C. Crane CCRadio 2E User manual

INSTRUCTION MANUAL
PLEASE READ ALL THE INSTRUCTIONS COMPLETELY BEFORE USE
AND SAVE THIS MANUAL FOR FUTURE REFERENCE

Page 3
CCRadio2E
About the CCRadio2E
Thank you for purchasing the CCRadio2E. Please read through these
instructions thoroughly before using the product.
The CCRadio2E has many of the renements and improvements
requested by customers who have used previous versions of our 4-band
CCRadios. This radio is built for the highest performance ever on AM.
Traditional FM reception is amazing in its ability to bring in a weak station
clearly. The CCRadio2E also has the NOAA Weather band & alert along
with the 2-Meter Ham band.
With the new CCRadio2E, the audio has been enhanced and can be
accurately tuned for realistic human voices. It can also be adjusted for
good musical performance. Five memory buttons on top of the radio makes
it easier to change stations rather than front mounted buttons.
For many radio listeners, the addition of the 2-Meter VHF Ham band will be
their rst experience with amateur (ham) radio. I hope you have the time to
explore this band. What you’ll hear is a lot of dedicated radio people using
a communication device with pride. You will especially want to tune in to
2-Meter VHF during a local, area wide emergency when communications
will be very di󰀨erent. When the power in an area is down and cell phones
and other modes of communication are unavailable, many hams use
portable equipment that lets them work as beacons of information. They
have direct communication with federal agencies and the Red Cross. We
recommend that you nd out which local 2-Meter frequencies are
used during an emergency in your area and have them installed into the
ve memory locations.
The CCRadio2E has been designed to be long lasting. We hope it will give
you many years of learning, news, and entertainment. If you have any
questions about your radio, please give us a call or check out ccrane.com.
Also, if you have a problem and you purchased the CCRadio2E from
another company, call us and C. Crane may be able to help you faster.
Thanks! From all of us at C. Crane.

Page 4 CCRadio2E
Safety Instructions
Before Use
Please read IMPORTANT SAFETY INSTRUCTIONS on pages 5 and 6
before use. It is important to read and understand all instructions.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
CAUTION
• Before turning the unit on, set your volume control to a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly
without distortion.
• Long-term exposure to loud sounds may cause hearing damage. It is best
to avoid high volume levels when using headphones/earbuds, especially
for extended periods.
THE LIGHTNING
FLASH AND
ARROWHEAD
WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU
OF “DANGEROUS
VOLTAGE” INSIDE
THE RADIO.
CAUTION: TO
REDUCE THE RISK
OF ELECTRIC
SHOCK, DO NOT
REMOVE THE
RADIO BACK. NO
USER SERVICEABLE
PARTS INSIDE.
REFER SERVICING
TO QUALIFIED
SERVICE
PERSONNEL.
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THIS RADIO.
For your future reference:
Serial No. (Found inside battery compartment): ____________________
Date of purchase / Name & address of dealer: _____________________
__________________________________________________________
Unpacking
The box should contain the CCRadio2E, AC power cord, this manual and a
warranty card. If anything is missing or damaged, please contact C. Crane
immediately. We recommend that you keep the box in the unlikely event
that your radio needs servicing.

Page 5
CCRadio2E
Safety Instructions
READ BEFORE OPERATING EQUIPMENT SAVE THESE
INSTRUCTIONS
1) Read and understand all safety and operating instructions before the
radio is operated.
2) Retain Instructions: The safety and operating instructions should be
retained for future reference.
3) Heed Warnings: All warnings on the appliance and in the operating
instructions should be followed.
4) Water and Moisture: The appliance should not be used near water. Do
not use near a bathtub, washbowl, laundry tub, kitchen sink, wet
basement, swimming pool, etc.
5) Cleaning: Unplug the receiver from the AC power outlet before clean ing.
Use only a dry cloth for cleaning the exterior of the receiver.
6) Placement: Do not place the radio on an unstable cart, stand, bracket or
table. The radio may fall, causing serious personal injury and dam age to
the receiver.
7) Ventilation: This radio should be situated so that its location or posi tion
do not interfere with its proper ventilation. For example, the radio should
not be used on a bed, sofa, rug or other soft surfaces that may block
the ventilation openings. It should not be placed in a built-in situation like
a cabinet that may reduce air ow through the ventilation openings.
8) Heat: Never put the radio in direct sunlight in an unventilated area or
behind glass like a car’s interior. The appliance should be away from
heat sources such as radiators, heat registers, stoves, or other
appliances that produce heat.
9) Power Cords: The power cord should be positioned so it is not walked
on, pinched, or have items placed on top of it. Pay particular attention
to cords at plugs, convenience receptacles, and the point where they
exit from the unit. Unplug the power cord by gripping the power plug,
not the cord. Operate the radio using only the correct type of power
source indicated. If you are not sure of the type of power supply to your
home, consult your dealer or local power company.
10) Do not overload wall outlets or extension cords. This can result in a risk
of re or electrical shock. Never insert objects of any kind into the
receiver through openings. The objects may touch dangerous voltage
points or short out parts. This could cause a re or electrical shock.

Page 6 CCRadio2E
11) If the radio is left unattended and unused for long periods of time,
unplug it from the wall outlet. This will prevent damage caused by
lightning or power line surges.
12) If the radio is left unattended and unused for long periods of time,
remove the batteries. The batteries may leak and damage furniture or
your radio.
13) Do not attempt to service the receiver yourself. Removing the cover
may expose you to dangerous voltage, and will void the warranty. Refer
all servicing to authorized service personnel.
14) The receiver is equipped with a polarized type plug (a plug having
one blade wider than the other). This plug will t into the power outlet
only one way. This is a safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the plug still fails to
t, contact an electrician to replace the obsolete outlet. Do not defeat
the safety purpose of this plug.
15) The appliance should be serviced by qualied service personnel when:
A. The power supply cord or the plug has been damaged, or
B. Objects have fallen or liquid has been spilled into the radio, or
C. The radio has been exposed to rain, or
D. The radio does not appear to operate normally or exhibits a
marked change in performance, or
E. The radio has been dropped or the enclosure damaged.
16) The user should not attempt to service the appliance beyond that
described in the operating instructions. All other servicing should be
referred to qualied service personnel. This symbol is to alert you
to important operation or servicing instructions that may appear in the
owner’s manual.
17) Antenna installations can be dangerous because many times it
involves the use of a ladder and a possible fall. The antenna can be
struck by lightning, which can be fatal. We recommend a licensed and
insured installation by a qualied person.
18) Long-term exposure to loud sounds may cause hearing damage. It is
best to avoid high volume levels when using headphones or earbuds,
especially for extended periods.
Safety Instructions

Page 7
CCRadio2E
About the CCRadio2E ....................................................................
Safety Instructions/Unpacking.........................................................
Button Identication ........................................................................
Getting Started
Powering Your Radio ....................................................................
Installing The Batteries .................................................................
Display Panel ................................................................................
Setting The Clock ..........................................................................
Setting The Alarm .........................................................................
Snooze Feature ............................................................................
Sleep Timer ...................................................................................
Radio Operation
Tuning ...........................................................................................
Weather Alert System ...................................................................
2-Meter Ham (VHF) ......................................................................
Clock/Frequency Setting...............................................................
Display Light .................................................................................
Lock Switch ..................................................................................
Headphone Jack ..........................................................................
Reset Button ................................................................................
Audio & Recording Jacks .............................................................
Setting The Timer .........................................................................
Specications ...............................................................................
Troubleshooting Guide
Troubleshooting............................................................................
AM Alignment Procedure..............................................................
Radio Noise Troubleshooting ........................................................
AM Listening Tips .........................................................................
Accessories ..................................................................................
Personal Station Log ....................................................................
2-Meter Ham Frequency Log ........................................................
About C. Crane..............................................................................
Table of Contents
3
4
8
9
10
11
12
12
13
13
14
15
17
18
19
19
19
19
20
21
23
25
26
27
28
29
30
31
32

Page 8 CCRadio2E
NOTE: When you see a “•” next to a button on the radio, it means you
must press and hold the button down for two seconds to activate the
function. The appropriate symbol will then appear on the display along
with sounding a “beep”. If the radio is turned o󰀨, the beep volume is
signicantly reduced. To deactivate the Alarm and Timer functions,
press and hold the button until it beeps again and the symbol
disappears from the display. (Please see Display Panel symbols on
page 11.)
1) •Clock Set
2) •Alarm Set
3) •Timer Set
4) Display Clock or Frequency
5) Bass Control
6) Treble Control
7) Tuning /Time Set (Up/Down)
8) Headphone Jack
9) Volume Control
10) Lock Switch
11) Tuning Knob /•Squelch Set
12) Power /•Sleep Timer
13) Display Light
14) Telescopic Antenna
15) Memory (1-5)
16) Weather Alert (3 Modes)
17) Band /•AUXILIARY
18) Weather Alert Light
12
13
14
15
16
17
18
Button Identication

Page 9
CCRadio2E
Getting Started
POWERING YOUR RADIO
Before powering your radio be sure to read the Safety Instructions
on pages 4 through 6.
The CCRadio2E will run on (4) “D” size NiMH or alkaline batteries or on
120V AC house current using the included power cord. Batteries are
optional. The batteries are necessary to retain the timer, clock, and
memory settings if the power cord is removed from the radio for more than
three minutes. Lithium batteries are not recommended.
Rechargeable batteries work well in this radio. The Battery Power Level
Indicator will be lower because the total voltage is lower for recharge able
batteries.
AC OPERATION
Before you plug the AC cord into the radio be sure the AC voltage is
120Volts/60Hz. If you have batteries in the radio and you use the AC power
cord, the batteries will automatically be disconnected.
Note: If you remove the power cord without turning the radio OFF, the
radio will automatically revert to the batteries.
Insert the plug on the end of
the supplied power cord
securely into the AC power
jack on the back of the radio
as shown.
Back of Radio

Page 10 CCRadio2E
Getting Started
DISPLAY SYMBOLS
BATTERY REPLACEMENT
The battery indicator will display the battery level for approximately one
second when the radio is switched o󰀨. After removing dead batteries for
replacement, you have approximately three minutes to replace the
batteries before your clock and memory information will be lost (if the
radio is not plugged in).
This symbol means
the batteries are full.
This symbol means
the batteries are low.
This symbol ashing
means the batteries
need replacing.
INSTALLING THE BATTERIES
1) Position the radio face down on a soft surface to protect it.
2) Remove the battery compartment cover.
3) Insert the (4) “D” cell batteries into the compartment as indicated in the
drawing below. Be sure the negative(-) end is against the spring. Refer
to the drawing below to insure correct installation of your batteries.
4) Replace the battery cover. You are now ready to operate your radio.
Remove Battery Cover by pressing
both clips at the same time towards
the bottom of the radio.
AC Power Cord
plugs in here.

Page 11
CCRadio2E
Getting Started
Display Panel
1) Weather Alert Modes
2) Memory Location (1 - 5)
3) Key Lock On/O󰀨
4) Sleep Timer/Snooze Status
5) Battery Symbol
6) Battery Power Level Indicator
and Signal Strength Meter
7) Squelch Indicator
8) Timer Active Indicator
9) Clock Seconds
10) Frequency/Clock Display
11) Alarm Status and Type
12) AM/PM Indicator
13) Indicates Band In Use
14) AUX IN Indicator
15) Stereo Reception

Page 12 CCRadio2E
Getting Started
SETTING THE CLOCK
Please read this entire section carefully before you start. Set the time
with the radio o󰀨. You must go through the steps listed below without
stopping for more than 15 seconds at any given time or you will have to
start over. (Refer to page 8 for Button Identication.)
1) Press the Clock Set Button and hold for two seconds then release.
The hour digit will ash.
2) Using the Up/Down Tuning Button, select the appropriate hour
digit and AM or PM.
3) Press the Clock Set Button again, then release. The minutes digits will
ash. Use the Up/Down buttons to adjust the minutes to the appropriate
time.
4) You must press the Clock Set Button again then release to complete the
time setting. This also sets the seconds to “00”.
SETTING THE ALARM
There are two di󰀨erent alarm modes on the CCRadio2E. You can choose
to wake up to the radio or to a tone. You can set the alarm with the radio on
or o󰀨. If the radio is o󰀨, the beep volume is signicantly reduced.
To set the type of alarm:
Press and hold the Alarm Button until you hear a beep and see one of
these symbols ashing on the display then release.
To wake with the radio: While Alarm is ashing on the display, press
and release the Clock Set Button until you see the symbol.
When the alarm goes o󰀨 the radio will play the last station selected at
the same volume level last set.
To wake with a multi level tone: While Alarm is ashing, press and
release the Clock Set Button until you see the symbol.
To shut o󰀨 the alarm function: Press and hold the Alarm Button until you
hear a short beep and the alarm symbol disappears then release.
To set the alarm time:
1) Press and hold the Alarm Button for two seconds then release. The hour
digit and Alarm symbol will ash.
2) Using the Up/Down Tuning Button, select the appropriate hour
digit and AM or PM.
3) Press the Alarm Button again then release. Use the Up/Down Tuning
Buttons to adjust the minute to the appropriate time.
4) Press the Alarm Button again then release to complete the alarm setting.

Page 13
CCRadio2E
Getting Started
Although very high quality parts were used in the manufacturing of your
radio, buttons, knobs, and dials should be operated with a light touch for
best longevity.
NOTES ON THE ALARM
You can also set the alarm time immediately after selecting the radio or
buzzer alarm as described on page 12.
To stop the alarm from going o󰀨 every day, press and hold the Alarm
Button until ALARM disappears from the display.
1) Once the alarm is set, it will automatically go o󰀨 the next day at the
same time. Use the Power Button to shut o󰀨 the alarm until the next day.
2) If the radio alarm is selected, tune the radio to your favorite station and
set the volume before turning your radio o󰀨 for the day. When the alarm
acti vates, the radio will play the last station listened to. NOTE: There will
be no audio if the AUX IN is set.
3) The tone alarm is called HWS or Humane Wake (if that is possible)
System. The alarm tone beep will increase in volume every 15 seconds
for one minute followed by one minute of silence before repeating the
cycle.
4) The alarm system will sound for one hour unless turned o󰀨 by pressing
the Power Button.
SNOOZE FEATURE
When the buzzer alarm is sounding, if you press any button except the
Power Button, the alarm will temporarily stop for ve minutes. The little Zs
and Alarm symbol will ash on the display (above the little bed) while the
radio is in snooze mode. To shut o󰀨 the alarm and snooze feature press
the Power Button.
SLEEP TIMER FEATURE
Your CCRadio2E is equipped with a Sleep Timer that enables the radio to
continue playing for up to 120 minutes after activation, then shuts the radio
o󰀨. Selectable times are 120, 90, 60, 45, 30 and 15 minutes.
Press and hold the Power/Sleep Button until the pictograph of a person in
bed and the numbers 120 are displayed.
Holding the Power/Sleep Button down will reduce the time in steps,
showing times of 120, 90, 60, 45, 30 and 15 minutes. If you miss the time
you want, simply continue holding the button until the desired time shows
on the display. Release the button. Now the pictograph of the
person in bed will appear on the display. The radio will then shut o󰀨 after
the set amount of time. To deactivate the Sleep Timer, simply shut the radio
o󰀨 using the Power Button.

Page 14 CCRadio2E
Radio Operation
TUNING
The CCRadio2E features four bands: AM / FM / 2-Meter Ham (VHF) and
Weather (WX).
Manual Tuning
1) Press the Power Button to turn on the radio.
2) Select the band by pressing the BAND/AUX button on the top panel.
3) A single press of the Up or Down Tuning Buttons will change
the frequency up or down for AM, FM and Ham (VHF) bands, and
channel up or down for Weather.
Each press of Up and Down Tuning Buttons will change the frequency by
10 kHz in AM mode, 100 kHz in FM mode, and 5 kHz in Ham (VHF).
Scan Tuning
Same as above except press and hold the Tuning Up or Down
Button for more than 0.5 second. The radio will scan and stop automatically
when it nds an active station. The Scan Tuning will not work on the
weather band. It may also stop scanning on strong interference or noise.
Press and hold again to resume. For 2-Meter Ham scanning, please see
page 17 for more advanced information.
Rotary Tuning
Rotating the tuning knob will change AM/FM/Ham (VHF) by frequency and
the weather band by channel.
Memory Tuning
Five stations may be stored into memory in each of the four bands.
1) Tune to the station or channel you want to memorize. Wait 5 seconds
for best tuning.
2) Press and Hold the desired Memory Button for two seconds or until you
hear a beep. The station or channel is then memorized.
The display will show the memory number.
To recall the memorized station, select the correct band and briey press
and release the Memory Button. The radio will instantly tune to the station
stored in memory.
NOTE: The large buttons on top of the radio make it easy to locate your
favorite station. Very high quality switches are used in manufacturing, so a
light touch is all you need to save and restore your favorite stations.
Memory buttons on
Top of Radio

Page 15
CCRadio2E
WEATHER ALERT SYSTEM
The WEATHER ALERT modes on the CCRadio2E can alert you to special
weather related emergencies. During an emergency or weather related
hazard, NOAA issues an emergency tone that will set o󰀨 an audible and/or
visual alarm on the radio.
NOTE: Hazard warnings are not available in all areas.
There are seven standard NOAA weather channels used in the US and
Canada. This radio receives broadcasts up to 40 miles from transmitting
stations.
1) To listen to the standard NOAA weather channels, turn the radio on,
press the Weather Alert button until WX shows on the display. The
telescopic whip antenna may need to be fully extended and in a vertical
position to receive a station clearly.
2) The channel number of the weather station is shown on the display.
Pressing the Tuning Up or Down Buttons will toggle you through the
seven programmed channels. There should be one or more weather
service stations broadcasting in your local area. You will hear a report
that is updated usually once or more per day for your area. If there is
a severe weather or weather-related emergency, NOAA will update the
weather broadcast more frequently. If there is a weather emergency, the
NOAA will issue an alert tone.
The WEATHER ALERT mode enables you to listen to your favorite AM or
FM station, Auxiliary device, 2-Meter Ham frequencies or turn the radio o󰀨,
and still receive an alert signal warning you of a special emergency. There
are three active WEATHER ALERT modes on the CCRadio2E.
NOTE:
1) When activated, the WEATHER ALERT consumes power even when the
radio is turned o󰀨.
2) Be aware that if you are not using AC power the WEATHER ALERT
will completely drain your batteries. If your batteries are dead and
AC power is o󰀨, the WX Alert Alarm will not work.
SETTING THE WEATHER ALERT
1) To place the radio in WEATHER ALERT mode, press and hold the
Weather Alert button for two seconds: You will hear a short beep and
see the alert symbol, shown on page 16, on the display. When the radio
is o󰀨, the beep volume is signicantly reduced.
Radio Operation

Page 16 CCRadio2E
Radio Operation
This symbol is the WEATHER ALERT mode with ashing
light only (no Alarm). If NOAA issues a weather related emergency, the
radio will automatically alert you with a small ashing light near the top of
the radio. The Alert light will continue to ash until any button is pushed.
2) To access the second mode, (WEATHER ALERT with NOAA Audio).
Press and hold the Weather Alert button again for two seconds until
you hear a long beep. This symbol will be displayed in
this mode. In this mode, if the NOAA alert tone is issued, the red light
ashes and the radio switches to Weather Audio automatically.
3) To access the third mode, (WEATHER ALERT with ashing light and
siren). Press and hold the Weather Alert button again for two seconds
until you hear a double beep. This symbol will
appear and the red light near the top radio comes on continuously.
In this mode, if the NOAA alert tone is issued, the red light on the top of
the radio ashes and a siren turns on for up to 1 minute. In this mode,
when the siren is active, pressing any button on the radio instantly turns
the radio to the Weather Audio and cancels the siren.
SPECIAL NOTE: If you have the headphones plugged in and a weather
alert is issued, the audio to the headphones will be cut-o󰀨 and the siren
will sound through the radio’s speaker.
TURNING OFF THE WEATHER ALERT
Press the Weather Alert button again for two
seconds. The alarm will go o󰀨 and become
inactive. The ALERT symbol will disappear from
the display.
In any of the active WEATHER ALERT modes, the
weather receiver stays on and listens for an
emergency tone issued from NOAA in case of
emergency.
You may get a periodic test tone from the NOAA that will cause an
unexpected alarm on your CCRadio2E. This tone is only a test and will
happen periodically, usually every Wednesday at noon, or whenever the
agency decides to test their emergency alert system. Simply pressing any
button on the receiver will shut the alert tone o󰀨. After an alert has been
issued, the WEATHER ALERT light and/or siren will stay on for one minute
or until you turn it o󰀨 by pressing any button.
Weather Alert Button
Left Side
Top of Radio

Page 17
CCRadio2E
2-METER HAM (VHF) BAND (144 TO 148 MHZ)
The 2-Meter Ham Band is a popular radio band used by amateur radio
operators for civil defense. After a hurricane, earthquake or other calamity,
90% of emergency coordination at the local level takes place on this band.
Listening to this band during an emergency can be extremely valuable and
even life saving. For most people, the CCRadio2E will probably be their
rst experience with Ham radio.
We have preprogrammed some of the most popular frequencies into the
ve memories of the CCRadio2E. Di󰀨erent frequencies may be active at
your location, other than those preprogrammed into the memories. The
following are the frequencies and memory locations as they were originally
preprogrammed:
1) 146.520
2) 146.760
3) 146.880
4) 146.940
5) 147.000
You can program your frequencies of interest into a memory location at any
time.
To scan the ve memory channels when in 2-Meter Ham, momentarily
press both of the Up and Down Tuning Buttons at once, the radio
will scan the memories and automatically stop when it detects a voice
transmission. Raise the telescopic antenna up fully in a vertical position. It
is best to set the squelch level prior to scanning the memory stations. See
“Setting the Squelch” below.
SETTING THE SQUELCH
Background noise or static is present to some
degree at every location and on every frequency of the
2-Meter Ham Band. This is a normal con dition. If you set
the squelch above the background noise level, the radio
will remain silent until a voice
transmission is detected. It is best to set the squelch as low as possible
(to just before static is constant). This way you can hear signals that may
be weak. If you set the squelch too high, you may miss some weak voice
transmissions.
To adjust the squelch level, press and hold the main Tuning Knob in for
three seconds until the display changes. Turn the Tuning Knob slowly
clockwise from OFF through 12 (increasing squelch) until the radio just
becomes silent. NOTE: Squelch operates on the 2-Meter Ham Band only.
Radio Operation

Page 18 CCRadio2E
SEARCHING FOR A NEW ACTIVE FREQUENCY
At times, more frequencies will become active than have been
prepro grammed into the radio. You can search the 2-Meter Ham band by
pressing the Up or Down Tuning Button and holding it momentarily.
You can also start scanning by pressing and releasing the main Tuning
Knob. The radio will begin searching the entire 2-Meter Ham band until it
nds an active frequency and then it will stop. You may want to write down
this frequency to keep track of which frequencies are active. With time you
may nd a frequen cy of interest.
During non-emergency times, you can listen and learn more about the
Ham radio operators that live around you. After listening to them for a time,
you may nd you would like to be a Ham, too. Joining requires passing
an entry level multiple choice test and purchasing reasonably priced Ham
radio equipment. The 2-Meter band is the most popular place to start for a
Ham. You can contact the American Radio Relay League (ARRL) toll free
at 888-277-5289 or at arrl.org to nd out what you need to learn and the
nearest testing location.
C. Crane salutes every Ham who has volunteered to be a part of
emergency radio operations.
DEFAULT CLOCK/ FREQUENCY SETTING
When listening to AM and FM bands the default setting is for the
Frequency to be displayed for approximately 5 seconds and then return to
the Clock Display. This can be changed to show just the Frequency unless
the Clock/Freq button is pushed and then the clock will display for
approximately 5 seconds and then show the Frequency.
To change the display to show Frequency - turn on the power, and press
and hold the Clock/Freq button. Then quickly press the Memory 1 button
until you hear a beep. Release. You should now see the frequency
displayed unless you push the Clock/Freq button, in which case you will
see the clock for approximately 5 seconds.
Reverse the process to return to the default of showing the clock.
Radio Operation

Page 19
CCRadio2E
Radio Operation
RESET
DISPLAY LIGHT ON AC POWER
When the radio is plugged into AC power, the display light will
always be on unless you turn it o󰀨. The special green LED bulbs
last about 100,000 hours and use very little electrical energy. The
display light has three light levels. If you want to change the light level or turn
o󰀨 the display light, press and release the Light button until you reach the
desired level. Refer to page 8 for button identication.
DISPLAY LIGHT ON BATTERIES
When batteries are used, the display light can be turned on by pressing the
light button. The display light automatically goes o󰀨 2 minutes after the last
time you press any button.
LOCK SWITCH
The Lock switch can be used when transporting the
radio to prevent accidentally turning it on. When the
switch is pushed up you will see the Lock symbol
appear on the display. It can also be used to
disable all functions of the radio when it is turned
on. Push the switch down to release the lock for
normal operation.
HEADPHONE JACK
You can use a stereo or mono headphone with a 1/8”
(3.5 mm) plug. When you insert the headphone plug,
the speaker is discon nected. This radio delivers FM
in stereo through the headphones.
RESET BUTTON
Once in a while glitches may occur on any portable digital radio. This can be
caused by static electricity, unusual key strokes or a power dis ruption.
If this happens, use the end of a paper clip and push it into the hole briey to
reset the radio. You will lose the clock time and all the stations stored in
memory when the radio is reset.
Lock
Switch
Headphone
Jack
Right Side View
Bottom View

Page 20 CCRadio2E
Radio Operation
AUDIO & RECORDING JACKS
The jacks on the back left side of the radio are for audio input (AUX IN),
audio output (LINE OUT) and a timer activation switch .
AUX IN JACK
The green jack, labeled AUX IN, is used to connect an external audio
source such as a CD Player or recorder, so you can listen through your
CCRadio2E’s speaker. To do this, you will need an appropriate patch cord
(1/8” (3.5mm) stereo).
Warning: If a “LINE OUT” is not available on your external audio
source, you can use the headphone jack. However, the volume must
be kept low or damage to the CCRadio2E may result.
1) Plug your patch cord into the LINE OUT or Headphone Jack of your
external audio source.
2) Plug the other end into the AUX IN jack on the CCRadio2E.
3) With the power on, press and hold the BAND/AUX button until you hear
a short beep and AUX appears on the display.
4) Turn on your external audio source to hear the audio played through the
CCRadio2E.
5) To turn the AUX o󰀨, press the BAND/AUX button again and the AUX
will disappear from the display.
NOTE: Volume can be controlled from the CCRadio2E.
AUX IN JACK
TIMER ACTIVATION
SWITCH
LINE OUT JACK
Left Side
Back of Radio
