BVM F-15B User instructions

BVM-2021
F-15B
ASSEMBLY AND OPERATING MANUAL
1:8 Scale
Length: 96”, Wing Span: 65”, Weight:34# Dry, Fuel Capacity: 4.0L, Smoke: 2.2L
CONSTRUCTION AND OPERATING MANUAL
Version 1.0
April 2021
Vne 180 MPHLimit Thrust to 36 lbs.
Equipped with HV Servos and should not be operated below 7.2 volts

BVM ®2021 1 April 2021
3481 State Road 419 • Winter Springs, FL 32708 USA
tel. [phone] • fax. [phone]
INTRODUCTION.................................................................................................................................................. 2
DISCLAIMER........................................................................................................................................................ 2
Notice:.................................................................................................................................................................... 2
Recommended Accessories........................................................................................................................... 3
Required Tools ........................................................................................................................................................ 4
Accessories Used to Complete Prototype........................................................................................................ 4
Installing the Horizontal Stabilizers.................................................................................................................... 5
Preparing The Wings........................................................................................................................................... 5
Installing The Vertical Fins.................................................................................................................................. 6
Receiver, Gyro and Battery Installation ............................................................................................................ 7
CCU/ Air Fill Valve................................................................................................................................................ 7
Turbine and Pump Mounting.............................................................................................................................. 8
Wheels & Brakes Preparation............................................................................................................................ 9
Connecting RX wires ......................................................................................................................................... 10
Gyro...................................................................................................................................................................... 10
Control Deflections............................................................................................................................................. 11
Center Of Gravity................................................................................................................................................ 12
First Flight Profile................................................................................................................................................ 13
Taxi Test/Engine Run Up....................................................................................................................... 13
Takeoff........................................................................................................................................................ 13
RX Battery Consumption........................................................................................................................... 13

BVM ®2021 2 April 2021
INTRODUCTION
Thank you for purchasing the BVM GO Fly F-15. This model represents the latest in manufacturing
technology and completion for the R/C jet enthusiast. The factory has expertly crafted and thoroughly
inspected all aspects of the model. Only a small amount of work is required to complete the assembly
of your F-15.
This manual contains instructions for safety, operation and maintenance. It is essential to read and
follow all of the instructions and warnings in the manual.
Please read the entire manual to become familiar with the processes and procedures before you
begin to assemble your aircraft.
DISCLAIMER
Bob Violett Models Inc. assumes no liability for the operation and use of these products. The owner
and operator of these products should have the necessary experience and exercise common sense.
Said owner and operator must have a valid Academy of Model Aeronautics license and a “Turbine
Waiver” for operation in the U.S.A.
This is a sophisticated jet model aircraft. It must be operated with caution and common sense and
requires some basic mechanical ability. Failure to operate this product in a safe and responsible
manner could result in injury or damage to the product or other property.
Notice: Do not use with incompatible components or alter this product in any way outside of the
instructions provided by BVM, Inc. The BVM F-15 has been designed and flight tested around 36 lbs
class engines. Damage to the aircraft may result from exceeding this thrust limitation (36 lbs).

BVM ®2021 3 April 2021
Recommended Accessories
You may have some of these products in your shop, but if not, refer to this list.
140N-160N engine of your choice.
#2 x 3/16 Button Head SMS Package (BVM # 5625)
BVM UAT (BVM# 6044)
Spektrum 20310T Power Safe Receiver (# VJ-SPMAR20310T)

(2) 7.4v Pulse 3600 mah Rx packs (#V-PLURX15-3600 )
Demon Aero Cortex Gyro Pro (# V-DA-BD-CortexPro)
BVM Over Flow Tank (BVM # 6047)
8" Warbird Jet Pilot (#V-WB 10"/8 JET PILOT)
BVM Ultimate Air Trap
BVM Ultimate Air Trap
Fill line

BVM ®2021 4 April 2021
Required Tools
A combination of Metric and SAE hex socket and drivers along with a small standard and Phillips
head drivers will be necessary.
List of Adhesives/Lubricants/Heat Shield+
Available at BVMjets.com
BVM Aeropoxy (BVM # 9566)
BVM Qt Poxy (# PA-SR-0042)
Slo-Zap (# PT20)
Pacer Z-42 (#PT42)
Super O-Lube (BVM #5779)
BVM Thin Lube for “O” Rings (BVM # 1945)
Axle Super Lube (BVM # 5784)
BVM Dry Lube (BVM # 1947)
Accessories Used to Complete Prototype
1 x AR20310T 20-Channel PowerSafe Integrated Telemetry Receiver (SPMAR20310T)
2 x 3600mAh 2S 7.4V LiPo Receiver Battery
1 x Cortex Pro Gyro
1 x BVM T-16 Turbine
Begin assembly by removing and inspecting all airframe components. Carefully become
familiar with the wiring, landing gear, gear doors, etc. The BVM F-15 GO Fly is not meant to
be a primary turbine trainer. The manual assumes you already have experience with high
performance aircraft.

BVM ®2021 5 April 2021
Installing the Horizontal Stabilizers
•Use a Phillips head screw driver to remove
the (4) screws holding the cover plate in
place.
•The elevator clamping block uses (2) 8/32
bolts. A 9/64 wrench is required to tighten
these.
NOTE: Final adjustment should be done with the
radio on.
Use the provided Template to set the neutral point
for the Elevator This will be used later as well for
surface throws.
Preparing The Wings
•On the BVM demo model we moved the
aileron linkage to a lower hole on the servo
to improve resolution. The flaps do not need
to be changed.

BVM ®2021 6 April 2021
Wing Installation
•The servo wires and light plugs are all
different. Match them accordingly. Use tape to
secure them.
Pro Tip:Use BVM Dry Lube (#1947) to allow dowel
pins, tubes, and spars to be inserted with less friction.
•The wings are secured to the fuse by
clamping brackets. You need a 9/64 wrench
to complete this.
Installing The Vertical Fins
•Connect the LED and Servo connection. One
side will have (2) and one will have (1).
•Use a 9/64” driver to secure the clamp.

BVM ®2021 7 April 2021
•Use a 9/64” driver to secure the clamp. There
is (2) clamps. One front and one aft.
Receiver, Gyro and Battery Installation
•The BVM demo uses a Cortex Pro and a
Spektrum 20ch RX. The gyro is mounted in
front of the RX. The Pulse 3600 mah RX
batteries sit on the Velcro just in front of the
Gyro.
NOTE: The air bottles are under the front tray..
CCU/ Air Fill Valve
•The CCU and Air Fill valve are mounted
under the nose cone This has been
programmed from the factory and shouldn’t
need to be touched.

BVM ®2021 8 April 2021
UAT Mounting
•The UAT has spot under the canopy on the
right side of the fuse. We routed the fill line for
the fuel system under the nose cone.
Turbine and Pump Mounting
•
•Our demo model has a BVM T-16 for
power. We mounted the Fuel Pump
on the right side and the ECU
Battery on the left. Our ECU is built
into the front cover of the engine, so
you will not see it in the photos.
Follow your manufactures guide
lines for mounting.
NOTE: The engine rails will look a bit
different on the production versions.
Turbine and Pump Mounting
•Heatsheild was used on the
inside of Turbine Hatch as added
protection. (BVM#PA-MA-1940

BVM ®2021 9 April 2021
Wheels & Brakes Preparation
•Remove the wheel retaining screw with a 2mm
driver. Use a small amount of Z-42 when re
installing.
NOTE: If you need to remove the O'Ring. Use a
sharpened wood stick to help remove the O-Ring. Don't
use anything metal. This will scratch the inside of the
brake hub.
•Use a small amount of Axle Grease on the wheel
axle. (BVM#5784)
•Use a small amount of BVM Dry Lube on the
pivot joints on your gear.(BVM1947) Also use
a small amount of Super-O-Lube on the brake
O-ring. (BVM5779) This will help the brakes
work smoothly.

BVM ®2021 10 April 2021
Connecting RX wires
The wires are labeled from the factory. If you are using the IX20, the program is available on a SD
card from BVM. Follow the chart below to connect the servos.
IX20 Wire Connection Chart
RX Port
CH 1
CH-2
CH-3
CH-4
Surface
Turbine
RAL
REL
RRU
RX Port
CH-5
Aux1 (6)
Aux2 (7)
Aux3 (8)
Surface
LFL
LAL
RFL
LRU
RX Port
Aux4 (9)
Aux5 (10)
Aux6 (11)
Aux7 (12)
Surface
LEL
Gear
Lights
NWH
RX Port
X+1 (13)
X+2 (14)
X+3 (15)
X+4 (16)
Surface
WHL Brakes
SPD Brakes
Gyro Gain
AFTB Ring
IX20 Control Switches
Switch
A
B
C
D
Surface
LG
Flight Timer
Lights
Speed Brake
Flaps and
F.Modes
Switch
L. Trim
E
F
G
Surface
NWL Trim
WHL Brakes
Smoke
Gyro Gain
Gyro
We used the Cortex Pro in our demo model. We use 40% gain for Normal Flight and 55% for landing.
These will vary for each customer's preference.

BVM ®2021 11 April 2021
Control Deflections
Surface
Direction
Measurement Location
Low
Medium
High
Rudder
Left/Right
Base of Rudder
.75”
.90”
1.2”
Elevator
Up/Down
Use Template provided
Aileron
Up/Down
Ail/Flap Junction
.75”
.90
1.1”
Expo: Typically 15%-25% is used on all surfaces. This is pilot’s discretion
Flap Settings
Measurement
Measurement Location
Takeoff
1.0”
Flap/Aileron Junction
Landing
2.25”

BVM ®2021 12 April 2021
Center Of Gravity
•The Center of Gravity comes pre-marked from
the factory. Verify that it is marked at 2” forward
of the front spar.
To help mark the Center of Gravity position when the
wing is in place, you can use two Buttonhead screws
on the bottom of fuse at the fuse wing joint. (BVM #
5625)

BVM ®2021 13 April 2021
First Flight Profile
Flight Time
The BVM demo model’s transmitter timers are set for 6 min. On the first flight, land a couple
minutes early to check fuel consumption. Adjust the flight timer accordingly.
Taxi Test/Engine Run Up
A taxi test should include a radio range check with the engine running at various power
levels. Check that the wheel brakes are adequate and the stopping action is without skidding
or pulling left or right. Be sure to shake the aircraft and push fore and aft with the engine at
half power, this will help remove any trapped air bubbles in the fuel system.
Takeoff
NOTE: If a gyro is used select the off position, for first flight until gyro can be tested at a safe
altitude.
Begin the takeoff roll by slowly advancing the throttle. Maintain runway center while holding
about 1/2 stick up elevator; the F-15 will rotate when it is ready. It there is a cross wind, hold
a small amount of aileron into the wind, be prepared with opposite rudder. The aircraft does
not need flaperons, we suggest making your first flights “clean wing”.
Trim
Once in the air, find a nice cruise speed to set the trims. The aircraft should fly straight and
level when “hands off”. When the landing gear come down, a few clicks of trim will be
needed. This can be mixed in, or use flight modes to trim automatically.
Practice Approaches
Save some time at the end of your first flight to practice approaches and go arounds. It is
beneficial to become familiar with the low speed handing of the aircraft.
Landing
Landing is like most jets, “power on” during the approach. The F-15 does not stall easily, it is
best to land nose high, touching on the main wheels first.
The majority of the first flight should be spent trimming and practicing for the first landing.
Save the aerobatics and air show stuff for later flights.
RX Battery Consumption
The average flight using the lights the entire flight consumes 500 mAh. We recommend two
flights and recharge. Use this data to calculate how many flights you can achieve from your
system. The use of the smoke pump will consume more mAh per flight. 3600 mAh combined
capacity is the minimum BVM recommends.

BVM ®2021 14 April 2021
BVM is synonymous with “Success Jets.” It is very important to us that you are successful
with our products. This extensive manual reflects our sincerity. As always, your comments
and suggestions on BVM products are appreciated.
Pilot’s Notes:
