is 500 yards / 457 meters while for highly reflective objects the maximum is 1000 yards /
914 meters. Note: You will get both longer and shorter maximum distances depending on the reflective
properties of the particular target and the environmental conditions at the time the distance of an object
is being measured.
The color, surface finish, size and shape of the target all affect reflectivity and range. The brighter the
color, the longer the range. Red is highly reflective, for example, and allows longer ranges than the color
black, which is the least reflective color. A shiny finish provides more range than a dull one. A small target
is more difficult to range than a larger target. The angle to the target also has an effect. Shooting to a
target at a 90 degree angle (where the target surface is perpendicular to the flight path of the emitted
energy pulses) provides good range while a steep angle on the other hand, provides limited ranging. In
addition, lighting conditions (e.g. the amount of sunlight) will affect the ranging capabilities of the unit.
The less light (e.g. overcast skies) the farther the unit’s maximum range will be. Conversely, very sunny
days will decrease the unit’s maximum range.

4
GETTING STARTED
INSERTING THE BATTERY
Lift the battery door tab and remove the battery door. Attach one 9-volt alkaline battery and replace the
battery door.
NOTE: Use only high quality alkaline batteries. Do not use heavy duty or lithium batteries. It is recommended
that the battery be replaced at least once every 12 months.
Low Battery Indicator (Lob): If the letters Lob appear, the battery charge is getting low and the 9-volt
alkaline battery should be replaced.
OPERATIONAL SUMMARY
While looking through the 4x eyepiece, depress the power button once to activate the in-view Liquid
Crystal Display (LCD). Place the aiming circle (located in the center of the field of view) upon a target at
least 5 yards away, depress and hold the power button down until the range reading is displayed near
the bottom of the in-view display. Crosshairs surrounding the aiming circle indicate that the laser is
being transmitted. Once a range has been acquired, you can release the power button. The crosshairs
surrounding the aiming circle will disappear once the power button has been released (i.e. the laser is no
longer being transmitted). Note: Once activated, the LCD will remain active and display the last distance
measurement for 30 seconds. You can depress the power button again at any time to distance to a new
target. As with any laser device, it is not recommended to directly view the emissions for long periods of
time with magnified lenses. The maximum time the laser is transmitted (fired) is 10 seconds. To re-fire,
press the button down again.

5
LIQUID CRYSTAL DISPLAY (LCD) INDICATORS
Your MEDALIST’s LCD incorporates illuminated indicators that advise the user unit of measure, when
the laser is actively firing, when a target has been acquired, and targeting modes. A summary of these
features is presented below:
UNIT OF MEASURE OPTIONS
The MEDALIST can be used to measure distances in yards or meters. The unit of measure indicators are
located in the lower right portion of the LCD. To select between yards and meters, quickly press and
release the POWER button to turn on the unit (on top of the unit), look through the eyepiece, depress the
“MODE” button and hold it down for approximately 5 seconds. If you are changing from yards to meters,
a change in unit of measure will be indicated by the illumination of the M for meter indicator while the
Y for Yard indicator is turned off. If you are changing from meters to yards, the opposite will occur. The
MEDALIST™ will return to the last unit of measure setting used each time the unit is turned on.
ACTIVE LASER
Crosshairs surrounding the aiming circle indicate that the laser is being transmitted. Once a range has
been acquired, you can release the power button. The crosshairs surrounding the circle will disappear
once the power button has been released (i.e. the laser is no longer being transmitted).
SELECTIVE TARGETING™ MODES
The MEDALIST™ was especially designed with golfers in mind. The selective targeting modes allow you
to adjust the performance parameters of the unit to suit your specific situation and environment. To move
from one mode to another, press the POWER button once to turn on the unit. While looking through the
eyepiece, press the MODE button and quickly release. The different targeting modes available and mode
indicators are listed below:

PinSeeker (LCD Indicator - ) Ever wonder how far the flag is? This advanced mode allows easy acquisition
of the flag without inadvertently getting distances to background targets (i.e. trees) that have stronger
signal strength.
Once in this mode, press the POWER button to turn the unit on. Next, align the aiming circle reticle onto
the flag that you want distance to. Next, press and hold the POWER button and move the laser slowly
over the flag or desired object until a circle surrounds the flag indicator. If the laser beam recognized
more than one object (i.e. flag and background trees), distance of the flag will be displayed and a circle
will surround the PinSeeker®indicator informing the user that distance to the flag (i.e. closer object) is
being displayed in the LCD (as seen below). There may be times when only the laser beam only sees one
object in its path. In this case, the distance will be displayed, but because more than one object was not
acquired, a circle will not surround the flag indicator.
TIP: While pressing the POWER button, you can move the device slowly from object to object and
intentionally force the laser to hit multiple objects to ensure that you are only displaying the closest of the
objects recognized by the laser.
Once the device has shut off, the unit will always default back to the last mode used.
OPTICAL DESIGN
Magnification and Coatings
The MEDALIST™ provides 4x magnification resulting in up-close and personal details of targeted objects
on the course. Optics are Multi-Coated allowing maximum light transmission for optimum brightness,
superb resolution and contrast for a clear vivid image even in low light conditions such as dusk or dawn.
A liquid crystal display (LCD) is mounted within the optical system and when activated, displays a reticle
for targeting, yards / meters, and Mode indicators. Inherent in the manufacturing process are small black
6

spots that appear in the optical system. These are a natural characteristic of the LCD and cannot be fully
eliminated in the manufacturing process. They do not affect the distancing performance of the unit.
TRIPOD MOUNT
Molded into the bottom of the MEDALIST™is a threaded tripod mount that will allow you to attach the
device to our Cart Mount Accessory.
CLEANING
Gently blow away any dust or debris on the lenses (or use a soft lens brush). To remove dirt or fingerprints,
clean with a soft cotton cloth, rubbing in a circular motion. Use of a coarse cloth or unnecessary rubbing
may scratch the lens surface and eventually cause permanent damage. For a more thorough cleaning,
photographic lens tissue and photographic-type lens cleaning fluid or isopropyl alcohol may be used.
Always apply the fluid to the cleaning cloth - never directly on the lens.
7

SPECIFICATIONS:
Dimensions: Measuring 1.7 x 4.5 x 3.8 inches
Weight: 9 oz.
Ranging Accuracy: +/- 1 yard
Range: 5-1000 Yards / 5-914 Meters
Magnification: 4x
Objective Diameter: 20 mm
Optical Coatings: Multi-Coated
Display: LCD
Power Source: 9-volt alkaline battery
Field Of View: 430 ft. @ 1000 yards
Extra Long Eye Relief: 17 mm
Exit Pupil: 4.0 mm
Built-In Tripod Mount
Includes case and strap
Patent #’s: 6,445,444 | 5,612,779 | 6,057,910 | 6,226,077 | 6,542,302 | 7,239,377 (205106)
TWO-YEAR LIMITED WARRANTY
Your Bushnell®product is warranted to be free of defects in materials and workmanship for two years
after the date of purchase. In the event of a defect under this warranty, we will, at our option, repair or
replace the product, provided that you return the product postage prepaid. This warranty does not cover
damages caused by misuse, improper handling, installation, or maintenance provided by someone other
than a Bushnell Authorized Service Department.
