BZB Gear BG-BFS User manual

BG-BFS
User Manual

- 1 -
Attention
Electrical Safety
Installation and operation must be performed in accordance with local safety standards.
Polarity of power supply
The power supply of the product is DC 12V and following is the polarity of the power supply drawing.
Handle with care
Never move the camera by seizing the camera head. Never rotate camera head by hand, mechanical
damage will occur.
Never power on before installation is completed.
Do not disassemble camera
We are not responsible for any unauthorized modification or dismantling.
Attention:
Electromagnetic fields may affect camera image!

- 2 -
Content
ATTENTION........................................................................................................................................- 1 -
1.1 CAMERA INTERFACE EXPLANATION...........................................................................................................- 3-
1.2 POWER ON ............................................................................................................................................. - 3-
1.3 VIDEO OUTPUT........................................................................................................................................ - 3-
1.4 BRACKET MOUNTING............................................................................................................................... - 4-
2. PRODUCT OVERVIEW................................................................................................................- 5 -
2.1 PRODUCT INTRODUCTION ........................................................................................................................- 5-
2.1.1 Dimension .....................................................................................................................................- 5 -
2.1.2 Accessories...................................................................................................................................- 6 -
2.2 MAIN FEATURES......................................................................................................................................- 6-
2.2.1 Camera performance....................................................................................................................- 6 -
2.2.2 Network performance....................................................................................................................- 6 -
2.3 TECHNICAL SPECIFICATION ......................................................................................................................- 7-
2.4 INTERFACE INSTRUCTION.........................................................................................................................- 8-
2.4.1 External Interface..........................................................................................................................- 8 -
2.4.2 RS-485 interface ...........................................................................................................................- 8 -
3. APPLICATION INSTRUCTION.....................................................................................................- 9 -
3.1 VIDEO OUTPUT .......................................................................................................................................- 9-
3.1.1 Power-On Initial Configuration......................................................................................................- 9 -
3.1.2 Video output..................................................................................................................................- 9 -
3.2 MENU SETTING...................................................................................................................................- 9-
3.2.1 Main menu.....................................................................................................................................- 9 -
4. NETWORK CONNECTION.........................................................................................................- 14 -
4.1 CONNECTING MODE..............................................................................................................................- 14 -
4.2 WEBGUI LOG IN...................................................................................................................................- 15 -
4.2.1 Web client....................................................................................................................................- 15 -
4.2.2 Preview........................................................................................................................................- 16 -
4.2.3 Configuration...............................................................................................................................- 16 -
4.2.4 Video configuration .....................................................................................................................- 17 -
4.2.5 Network configuration .................................................................................................................- 19 -
4.2.6 System configuration...................................................................................................................- 20 -
4.2.7 Logout .........................................................................................................................................- 21 -
5. CAMERA MAINTENANCE AND TROUBLESHOOTING............................................................- 21 -
5.1 CAMERA MAINTENANCE.........................................................................................................................- 21 -
5.2 TROUBLESHOOTING ..............................................................................................................................- 21 -
WARRANTY / MISSION STATEMENT..............................................................................................- 22 -

- 3 -
1. FAST INSTALLATION
1.1 Camera Interface Explanation
Figure 1.1
1. RESET
2. RS485 and alarm interface
3. DC12V Power Supply Socket
4. Power Indicator
5. 3G-SDI Interface
6. Network Interface
7. Audio Input Interface
8. Auto Iris Interface
9. Function Key
10. Lens Interface
11.1. Tripod screw hole
11.2. Tripod screw hole
1.2 Power on
Power on: connect DC12V power supply adapter. Then the power indicator light on and it is always mode.
1.3 Video output
1) Video output from LAN
a. Network cable connection port: No.6 in above Figure
b. Webpage Login: open your browser and enter 192.168.5.163 in the address bar (factory default); press Enter to enter
into the login page; click on the “player is not installed, please download and install!" and follow the installation steps

- 4 -
for installation. Then enter the username admin and password admin (factory default); press Enter to enter into the
preview page, users can carry out PTZ control, video recording, playback, configuration and other operations.
2) 3G-SDI video output
a. 3G-SDI video cable connection: S model refer to No5 in above Figure.
b. Connect the camera and the monitor via 3G-SDI video cable; video output is available after camera power on.
1.4 BRACKET MOUNTING
1) Bracket installation accessory introduction
2) Bracket installation steps

- 5 -
2. Product overview
2.1 Product introduction
2.1.1 Dimension

- 6 -
2.1.2 Accessories
Accessories
Power adapter
User manual
Warranty card
2.2 Main Features
2.2.1 Camera performance
This camera features advanced ISP processing algorithms to provide vivid images with a strong sense of depth, high
resolution and fantastic color rendition. It supports H.264/H.265 encoding which makes motion video fluent and clear even
with less than ideal bandwidth conditions.
1.Superb high-definition image: It employs 1/2.8-inch high quality CMOS sensor. Resolution is up to 1920x1080 with
frame rate up to 60 fps.
2. Low noise and High SNR: Low Noise CMOS effectively ensure high SNR of camera video.
Advanced 2D/3D noise reduction technology is also used to further reduce the noise, while ensuring image sharpness.
3.Multi-Format Video Outputs: support 3G SDI and LAN interfaces
The 3G-SDI is available for 100m transmission at 1080p60 format.
4.Multiple Video compression: Support H.264/H.265 video compression; Support compression of resolution up to
1920x1080 with frame up to 60 fps and 2 channel 1920x1080p with 30 fps compression.
5. Multiple network protocol: Support ONVIF, RTSP, RTMP protocols and RTMP push mode, easy to link streaming
media server (Wowza, FMS)
6. Support Multiple Control Protocol: Support VISCA, PELCO-D, PELCO-P protocols which can also be automatically
recognized. Support VISCA control protocol through IP port.
7. Wide application:
Tele-education, lecture capture, Webcasting, Videoconferencing, Tele-training, Tele-medicine, Interrogation and
Emergency command systems.
2.2.2 Network performance
1. Audio Input Interface: Support 16000,32000,44100,48000 sampling frequency and AAC, MP3, PCM audio coding.
2. Multiple Audio/Video compression: Support H.264/H.265 video compression; AAC, MP3 and PCM audio
compression; Support compression of resolution up to 1920x1080 with frame up to 60 fps and 2 channel 1920x1080p
with 30 fps compression.
3. Multiple network protocol: Support ONVIF, RTSP, RTMP protocols and RTMP push mode, easy to link streaming
media server (Wowza, FMS)

- 7 -
2.3 Technical specification
Model
Camera Parameter
Sensor
1/2.8-inch high quality HD CMOS sensor
Effective Pixels
16: 9; 2.07 megapixel
Video Format
1080P60/30/25/59.94/29.97 ,720P60/30/25/59.94/29.97
Auto Iris
DC driving mode
Digital Zoom
X5
Minimum Illumination
0.5Lux (F1.8, AGC ON)
DNR
2D﹠3D DNR
White Balance
Auto/Manual/One Push/ 3000K/ 4000K/5000K/6500K
Focus
Auto/Manual
Aperture
Auto/Manual
Electronic Shutter
Auto/Manual
BLC
ON/OFF
WDR
OFF/ Dynamic level adjustment
Video Adjustment
brightness, color, saturation, contrast, sharpness, B/W mode, gamma curve
SNR
>55dB
Input/output Interface
Video Interface
3G-SDI
Image Code Stream
Dual streams output
Video Compression Format
H.264/H.265
Control Interface
RS-485
Control Protocol
VISCA/Pelco-D/Pelco-P; Baud Rate: 115200/9600/4800/2400bps
5 Control Keys
UP/DOWN/LEFT/RIGHT/CONFIRM keys for OSD setting, EPTZ controlling
HD IP Interface
100M IP port (10/100BASE-TX), Support VISCA protocol control through IP port.
Network Protocol
RTSP, RTMP, ONVIF
Power Interface
Standard DC interface
Other Parameters
Power Adaptor
Input AC110V-AC220V, output DC12V/1A, support POE (optional)
Input Voltage
DC12V±10%
Input Current
400mA（max）
Consumption
4.8W (max)
Store Temperature
-10℃～+60℃
Store Humidity
20%～95%
Working Temperature
-10℃～+50℃
Working Humidity
20%～80%
Dimension
126.8mmX55mmX58.6mm
Weight
0.5kg
Remote Operation (IP port)
remote upgrade, remote reboot and remote reset
Accessory
12V/1A power supply, user manual, warranty card
Optional Accessory
Installation Bracket

- 8 -
2.4 Interface instruction
2.4.1 External Interface
1) RS485 interface, alarm input output, audio input interface, 3G-SDI output, LAN, DC12V power interface, auto iris
interface
2.4.2 RS-485 interface

- 9 -
3. Application Instruction
3.1.1 Power-On Initial Configuration
Connecting the DC12V power cable, and then the power indicator light will be flashing.
3.1.2 Video output
1)Network output: connect this product and your computer through network cable, then open the browser, enter the
camera IP address (factory default 192.168.5.163) in the address bar, then to the login page and input a username
and password (factory defaults are “admin”). Finally enter the preview page, and the image comes out.
(Note: If you forget your username, password, IP address, you can manually restore the default by the RESET key
at the bottom of the machine.)
2)3G-SDI output: Connect the monitor with the corresponding video output interface, then the monitor output image.
3.2 MENU SETTING
3.2.1 Main menu
In normal working mode, press 【Function】key to display the menu(as shown in No. 9 Figure 1.1), using scroll arrow to
point at or highlight the selected items.
LANGUAGE: Language setting, Chinese / English
Exposure: enter sub menu
Color: enter sub menu
Image: enter sub menu
Noise Reduction: enter sub menu
Video format: enter sub menu
VERSON: enter sub menu
Restore Default: enter reset setting, select YES or NO to confirm
MENU
＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝
Language English
（Exposure）
（Color）
（Image）
（Noise Reduction）
（Video Format）
（Version）
（Restore Default）
Back
[↑↓]Select [←→]Change Value
[Menu]Back [Home]OK
