C.P. Electronics Ellipse Instruction manual

PRODUCT DATA AND INSTALLATION SHEET
ELLIPSE AND KH2 ELECTRONIC
TIME LAG SWITCHES The ELLIPSE and KH2 time lag switches are a quick and effective
way to reduce energy consumption for lighting applications. Press-
ing the button or touch pad brings the lights on; the lights will then
switch off automatically after a preset time period has elapsed.
These units do not require a neutral connection, therefore they can
be used to replace an existing light switch. The duration of the time
delay is set by a thumbwheel on the reverse of the unit.
The ELLIPSE/TN and KH2N have neon illumination to allow the
unit to be located in the dark.
Time lag switches can be used in two way and intermediate switch-
ing arrangements without any extra wiring.
DESCRIPTION AND OPERATION
WIRING
Warning. This device works at mains potential. Be sure to take care when
working with electricity.
1. Make sure the load is connected and in working order.
2. Isolate the mains supply to the circuit at the main consumer unit.
3. Connect the controller via the terminal block. Live supply to the L
terminal and the load to the LIVE OUT terminal.
4. Push the override switch to the off position (see diagram).
5. Set the timing range using the thumbwheel. Turn clockwise to
increase timing.
6. Screw the unit to the wall and switch the mains supply back on at
the distribution board.
7. Wait 20 seconds before pushing the button
8. Push the button or touch pad and the lights will come on
9. Wait for the time period and the lights will turn off again.
INSTALLATION
Conventional Wiring
Wire the units as in diagram 1. When using multiple switch posi-
tions see diagram 2.
For two way and intermediate switching follow the diagrams over-
leaf. Note that as long as each switch position has a Live feed
and a Live Out connection to the load then the switch will be
properly wired.
Diagram 1
Conventional
wiring
Diagram 2
Multiple switch
locations
ELLIPSE
Push button activated time lag switch KH2
Touch activated time lag switch
Ref %WD124 Issue 3

LOAD
10A of lighting including incandescent, fluorescent, compact fluorescent, low voltage (switch
primary of transformer).
Fluorescent and compact fluorescent fittings with “switch start” ballasts - 10 ballasts maximum.
Power factor correction capacitors must be fitted.
Most fluorescent fittings have power factor correction capacitors fitted. If they are not present
the unit may fail to turn off properly or flicker. In this case fit one capacitor per circuit with a
minimum value of 1μF for every unit installed. The capacitor should be fitted across switched
live and neutral. Note that it is not necessary to fit a capacitor on every fitting. This also applies
to fittings controlled with high frequency ballasts and maintained emergency fittings.
Not suitable for switching contactors
Not suitable for SON lighting
Not suitable for heating or ventilation loads.
Please contact our sales department for a suitable alternative product.
SUPPLY VOLTAGE 220-240 Volts AC 50 Hz
TIME OUT PERIOD 20 seconds to 20 minutes (approximate)
FIXING METHOD Surface fixing 25mm deep plastic surface mount moulded box.
Flush fixing 25mm steel wall box or 32mm deep cavity wall box.
TERMINAL CAPACITY1.5mm2
MATERIAL Flame retardant ABS
TYPE Class 2
TEMPERATURE -10°C to 35°C
CONFORMITY EMC-89/336/EEC
LVD-73/23/EEC
IMPORTANT NOTICE!
This device should be installed by a qualified electrician
in accordance with the latest edition of the IEE wiring
regulations.
C.P. Electronics Ltd
Unit 2 Abbey Manufacturing Estate
Mount Pleasant, Wembley
Middlesex. HA0 1RR
Tel: + 44 (0) 20 8900 0671
Fax: + 44 (0) 20 8900 0674
www.cpelectronics.co.uk
[e-mail]
Due to our policy of continual
product improvement CP
Electronics reserves the right to
alter the specification of this
product without prior notice.
PART NUMBERS
ELLIPSE Electronic time lag switch push button activated
KH2 Electronic time lag switch touch activated
ELLIPSE/TN Electronic time lag switch push button activated with neon
KH2N Electronic time lag switch touch activated with neon
Ref %WD124 Issue 3
