BWT BC Series User manual

USER MANUAL
BEDIENUNGSANLEITUNG
MANUEL D'UTILISATION
MANUAL DE USUARIO
MANUALE DELL'UTENTE
HANDLEIDING
ANVÄNDARHANDBOK
KÄYTTÖOHJE
BRUKSANVISNING
MANUAL DE UTILIZADOR
РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ
UŽIVATELSKÝ MANUÁL
BWT RECHARGEABLE POOL & SPA VACUUM
WIEDERAUFLADBARER POOL & SPA VAKUUM
ASPIRATEUR RECHARGEABLE POUR PISCINE ET SPA
ASPIRACIÓN RECARGABLE PARA PISCINA Y SPA
ASPIRATORE PER PISCINA E SPA RICARICABILE
OPLAADBARE BODEMZUIGER EN SPA
UPPLADDNINGSBAR POOL & SPA VAKUUM
LADATTAVA POOL & SPA Pölynimuri
OPPLADBART BASSENG OG SPA-VAKUUM
PISCINA RECARREGÁVEL E ASPIRAÇÃO DE SPA
ПЕРЕЗАРЯЖАЕМЫЙ БАССЕЙН И СПА-ВАКУУМ
NABÍJECÍ BAZÉNOVÝ A LÁZEŇSKÝ VYSAVAČ
LINEBC
BC50

SAFETY WARNINGS & INSTRUCTIONS
Information contained in this Instruction Manual will help you operate the item safely,
protect yourself and others from hazards, and prevent damage to the device and other
property.
SAVE THESE INSTRUCTIONS
WARNING!
- This is not a TOY. Children should be kept out of reach from this pool
vacuum and its accessories.
- Never allow children to operate this pool vacuum.
- This appliance is not intended for use by persons with reduced physical,
sensory, mental capabilities, or a lack of experience and knowledge,
unless they are given supervision or instructions concerning the safe
use of the appliance and understand the hazards involved by a person
responsible for their safety.
- Children must not play with this product.
- Cleaning and maintenance of the pool vacuum must not be carried out
by children.
- Make sure the pool vacuum is fully immersed in the pool before initiating
operation. The minimum water level required to operate the pool
vacuum must reach above the power ON/OFF switch of the pool
vacuum when it is held in a vertical position. Operating the pool vacuum
when it is not immersed correctly could damage the unit and void the
warranty.
- Maximum operating depth in water is 3 meters (9.8ft).
- Maximum water temperature: 5˚C (41˚F) –35˚C (95˚F)
- Detachable supply unit (external adaptor).
- The pool vacuum should only be recharged with the external adaptor
and charging base delivered with this product.
- For the purposes of recharging the battery, only use the detachable
supply unit (external adaptor model number: DSS12D-1261000-B /
DSS12D-1261000-C / DSS12D-1261000-D/ LX135100U) that provided
with this pool vacuum to charge the battery.
- Connect the external adaptor to a power source through a residential
current device (RCD) / a ground fault circuit interrupter (GFCI). If in
doubt, consult a qualified electrician.
- Do NOT use this pool vacuum if any damage is detected.
- Replace damaged parts with ones that are certified by the distributor or
manufacturer.
- Turn off the power, disconnect the external adaptor from the power
source, and unplug the external adaptor from the charging base before
detaching the pool vacuum from the charging base.
- Disconnect the pool vacuum from the supply mains and make sure the
pool vacuum is OFF prior to carrying out regular maintenance – such as
cleaning the filter and the charging contact plates.
- DO NOT attempt to replace the installed rechargeable Li-ion battery
1/175

pack.
- DO NOT handle the pool vacuum, external adaptor, and charging base
while it is charging with wet limbs and without shoes.
-You should not operate this pool vacuum when people/pets are present
in the water.
- DO NOT use this pool vacuum without an intact filter cone in place, as
your warranty will be voided as a result.
- Suction entrapment hazard: This pool vacuum generates suction. Do
not allow hair, body, or any loose parts of your clothing to make contact
with the suction hole of the pool vacuum during its operation.
- Never insert body parts, clothing or other objects into the openings and
moving parts of the pool vacuum.
- DO NOT use this pool vacuum to pick up any toxic substance,
flammable, and combustible liquids (i.e. gasoline) in the presence of
explosive or flammable fumes.
- Under no circumstances should you attempt to disassemble the pool
vacuum and replace the impeller, motor, and battery by yourself.
- Never insert fingers or any object to touch the impeller.
- The built-in battery must be removed by a skilled technician before it is
scrapped.
- This pool vacumm contains a battery that are only to be removed by
skilled persons.
- The pool vacumm must be disconnected from the supply mains as the
battery is removed.
- For details regarding battery recycling/disposal, refer to the section
“BATTERY DISPOSAL” in this manual and contact your local authorities
for more information.
- The battery must be disposed safely in accordance with local
ordinances or regulations.
- External adaptor and charging base:
Never use the external adaptor and charging base for anything
other than charging the battery of the pool vacuum that is
supplied in the same pack.
The external adaptor and charging base should not be used
outdoors, nor should it be exposed to rain, humidity, and any
liquid or heat.
The transformer ( or external adaptor) is to be located outside
zone 1
Keep the external adaptor and charging base out of reach of
children.
Never use the external adaptor and charging base if any
damage is detected.
DO NOT handle the external adaptor and charging base with
wet hands.
2/175

DO NOT handle the pool vacuum, external adaptor, and
charging base while charging with wet hands and without shoes.
Keep the external adaptor disconnected from power when it is
not in use.
Never attempt to open the external adaptor and charging base.
If the supply cord of the external adaptor is damaged, the
external adaptor must be replaced by the manufacturer or its
service agent to prevent hazards of any kind.
Make sure the pool vacuum and the charging base are
completely dry before charging.
CAUTION!
- This pool vacuum is designed for underwater use only; it is not an all-purpose
vacuum cleaner. DO NOT attempt to use it to clean anything other than your
pool / spa.
- Use only original accessories delivered with this product.
- DO NOT use this pool vacuum right after pool-shocking. It is recommended to
leave the pool circulating for at least 24-48 hours.
- If you are planning on using the pool vacuum in a saltwater pool, make sure
all salt are dissolved before deploying the pool vacuum.
- DO NOT use this pool vacuum with another automatic cleaner/cleaner
simultaneously in the pool/spa.
- Avoid picking up hard, sharp objects with this product. They may damage the
pool vacuum and filter.
- Exercise caution when cleaning pool stairs.
- To avoid damages to the external adaptor and charging base, do not attempt
to carry the pool vacuum by the cord of external adaptor / charging base or
pull the cord to disconnect it from the power source andcharging base.
- Charge the pool vacuum indoor in a clean, dry area with good ventilation and
an ambient temperature between 5˚C (41˚F) and 35˚C (95˚F).
- DO NOT leave the pool vacuum charged for over 10 hours.
- If the pool vacuum will not be used for an extended period, detach it from the
charging base and use a damp cloth to clean and dry the pool vacuum and
accessories. Make sure to charge the pool vacuum to about 30% to 50% of
the battery capacity before it is stored. Store in a well-ventilated area away
from sunlight, heat, ignition sources, pool chemicals, and children. Never
leave the pool vacuum plugged in for long-term storage. Recharge the pool
vacuum every three months.
Above warnings and cautions are not intended to incorporate all possible
instances for risks and / or severe injuries. Pool / spa owners should always
exercise extra caution and common sense when utilizing the product.
Remark: Product/parts photos/drawings in this manual are for demonstration only.
Product/parts in photos/drawings may vary with the model purchased.
Accessories / parts shown in this manual & parts diagram are not necessarily
included with every model.
3/175

GETTING STARTED
Charging the battery
IMPORTANT NOTE: Fully charge the pool vacuum (about 6 hs) before
using it for the first time.
WARNING!
Use only the original external adaptor and charging base provided.
Make sure the pool vacuum and the charging contact plates are clean
and dry before set-up and charging. (TIPS: Use a cotton bud to dry the
charging contact plates)
Charging must be done indoors, in a well-ventilated area away from
sunlight, children, heat, ignition sources, and with an ambient
temperature between 5˚C (41˚F) and 35˚C (95˚F).
Never use the external adaptor and charging base if any damage is
detected.
The charging contact plates are waterproof. However, remnants of
water on the contact plates could result in natural occurrence of stains (a
byproduct of chemical reaction between water and electric currents).
Otherwise, the stains can be removed by light scrubbing with a cotton
bud soaked with juice of lemon or vinegar.
Make sure that the pool vacuum is turned off prior to charging.
1. Place the unit on a flat surface. Make sure the pool vacuum is off by
turning the power ON/OFF switch to the OFF position prior to charging.
2. Turn the locking knob (on each side) anticlockwise until it points to the
green dot marking (unlock position) to unlock and release the rear body
from the transparent canister.
4/175

3. Place the rear body (upside down - power on/off switch face up) on a flat
surface. Align and slide the hook of the charging base onto the side notch
at the bottom of the rear body until it stops. Make sure their contact plates
are properly in contact. Plug the female jack of the external adaptor into
the charging port at the end of the charging base.
4. Connect the external adaptor to the power source. Once the pool vacuum
begins charging, the indicator light on the external adaptor will turn red.
Normally, it takes about 5-6 hours to reach a full charge. The indicator
light will turn green when the pool vacuum is almost fully charged.
NOTE: if the motor is generating noise, ensure “OFF” is selected on the
power switch.
Immediately disconnect the external adaptor from the power source if you
detect any of the following:
- Offensive or unusual odor
- Excessive
heat
- Deformation, cracks, leaks
- Smoke
5. When charging is complete, disconnect the external adaptor from the
power source and detach the charging base from the unit and external
adaptor.
Normally, the pool vacuum can operate up to 40 minutes on a full charge (charged for
5-6 hours)
5/175

Note: Clean the filter regularly. Too much debris inside the filter will increase burden to
the motor operation and then shorten the operating duration.
To re-position the transparent canister (with the filter cone inside) to the rear body, make
sure the locking knob on both sides is turned to the unlock position. Align the raised arch
on both sides of the transparent canister with the locking knobs and then turn the knob
clockwise until it points to the red marking to secure the assembly.
Attention: The case has one correct position only. The water-draining valve must be
facing the bottom when holding the cleaner horizontally by the handle.
FACT: Rechargeable lithium-Ion battery is classified as a consumable item. It has a limited life
and will gradually lose its capacity to hold a charge. Therefore, running time of the pool vacuum
will gradually reduce through repeated charging and discharging in operation.
Once the lifespan of the battery reaches its end, refer to section “BATTERY DISPOSAL” for
instructions regarding battery disposal
NOTE: Let the pool vacuum rest for 30 to 40 minutes before charging it again.
Set-Up Before Use
Handle assembly
Insert the handle into the pool vacuum as shown, until the side pin on the handle is
secured to the handle’s locking hole on the rear body.
To release the handle, press down on the side pin and pull out the handle.
6/175

Telescopic pole (not included) assembly (only for EU & USA)
Insert the end (with one side pin) of the pole connector into the pool vacuum as shown
until its single side pin is secured to the handle’s locking hole on the rear body. Slide the
telescopic pole into the pole connector until the side holes of the telescopic pole are
secured to the side pins of the pole connector.
To release the telescopic pole, press down on the two side pins simultaneously and pull
out the pole.
Specific Telescopic pole (not included) assembly (only for Australia & New Zealand)
Insert the end (with two side pins) of the pole connector into the pool vacuum as shown
until its side pins are secured to the handle’s locking hole on the rear body. To install the
telescopic pole (with internal wishbone clip) to the pole connector as shown:
Pool Preparation
- If there are stones, roots or metal corrosion in contact with the underside of the liner,
discard them prior to using the pool vacuum. If necessary, seek assistance from a
qualified professional.
- If the liner is brittle, damaged or wrinkled, contact a qualified professional to perform
the necessary repairs or perform a liner replacement prior to using the pool vacuum.
- If you are using a saltwater pool, make sure all salt are dissolved before placing the
pool vacuum into the water.
7/175

OPERATION
WARNING!
Make sure the pool vacuum is off
Do not use the pool vacuum if any damage is detected.
Oil stain could occur due to possible leakage of lubricants applied to the
O-ring.
Do not operate this pool vacuum if there are people/pets present in the
water.
Make sure the pool vacuum is fully immersed in the pool before initiating
operation. The minimum water level required to operate the pool
vacuum must reach above the power ON/OFF switch of the pool
vacuum when it is held in a vertical position. Operating the pool vacuum
when it is not immersed correctly could damage the unit and void the
warranty.
DO NOT use the pool vacuum without an intact filter cone in place.
Using your pool vacuum without an intact filter cone in place will VOID
your warranty.
DO NOT cover the side slot of the vacuum during operation. The
impeller /motor may be damaged as a result.
DO NOT leave the pool vacuum in the water when it is not in use.
1) Bring your pool vacuum to the side of your pool / spa. Immerse the pool vacuum in
water and turn the power ON/FF switch to the ON position to initiate operation.
CAUTION! Make sure the pool vacuum is always facing downwards when it is placed
into the pool/spa. Otherwise it may bend the pole connector and damage it during the
process.
2) To remove the pool vacuum from the pool / spa, lift the pool vacuum while pointing it
downwards in order to allow water to escape from the outlet valve. Water is going to
escape via the handle / pole connector and draining holes inside the handle chamber
on the rear body.
CAUTION! Make sure the pool vacuum is always facing downwards when it is removed
from the pool/spa. Otherwise, the pole connector may be bent and damage the pool
vacuum in the process
3) Rinse the pool vacuum with fresh water after every use. DO NOT use any detergent.
EMPTYING THE FILTER
WARNING! Using the pool vacuum without a filter cone in place will
VOID your warranty.
8/175

In order to maximize the cleaning efficiency, be sure to clean the filter cone before and
after each use.
CAUTION! If the pool vacuum is charging, disconnect the external adaptor from the
power source and detach the pool vacuum from the charging base. Make sure the pool
vacuum is OFF
Emptying filter cone
1. Place the pool vacuum on a stable surface.
2. Turn the locking knob (on each side) anticlockwise until it is pointing towards the
green marking to unlock and release the transparent canister. Remove the
transparent canister from the rear body.
3. Tilt the transparent canister and make sure the smaller end is pointing upwards,
then pull out the filter cone from the transparent canister. Hold the filter cone
horizontally and turn its lid clockwise to detach it from the cone.
4. Rinse the transparent canister and clean out the debris inside the filter cone. It is
recommended to clean the filter cone’s net with splashing water. If brushing is
deemed necessary, use only a soft brush to clean it carefully and gently. DO NOT
apply any pressure to the net.
5. To lock the lid onto the filter cone, align the slot of the lid’s edge to the tab of the
bottom part of the cone. Push the lid on the cone and turn the lid anticlockwise
until it stops. Attach the filter cone to the transparent canister.
CAUTION! Replace a damaged filter cone immediately with a new one before the
next operation.
9/175

6. To re-position the transparent canister (with filter cone inside) onto the rear body,
make sure the locking knob on each side is turned to the unlocked position. Align the
raised arches on both sides of the transparent canister with the locking knobs and
turn each knob clockwise until it points towards the red marking to secure the
assembly. Attention: The case has one correct position only. The water-draining
valve must be facing the bottom when holding the cleaner horizontally by the handle.
MAINTENANCE & STORAGE
NOTE:
1. Be sure to clean and dry the charging contact plates after every use to avoid the
forming of stains (byproduct of a natural chemical reaction between electric current
and water). Otherwise, the stains can be removed by light scrubbing with a cotton bud
soaked with juice of lemon or vinegar.
2. Battery discharges on its own during storage. Make sure to charge the pool vacuum
to about 30% to 50% of the battery capacity before it is stored.
3. You must re-charge the battery at least once every three months when it is not in use.
Unplug the external adaptor from socket and then unplug the adapter jack from the
charging base.
Detach accessories from the pool vacuum. If necessary, rinse the pool vacuum and
accessories with fresh water. DO NOT use detergent.
Make sure to drain the water from the rear body through the holes located inside the
chamber that connects to the handle/ pole connector, and the hole on the rear of the
body.
10/175

Make sure to drain the water from the handle through its hole on the bottom end.
Use a damp cloth to clean and dry the pool vacuum and its accessories.
Store them in a well-ventilated area away from the sunlight, children, heat, ignition
sources, and pool chemicals. Ambient temperature for storage should be 10˚C –
25˚C (50˚F – 77˚F). NOTE: A higher temperature may reduce the battery life during
storage.
WARNING!
-Never attempt in any way to disassemble the pool vacuum.
-Under no circumstances should you attempt to disassemble the pool
vacuum and replace the impeller, motor and battery by yourself.
CAUTION!
Excessive heat can damage the battery and reduce its lifespan as a result.
Consult your dealer regarding battery replacement if the following happens:
- Battery does not charge fully.
- Battery operation time is noticeably reduced. Observe and record the run times of the
first few operations (on a full charge). Use these run times as a reference point for
comparison with run times in the future.
The battery must be removed from the pool vacuum before it is scrapped.
The pool vacuum must be disconnected from the supply mains when removing the
battery
The battery is to be disposed safely and according to local ordinances or regulations.
NOTE: Incorrect maintenance may reduce the battery life and affect its capacity as a
result.
BATTERY DISPOSAL (To be carried out by an authorized technician)
Your pool vacuum battery is a maintenance-free rechargeable lithium-ion battery pack,
which must be disposed properly. Recycling is required; please contact your local
authority for information.
WARNING!Never attempt to disassemble a battery pack
Remove all personal items such as rings, bracelets, necklaces and
watches when the battery pack is unwired from the pool vacuum.
A battery can produce a short circuit current high enough to weld a ring
(or similar item) to metal, causing a severe burn in the process.
Wear complete eye protection, gloves and protective clothing when the
battery pack is being removed.
11/175

Avoid touching the wires altogether and avoid allowing them to make
contact with any metal items, which could cause sparking and/or short
circuit the battery.
Never smoke or allow a spark or flame in the vicinity of the battery or the
pool vacuum.
Do not expose the battery to fire or intense heat as this may result in an
explosion.
CAUTION!
If a battery leak occurs, avoid contact with the leaking fluids and place the damaged
battery in a plastic bag.
-If leaking fluids come in contact with skin and clothing, wash immediately with plenty
of soap and water.
-If leaking fluids come in contact with eyes, immediately flush eyes with cool running
water for at least 15 minutes and do not rub them. Seek medical attention as soon as
possible.
How to remove the battery pack for battery disposal only (To be done by
authorized technician)
Recommended tools (not included): Philips screwdriver
1. Turn the locking knob (on each side) anticlockwise until it points to the
green dot marking (unlock position) to unlock and release the rear body
from the transparent canister.
2. Use the screwdriver to unscrew the 4 screws located on the top plate and
then detach it from the rear body to expose the rear body’s cover.
3. Unfasten 6 screws and detach the cover to expose the PCBA, motor
assembly, and battery pack.
4. To detach the battery connection wire, press the clip on the connector
and then pull it out.
12/175

5. Unfasten the 3 screws to remove the battery compartment cover and
then remove the battery pack. NOTE: Wrap the connector immediately
with insulating tape in order to avoid short circuit caused by contact of
both wire terminals.
13/175

TROUBLESHOOTING
Problem Possible Cause Solution
Pool vacuum does not capture the
debris
Battery is running out Charge the battery again.
Impeller is jammed Power off the pool vacuum and visually check the gap
in middle of the pool vacuum to see if the impeller is
jammed by larger debris. If possible, use a small tool to
remove it with intensive care & caution. If necessary,
contact your dealer for further instructions.
WARNING! Make sure the pool vacuum is
powered off when the unit is being serviced.
Impeller is broken Contact your dealer for impeller replacement.
Filter is full Clean the filter cone if applicable.
Larger debris / large volume
of debris
Remove the pivoting suction head (not recommended
for SPAs, vinyl liner and fibreglass pools as it could
scratch the spa & pool surface.)
Debris escapes from the filter Suction nozzle flap is
broken
Suction nozzle flap works like a door to prevent the
debris from escaping from the filter. Contact dealer for
replacement parts and instruction.
Debris goes outside the filter cone Filter net is damaged Replace with a new filter cone.
Outlet valve comes off Without the outlet valve, the pool vacuum might
capture debris through this opening. Contact dealer for
valve replacement.
Handle / pole connector cannot be
secured in assembly
Side pin is broken Replace with a new handle / pole connector.
Pool vacuum cannot be charged /
recharged
Battery is damaged Contact dealer for battery replacement.
WARNING! DO NOT open the pool vacuum
and replace the battery by yourself. This could result in
severe or fatal injuries and the warranty will be voided
as a result.
Contact plates of the
charger base and unit are
not connected.
Make sure that the charger base is assembled on the
unit properly so that their contact plates are touching.
External adaptor is out of
order
Contact dealer for replacement.
WARNING! Using the wrong external adaptor
will result in damaging the pool vacuum / battery and
voiding the warranty as a result.
Pool vacuum is activated even
though the switch indicates it’s off.
Presence of magnetic
objects nearby has
inadvertently switched on
the motor.
Move the magnetic objects or vacuum away from each
other.
Operation time is shorter as
expected
Battery is not fully charged Charge the pool vacuum for at least 6 hrs. NOTE: if
any stains are found on the charging contact plates,
remove them by using a cotton bud soaked with lemon
juice or vinegar
Environmental Pro
g
rammes, WEEE Euro
p
ean Directive
Please respect the European Union regulations and help to protect the environment.
Return non-working electrical equipment to a facility appointed by your municipality that properly
recycles electrical and electronic equipment. Do not dispose them in unsorted waste bins. For items
containing removable batteries, remove batteries before disposing of the product.
© 2021 BWT Holding GmbH. 21010029
All rights reserved. No part of this document may be reproduced or transmitted in any form or by any
means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission
ofBWTHoldingGmbH. (V1)
If soft copy of this instruction manual is required, please contact our customer service by
email.
SAVE THESE INSTRUCTIONS
14/175

SICHERHEITSWARNUNGEN UND -HINWEISE
Die in dieser Bedienungsanleitung enthaltenen Informationen helfen Ihnen, das Gerät
sicher zu bedienen, sich und andere vor Gefahren zu schützen und Schäden am Gerät
und anderem Eigentum zu vermeiden.
BEDIENUNGSANLEITUNG GUT AUFBEWAHREN
WARNUNG!
- Dies ist kein SPIELZEUG. Dieser Poolsauger und dessen Zubehörteile
sind von Kindern fernzuhalten.
- Erlauben Sie den Kindern niemals die Bedienung des Poolsaugers.
- Dieses Gerät ist nicht für die Verwendung durch Personen mit
eingeschränkten physischen, sensorischen oder geistigen Fähigkeiten
oder fehlender Erfahrung und mangelndem Wissen bestimmt, es sei
denn, sie wurden von einer für ihre Sicherheit verantwortlichen Person
beaufsichtigt oder in die sichere Verwendung des Geräts eingewiesen
und verstehen die vorhandenen Gefahren.
- Kinder dürfen nicht mit diesem Produkt spielen.
- Die Reinigung und Wartung des Poolsauger darf nicht von Kindern
durchgeführt werden.
- Vergewissern Sie sich, dass der Poolsauger vollständig in den Pool
eingetaucht ist, bevor Sie mit dem Betrieb beginnen. Der
Mindestwasserstand, der zum Betrieb des Poolsaugers erforderlich ist,
muss über den EIN/AUS-Schalter des Beckensaugers liegen, wenn
dieser in vertikaler Position gehalten wird. Der Betrieb des Poolsaugers
bei nicht ordnungsgemäßem Eintauchen könnte das Gerät beschädigen
und zum Erlöschen der Garantie führen.
- Die maximale Betriebstiefe im Wasser beträgt 3 Meter (9.8 ft).
- Maximale Wassertemperatur: 5 ˚C (41 ˚F) – 35 ˚C (95 ˚F)
-Abnehmbares Ladegerät (externer Adapter).
- Der Poolsauger sollte nur mit dem externen Adapter und dem mit diesem
Produkt gelieferten Ladestation aufgeladen werden.
- Verwenden Sie zum Aufladen der Batterie nur die abnehmbare
Stromversorgung (Modellnummer des externen Adapters:
DSS12D-1261000-B / DSS12D-1261000-C / DSS12D-1261000-D/
LX135100U), die mit diesem Pool-Sauger geliefert wird.
- Verbinden Sie den externen Netzadapter über eine Fehlerstrom -
Schutzeinrichtung, (RCD) / einen Fehlerstrom - Schutzschalter (RCCB)
mit dem Netz. Ziehen Sie in Zweifelsfällen einen qualifizierten Elektriker
zu Rate.
- Verwenden Sie diesen Poolsauger nicht, wenn irgendwelche Schäden
festgestellt werden.
- Ersetzen Sie beschädigte Teile durch solche, die vom Händler oder
Hersteller zertifiziert sind.
- Schalten Sie den Strom aus, trennen Sie den externen Adapter von der
Stromquelle und ziehen Sie den externen Adapter vom Ladestation ab,
15/175

bevor Sie den Poolsauger vom Ladestation ziehen.
- Schalten Sie den Poolsauger vom Versorgungsnetz ab und
vergewissern Sie sich, dass der Poolsauger AUS ist, bevor Sie
regelmäßige Wartungsarbeiten durchführen - wie z.B. die Reinigung des
Filters und der Ladekontaktplatten.
- Versuchen Sie nicht, den eingebauten wiederaufladbaren Li-Ionen-Akku
zu ersetzen.
- Fassen Sie den Poolsauger, den externen Adapter und den Ladestation
NICHT mit nassen Gliedmaßen und ohne Schuhe an, während er
geladen wird.
- Verwenden Sie diesen Poolsauger nicht, wenn sich Personen/Haustiere
im Wasser befinden.
- Diesen
Poolsauger KEINESFALLS ohne intakten eingesetzten
Filterkonus verwenden, da ansonsten die Garantie erlischt.
-Quetschgefahr durch Ansaugen: Dieser Poolsauger erzeugt Saugkraft.
Vermeiden Sie, dass während des Betriebs des Poolsaugers Haare,
Körperteile oder sonstige lose Kleidungsstücke in die Nähe der
Saugöffnung gelangen.
- Führen Sie unter keinen Umständen Körperteile, Kleidungsstücke oder
sonstige Gegenstände in die Öffnungen und beweglichen Teile des
Poolsaugers ein.
- Verwenden Sie diesen Poolsauger NICHT, um toxische Substanzen,
entzündliche und brennbare Flüssigkeiten (z. B. Benzin) in Gegenwart
von explosiven oder entflammbaren Dämpfen aufzunehmen.
- Sie sollten unter keinen Umständen versuchen, den Poolsauger
auseinanderzubauen und das Flügelrad, den Motor oder die Batterie
eigenhändig auszutauschen.
- Führen Sie niemals Körperteile oder andere Gegenstände in das
Laufrad ein, um das Laufrad zu berühren.
- Die eingebaute Batterie muss von einem Fachmann entfernt werden,
bevor sie verschrottet wird.
- Dieses mit Poolsauger arbeitende Gerät enthält einen Akku, der nur von
Fachpersonal entfernt werden darf.
- Bevor der Akku entfernt wird, muss das Poolsauger von der
Stromversorgung getrennt werden.
- Einzelheiten zum Recycling bzw. zur Entsorgung des Akkus finden Sie
im Abschnitt „ENTSORGUNG DES AKKUS” in dieser Anleitung und
wenden Sie sich für weitere Informationen an Ihre örtlichen Behörden.
- Der Akku muss im Einklang mit den im Verwendungsland geltenden
Vorschriften entsorgt werden.
- Externes Ladegerät und Ladestation:
Verwenden Sie nie das externe Ladegerät und die Ladestation für einen
anderen Zweck als das Aufladen der Batterie des im selben Pack
gelieferten Poolsaugers.
Der externe Netzadapter und der Ladestation dürfen weder im Freien
benutzt werden und dürfen weder Regen, Feuchtigkeit, Flüssigkeiten
16/175

noch Hitze ausgesetzt werden.
Der Transformator (bzw. der externe Adapter) muss außerhalb von Zone
1 aufgestellt werden.
Halten Sie das externe Ladegerät und die Ladestation von Kindern fern.
Verwenden Sie niemals das externe Ladegerät und die Ladestation,
sollten Sie Schäden festgestellt haben.
Handhaben Sie das externe Ladegerät und die Ladestation NICHT mit
nassen Händen.
Handhaben Sie den Poolsauger, den externen Stecker und die
Ladestation während des Ladevorgangs NICHT mit nassen Händen und
Barfuß.
Trennen Sie das externe Ladegerät von der Stromversorgung, wenn es
nicht verwendet wird.
Versuchen Sie keinesfalls, das externe Ladegerät und die Ladestation zu
öffnen.
Wenn das Netzkabel des externen Adapters beschädigt ist, muss der
externe Adapter durch den Hersteller oder seinen Kundendienstvertreter
ersetzt werden, um Gefahren jeglicher Art zu vermeiden.
Vergewissern Sie sich, dass Poolsauger und Ladestation vor dem
Aufladen völlig trocken sind.
ACHTUNG!
- Dieser Poolsauger ist ausschließlich für den Unterwassergebrauch konzipiert. Es
ist kein Allzweck-Staubsauger. Versuchen Sie NICHT, dieses Gerät zum Reinigen
von etwas Anderem als Ihren Pool zu verwenden.
- Verwenden Sie ausschließlich das mit diesem Produkt gelieferte Originalzubehör.
- Verwenden Sie diesen Poolsauger NICHT unmittelbar nach einer
Wasserbehandlung. Es wird empfohlen, das Poolwasser mindestens 24-48
Stunden umzuwälzen.
- Bei einen Salzwasserpool müssen Sie sich vergewissern, dass das Salz komplett
gelöst ist, bevor Sie den Poolsauger ins Wasser setzen.
- Verwenden Sie diesen Poolsauger NICHT gleichzeitig mit einem anderen
automatischen/manuellen Reingigungsgerät im Becken.
- Vermeiden Sie es, mit diesem Produkt harte, scharfe Gegenstände aufzusaugen.
Sie können den Poolsauger und den Filter beschädigen.
- Lassen Sie bei der Reinigung von Pooltreppen Vorsicht walten.
- Um Beschädigungen des externen Adapters und des Ladestation zu vermeiden,
versuchen Sie nicht, den Poolsauger am Kabel des externen Adapters/
Ladestation zu tragen oder am Kabel zu ziehen, um ihn von der Stromquelle und
dem Ladestation zu trennen.
- Laden Sie den Poolsauger im Inneren in einem sauberen, trockenen und gut
belüfteten Bereich bei einer Umgebungstemperatur zwischen 5 ˚C (41 ˚F) und 35
˚C (95 ˚F) auf.
- Der Poolsauger DARF NICHT länger als 10 Stunden ununterbrochen aufgeladen
werden.
- Ist über einen längeren Zeitraum keine Verwendung des Poolsaugers vorgesehen,
nehmen Sie ihn aus der Ladestation und reinigen und trocknen Sie den
Poolsauger und das Zubehör mit einem trockenen Tuch. Achten Sie darauf, den
Poolsauger auf 30 - 50 % Akkukapazität aufzuladen, bevor er weggelegt wird.
Lagern Sie das Gerät an einem gut belüfteten, vor Sonnenlicht, Hitze,
Zündquellen, Poolchemikalien und Kindern geschützten Ort. Lassen Sie den
Poolsauger während einer Lagerung über einen längeren Zeitraum niemals
angeschlossen. Laden Sie den Poolsauger alle drei Monate wieder auf.
17/175

Oben aufgeführte Warnungen und Vorsichtsmaßnahmen umfassen nicht alle
möglichen Risiken und/oder schweren Verletzungsgefahren.
Pool/Spa-Eigentümer sollten bei der Verwendung des Produkts stets zusätzliche
Vorsicht und gesunden Menschenverstand walten lassen.
Kommentare: Produkte/Teile auf den Fotos/Zeichnungen in dieser Anleitung
dienen nur zur Veranschaulichung. Produkte/Teile auf den Fotos/Zeichnungen
können beim gekauften Artikel variieren. Das in dieser Anleitung gezeigte
Zubehör/Teile, und Teileübersicht sind nicht unbedingt bei jedem Modell
enthalten.
ERSTE SCHRITTE
Laden der Batterie
WICHTIGER HINWEIS: Laden Sie den Poolsauger 6 Stunden auf, bevor
Sie ihn zum ersten Mal benutzen.
WARNUNG!
Verwenden Sie nur den mitgelieferten Original-Netzadapter und den
mitgelieferten Ladestation
Vergewissern Sie sich, dass der Poolsauger und die Ladekontaktplatten
sauber und trocken sind, bevor Sie das Gerät einrichten und aufladen.
(TIPP: Benutzen Sie ein Wattestäbchen, um die Ladekontaktplatten zu
trocknen)
Das Aufladen hat im Inneren in einem gut belüfteten, vor Sonnenlicht,
Kindern, Hitze und Zündquellen geschützten Raum bei einer
Umgebungstemperatur zwischen 5 ˚C (41 ˚F) und 35 ˚C (95 ˚F) zu
erfolgen.
Verwenden Sie niemals das externe Ladegerät und die Ladestation,
sollten Sie Schäden festgestellt haben.
Die Ladekontaktplatten sind wasserdicht. Wasserreste auf den
Kontaktplatten könnten jedoch zum natürlichen Auftreten von Flecken
führen (ein Nebeneffekt der chemischen Reaktion zwischen Wasser und
elektrischem Strom). Die Flecken können ansonsten durch leichtes
Schrubben mit einem mit Zitronensaft oder Essig getränkten
Wattestäbchen entfernt werden.
Stellen Sie sicher, dass der Poolsauger ausgeschaltet ist, bevor Sie
einen Ladevorgang beginnen.
1. Stellen Sie das Gerät auf eine flache Oberfläche. Vergewissern Sie sich,
dass der Poolsauger ausgeschaltet ist, indem Sie den EIN-/AUS-Schalter
vor dem Aufladen in die Position “EIN” schalten.
18/175

2. Drehen Sie den Verriegelungsknauf (auf beiden Seiten) entgegen dem
Uhrzeigersinn, bis die grüne Markierung (Entriegelungsposition) erreicht
ist, um das rückseitige Gehäuse zu entriegeln und von dem
durchsichtigen Deckel abzubauen.
3. Legen Sie das rückseitige Gehäuse (umgekehrt, mit der Ein-/Aus-
Schalter nach oben gerichtet) auf eine ebene Oberfläche. Richten Sie
den Haken der Ladestation mit der seitlichen Nut am Boden des
rückseitigen Gehäuses aus und führen Sie ihn bis zum Anschlag ein.
Stellen Sie sicher, dass die Kontaktplatten einen guten Kontakt herstellen.
Stecken Sie die Buchse des externen Ladegeräts in den Ladestecker am
Ende der Ladestation ein.
4. Verbinden Sie das externe Ladegerät mit der Stromversorgung.
Nachdem der Poolsauger mit der Aufladung begonnen hat, leuchtet die
Leuchtanzeige am externen Ladegerät rot. Normalerweise dauert ein
19/175
