BVM Grumman F-9F Cougar User manual

K7000 BVM-2015
Grumman F-9F Cougar
1/5.8 Scale
Length: 84”, Wing Span: 72”
Weight: 26-27lbs Dry
Fuel Capacity: 3.0L,
Smoke Capacity: 2.0L
CONSTRUCTION AND OPERATING MANUAL
Version 1.3
January 2017
Vne 165 MPH Limit Thrust to 25 lbs.
Equipped with HV Servos and should not be operated below 7.2 volts
3481 State Road 419 • Winter Springs, FL 32708 USA
tel. [phone] • fax. [phone]

BVM ®2015 2 Printed 7/3/2019
Contents
INTRODUCTION .................................................................................................................. 4
DISCLAIMER ....................................................................................................................... 4
Recommended Accessories ................................................................................................. 4
Required Tools ..................................................................................................................... 5
List of Adhesives/Lubricants ................................................................................................. 5
Available Options ................................................................................................................. 5
Touch Up Paint ..................................................................................................................... 5
Unpacking ............................................................................................................................ 6
Preparing to work ................................................................................................................. 6
Tail section ........................................................................................................................... 7
Painting Rudder and Elevator Linkages ........................................................................... 7
Installing the Horizontal Stabilizer .................................................................................... 8
Installing the Vertical Fin ................................................................................................ 10
Mid Fuselage Section ......................................................................................................... 12
Installing the Engine ....................................................................................................... 12
Front Fuselage Section ...................................................................................................... 16
General Preparation ....................................................................................................... 16
Mount the BVM UAT ....................................................................................................... 16
Mount the Fuel Pump ..................................................................................................... 16
Mount the ECU ............................................................................................................... 17
Mount the Receiver ........................................................................................................ 17
X+8 Xpander and Optional Gyro .................................................................................... 18
Misc Fuel Lines .............................................................................................................. 18
Reinstall the Radio/ECU Tray ......................................................................................... 18
Switch ............................................................................................................................. 19
Final install Photos ........................................................................................................ 21
Nose Cone Section ............................................................................................................ 22
Mount RX Batteries ........................................................................................................ 22
Front Battery Tray ........................................................................................................... 22
Miscellaneous Equipment ............................................................................................... 23
Battery Extensions .......................................................................................................... 24

BVM ®2015 3 Printed 7/3/2019
Nose Cone ..................................................................................................................... 25
Cockpit/Pilot ....................................................................................................................... 26
Wing Section ...................................................................................................................... 28
Painting Aileron and Flap Linkages ................................................................................ 28
Secure Flap Hinge Bolts ................................................................................................. 28
Installing wings ............................................................................................................... 29
Lubing the Brakes .............................................................................................................. 30
Wheel Bearing Maintenance .............................................................................................. 30
Systems Information ........................................................................................................... 31
Smoke Pump .................................................................................................................. 31
Relocating the Smoke tube ............................................................................................ 31
Air System and Electronics (For Models shipped prior to September 2015) .................. 32
PSI to BAR Conversion Table ........................................................................................ 32
Landing Gear/Door /Brake Sequencer Instructions ........................................................ 33
Light System ................................................................................................................... 34
Central Control Unit Instructions ..................................................................................... 35
Light Connections (New Style Controller-September 2015) ........................................... 37
Flush Mount Vent and Overflow System ............................................................................ 38
Center of Gravity ................................................................................................................ 39
Control Surface Deflections and Expo Settings .................................................................. 39
Connecting RX wires .......................................................................................................... 40
DX18 and DX18QQ Transmitter File .................................................................................. 40
First Flight Profile ............................................................................................................... 41
Flight Time ...................................................................................................................... 41
Taxi Test/Engine Run Up ............................................................................................... 41
Takeoff ........................................................................................................................... 41
Trim ................................................................................................................................ 41
Practice Approaches ...................................................................................................... 41
Landing ........................................................................................................................... 41
RX Battery Consumption .................................................................................................... 41

BVM ®2015 4 Printed 7/3/2019
INTRODUCTION
Thank you for purchasing the BVM F-9F Cougar. This model represents the latest in
manufacturing technology and completion for the R/C jet enthusiast. The factory has expertly
crafted and thoroughly inspected all aspects of the model. Only a small amount of work is
required to complete the assembly of your Cougar.
This manual contains instructions for safety, operation and maintenance. It is essential to
read and follow all of the instructions and warnings in the manual. Please read the entire
manual to become familiar with the processes and procedures before you begin to assemble
your aircraft.
DISCLAIMER
Bob Violett Models Inc. assumes no liability for the operation and use of these products. The
owner and operator of these products should have the necessary experience and exercise
common sense. Said owner and operator must have a valid Academy of Model Aeronautics
license and an AMA Turbine Waiver.
This is a sophisticated jet model aircraft. It must be operated with caution and common sense
and requires some basic mechanical ability. Failure to operate this product in a safe and
responsible manner could result in injury or damage to the product or other property.
If you do not have recent and successful experience operating and flying a turbine powers
model, contact your local BVM Rep (http://bvmjets.com/Pages/fieldreps.htm) or call BVM for
assistance 407-327-6333.
Notice: Do not use with incompatible components or alter this product in any way beyond the
instructions provided by BVM, Inc. The BVM Cougar has been designed and flight tested
around 100N class engines. Damage to the aircraft may result by exceeding this thrust
limitation (25 lbs).
Recommended Accessories
You may have some of these products in your shop, but if not, refer to this list.
 10" Warbird jet pilot figure
 BVM UAT
 Spektrum 12120 Power Safe Receiver
 Spektrum X+8 Expansion Module
 (2) 7.4v Batteries 3,000 mAh each.
 100N engine of your choice, with FOD screen
 (2) EC3 Extension Lead 6” for RX BVM# VJ-EFLAEC311
 Gyro System
 Fuel Pump/Filter Mount for Jet Cat fuel filter. BVM# PA-SR-0064

BVM ®2015 5 Printed 7/3/2019
Required Tools
 Metric Allen wrench set
 Needle nose Pliers
 BVM Clevis Tool BVM# PA-SR-0060
 9/64 Ball Driver
 Perma Grit Large Flat File BVM# LNF-FLAT
 6” long 1/16th drill
List of Adhesives/Lubricants
 Pacer Z-42 PT42
 Super O-Lube BVM #5779
 Axle Super Lube BVM #5784
Available Options
#V-WB 10" JET PILOT
10" Jet Pilot $79.99
Touch Up Paint
Model Master paints:
FS15042 Gloss Sea Blue

BVM ®2015 6 Printed 7/3/2019
Unpacking
Carefully remove items from the box. Open each package and inspect for shipping damage.
After reading this entire manual, get familiar with the major kit components.
Note: Damaged parts must be reported to BVM within 7 days of receiving your kit.
Become familiar with the work completed at the factory. It is important that you inspect and
approve this work now.
Preparing to work
 Support the fuselage on a stand. Be sure to use foam padding to prevent scratching
and denting.
 Fill air system to around 50 Psi, use a piece of scrap air line pressed into the BVM Fill
Valve (typical).
Note: There may be sufficient air pressure from the factory.
 Remove the masking tape securing the gear doors and body flaps in closed position.
NOTE: The electronic valves can be operated manually by depressing the small orange
buttons on the valves that corresponds to the action desired. Label the valves for easy
reference. Fill the air system to around 50 psi.
 Manually extend the landing gear by pressing the small orange buttons located on the
front of the electronic valves, follow the sequence below.
To Extend the Gear
1. Main Door Open (M.O.)
2. Nose Door Open (N.O.)
3. Landing Gear Down (G.D.)
4. Main Door Close (M.C.)
To Retract the Gear
1. Main Door Open (M.O.)
2. Landing Gear Up (G.U.)
3. Nose Door Close (N.C.)
4. Main Door Close (M.C.)
Note: Now the fuselage can rest on the landing gear if you prefer versus using a work stand.
M.O. M.C. N.O. N.C. G.D. G.U. BRK

BVM ®2015 7 Printed 7/3/2019
Tail section
Painting Rudder and Elevator Linkages
 Apply Pacer Z-42 to the rudder pushrod
clevises.
An easy cosmetic improvement for your Cougar is to brush paint the external rudder and
elevator linkages. Use the appropriate color and small brush. Avoid getting paint on the clevis
pins or the ball links. The servo cover screw heads can be hidden with paint as well.
NOTE: The color paint on your BVM Cougar is blended to match U.S. Federal Standard
(F.S.) Numbers. These F.S. number paints are available from Testor’s “Model Master” plastic
model paints.
I.e. the dark blue on this prototype Cougar is identified as F.S. 15042 Gloss Sea Blue.

BVM ®2015 8 Printed 7/3/2019
Installing the Horizontal Stabilizer
 Remove the (4) 4mm bolts. The front bolts
are 30mm long and the rear bolts ar 25mm
long.
 Use a 2mm Allen wrench and pliers to hold
the nut to disconnect the elevator pushrods
from the control horns.
 Install the stabilizer by carefully routing the
pushrods through the openings.
NOTE: Secure the elevator servo
connection with a plastic clip or tape.
 Apply a drop of Pacer Z-42 to the (4)
stabilizer bolts and secure the stab to the
fuselage with a 3mm Allen wrench.

BVM ®2015 9 Printed 7/3/2019
 Use a Perma Grit Flat File if required to
achieve full elevator deflection.
See Control “Travels” at end of this manual.
 Reconnect the (2) elevator ball links.
 Apply a drop of Z-42 on the end of the bolt
that protrudes beyond the nut.

BVM ®2015 10 Printed 7/3/2019
Installing the Vertical Fin
 Remove the 2 mm bolt from the bottom of
the rear aluminum rod.
 You may wish to enlarge the hole for the
wire and connector to pass through.
NOTE: If the fin tubes (3) fit is a bit tight when
installing onto the fuselage, follow the (2) steps
below.
 Use a Drum Sander to chamfer the ends of
the three tubes/rods.
 Use 320 grit sand paper to stroke the rods
in the long direction. The grain should be
the same as the direction of insertion.
 Apply a small amount of Lube to three
tubes.

BVM ®2015 11 Printed 7/3/2019
 Connect Fin strobe light connection.
 Insert wires into the fin while installing the fin
onto the fuselage.
 Hold the front of the fin down firmly while
tightening the front clamp bolt; use a 3mm
Allen wrench.
Important! The clamping bolt has an “E” clip on the
end of the bolt to prevent the bolt from falling out
during transportation. Do not continue to loosen the
bolt once you feel the resistance of the “E” clip, you
will damage and loose the “E” clip.
 Install the rear rudder post bolt through the
lower rudder using a 2mm Allen wrench.

BVM ®2015 12 Printed 7/3/2019
Mid Fuselage Section
Installing the Engine
The engine bay comes with the engine rails,
tailpipe, and smoke tube factory installed. The rails
are made to accept various engine installations
with minor trimming. This installation features the
Jet Cat P-100RX, other installations will be
accomplished using the same steps with minor
variations.
 Prepare the engine and engine mount. The
standard P-100RX mount supplied with the
engine is used in this prototype. Use the #6
Truss Head screws provided from BVM to
secure the engine.
 Set the engine and mount in place, get
familiar with the next few steps before
proceeding.
 Consult your engine manufacture for the
distance between the bellmouth and the
tailcone of the engine. A distance of 5/8” is
used with the P-100RX as shown.
Note: The engine mounting rails will require
trimming for the engine mount to sit on the
rails.
 Not shown in these steps, but use a F.O.D. screen.

BVM ®2015 13 Printed 7/3/2019
 Remove the smoke tube.
 Remove the tail pipe screws and slide the
tailpipe aft to allow access to the engine
mounting rail bolts.
 Remove the engine mounting rail bolts with
a 2mm Allen wrench.

BVM ®2015 14 Printed 7/3/2019
 Mark and trim the rails at a distance of .3” as
shown.
This sample accommodates a Jet Cat P-100RX.
Note: When installing a King Tech K-100G Mark
and trim the rails at a distance of .4”.
 Reinstall the rails and the tail pipe. The
smoke tube will be reinstalled after the
engine is mounted.
 With the engine set at the appropriate
distance and centered within the tail pipe,
mark the (4) mounting holes.
JetCat P-100RX distance from bellmouth = 7/8”
KingTech K-100G distance = 7/8”-1”
 Use a 6” long 1/16” drill to make the (4)
holes for the #6 Truss Head wood screws.

BVM ®2015 15 Printed 7/3/2019
 Install the #6 Truss Head wood screws.
 Reinstall the Smoke Tube.
Note: If your engine mount interferes with the
smoke tube, see the section titled Relocating the
Smoke Tube.
 Route the engine fuel and electrical lines.
Use small zip ties to maintain security and
an organized installation. Not shown here,
but use a F.O.D. screen.

BVM ®2015 16 Printed 7/3/2019
Front Fuselage Section
General Preparation
 Un-wrap and familiarize yourself with the fuselage servo wires.
 Arrange servo wires, fuel line, light system, and air line neatly into groups. Keeping an
organized installation can help diagnose problems down the road.
 Check fuel tank installation and factory plumbing. Blow through the main supply line. It
should not be blocked or restrictive.
 Remove the front radio/ECU tray to ease installation of components. Two Phillips head
screws secure the tray into position.
Mount the BVM UAT
 Two 11” zip ties are used to secure the
BVM UAT between its mounts.
Mount the Fuel Pump
 Secure the fuel pump using an 8” zip tie.
(King Tech fuel pump shown)

BVM ®2015 17 Printed 7/3/2019
Mount the ECU
 Secure the ECU in place with wide “Sticky”
Velcro; supplied with the BVM Manual
packages. If your ECU allows for screws,
they could be used as well.
Mount the Receiver
 Secure the receiver in place with wide
“Sticky” Velcro.
 Use a 7” length of 6mm fuel tubing to
connect the UAT output to the input of the
fuel pump.
 Use a short piece of 4mm fuel tubing as an
adaptor for the larger 6mm tubing on the
pump input barb.
 Use safety wire to secure the connection.

BVM ®2015 18 Printed 7/3/2019
X+8 Xpander and Optional Gyro
 Use sticky back Velcro to secure the X+8
Expansion Module.
 Refer to your gyro manufacturer’s
recommendations for mounting your
(optional) gyro.
 BVM adds a Velcro strap for security.
The Cortex gyro is shown. The gain values
used are 40% for normal flight and 60% for
landing.
Important!!! DO NOT use heading mode unless you are experienced with this mode.
Misc Fuel Lines
 Add a 13” length of 4mm fuel line to the fuel
pump and an 18” length of 6mm to the UAT
fill barb.
The remaining brass barb will be connected to the
fuel tank after the tray is installed.
Use safety wire to secure and prevent leaks.
Reinstall the Radio/ECU Tray
Note: These photos are from an earlier
prototype. The UAT was mounted pointing
forward on this model.
 Slide the tray through the opening as
shown. Once in position, check for pinched
wires or air tubing.
 Reinstall the smoke pump after the tray is in
position. An 8” zip tie can be started with the
tray out of the aircraft.

BVM ®2015 19 Printed 7/3/2019
 Reinstall the (2) Phillips head screws to
secure the tray.
Switch
 Mount the Receiver’s switch in the location provided.

BVM ®2015 20 Printed 7/3/2019
 Mount Remote Receivers in various positions, follow the recommendations for your
particular receiver. Use Aluminum Tape to secure the wires.
